StarTech.com 8STSV211HDUA4K User manual

Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: December 9, 2019
Product Diagram (SV211HDUA4K)
Component Function
1Stereo Audio Connector • Connect the Speaker Audio from the
Computer
2USB-A Connector • Transmit the signal of a Keyboard and Mouse
from the KVM Switch to the Computer
3Microphone Audio
Connector • Connect the Microphone Audio to the Computer
4Microphone Audio Port • Connect a Microphone
5USB HID Ports • Connect a Keyboard and Mouse
• (Optional) Connect USB Peripherals
6HDMI Port • Connect a HDMI Display
7HDMI Connector • Connect a HDMI Enabled Computer
2-Port USB HDMI® Cable KVM Switch w/ Audio and Remote Switch - 4K 60Hz
8LED Indicators • Indicates Computer selection and activity
9Stereo Audio Port • Connect Stereo Speakers
10 Remote Switch
• A wired button used to switch between
Computer 1 and 2
• Press and Release the Remote Switch to
switch between Computer 1 and 2
Requirements
• HDMI Enabled Computers x 2
• HDMI Display x 1
• USB HID Devices (Keyboard and Mouse) x 2
• (Optional) USB Peripherals x 2
• (Optional) Microphone x 1
• (Optional) Stereo Speakers or Headphones x1
• (Optional) Headset x 1
Note: A Headset may require the use of a Headset Adapter. Check with the
manufacturer of the Headset for more details.
• (Optional) 3.5 mm Audio Cables x 2
For the latest requirements and to view the full User Manual, please visit
www.startech.com/SV211HDUA4K.
Installation
Connect the Computers
1. Connect the built-in Computer 1 HDMI Connector to the HDMI Port on
Computer 1.
2. Connect the built-in Computer 1 USB-A Connector to the USB-A Port on
Computer 1.
3. (Optional) Connect the built-in Computer 1 Stereo Audio Connector (green) to the
3.5 mm Stereo Audio Port on Computer 1.
4. (Optional) Connect the built-in Computer 1 Microphone Audio Connector (pink)
to the 3.5 mm Microphone Audio Port on Computer 1.
5. Repeat steps 1-4 to install Computer 2.
Connect the Console
1. Connect the USB-A Devices (Keyboard, Mouse, or USB Peripherals) to the USB-A
Ports on the KVM Switch using the built-in Keyboard and Mouse USB Cables or
USB-A Cables (sold separately).
7
12
3
5
659
10
8
4

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could
void the user’s authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
Warranty Information
This product is backed by a two-year warranty.
For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of
business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
Safety Measures
• If product has an exposed circuit board, do not touch the product under power.
Mesures de sécurité
• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.
安全対策
• 製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。
Misure di sicurezza
• Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando è acceso.
Säkerhetsåtgärder
• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.
FR: startech.com/fr
DE: startech.com/de
ES: startech.com/es
NL: startech.com/nl
IT: startech.com/it
JP: startech.com/jp
StarTech.com Ltd.
45 Artisans Cres
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Rd,
Brackmills
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
2500 Creekside
Parkwy
Lockbourne, Ohio
43137
U.S.A.
2. (Optional) Connect a 3.5 mm Audio Cable from the Stereo Speakers or
Headphones to the Speaker Audio Port (pink) on the KVM Switch.
3. (Optional) Connect a 3.5 mm Audio Cable from the Microphone to the Microphone
Audio Port (pink) on the KVM Switch.
Operation
About the LED Indicators
LED Behavior Signicance
LED is illuminated
orange A Computer is selected and a link has been established
LED is ashing orange A Computer is selected but not detected
Hotkey Reference Guide
• Windows® Keyboard: To switch Computers the hotkey combination is Scroll Lock +
Scroll Lock
• Mac Keyboard (or a Windows Keyboard with no Scroll Lock): Use the Included
Software to dene the new hotkey sequence.
Note: Each hotkey sequence keystroke should be pressed within two seconds.
