Instruction Manual

Thank you for purchasing a StarTech.com Multi-port 10/100 Desktop Ethernet
Switch. Providing 10/100Mbps auto-negotiation, all ports support auto MDI/MDIX
functions, eliminating the need for crossover cables or uplink ports. Featuring plug
and play functionality, the hub offers a practical and cost-effective way to upgrade
existing networks to 100Mbps standard or bridge 10BaseT and 100BaseTX net-
works.
• All RJ-45 ports support 10BaseT/100BaseTX and Full-Duplex/Half-Duplex Auto-
negotiation function
• Auto MDIX (crossover) function provides automatic crossover when cascading
switches or hubs - crossover cables or special uplink ports are no longer
required
• Complies with IEEE 802.3 10BaseT Ethernet and 802.3u 100BaseTX Fast
Ethernetstandards
• IEEE 802.3x compliant flow control for full duplex and backpressure for half-
duplex
This Fast Ethernet switch can be connected to PC computers with Ethernet net-
working cards, or other compatible switches, hubs, or servers.
Note: For each device you want to attach to the switch, you will need a Category 5
Ethernet UTP patch cable. StarTech.com offers a wide range of these cables in
various lengths and colors to suit your network needs. StarTech.com also carries a
wide range of Ethernet cards for both PC and notebook computers. For more
information on available cables and accessories, please see Accessory Products
from StarTech.com on page 5.
This package should contain:
• 1 x Ethernet Switch
• 1 x Power Adapter
• 1 x Instruction Manual
Features
Introduction
Instruction Manual
System Requirements
Contents
1

Installation
and usage
This section will guide you through the installation of your Fast Ethernet switch.
Please read through the instructions carefully and complete each step in the order
listed.
Rear Panel
Available ports
Please note: all RJ45 ports
can be used as the Uplink port.
Please note that the following instructions describe how to mount your new
Ethernet Switch on a wall. If you do not wish to perform this step, please skip to
step 5.
1. Place the Switch on a flat table or, if you wish to mount the Switch, the
StarTech.com Fast Ethernet switch has two wallmount sockets that allow it to be
hung from most walls. To mount the switch, you will need a drill, a screwdriver,
two #6 wood screws and their corresponding wall plugs.
2. Carefully measure the distance between the centers of the two screw-holes on
the back of the switch. Mark the location of the screw-holes on your wall,
making sure your marks are straight and even.
3. Drill the holes in the wall and insert the plastic wall plugs.
4. Insert the screws into the wall plugs so that there is a gap of about 2 mm (about
1/10 of an inch) between the head of the screw and the wall.
5. Place the Fast Ethernet switch so that the wide end of the mounting sockets are
Instruction Manual
2

over the screwheads. Slide the case downward so that the screwheads slide into
the narrow slots.
6. Connect one end of your network cable to an open port on the rear panel of the
switch.
7. Plug the other end of the cable into the RJ-45 port on your network device.
8. Repeat steps 5 and 6 for any other devices you want to connect.
9. Plug one end of the the power adapter into an open outlet and plug the other
end into the DC connector on the side panel of the device. The Power LED on
the front of the switch should now be lit.
10. Once the Switch is powered on, it will be automatically initialized, and all
Link/Act LEDs will flash momentarily, indicating that the system has been reset.
Power LED
Front Panel
Port Link/Activity LEDs
The LED indicators are used for monitoring and troubleshooting of the Switch:
Power LED: This indicator will light up when the Switch powers up. If the LED is
not lit, please check the power adapter and connection.
LINK/ACT LEDs: These LEDs indicate Link/Active status. One LED indicator will
light green when a device is connected to the corresponding port. It flashes when
data is being transmitted or received on the connection.
Instruction Manual
3

Standards IEEE802.3 10Base-T, IEEE802.3u, 100Base-TX
Topology Star
Protocol CSMA/CD
Data Transfer
Rate
Ethernet: 10Mbps (Half Duplex), 20Mbps (Full Duplex);
Fast Ethernet: 100Mbps (Half Duplex), 200Mbps (Full Duplex)
Network Media
(cable)
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ù STP (maximum 100m)
100BASE-Tx: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ù STP (maximum 100m)
Number of Ports DS5107: 5 x 10/100Mbps Auto-Negotiation ports
DS8107: 8 x 10/100Mbps Auto-Negotiation ports
LED indicators Power, Link/Act
Transfer Method Store-and-Forward
MAC Address
Learning Automatically learning, automatically update
Frame Filter Rate 10Base-T: 14880pps/Port;
100Base-Tx: 148800pps/Port
Frame Forward
Rate
10Base-T: 14880pps/Port;
Rate 100Base-Tx: 148800pps/Port
Regulatory certi-
fications FCC, ROHS, CE
Specifications
General Specifications
Environmental and Physical Specifications
Dimensions (W x D x H) 5.5” x 3.3” x 1.2” (140 x 85 x 30mm)
Power Supply Output DS5107: AC12V~ 0.35A
DS8107: AC9V~ 0.8A
Operating Temperature 0 ~40 (32 ~104 )
Storage Temperature -40~70 (-40 ~158 )
Operating Humidity 10%~90% non-condensing
Storage humidity 5%~95% non-condensing
Instruction Manual
4

Accessory
Products from StarTech.com
Contact your local StarTech.com dealer or visit www.startech.com for cables or other
accessories that will help you get the best performance out of your new product.
ET90110SC
10/100 Mbps RJ45 to Multimode SC Fiber Media Converter
ET90110ST
10/100 Mbps RJ45 to Multimode ST Fiber Media Converter
M45PATCH10BL
10 ft Blue Molded Category 5e (350 MHz) UTP Patch Cable
M45PATCH15BL
15 ft Blue Molded Category 5e (350 MHz) UTP Patch Cable
M45PATCH100B
100 ft Blue Molded Category 5e (350 MHz) UTP Patch Cable
5
Instruction Manual

Technical
Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online
tools, documentation, and downloads.
Warranty
Information
This product is backed by a one year warranty. In addition, StarTech.com warrants
its products against defects in materials and workmanship for the periods noted, fol-
lowing the initial date of purchase. During this period, the products may be returned
for repair, or replacement with equivalent products at our discretion. The warranty
covers parts and labor costs only. StarTech.com does not warrant its products from
defects or damages arising from misuse, abuse, alteration, or normal wear and
tear.
Limitation
of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or
their officers, directors, employees or agents) for any damages (whether direct or
indirect, special, punitive, incidental, consequential, or otherwise), loss of profits,
loss of business, or any pecuniary loss, arising out of or related to the use of the
product exceed the actual price paid for the product. Some states do not allow the
exclusion or limitation of incidental or consequential damages. If such laws apply,
the limitations or exclusions contained in this statement may not apply to you.
6
