StarTech.com SV221MICRO User manual

PS/2 KVM Switch
SV221MICRO Instruction Manual
Actual product may vary from photo
2 Port PS/2 KVM Switch with Integrated Cables

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd
ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and
do not represent an endorsement of a product or service by StarTech.com, or an
endorsement of the product(s) to which this manual applies by the third-party company in
question. Regardless of any direct acknowledgement elsewhere in the body of this
document, StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this
manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Using the KVM Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Instruction Manual
i

IInnttrroodduuccttiioonn
Thank you for purchasing a StarTech.com personal 2 port PS/2 micro KVM switch. This
KVM has a small footprint with integrated cables that won’t clutter your workspace. You
can use keyboard hotkeys to switch computers, or use the Auto Scan feature to monitor
two computers automatically.
FFeeaattuurreess
• Hotkey switching avoids having to reach for buttons
• Integrated cable design prevents clutter and avoids hassles
• Auto Scan feature provides automatic monitoring capability
BBeeffoorreeYYoouuBBeeggiinn
System Requirements
• One set of PS/2 console peripherals (keyboard, mouse) and a VGA monitor
• Computers must have PS/2 keyboard and mouse ports
Contents
This package should contain:
• 1 x KVM Switch
• 1 x User Manual
Instruction Manual
1

IInnssttaallllaattiioonn
Please read this section thoroughly before installing the KVM switch.
Connecting Computers to the KVM Switch
1. Remove any existing keyboards, mice, and monitors from the computers
that you wish to use with the KVM switch.
2. Connect a PS/2 keyboard to the console port on the side of the KVM switch, marked
with a purple connector (see above).
3. Connect a PS/2 mouse to the console port on the side of the KVM switch, marked
with a green connector (see above).
4. Connect a monitor to the console port on the front of the KVM switch.
5. Connect the integrated cable for computer 1 (see above) to the keyboard, mouse and
video connectors on the computer. If you need assistance in identifying any ports,
please consult the documentation for your computer.
6. Connect the integrated cable for computer 2 (see above) to the keyboard, mouse and
video connectors on the computer. If you need assistance in identifying any ports,
please consult the documentation for your computer.
7. Power on computer 1 and computer 2. You can now use the KVM switch.
Instruction Manual
2
Monitor In
Console PS/2
Keyboard & Mouse
Connection to
Computer 1
Connection to
Computer 2

Using the KVM Switch
Once you have completed the installation process, you can use the following methods to
view computers connected to the KVM switch:
Hotkey: The command [Scroll Lock] - [Scroll Lock] followed by the computer
number (1 or 2) to switch between computers. Scroll Lock must be pressed twice
within 3 seconds to activate the hotkey feature. If you do not wish to switch between
computers, the KVM will cancel the command after 5 seconds.
Computer 1: [Scroll Lock] - [Scroll Lock] -[1]
Computer 2: [Scroll Lock] - [Scroll Lock] -[2]
Auto Scan: This feature automatically switches between the two connected
computers at 5 second intervals for monitoring purposes. To enter Auto Scan mode,
use the following hotkey sequence:
[Scroll Lock] - [Scroll Lock] -[S]
To cancel Auto Scan, press any key on the keyboard. The KVM will leave the
computer being viewed as the active port.
Instruction Manual
3

TTeecchhnniiccaallSSuuppppoorrtt
StarTech.com’s lifetime technical support is an integral part of our commitment to provide
industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
WWaarrrraannttyyIInnffoorrmmaattiioonn
This product is backed by a three-year warranty. In addition, StarTech.com warrants its
products against defects in materials and workmanship for the periods noted, following
the initial date of purchase. During this period, the products may be returned for repair, or
replacement with equivalent products at our discretion. The warranty covers parts and
labor costs only. StarTech.com does not warrant its products from defects or damages
arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
officers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential
damages. If such laws apply, the limitations or exclusions contained in this statement
may not apply to you.
Instruction Manual
4

Revised: 2 December 2005 (Rev. A)
