StarTech.com SV221MICROUA User manual

USB KVM Switch
SV221MICROUA Instruction Manual
Actual product may vary from photo
2 Port USB KVM Switch with Integrated Cables and Audio Switching

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd
ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and
do not represent an endorsement of a product or service by StarTech.com, or an
endorsement of the product(s) to which this manual applies by the third-party company in
question. Regardless of any direct acknowledgement elsewhere in the body of this
document, StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this
manual and related documents are the property of their respective holders.

TTaabblleeooffCCoonntteennttss
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Connecting Computers to the KVM Switch
Installing the Windows Management Software (Optional) . . . . . . . . . . . . . . . .3
Using the Windows Management Software . . . . . . . . . . . . . . . . . . . . . . . . . .3
Hot Key Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Using the KVM Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Instruction Manual
i

IInnttrroodduuccttiioonn
Thank you for purchasing a StarTech.com personal 2 port USB KVM switch. This KVM
has a small footprint with integrated cables that won’t clutter your workspace, and
includes audio switching so you only need one set of speakers. You can use
customizable keyboard hotkeys to switch computers, or the push-button interface on the
from of the KVM.
FFeeaattuurreess
• Supports USB peripherals for easy installation
• Audio switching support eliminates the need for two sets of speakers
• Hotkey switching with customizable key combinations
• Integrated cable design prevents clutter and avoids hassles
BBeeffoorreeYYoouuBBeeggiinn
System Requirements
• One set of USB console peripherals (keyboard, mouse) and speakers (optional)
• Computers must have an available USB port, and a sound card (optional)
• Computers must have a CD-ROM or other compatible optical drive for optional
software installation (Windows only)
Contents
This package should contain:
• 1 x KVM Switch
• 1 x Installation CD
• 1 x User Manual
Instruction Manual
1

IInnssttaallllaattiioonn
Please read this section thoroughly before installing the KVM switch.
Connecting Computers to the KVM Switch
1. Remove any existing keyboards, mice, monitors, and speakers from the computers
that you wish to use with the KVM switch.
2. Connect a USB keyboard to the console port on the front of the KVM switch, marked
with a keyboard icon (see above).
3. Connect a USB mouse to the console port on the front of the KVM switch, marked
with a mouse icon (see above).
4. Connect a monitor to the console port on the front of the KVM switch, marked Monitor
(see above).
5. Connect a microphone to the pink connector on the side of the KVM switch, also
marked with a microphone icon (optional, see above).
6. Connect speakers to the green connector on the side of the KVM switch, also marked
with a speaker icon (optional, see above).
7. Connect the integrated cable for computer 1 (corresponds to the LED indicator on the
top of the KVM, as marked) to the USB, video, speaker, and microphone connectors
on the computer. If you need assistance in identifying any ports, please consult the
documentation for your computer. If you are not using the audio switching feature and
did not connect a microphone and speakers to the KVM, you do not need to connect
the microphone and speaker connectors to the computer.
8. Connect the integrated cable for computer 2 (corresponds to the LED indicator on the
top of the KVM, as marked) to the USB, video, speaker, and microphone connectors
on the computer. If you need assistance in identifying any ports, please consult the
documentation for your computer. If you are not using the audio switching feature and
did not connect a microphone and speakers to the KVM, you do not need to connect
the microphone and speaker connectors to the computer.
Instruction Manual
2
Console USB Mouse
Console USB Keyboard
Console Monitor
Selection Button Speaker/Mic
Integrated Cable
(Computer 1)
Integrated Cable
(Computer 2)

9. Power on computer 1 and computer 2. You can now use the KVM switch.
(!) NOTE: If you experience problems with Windows detecting the KVM switch, you may
wish to connect the devices you will be using at the KVM console, restart the machine,
and re-attach the KVM switch. This will allow Windows to configure itself to use USB
input devices.
(!) NOTE: If at any time during the installation process Windows warns you about a driver
file not being digitally signed, this is normal. Choose to continue the installation to
complete the detection process.
Installing the Windows Management Software (Optional)
The software included with the KVM switch is designed for use with computers that use
Windows 98, 98SE, ME, 2000, XP, or Server 2003. This software allows you to configure
custom hotkey sequences for KVM features and provides a software menu you can use
to switch computers, as an alternative to keyboard hotkeys or the push-button selector on
the top of the KVM.
1. Once you have installed the KVM switch following the instructions above, insert the
CD that came in the package in your computer’s CD-ROM or other optical drive. The
KVM software installation should start automatically. If it doesn’t, open My
Computer and double click the icon for the CD-ROM drive. Double click the
USBKVMIn.exe file to start the setup program.
2. Walk through the setup process by accepting the default settings and choosing Next
whenever prompted. Windows may warning you during the install process that the
driver being installed is not digitally signed. If this occurs, choose to continue the
installation. When the setup routine is complete, setup will notify you with a final
screen. Click Finish to complete the setup process.
3. The software will now load each time Windows starts. You can open the
configuration menu by double-clicking one of the following icons:
Using the Windows Management Software
The management software allows you to configure custom hotkeys, turn the status
buzzer indictor off or on, and use the autoscan feature. You can access the software by
double clicking its icon on the taskbar, or you can right-click it once and choose the
Settings option from the menu. You can also use this menu to activate Auto Scan and
switch active computers.
Instruction Manual
3

Hot Key Configuration
This setting configures custom key configurations that you can use to switch between
PCs on the KVM. By default, the [Ctrl] + [Alt] + [1] hotkey sequence is active, where
the [1] key is the number of the KVM port you wish to access. To use the custom hotkey
feature, all keys must be pressed simultaneously. You can change the command key
from the default to any letter or number on the keyboard. Control keys such as [Tab],
[Esc], and [Num Lock] cannot be used.
Turn On Buzzer
When checked, activates the audible notification when the port is changed.
Fix Audio Port at PC
When checked, locks audio input to the selected port regardless of which KVM port is
active. When unchecked, audio input is selected along with the KVM port.
Auto Scan Period
Sets the amount of time the Auto Scan feature will wait between switching ports.
Selectable between 10 ~ 60 seconds.
NOTE: Although there are options to change hotkeys for ports 3 and 4, they are inactive
on this product.
Instruction Manual
4

Using the KVM Switch
Once you have completed the installation process, you can use the following methods to
select a KVM port:
Selection Button: You can switch between ports by press the button on the top of
the KVM.
Universal Hotkey: The command [Scroll Lock] - [Scroll Lock] can be used
with any operating system, including Windows computers with the KVM management
software installed. This toggles control to the next KVM port.
Customized Hotkey: If you are using Windows-based computers and have installed
the KVM management software, you can use the [Ctrl] + [Alt] + [1] sequence to
switch computers. The [1] key corresponds to the key you have configured in the
software (see the previous section for details).
(!) NOTE: You cannot use either keyboard hotkey sequence to select a port that does not
have the USB cable connected or where the computer is powered off.
(!) NOTE: Mac users will need to use an IBM-compatible USB keyboard for the console
since most Apple keyboards do not have a [Scroll Lock] key.
Instruction Manual
5

TTeecchhnniiccaallSSuuppppoorrtt
StarTech.com’s lifetime technical support is an integral part of our commitment to provide
industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
WWaarrrraannttyyIInnffoorrmmaattiioonn
This product is backed by a one-year warranty. In addition, StarTech.com warrants its
products against defects in materials and workmanship for the periods noted, following
the initial date of purchase. During this period, the products may be returned for repair, or
replacement with equivalent products at our discretion. The warranty covers parts and
labor costs only. StarTech.com does not warrant its products from defects or damages
arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
officers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential
damages. If such laws apply, the limitations or exclusions contained in this statement
may not apply to you.
Instruction Manual
6

Revised: 10 May 2005 (Rev. A)
AAbboouuttSSttaarrTTeecchh..ccoomm
StarTech.com is “The Professionals’ Source for Hard-to-Find Computer
Parts”. Since 1985, we have been providing IT professionals with the
quality products they need to complete their solutions. We offer an
unmatched selection of computer parts, cables, server management
solutions and A/V products and serve a worldwide market through our
locations in the United States, Canada, the United Kingdom and Taiwan.
Visit www.startech.com for complete information about all our products
and to access exclusive interactive tools such as the Parts Finder and the
KVM Reference Guide. StarTech.com makes it easy to complete almost
any IT solution. Find out for yourself why our products lead the industry in
performance, support, and value.
