SCP SCIENCE DigiPREP HP User manual

User Manual
www.scpscience.com
DigiPREP Digestion Blocks
PROVIDING INNOVATIVE SOLUTIONS TO ANALYTICAL CHEMISTS

DigiPREP Jr, MS, LS, HP CONTROLLERS
KEYPAD
010-500-220
When an application requires a one-step set-
point temperature, the KeyPad controller offers all
the required features to respond to your needs.
A total of 16 pre-defined keys which include a
"Target Temperature" button to input the desired
operating temperature; "Target Time" button to
enter both the time required at the designated
"Target Temperature" and the time delay before an
alarm will sound if the alarm is activated; and an
"audible alarm" button to activate the alarm. Inputting
operating parameters is made simply and easily. A
liquid crystal display screen presents information
clearly. A com port on the back of the controller allows
the possibility to use a DigiSET (catalogue number
010-500-014).
COLOUR TOUCH SCREEN
010-500-275
Users may program and save 12 different multi-step
methods with the controller. In each method, users
may input three “Time-to-Temperature” and three
“Time-at-Temperature” parameters. Other features
include: timer and shut-off option; as well as operat-
ing language options in English, French, Japanese,
Chinese, Korean, German, Italian, Spanish and Dutch.
The controller is CE/UL/CSA approved to comply with
major electrical and safety standards.
The USB port is conveniently located at the back
of the controller and enables users to save detailed
reports for laboratory audits. The reports are saved
onto a USB stick and include the following data: date
and time of the sample run, instrument serial number,
temperature log in 15 second intervals and safety
messages. The controller is perfect for quality control,
research and method development.

Disclaimer: Products are supplied for laboratory use only and should not be used for any household,
medical or therapeutic application. SCP SCIENCE presumes that only trained and qualified individuals, familiar
with procedures suitable for the safe operation of these instruments, will handle them. Our customers are
solely responsible for the safe operation, handling and use of these products.
CERTIFIED to comply with the following EMC and safety requirements standards:
IEC 61000-4-3:2006 A1:2007 A2:2010, EN 55011: 2016, Group 1, Class A, EN61000-4-6 (2014),
EN61000-4-2 (2009), EN61000-4-4 (2012), EN61000-4-5 (2014), IEC 61000-4-11:2004, CSA-C22.2
NO. 61010-1-12 (3rd edition), CAN/CSA-C22.2 NO. 61010-2-010-04(R09), UL61010-1-2012 (3rd edi-
tion), UL61010A-2-010 (1st edition), IEC61010-1:2010 (3rd edition), IEC61010-2-010: 2014 (3rd ed.) and
EN50581:2012.
MANUFACTURED IN CANADA
EU Users:
Contact your local
distributor for dis-
posal instructions.
Copyright by SCP SCIENCE. All Rights Reserved.
This manual contains proprietary information, which shall not be reproduced or transferred to other documents
or disclosed to others without prior written permission from SCP SCIENCE.
Service Department • Technical Support
[email protected]
PROVIDING INNOVATIVE SOLUTIONS TO ANALYTICAL CHEMISTS
CORPORATE
HEADQUARTERS
USA FRANCE GERMANY
21800 Clark Graham
Baie D’Urfé (Montréal),
Quebec, H9X 4B6 Canada
3rd Party Distribution Center
348 Route 11, Champlain,
N.Y. 12919-4816
12 Ave. de Québec, Bat. Iberis
SILIC 642, 91965
Villebon sur Yvette
Alte Marktoberdorfer Straße 14,
87616 Marktoberdorf
Phone: [phone]
[phone]
Fax: [phone]
[phone]
Phone: [phone]
Fax: [phone]
Phone: [phone]
Fax: [phone]
Phone: [phone]
Fax: [phone]
UK
Phone: [phone]
Phone: [phone]
SIÈGE SOCIAL CANADA / É.-U. FRANCE ALLEMAGNE
21800 Clark Graham
Baie D’Urfé (Montréal),
Quebec, H9X 4B6 Canada
3rd Party Distribution Center
348 Route 11, Champlain,
N.Y. 12919-4816
12 Ave. de Québec, Bat. Iberis
SILIC 642, 91965
Villebon sur Yvette
Alte Marktoberdorfer Straße 14,
87616 Marktoberdorf
Tél : [phone]
[phone]
Fax : [phone]
[phone]
Tél : [phone]
Fax : [phone]
Tél : [phone]
Fax :[phone]
Tél : [phone]
Fax : [phone]
ROYAUME-UNI
Tél : [phone]
Tél : [phone]

TABLE OF CONTENTS
DigiPREP Jr, MS, LS, HP CONTROLLERS ...... 2
ColoUr Touch Screen ..................... 2
KeyPad.................................. 2
INTRODUCTION .............................. 1
CAUTIONS AND NOTES......................... 2
WARRANTY............................. 2
OPERATIONAL PRECAUTIONS.................... 3
SAFETY INFORMATION ......................... 3
INSTALLATION ............................... 3
Unpacking ............................... 3
SETTING UP ................................. 4
OPERATION WITH PROBES................... 4
DigiPROBE ......................... 4
DigiSET ................................. 5
BLOCK DESCRIPTION .......................... 6
CLEANING .................................. 7
Cleaning of minor surface spills.............. 7
Cleaning of digestion wells ................. 7
Cleaning melted plastic from wells ........... 7
CLEANING OF A MAJOR SPILL ................... 7
SPECIFICATIONS ............................. 8
Environmental ............................ 8
Electrical ................................. 8
RoHs............................... 9
DigiPREP 240 Jr, MS, LS................... 10
START UP KITS.............................. 10
Options................................. 10
DigiPREP 240 Blocks.................... 11
Accessories 15 ml ....................... 11
Accessories 100 ml ...................... 12
DigiPREP 240 Jr, MS ...................... 13
START UP KITS.............................. 13
DigiPREP 240 MS ......................... 13
TEFLON®INSERTS ........................... 13
ELECTRICAL SCHEMATIC ...................... 14
DigiPREP Jr, MS, LS, HP ............... 14
DigiPREP 240 .......................... 15

1
DigiPREP Digestion Blocks
Version 16.0
INTRODUCTION
DigiPREP Digestion blocks are designed for labora-
tory use in the digestion and evaporation of a variety of
samples, primarily water, wastewater, soil, and sludge
samples. They are Teflon®coated.
DigiPREP Jr, DigiPREP MS, DigiPREP LS and
DigiPREP HP blocks have a temperature range of
ambient to 180 °C. These blocks are designed to
hold DigiTUBE sample digestion vessels and glass
/ quartz digestion tubes.
DigiPREP 240 Jr, DigiPREP 240 MS and
DigiPREP 240 LS blocks have a temperature range
of ambient to 240 °C. A “spill proof” design prevents
acid migration to the inside of the block housing. The
top white ring is removable.
Optional accessories include DigiPROBE, which is
used to monitor sample temperature, and DigiSET,
which is used to monitor and shut off the heating
system at a set sample volume level.
Old controllers will work with new
blocks but will not allow the blocks
to reach 240 °C. New controllers are
required to reach 240 °C.
DigiTUBEs have a temperature
range of up to 115 °C.
CA
UT
ION

2DigiPREP Digestion Blocks
Version 16.0
CAUTIONS AND NOTES
Cautions, warnings, and notes are included
throughout this manual.
CAUTION
A caution is used to emphasize
information pertaining to procedures
that, if not strictly followed, may result
in damage or destruction to the
instrument or improper instrument
operation.
WARNING
A warning is used to emphasize
information about dangerous or
hazardous conditions relating to the
operation, cleaning, or maintenance
of the instrument that may result in
personal injury.
NOTE
A note is used to emphasize
procedures or conditions that may
be misinterpreted or overlooked,
and to clarify potentially confusing
situations.
WARRANTY
SCP SCIENCE warrants that this product be
free from defect in workmanship and materials
for one (1) year from date of purchase.
`Should the unit malfunction, call SCP SCIENCE
service department, or your local distributor, and
a service representative will instruct you on how
to proceed.
`There are no user-serviceable parts in this unit.
The warranty is void if the unit shows evidence
of being tampered with, of being subjected to
excessive moisture, heat or corrosion, or of
other misuse.
`SCP SCIENCE shall not be responsible
for any damage or losses however caused
which may be experienced as a result of the
installation or use of this product.
`This product is not warranted for, nor has it
been tested for, use with perchloric acid.
The user accepts all responsibility if this
product is used with perchloric acid.
Symbol Description Symbol Description
VVoltage lMains on
~Alternating current 0Mains off
ACurrent
Attention, consult
accompanying documents
Hz Frequency Caution, hot surfaces
FFast-acting fuse Protective conductor terminal
CA
UT
ION
WA
RNING
NOTE

3
DigiPREP Digestion Blocks
Version 16.0
OPERATIONAL PRECAUTIONS
DigiPREP block must be connected to a
controller that is properly grounded. In the event
of an electrical short circuit, grounding reduces
the risk of electrical shock by providing an escape
wire for electrical current. DigiPREP controllers are
supplied with an electrical cord that has a grounding
wire with a grounding plug. Ensure that the plug
is connected into an outlet that has been properly
installed and grounded. Consult a qualified
electrician if there is any doubt about the existence
of proper grounding at the outlet.
DigiPREP block is designed to be lifted from
the bottom only. Ensure that the controller is
disconnected prior to moving the block. Do not
attempt to lift the block by the top white trim
as damage may result.
DigiPREP blocks are elevated-temperature
digestion systems with exposed hot surfaces. Be
careful around the instrument when it is in operation.
SAFETY INFORMATION
A minimum of safety considerations must be
followed when working with DigiPREP low
temperature blocks in order to maintain good
laboratory practice:
`Do not place the DigiPREP blocks on a sur-
face containing flammable material.
`DigiPREP block requires a clearance of three
inches (7.5 cm) on all sides.
`DigiPREP block should be operated in a fume hood.
`Do not place the DigiPREP controller in a fume
hood.
`DigiPREP system must be plugged into a
three-prong grounded outlet.
For indoor use only. Disconnect
mains power supply before any
services.
Mains power source suitable for
equipment shall be provided at the
installation location.
If the equipment is used in a manner
not specified by SCP SCIENCE,
the protection provided by the
equipment may be impaired.
INSTALLATION
UNPACKING
Retain all packing material in case
you need to return the instrument to
the manufacturer for service.
Verify that all components listed have been
included:
`DigiPREP block
`Operation manual
`DigiPROBE dongle
(ambient to 180 °C series only)
`DigiTUBE rack:
■Jr / 240 Jr: 1 rack
■MS / 240 MS: 2 racks
■LS / 240 LS: 3 racks
■HP: No racks
Optional items, such as glass,
quartz, calibrated or non-calibrated
digestion tubes may have been
included in the shipment. Carefully
check the packing list(s) and
the contents of shipping cartons
to verify that all items listed are
included. Please notify SCP SCIENCE
or your local distributor of any
discrepancies.
Inspect the products for any shipping damage.
If the instrument has been damaged in shipping,
contact the freight carrier to report damage and
to file a damage report. Also contact the SCP
SCIENCE service department to report damage
and to request service information.
If you find evidence of damage, do
not attempt to operate the
instrument.
CA
UT
ION
WARNING
NOTE
NOTE
WA
RNING

4DigiPREP Digestion Blocks
Version 16.0
SETTING UP
Place the DigiPREP block in a fume hood. The
controller must not be placed in the fume hood.
With the controller’s power switch in the “off”
position, do the following:
`Connect the block’s umbilical cable to the con-
troller.
Disconnecting or reconnecting the
umbilical cable while the controller
is turned on, especially while it
is on the RUN screen, will likely
result in permanent damage to the
instrument.
`Connect the power cord to the back of the
controller.
`Connect the DigiSET (or DigiSET dongle) to
the back of the controller.
`Connect DigiPROBE (or DigiPROBE dongle)
to the back of the block.
If you are not using the DigiPROBE
or DigiSET, the dongles must be
connected; otherwise, an error
message may be displayed.
`Insert the glass well liner into the DigiPROBE
well (Small hole near right of block).
`If you are using DigiPROBE, insert the probe
into the well liner.
The system is now ready to be plugged in
and turned on. Please see your controller
manual for operation instructions.
OPERATION WITH PROBES
DigiPROBE
DigiPROBE (optional) may be
used with DigiPREP systems
to monitor and control the
sample temperature (when
placed in the sample) or the
block temperature when placed
in the storage well located
on the block).
When using the DigiPROBE with
the DigiPREP HP, a flat-bottomed,
conical flask is recommended for
best results.
Install the probe in the port marked “DigiPROBE”
on the back of the DigiPREP block. If using to
monitor and control the heating of the block via
the sample temperature, insert the probe end into
a control sample with the probe holder supporting
the DigiPROBE. (The 010-515-036 is used with 15
ml DigiTUBEs, 010-500-035 probe holder is used
with 50 ml DigiTUBEs, 010-501-010 is used with
100 ml DigiTUBEs and a 6"(15 cm) probe. The 010-
500-037 probe holder is used with glass digestion
tubes and a 10" (25 cm) probe).
DigiTUBEs are used with DigiPREP
Jr, MS, and LS, up to 115 °C.
When DigiPROBE is not being used it
may be placed in the storage well, located
at the rear right corner of the graphite
block. Ensure that there is a glass liner (catalogue
number 010-500-041) in the well.
The control sample should be a
typical digestion sample. The tip
of the DigiPROBE should be
approximately 1 mm from the bottom
of the digestion vessel.
Serious temperature overrun may
occur during digestion if the
DigiPROBE is not in an appropriate
sample or the storage well. Always
place the DigiPROBE in the storage
well when not in use.
WARNING
NOTE
NOTE
CA
UT
ION
NOTE
CA
UT
ION

5
DigiPREP Digestion Blocks
Version 16.0
DigiPROBE can be calibrated with DigiPREP
controllers or the PC Classic controller (with
Go2Temp software). Please see your controller
manual for calibration instructions.
DigiSET
DigiSET (optional) can be used with all
DigiPREP systems to monitor and suspend the
heating cycle at a pre-set sample volume level.
DigiSET probe is connected to the DigiSET
unit and 'COM 2' from DigiSET unit is connect-
ed to the 'COM 2' of the controller with the sup-
plie cable. Please consult the DigiPREP control-
ler manual for more detailed instructions.

6DigiPREP Digestion Blocks
Version 16.0
BLOCK DESCRIPTION
DigiPREP Jr, MS,
LS, HP Blocks
DigiPREP 240 Jr, MS, LS and
DigiPREP 240 MS Combi Blocks
1. DigiPROBE connection port
2. Umbilical cable connects to controller
3. Spill proof graphite block
4. Top white ring
5. DigiPROBE storage well position
6. DigiPREP 240 MS Combi Teflon®
insert
7. DigiPREP MS 24-position rack
u
v
v
w
wx
y
DigiPROBE
dongle (4 pin male)
x
z
{
y

7
DigiPREP Digestion Blocks
Version 16.0
CLEANING
If the surface is still hot, contact with
liquid may create steam that can
scald you. It is important to allow
the instrument to cool before
cleaning.
CLEANING OF MINOR SURFACE SPILLS
Turn off the system and disconnect the block from the
DigiPREP controller. Allow the block to cool. Sponge
up any excess liquid, dilute the area with clean water,
and wipe dry with a paper towel.
CLEANING OF DIGESTION WELLS
Turn off the system and disconnect the system
from the block controller. Allow the block to cool
before proceeding further.
Suction the solution out of the well(s) with an eye
dropper, squeeze bottle, or pipette. Dilute any
remaining spillage with water, two or three times,
and suction as much solution out as possible.
Sponge the remaining residue with a paper towel.
Allow the system to dry completely before
plugging into a power outlet. Observe good laboratory
practices by wearing gloves to perform the above
task.
CLEANING MELTED PLASTIC FROM WELLS
Heat the block to 160 °C. Using a pair of needle-
nose pliers, carefully pinch and gently pull
the softened plastic residue from inside the well.
If it is difficult to remove the melted plastic increase
the block temperature by 5 °C.
CLEANING OF A MAJOR SPILL
If a solution has run down below the white top ring and
under the block, turn off the system and unplug the
block from the power source (ambient to 180 °C). Allow
the block to cool before proceeding further.
The block must be disassembled, cleaned, and
thoroughly dried prior to running again.
Please consult the service
department for help if required.
For DigiPREP Jr, MS, LS, Systems:
In order to access the block, you must first
remove the white top ring.
The white top ring is held in place by plastic
spring clips inside the housing at all four corners.
Release the clips by gently lifting the corners of
the white top ring until it becomes free. If it
does not remove easily, insert a flat-blade screw-
driver between the white top ring and the outer
Kydex
®
skin. Gently twist the screwdriver to
pry the white top ring off at al four corners.
Next, use tweezers or pliers to gently remove
the insulation from the sides of the block. (If
a replacement set of insulation is required,
contact the service department.)
The graphite block is held into place by four
mounting bolts located on the bottom of the unit.
Turn the unit upside-down onto a soft surface, being
careful not to scratch the Teflon
®
coating on the
graphiteblock. Using a flat-blade screwdriver,
remove the plastic cover plates. Next, using an
Allen wrench (6 mm or ¼ inch), remove the
mounting bolts. Finally, lift the housing up from
around the graphite block. (Lift gently as there is wiring
attached to the graphite block).
You may now clean any affected parts with a
damp cloth. Gloves and a lab coat are strongly
recommended. (Be careful not to pinch the wires
between the graphite block and other components.)
To assemble repeat in reverse order.
Before reassembling, make sure that the Teflon
®
sheet is adhered to the block, that the heater is
secured in place, and that the aluminium plate
is placed over the insulation. Also ensure that all
components are dry prior to reassembling.
WARNING
NOTE

8DigiPREP Digestion Blocks
Version 16.0
SPECIFICATIONS
ENVIRONMENTAL
Relative humidity 30% to 80%
Altitude Up to 2000 m
Installation Category ll
Pollution Degree 2
Ambient operating
temp. -5 °C to 40 °C
The main supply cord is constructed
of heat-resistant material and should
only be replaced by an equivalent or
better cord.
Line voltage fluctuations greater
than 10% will affect instrument
performance.
ELECTRICAL
Model Voltage Power Frequency Maximum Operating Temp.
Jr 115/230V ±10% 725W 50/60 Hz 180 °C
HP / MS 115/230V ±10% 925W 50/60 Hz 180 °C
LS 230V ±10% 2665W 50/60 Hz 180 °C
240 Jr 115/230V ±10% 1000W 50/60 Hz 240 °C
240 LS 230V ±10% 2665W 50/60 Hz 240 °C
240 MS 230V ±10% 1380W 50/60 Hz 240 °C
NOTE

9
DigiPREP Digestion Blocks
Version 16.0
RoHs
Toxic or hazardous substances and elements
Part name Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
Hexavalent
Chromium
(Cr6+)
Polybrominated
Biphenyle
(PBB)
Polybrominated
Diphenyl Ether
(PBDE)
Housing o o o o o o
Graphite Block o o o o o o
RTD probe o o o o o o
Over temperature sensor o o o o o o
Heater o o o o o o
Umbilical Cord & wiring o o o o o o
Voltage Selector o o o o o o
Fasteners o o o o o o
O: Indicates that the toxic or hazardous substance
contained in all the homogenous materials for this
part, according to EIP-A, EIP-B, EIP-C, is below
the limit requirement in SJ/T11363-2006.
X: Indicates that the toxic or hazardous substance
contained in all the homogenous materials for this part,
according to EIP-A, EIP-B, EIP-C, is above the limit
requirement in SJ/T11363-2006.

10 DigiPREP Digestion Blocks
Version 16.0
DigiPREP 240 Jr, MS, LS
START UP KITS
Includes / Quantity
Description Volume and Catalog
Number
RackLock
DigiTUBEs
Disposable
Watch
Glasses
24 Position
RackLock
Rack
Foam
Storage
Racks
DigiPREP Jr.
15 ml; 010-515-040 540 - 1 -
50 ml; 010-505-066 500 1000 1 5
100 ml; 010-501-215 500 1000 1 5
DigiPREP MS
15 ml; 010-515-108 540 - 2 -
50 ml; 010-500-067 500 1000 2 5
100 ml; 010-501-235 500 1000 1 5
DigiPREP LS 50 ml; 010-500-069 500 - 3 10
100 ml; 010-501-255 500 1000 1 5
OPTIONS
# Catalog Description DigiPREP DigiPREP 240
010-500-014 DigiSET (115V/230 V) o o
010-500-051 Dongle for DigiSET port (2-pin female) o o
010-500-039 DigiPREP Fume Hood, 20" (H) x 26" (W) x 23.5" (D) o o
010-500-049 DigiPREP Fume Hood II, 25" (H) x 26" (W) x 23.5" (D) o o
010-500-059 DigiPREP Fume Hood, 20" (H) x 26" (W) x 28" (D) o o
010-500-031 DigiVAC top* o
010-500-033 DigiVAC blower unit* o
010-505-041 DigiPROBE storage wells for HP o
010-505-052 Dongle for DigiPROBE port (4-pin male) o o
010-500-041 Glass storage well (10/pk) o o
010-500-111 Adapter Male / New Controller to Old Block o o
010-500-117 Adapter Female / New Block to Old Controller o o
*For use with DigiPREP MS (Ambient to 180 degrees) only.

11
DigiPREP Digestion Blocks
Version 16.0
DigiPREP 240 BLOCKS (AMBIENT TO 240 °C)
Catalogue Number Description
010-501-xxx DigiPREP 240 Jr, 100 ml, 12 position, 115V/230V
010-505-xxx DigiPREP 240 Jr, 50 ml, 24 position, 115V/230V
010-515-xxx DigiPREP 240 Jr, 15 ml, 40 position, 115V/230V
010-501-xxx DigiPREP 240 MS, 100 ml, 30 position, 230V
010-500-420 DigiPREP 240 MS, 50 ml, 48 position, 230V, NA
010-515-xxx DigiPREP 240 MS, 15 ml, 108 position, 115V/230V
010-500-xxx DigiPREP 240 LS, 50 ml, 72 position, 230V
010-501-xxx DigiPREP 240 LS, 100 ml, 42 position, 230V
010-505-xxx DigiPREP 240 LS, 50 ml, 24 position
010-500-xxx DigiPREP 240 LS, 50 ml, 48 position
010-501-xxx DigiPREP 240 LS, 100 ml, 12 position
010-501-xxx DigiPREP 240 LS, 100 ml, 30 position
010-501-421 DigiPREP 240 MS, 50 ml, 48 position, 230V, Global
ACCESSORIES 15 ml
Catalogue Number Description
010-515-115 DigiPROBE, for use with DigiTUBEs (6" / 15 cm), 15 ml
010-515-036 DigiPROBE Holder, for 15 ml tubes
010-515-030 Foam Storage Rack 15 ml (pk/5)
010-515-060 Screw Cap Blue for 15 ml (pk/540)
010-515-172 Screw Cap Clear for 15 ml (pk/540)
010-515-261 DigiTUBE, 15 ml, with RackLock (pk1620)
010-515-262 DigiTUBE, 15 ml, with RackLock / No Caps (pk/1620)
010-515-263 DigiTUBE, 15 ml, with no RackLock (pk1620)
010-515-264 DigiTUBE, 15 ml, with no RackLock , No Caps (pk/1620)
010-515-023 Rack for DigiPREP Jr, 15 ml
010-515-027 Rack for DigiPREP MS, 15 ml
010-515-010 56-position rack, for DigiPREP LS, 15 ml

12 DigiPREP Digestion Blocks
Version 16.0
ACCESSORIES 100 ml
Catalogue Number Description
010-501-115 DigiPROBE, for use with DigiTUBEs (6" / 15 cm), 100 ml
010-501-010 DigiPROBE Holder, for 100 ml tubes
010-501-019 DigiPROBE watch glasses (25)
010-501-020 DigiSET Probe Holder
010-501-028 Foam Storage Rack 100 ml (pk/5)
010-501-060 Caps, Blue for 100 ml DigiTUBEs (pk/100)
010-501-172 Caps, Clear for 100 ml DigiTUBEs (pk/100)
010-501-150 Caps, Red for 100 ml DigiTUBEs (pk/100)
010-501-130 Caps, Yellow for 100 ml DigiTUBEs (pk/100)
010-501-140 Caps, Orange for 100 ml DigiTUBEs (pk/100)
010-501-081 Disposable Watch Glass, 100 ml (p500)
010-501-234 DigiFILTER manifold, 4 position, 100 ml
010-501-238 DigiFILTER manifold, 12 position, 100 ml
010-501-261 DigiTUBE, 100 ml, with RackLock (pk/300)
010-501-262 DigiTUBE, 100 ml, with RackLock/No Caps (pk/300)
010-501-263 DigiTUBE, 100 ml, with no RackLock (pk/300)
010-501-264 DigiTUBE, 100 ml, with no RackLock, No Caps (pk/300)
010-501-510 12-position rack for DigiPREP Jr, 100 ml
010-501-530 15-position rack for DigiPREP MS, 100 ml
010-501-550 15-position rack for DigiPREP LS, 100 ml

13
DigiPREP Digestion Blocks
Version 16.0
DigiPREP 240 Jr, MS
START UP KITS
Includes Quantity
DigiPREP 240 Jr.
Quantity
DigiPREP 240 MS
50 ml
010-505-466
100 ml
010-501-415
50 ml
010-500-467
100 ml
010-501-435
RackLock DigiTUBEs 500 200 500 200
Disposable Watch
Glasses 1000 500 1000 1000
24 Position RackLock
Rack 1222
Foam Storage Racks 5 5 5 5
DigiPREP 240 MS
TEFLON®INSERTS
Description Positions # Catalog
Insert, 60 ml, Savillex 8 010-500-422
Insert, 120 ml, Savillex 8 010-500-424
Insert, 50 ml for Teflon®DigiTUBEs 24 010-500-426
Insert, 100 ml for Teflon®DigiTUBEs 15 010-500-428
Insert for 22 mm Teflon®Vessels 54 010-500-430

14 DigiPREP Digestion Blocks
Version 16.0
6
4
2
3
1
7
5
1- EX-
2- M-
3- Ex+ 4- Ground
5- M+
6- L1
7- L2
31 5 246 7
Block 7 pin(male) connector
ELECTRICAL SCHEMATIC
Notes: *LS Heater 230 VAC 50/60 HZ 2655W ** No voltage selector switch for LS models *** DigiPROBE Dongle is used only when no DigiPROBE is connected **** No voltage selector switch for DigiPREP Jr. Model Serial #'s JRB05xxxx130 - JRB05xxxx179
DigiPREP Jr, MS, LS, HP
Notes: *Réchauffeur LS 230 VAC 50/60 HZ 2655W ** Pas de sélecteur de voltage pour modèle LS *** Clé DigiPROBE est utilisé seulement lorsqu'il y a aucun DigiPROBE connecté
RTD Interne
Connecteur Bloc á 7 broches (male)
Contrôleur

15
DigiPREP Digestion Blocks
Version 16.0
DigiPREP 240

16 DigiPREP Digestion Blocks
Version 16.0
NOTES
