Steinertractor Atractor Configuration guide

The Atractor is designed to increase
the life of your John Deere® hydraulics.
Small particles of metal that are not
caught by the uid screen can damage
moving parts. The Atractor, which is
placed inside of the screen, picks up
those small particles of metal reducing
the potential for damage.
Easy to install. Just insert the Atractor into
the transmission reservoir cross screen.
Remove metal particles from the
Atractor when you replace the uid.
Thank you for purchasing the Atractor.

Locate cross-screen (check operators manual for location or ask your local dealer).
Drain hydraulic oil. Discard if contaminated. Save in clean container if usable.
For tractors with Suction Pipe (Reference Figure 1)
1. Remove suction pipe.
2. Pull out cross screen (Use long magnet to “sh” out metal lings along load control shaft).
3. Clean or replace cross-screen.
4. Insert Atractor opposite the suction side of screen with washer end away from suction.
5. Install Snap-Ring into screen next to washer end of Atractor.
6. Re-install Atractor / Cross screen assembly, washer end rst, into transmission housing.
7. Ensure Atractor / Cross screen assembly engages inner screen support in housing.
8. Re-install suction pipe.
For tractors with Cross Screen Plug (Reference Figure 2)
1. Remove plug by tapping with hammer to loosen.
2. Pull out cross screen (Use long magnet to “sh” for metal lings along load control shaft).
3. Clean or replace cross screen.
4. If tractor has metal cross screen, install snap ring into metal cross screen tube ush with screen.
If tractor has nylon cross section, discard snap ring.
5. Insert Atractor through snap ring until washer end is ush with snap ring.
6. Install Atractor / Cross screen assembly, washer end towards plug.
7. Ensure Atractor / Cross screen assembly engages inner screen support in housing.
8. Reinstall plug.
Rell hydraulic oil.
Easy to Install Instructions
Note: Flow of oil must not go through washer end of Atractor
Figure 1
Figure 2
