stellar labs 17000 User manual

Model 17000
Articulating Crane
Owner’s Manual
Stellar Industries, Inc.
190 State Street
PO Box 169
Garner, IA 50438
800-321-3741
Fax: [phone]
www.stellarindustries.com
Subject to Change without Notication.
© 2017 Stellar Industries, Inc.
Rev 1
PN 90306
Installation • Assembly Drawings • Parts
Notice: A copy of this manual must remain with the equipment at all times.
For a printable download copy, please visit: www.stellarindustries.com

Page ii | Stellar®17000 Articulating Crane Owner’s Manual
Model 17000 Manual Revisions
Date of Revsion Section Revised Description of Revision
MODELNO.SERIAL NO.
DATE
MADE IN THE U.S.A. BY STELLAR INDUSTRIES, INC.
PNC5942
®
PATENTINFORMATION
http://www.stellarindustries.com/ip
MODEL NO.SERIAL NO.
DATE
MADE IN THE U.S.A. BY STELLAR INDUSTRIES, INC.
PN C5942
®
PATENT INFORMATION
http://www.stellarindustries.com/ip
Serial Tag
Location

Stellar®17000 Articulating Crane Owner’s Manual | Page iii
Table of Contents
Introduction ........................................................................................ iv
Chapter 1 - Specications.....................................................................1
Model 17000 Specications ...............................................................1
Capacity Chart - Decal PN 54620 ....................................................2
Chapter 2 - Installation ..........................................................................3
General Installation .............................................................................3
Installer Notice ...................................................................................3
Torque Data Chart ............................................................................4
Installation Overview ........................................................................5
Mounting Kit Drawing .......................................................................5
Hydraulic Installation...........................................................................6
Hydraulic Pressure Settings .................................................................7
Face Seal/O-Ring Size Chart .............................................................7
Hydraulic Kit - PN 71357 ......................................................................8
Control Kit (458 MHz) - PN 71330 .....................................................10
Control Kit (434 MHz) - PN 74108 .....................................................11
Control Kit (419 MHz) - PN 74110 .....................................................12
Decal Placement - PN 54621 ...........................................................13
Chapter 3 - Assembly Drawings .........................................................15
Base Assembly - PN 54372 ................................................................15
Bearing Assembly - PN 53500 ...........................................................16
Valve Bank - PN 53514 ......................................................................17
Stabilizer Valve Bank - PN 55400 ......................................................18
Mast Assembly - PN 71358 ................................................................19
Gearbox - PN 53499 ..........................................................................20
Main Cylinder Assembly - PN 54310 ................................................21
Main Boom Assembly - PN 71119 ....................................................22
Outer Cylinder Assembly - PN 54313 ...............................................23
Extension Boom Assembly - PN 71261 .............................................24
Extension Cylinder Assembly - PN 53515 .........................................25
Stabilizer Assembly - PN 54414 .........................................................26
Stabilizer Cylinder Assembly - PN 54415 ..........................................27
Reservoir Assembly - PN 85936 .........................................................28
Optional 15 Ton Hook Kit - PN 54768 ...............................................29
Radio Transmitter - PN 41922 ............................................................30

Page iv | Stellar®17000 Articulating Crane Owner’s Manual
Introduction
A copy of this manual is provided with every crane and can be found in the hard plastic
manual case that is installed on the chassis. A copy of this manual shall remain with the
crane at all times.
Throughout the manual, three signal words will be used to bring attention to important
items:
A NOTICE signal word indicates a practice not related to physical injury.
A WARNING signal word indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
A DANGER signal word indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
Information contained within this manual does not cover operation, maintenance, or
troubleshooting. Please refer to the Large OTR Crane Manual for details on these items.
This manual is not binding. Stellar Industries, Inc. reserves the right to change, at any
time, any or all of the items, components, and parts deemed necessary for product
improvement or commercial/production purposes. This right is kept with no requirement or
obligation for immediate mandatory updating of this manual.
In closing:
If more information is required or technical assistance is needed, or if you feel that any
part of this manual is unclear or incorrect, please contact the Stellar Customer Service
Department by phone at 800-321-3741 or email at [email protected].
WARNING
NOTICE
DANGER
For Technical Questions, Information, Parts, or Warranty, Call Toll-Free at
800-321-3741
Hours: Monday - Friday, 8:00 a.m. - 5:00 p.m. CST
Or email at the following addresses:
Technical Questions, and Information [email protected]
Order Parts [email protected]
Warranty Information [email protected]

Stellar®17000 Articulating Crane Owner’s Manual | Page 1
Crane Rating: 170,000 ft-lbs ( 23.5 ton meters)
Standard Boom Length: 13’6” (4.11 m) from CL of Crane
Boom Extension: Hydraulic 41” (104.14 cm)
Maximum Horizontal Reach: 16’11” (5.15 m) from CL of Crane
Maximum Vertical Lift: 25’8” (7.82 m)
(From Truck Frame)
Cylinder Specications: Inner Lift Cylinder: 7” (17.78 cm) bore with integral
pilot operated counterbalance valves
Outer Lift Cylinder: 5.5” (13.97 cm) bore with integral
pilot operated counterbalance valves
Extension Cylinder: 4” (10.16 cm) bore with integral
pilot operated counterbalance valves
Rotation: 315 degree power
(planetary gear with pinion)
Lifting Capacities: 17,000 lbs @ 10’ (7,710 kg @ 3.05 m)
(From CL of Truck) 10,050 lbs @ 16’ 11” (4555 kg @ 5.15 m)
Power Supply Required: PTO & Pump - 20 gpm @ 4,400 psi
(76 lpm @ 304 bar)
Controls: Fully Proportional Paddle Controls for all functions.
Stowed Height: 102” (259.08 cm)
(Above Truck Frame)
Mounting Space Required: 60” (152.4 cm)
Chassis RBM (Recommended): 2,040,000 in-lb
Approximate Shipping Weight: 9,500 lbs (4,310 kg)
Chapter 1 - Specications
Model 17000 Specications

Page 2 | Stellar®17000 Articulating Crane Owner’s Manual
10’
3.05m
56.00”
142.2 cm
(based on 41”
truck frame)
16’11”
5.16 m
13’6”
4.11m
10’
3.05m
16’11”
5.16 m
13’6”
4.11m
13’7”
4.14m
25’8”
7.82m
23’0”
7.01m
CAPACITY
CHART
17,000 lbs
7710 kg
12,600 lbs
5715 kg
10,050 lbs
4550 kg
0’
0m
CRANE
GROUND 0’
0m
54620 - Rev A
190 STATE STREET GARNER, IA 50438
PHONE: [phone] FAX: [phone]
17000
Do not exceed equipment load charts and ratings.
Failure to follow equipment load charts and ratings
Overload Hazard
WARNING
can result in death or serious injury.
Capacity Chart - Decal PN 54620

Stellar®17000 Articulating Crane Owner’s Manual | Page 3
Installer Notice
According to Federal Law (49 cfr part 571), each nal-stage manufacturer shall complete
the vehicle in such a manner that it conforms to the standards in effect on the date of
manufacture of the incomplete vehicle, the date of nal completion, or a date between
those two dates. This requirement shall, however, be superseded by any conicting
provisions of a standard that applies by its terms to vehicles manufactured in two or more
stages.
Therefore, the installer of Stellar®Cranes and Bodies is considered one of the manufacturers
of the vehicle. As such a manufacturer, the installer is responsible for compliance with all
applicable federal and state regulations. They are required to certify that the vehicle is in
compliance with the Federal Motor Vehicle Safety Standards and other regulations issued
under the National Trafc and Motor Vehicle Safety Act.
Please reference the Code of Federal Regulations, title 49 - Transportation, Volume 5 (400-
999), for further information, or visit http://www.gpoaccess.gov/nara/index.html for the full
text of Code of Federal Regulations.
Chapter 2 - Installation
General Installation
This chapter is designed to serve as a general guide for the installation of a Stellar 17000
Crane on a Stellar Service Body. Each installation is considered unique so certain portions
of this chapter may or may not apply to your direct application. If a question should arise
during the installation process, please contact Stellar Customer Service at [phone].
This crane is designed for use with a Stellar Service Body installed on a vehicle that meets
the minimum chassis requirements of the crane. It is the installer’s responsibility to assure
that the crane is mounted on a platform that will support the maximum crane rating of this
crane.
Do not install this crane on a body not capable of handling the loads
imposed on it. Failure to do so may result in serious injury or death.
When installing welder units to the service bodies, it is highly
recommended that a surge protector is installed on the chassis batteries to protect the
crane radio receiver, wiring and other electronic devices from an unexpected electrical
spike or surge. Failure to do so could result in extensive damage to the service body and
crane electrical circuit.
WARNING
NOTICE

Page 4 | Stellar®17000 Articulating Crane Owner’s Manual
When using the torque data in the
chart, the following rules should be
observed:
• Bolt manufacturer’s particular
specications should be consulted
when provided.
• Flat washers of equal strength
must be used.
• All torque measurements are
given in foot-pounds. To convert
to inch-pounds, multiply by 12.
• Torque values specied are for
bolts with residual oils or no special
lubricants applied.
• Torque values for socket-head
capscrews are the same as for
Grade 8 capscrews.
• Do not use these values if a different torque value or tightening
procedure is given for a specic application. Torque values listed are for general use
only. Check tightness of fasteners periodically.
• Shear bolts are designed to fail under predetermined loads. Always replace shear bolts
with identical grade.
• Fasteners should be replaced with the same or higher grade. If higher grade fasteners
are used, these should only be tightened to the strength of the original.
• Tighten plastic insert or crimped steel-type lock nuts to approximately 110 percent of the
dry torque values shown in the chart below, applied to the nut, not to the bolt head.
Tighten toothed or serrated-type lock nuts to the full torque value. Note: “Lubricated”
means coated with a lubricant such as engine oil, or fasteners with phosphate and oil
coatings. “Dry” means plain or zinc plated without lubrication. Tighten lubricated bolts
to approximately 80% of dry bolts.
Size Bolt DIA Plain Plated Plain Plated Plated
(DIA-TPI) (Inches) (Ft-Lb) (Ft-Lb) (Ft-Lb) (Ft-Lb) (Ft-Lb)
5/16-18 0.3125 17 13 25 18 22
3/8-16 0.3750 31 23 44 33 39
7/16-14 0.4375 49 37 70 52 63
1/2-13 0.5000 75 57 105 80 96
9/16-12 0.5625 110 82 155 115 139
5/8-11 0.6250 150 115 220 160 192
3/4-10 0.7500 265 200 375 280 340
7/8-9 0.8750 395 295 605 455 549
1-8 1.000 590 445 910 680 823
1 1/8-7 1.1250 795 595 1290 965 1167
1 1/4-7 1.2500 1120 840 1815 1360 1646
1 3/8-6 1.3750 1470 1100 2380 1780 2158
1 1/2-6 1.500 1950 1460 3160 2370 2865
GRADE 5 GRADE 8 GRADE 9
Torque Data Chart
NOTICE

Stellar®17000 Articulating Crane Owner’s Manual | Page 5
1. Relocate any obstructions on the frame that will be in the way of mounting the crane.
2. Measure the inside of the frame rails and cut the frame support to this length. Ensure that the frame
supports have a tight t between the frame rails.
3. Set the crane on the chassis and allow a minimum of 3” from the cab.
4. Make certain that the frame supports are installed square, cut to length in such a way as to support the
frame anges with the tie down rods are torqued.
5. Install the crane tie downs. Start at one corner and tighten both tie downs to 200 ft-lbs. Move to the
diagonal set and tighten to 200 ft-lbs. Tighten the remaining 2 corners. Continue this pattern at 200 ft-lb
increments until 500-550 ft-lbs is achieved. Be sure the mounting block stays perpendicular to the frame rail
as they are tightened down.
6. Connect the pressure and return lines per the hydraulic kit.
7. Connect the electrical power and ground wires. Ground preferrably connected to battery.
8. With the crane and outriggers in the stored position, check the reservoir for oil and ll if necessary.
9. Operate the crane for several cycles. Fully cycle the cylinder in both directions (blow past relief) to
remove any air from the system.
Installation Overview
Mounting Kit Drawing
PN 54420
7
5
5
4
1
2
3
6
7
ITEM PART DESCRIPTION QTY.
18900TIE DOWN ROD 15000 8
28202PC FRAME SUPPORT 15000 CRANE4
38054PCMTG BLOCK 150004
411677PCPLATE MOUNTING 23000 4
58978 NUT 1.25-7 HHGR8 16
68834NUT 1.25-7 HHGR8 TOP LOCKING8
79180WASHER 1.25 SAE FLAT YELLOW GR816

Page 6 | Stellar®17000 Articulating Crane Owner’s Manual
Hydraulic Installation
Never modify or alter any of the equipment, whether mechanical, electrical, or hydraulic,
without Stellar Industries’ approval.
Do not touch or grab any hoses that could be under pressure. Release
system pressure before attempting to make adjustments or repairs.
Do not attempt service or repair when PTO is engaged.
Disassemble and assemble hydraulic components on a clean surface.
Clean all metal parts in a nonammable cleaning uid. Then lubricate all components to
aid in assembly.
Hydraulic uid expands when heated. This raises the pressure in an
unventilated tank. Release the tank pressure before removing the cap completely. Failure
to do so may cause the oil to shoot out of the tank very rapidly and cause severe burns.
Do not rely on the hydraulic uid to support the boom or crane. If
hydraulic uid escapes, the boom or crane can fall immediately. Make sure the ground or
blocking is supporting the boom before performing any maintenance or repair.
Contaminants in a hydraulic system affect operation and will result in
serious damage to the system components. Dirty hydraulic systems are a major cause of
component failures.
If evidence of foreign particles is found in the hydraulic system, ush the system.
When installing metal hydraulic tubes, tighten all ttings nger tight. Then , in order, tighten
the ttings at the rigid end, the adjustable end, and the mounting brackets. After tubes
are mounted, install the hoses. Connect both ends of the hose with all ttings nger tight.
Position the hose so it does not rub the machine or another hose and has a minimum of
bending and twisting. Tighten ttings in both couplings.
Due to manufacturing methods, there is a natural curvature to a hydralic hose. The hose
should be installed so any bend is with this curvature.
WARNING
WARNING
WARNING
NOTICE

Stellar®17000 Articulating Crane Owner’s Manual | Page 7
Hydraulic Pressure Settings
Face Seal (A)
Stellar®PN
Hose
Size
Fitting
Size Stellar®PN
O-ring Boss (B)
#4 C2027 D1245
#6 C2028 D1246
#8 C2029 D1247
#10 32223 D1248
#12 D1244 D1249
#161”
3/4”
5/8”
1/2”
3/8”
1/4”
D1250
B
A
Face Seal/O-Ring Size Chart
Function Flow Extend Retract
Inner 10.6 4400 2200
Outer 10.6 4400 2200
Extension 10.6 4400 4400
Rotation 10.6 2200 2200
TM Rot 6.6 2200 2200
TM Pad Rot 6.6 2500 2500
TM Clamp 6.6 4200 4200
Main Relief 4600 PSI
Pressure (PSI)

Page 8 | Stellar®17000 Articulating Crane Owner’s Manual
Hydraulic Kit - PN 71357
PN 71357
22
21,22
26,24,
17
19 19
2 2
2
232 2
19 19 19 19 19
23222
28
28
21,2221,22 21,2221,2221,2221,22
37
37
37
37
ABCD
HGFE
IJ
A-TM PAD ROT CCW-(04-BULKHEAD-10)
B-EXT EXTEND-(04-BULKHEAD-11)
C-EXT RETRACT-(04-BULKHEAD-11)
D-TM ROT CCW-(04-BULKHEAD-10)
E-TM PAD ROT CW-(04-BULKHEAD-10)
F-TM CLAMP CLOSE-(04-BULKHEAD-13)
G-TM CLAMP OPEN-(04-BULKHEAD-13)
H-TM ROT CW-(04-BULKHEAD-10)
I-OUTER RETRACT-(04-BULKHEAD-12)
J-OUTER EXTEND-(04-BULKHEAD-12)
(LOCATION)-(FUNCTION)-(HOSE FROM MAST PORT TUBE-BULKHEAD-HOSE TO FUNCTION)
DHCGJIFBEA
DHCGJIFBEA
35
2
35
2
35
2
35
2
35
2
35
2
35
2
35
2
35
2
35
2
4444 4 4 4 444
02
02
06
06
12
12
13
13
10
10
10
10
11
11
05
05
03
03

Stellar®17000 Articulating Crane Owner’s Manual | Page 9
Hydraulic Kit - PN 71357 Continued...
PN 71357

Page 10 | Stellar®17000 Articulating Crane Owner’s Manual
PN 71330
Control Kit (458 MHz) - PN 71330

Stellar®17000 Articulating Crane Owner’s Manual | Page 11
Control Kit (434 MHz) - PN 74108

Page 12 | Stellar®17000 Articulating Crane Owner’s Manual
Control Kit (419 MHz) - PN 74110

Stellar®17000 Articulating Crane Owner’s Manual | Page 13
Decal Placement - PN 54621
NOTICE
15172
Thiscranehas been designed and
manufacturedtoASME/ANSI B30.22
and/orB30.5specifications.
Up Up
13036
Outrigger
CS
Outrigger
SS
Down Down
WARNING
CrushHazard
Keepclearof stabilizer legs during
operation.
Failuretokeep clear of moving
stabilizerlegscan result in death or
seriousinjury.
C4795-RevB
NOTICE
16973
UseonlyStellar
®
approvedlifting
devicesand/orattachements.
NOTICE
9188-RevC
Damagemayoccur if worm gear or
bearingsrundry.Refer to the equipment
manualforproper lubrication instructions.
ProudlyDesigned
andManufactured
intheUSAby
OFF
ON
Flood
MANUAL
REMOTE
OFF
Light
Speed Control
CIRCUIT
OFF
ON
ON
OFF
TOOL
TOOLCIRCUITMUST BE OFF
TOOPERATEAUX OUTRIGGERS
PN16620
Up
Down
INNER
Out
Up
In
Down
EXTENSIONROTATION Tireman
Rotation
Tireman
PadSpin
OUTER
Close
Open
Tireman
Clamp
USEMANUALCONTROLS ONLY IN CASE OF RADIO CONTROL FAILURE. ACTIVATEWITHMANUAL OVERRIDE SWITCH.
PN54771
INNERCYL
BASE
INNERCYL
ROD
INNER/MAST
PIN
OUTERCYL
BASE
OUTERCYL
ROD
INNER/OUTER
PIN EXTCYL GEAR BEARING
41918
WARNING
CrushHazard
Keepclearof stabilizer legs during
operation.
Failuretokeep clear of moving
stabilizerlegscan result in death or
seriousinjury.
C4795-RevB
3.05m
56.00”
142.2cm
(basedon41”
truckframe)
5.16m4.11m
3.05m 5.16m4.11m
4.14m
CAPACITY
CHART
0m
CRANE
GROUND
0m
54620-RevA
17000
®
Donotexceedequipment load charts and ratings.
Failuretofollowequipment load charts and ratings
WARNING
canresultin death or serious injury.
Donothandle tires filled with ballast.
Donotdrag the tire. the unit is designed
toliftand position.
Donotclamp an uninflated tire and then inflate.Donotuse the outer cylinder to push objects.
Donotuse the unit for any jacking, pulling, or
dragginginvolvingan object or another vehicle.
Donotuse one arm to break beads.
Donotuse one arm to sling a load.
54781-RevB
Readandunderstand all manuals and safety
signsbeforeoperating or servicing this
equipment.
UntrainedOperatorHazard
MisuseHazard
MisuseHazardMisuseHazard
MisuseHazardMisuseHazard
MisuseHazardMisuseHazard
Keepnon-essentialpersons clear of crane
duringoperation.
CrushHazard
DANGER
Deathorserious injury will result from
touchingtetheredremote if crane, load, or
vehiclebecomeselectrically charged.
Maintainsafeclearance from high voltage
powersources.
ElectrocutionHazardElectrocutionHazard
WARNING
Deathorserious injury will result from
inadequateclearanceif crane, load, or vehicle
becomeselectricallycharged.
•Maintainsafe clearance from high voltage
power sources.
•Neverapproach vehicle or load if equipment
is near a high voltage power source.
Keepclearof crane during operation.
Failuretokeep clear of moving crane can
resultindeath or serious injury.
CrushHazard
FORSERVICEONTHIS EQUIPMENT
CONTACT:
STELLARINDUSTRIES,INC.
190STATESTREET,GARNER, IA 50438
641-923-3741
800-321-3741
4214
10
11
12
13
14
15
16
17
18
01
03
02
04
07
05
06
02
TIRE SERVICE DECAL KIT
FOR
17000 - PN 54621
DECALS IN BOLD ARE NOT SHOWN - PLACE ON BODY
Serial
Tag
Location
General Tire Crane Decal Kit - PN 85362
Item No. PN Description Location QTY
01 15172 DECAL ASME/ANSI B30.22/B30.5 Crane Base 1
02 C4795 DECAL DANGER FOOT Stabilizers - CS & SS 2
03 73929 DECAL RADIO PRESSURE WASHER NOTICE Near Remote Receiver 1
04 16973 DECAL USE STELLAR APPROVED ATTACHMT Main Boom - Both Sides 2
05 9188 DECAL WORM GEAR LUBRICATION Crane Base 1
06 35234 MADE IN THE USA - STELLAR Main Boom - Both Sides 2
07 4214 DECAL CONTACT STELLAR Crane Base 1
08 C4545 DECAL DANGER ELECTROCUTION Four Corners of the Body 4
09 C5910 DECAL STELLAR LOGO 4.00X9.50 PRE-MASKED Body - Optional 3
17000 Decal Kit - PN 85369
Item No. PN Description Location QTY
10 54595 DECAL 17000 ID PRE-MASKED Main Boom - Both Sides 2
11 54620 DECAL CAPACITY 17000 Stabilizers CS & SS 2
12 16620 DECAL SWITCH PLATE 28000 Crane Control Station 1
13 54771 DECAL VB CONTROL 17000 Crane Control Station 1
14 41918 DECAL 9000 GREASE KIT Crane Base - CS 1
15 47404 DECAL COUPLERS 23000 Main Boom 1
16 13036 DECAL CRANE OUTRIGGER Crane Base 1
17 54781 DECAL WARNING PLACARD Stabilizers - CS & SS 2
18 54589 DECAL STELLAR LOGO 8X22.25 PRE-MASKED Main Boom - Both Sides 2

Page 14 | Stellar®17000 Articulating Crane Owner’s Manual
This page intentionally left blank.

Stellar®17000 Articulating Crane Owner’s Manual | Page 15
Base Assembly - PN 54372
.YTQNOITPIRCSEDTRAPMETI
100071ESAB063451
253514 VB 7 SECT DANFOSS PVG32 17000 1
3 55400 VB 2-SECT VDM8-1-1-YE-WCHA1
100071BVDRAUG453454
100032CINAPRAB280145
100071REVOCETALP653456
749327 PLATE SWITCH MTG 15000 1
878432 FILTER HIGH PRESSURE 1.06-12SAE 5000PSI
10 MICRON 1
978433 CLAMP HIGH PRESSURE FILTER 3.00 1
10 22921 E-STOP PANIC BAR 280001
11 54410 PLATE GREASE LINE MTG 17000 1
12 53500 BEARING TURNTABLE 170001
13 17962 CAP SCR 0.88-9X4.50 HHGR9 24
14 18041 WASHER 0.88 SAE FLAT YELLOW GR924
21TALFSSU52.0REHSAW043051
16 0479 CAP SCR 0.25-20X0.75 HHGR52
52TALFSSU13.0REHSAW343071
18 0420 CAP SCR 0.31-18X0.75 HHGR5 6
19 0485 CAP SCR 0.31-18X1.25 HHGR5 4
20 22183 SCREW #8-32X0.75 BTNHD SS 2
2TALFEAS8#REHSAW092512
22 C0927CAP SCR 0.31-18X2.25 HHGR5 2
23 0342 NUT 0.31-18 HHGR5 NYLOC9
24 C0930CAP SCR 0.31-18X3.00 HHGR5 3
2SSCOLYNHH23-8#TUN6812252
26 C0922CAP SCR 0.31-18X1.00 HHGR5 4
27 0480 CAP SCR 0.25-20X1.00 HHGR5 2
28 47425 CAP SCR 6MMX20MM HH 8.8(GR5) 4
29 0333 NUT 0.25-20 HHGR5 NYLOC2
30 82654 STRAIN RELIEF .50 NPT .24-.47 CABLE 90
DEG1
31 D0045 BACKUP ALARM .97 DECIBAL 1
17
12
14
13
18
WHEN MOUNTING
WITH THIS HOLE
11
1
617
18
28
27
15
31
16
15
7
24
3
223
17
20
25
21
10
89
15
19
23
4
17
26
22
17
17
23
5
29
30
17
GREASE ZERK
MUST LINE UP
NOTES:
FILTER ELEMENT 47860
BACK UP ALARM SHOWN
FOR REFERENCE
PN 54372
Chapter 3 - Assembly Drawings

Page 16 | Stellar®17000 Articulating Crane Owner’s Manual
Bearing Assembly - PN 53500
USE MOLY GREASE 936SF HEAVY, STELLAR PN 4460
ON BEARING GEAR TEETH
USE EP2 LITHIUM COMPLEX GREASE, STELLAR PN 78090
ON BEARING RACE
GREASE MAIN BEARING RACE THROUGH
REMOTELY MOUNTED GREASE ZERK
