stellar labs Bluetooth Diet Scale Installation guide

The Stellar Bluetooth Diet Scale accurately weighs weight,
milk and water volume.
Transferring this data to your mobile phone (with the free Modern Chef
app installed) via bluetooth allows you to keep track of your daily intake of
weighedcalories,fats,cholesterol,carbohydrates,bre,proteinandsodium.
Please read these instructions carefully to set up your scale.
BLUETOOTH
DIET
SCALE
BLUETOOTH
DIET SCALE
USER GUIDE AND CARE INSTRUCTIONS

Battery Installation
■The Stellar Bluetooth Diet Scale takes
2 x 1.5V AAA batteries.
■Remove the battery cover as shown and
install batteries according to the polarity
markings.
■Please remove the batteries before
long term storage.
LCD Display
Zero Indicator
Volume Unit
Weight Unit
Weight/Milk Volume/
Water Volume Mode
Tare Indicator
Weight
Weight Unit
Weight
Mode Milk Volume Mode Water Volume Mode

Before use
1. Install batteries as detailed overleaf.
2. Placeonasolid,atsurface.
3. Press the scale platform to turn the scale on.
4. Wait until the LCD display shows “0”.
Mode Conversion
Choose between Weight, Milk Volume and Water Volume as shown below
Weight
Mode
Milk Volume
Mode
Water Volume
Mode
Hold down Press
3 Seconds
Press
Changing between Metric and Imperial measurements
■To change between Metric (kg, g) and Imperial measurements
(lb:oz) simply press the Unit button on the base of the scale.
UNIT

Weight mode
1. Ensure the LCD display shows shows “0” (if using a bowl place on the
platformrstandpressZERO:MODEtoresettheLCDdisplayto“0”).
2. Place the object to be weighed either directly on the platform or into the
bowl.
3. The weight will be shown on the LCD display.
Milk/Water Volume mode
1. Place a bowl or other suitable container on the scale platform and press
ZERO:MODEtoresettheLCDdisplayto“0”.
2. Pour your liquid into the bowl/container.
3. The volume will be shown on the LCD display.
Add weigh/tare function
To weigh consecutively without removing the previous item from the scale
presstheZERO:MODEbuttontoresettheLCDto‘0’beforeaddingthe
next item.
Note: The tare symbol will only appear if the total load is greater than 200g.

Auto shut o (power saving mode)
Autoshutooccursisthedisplayshows‘0’orthesameweightreadingformore
than a couple of minutes.
Error Codes
Err Overloadwarning Scale is loaded past the maximum capacity
(5kg) - Remove items to avoid damaging
the scale.
Lo Low battery warning Battery power is low, please replace the
batteries.
Cleaning and care
■Clean the scale with a damp cloth or taint free wipe.
■Do not immerse the scale in water.
■Do not use harsh chemical/abrasive cleaning agents.
■Immediately clean plastic parts after contact with fats, spices, vinegar and
stronglyavoured/colouredfoods.
■Avoid contact with acidic citrus juice.
■Do not knock, drop or drop any item onto the scale.
■Store in a cool dry place when not in use.
■For domestic use only.

Using the Modern Chef App
Download the app, available from both the Apple App Store and
Google Play, by scanning the QR code to the right or searching for
‘ModernChef”.
Setting up the app
■Make sure bluetooth is
turned on in your phone
settings before use.
1. Turn the scale on.
2. OpentheModernChef
app.
3. Select the scale from the
scale menu to link it with
the app and rename it if
desired.
4. Setupyouruserprole
by entering the details
requested and pressing
the tick button.
Weighing and calculating nutrition
1. Ensure the LCD display shows shows “0”
(ifusingabowlplaceontheplatformrst
andpressZERO:MODEtoresettheLCD
display to “0”.
2. Enter the food to be weighed into the
searcheldontheModernChefapp
home screen.
3. Placing the object to be weighed either
directly on the platform or into the bowl.
4. The weight will be shown on the LCD
display of the scale and nutritional values
displayed in the app.
5. To save to your history press the tick
button, then Save

Custom foods
If the food you wish to weigh is not already in the app database press the + symbol
in the top right of the search screen and enter the name and nutritional values per
100g to save to the database.
For further instructions see the settings section of the app.
Troubleshooting
If the application cannot get data from the scale
■Make sure bluetooth is turned on in your phone settings
■Conrmthescaleispoweredonandwithinrangeofyourdevice
■Replace scale batteries
■Restart the Modern Chef Application
■Reboot your device
If Bluetooth connection fails
■Conrmthatonlyondeviceisconnectedtothescales
■Conrmyourdevice’sBluetoothversionisV4.0orabove
■ConrmyourdeviceiseitherAndroid4.3orAppleiPhone4Sorlater
withiOS7.0orlaterinstalled

FOR DOMESTIC USE ONLY
■The Stellar 2 Year Domestic Electrical
Guarantee covers the product to be free
of defects in materials and workmanship
foraperiodofTWOYEARSfromthe
date of original retail purchase.
■During this period, Stellar will, at their
option, repair or replace defective parts
of the product, or replace the product,
providing the Use Care and Safety Advice
have been followed.
■The Guarantee does not cover damage,
defect or failure caused by or resulting
from accidents, external damage,
alteration,modication,abuse,misuseor
misapplication.
■The Guarantee does not cover any
damage caused by taking the appliance
apart yourself, or attempting to repair the
appliance yourself.
■THE PRODUCT IS INTENDED FOR
DOMESTIC USE ONLY.
■Please keep your Purchase Receipt and
contact us directly if you encounter any
problems with your product.
STELLAR 2 Year Domestic Electrical Guarantee
YEAR
GUARANTEE
DOMESTIC
ELECTRICAL
USE
STELLAR
HORWOOD SHALL
NOT BE LIABLE FOR
INCIDENTAL OR
CONSEQUENTIAL
DAMAGES
RESULTING FROM THE USE OF
THIS PRODUCT (INCLUDING
COLOUR FADING, SCRATCHES OR
ACCUMULATED DIRT) WITHOUT
FOLLOWING THE USE, CARE & SAFETY
INSTRUCTIONS.
Note: Due to the introduction of improvements
from time to time, the right is reserved to
supply products which dier slightly from those
illustrated and described in this publication.
ErrorsandOmissionsExcepted.
CUSTOMER SERVICES
Horwood, Avonmouth Way,
Bristol, BS11 9HX, Great Britain
www.stellarcookware.co.uk
[e-mail]
Tel:01179400000
