Sterling Plumbing C711FAS User manual

Kitchen Classics™
Tribute™
Single Control Kitchen Faucets
Models C711FS, C711FAS, C711FWS,
C711FCGS, C711FGS, C711FST
SPECIFICATIONS
7 ⁵⁄₈"6 ¹³⁄₁₆"5 ¹¹⁄₁₆"
10 ¹⁄₈"
9 ¹⁄₁₆"
8 ⁷⁄₈"
2 ¹⁄₄"
⁷⁄₁₆"
⁷⁄₈"
1¹⁄₈"
¹¹⁄₁₆"
¹¹⁄₁₆"
¹⁵⁄₁₆"
4"
10 ⁵⁄₁₆"
5 ³⁄₁₆"
4 ¹⁄₄"
2"
8"
8"
FEATURES
■Input
Min. - Max. / 20 - 80 psi
Max. Allowable 125 psi
■Flow Rate
2.2 gpm at 60 psi
■Connectors
1/2" IPS
■Valve Type
Ceramic washerless cartridge
■Standards and Ratings
Meets or exceeds the requirements
of the following standards: ASME
A112.18.1M, ANSI 117.1, ADA
"Americans with Disabilities Act"
■Warranty
Limited Lifetime
PRODUCT OVERVIEW
Single Control Kitchen
Styled lever handle
Compatible with 4 sink holes
(Minimum 1-1/8" dia. In-line, 4" centers)
C711FS — Chrome plated, IPS connectors,
with side spray, styled lever handle, single pak
C711FAS — Almond, IPS connectors, with
side spray, styled lever handle, single pak
C711FWS — White, IPS connectors, with
side spray, styled lever handle, single pak
C711FCGS — Chrome/Endurable™ Lifetime
polished brass accents, IPS connectors, with
side spray, styled lever handle, single pak
C711FGS — Endurable™ Lifetime polished
brass finish, IPS connectors, with side spray,
styled lever handle, single pak
C711FST — Chrome plated, IPS connectors,
with side spray, styled lever handle, trak pak
3.0
2.5
2.0
1.5
1.0
0.5
0.0 0.0 10 20 30 40 50 60 70 80
LINE PRESSURE P.S.I. GAUGE
FLOWRATE (GPM)
© 2001 Sterling Plumbing, 444 Highland Drive, Kohler, WI 53044 1-888-STERLING
Pub. No. 00072 01/02 www.sterlingplumbing.com Printed in U.S.A.
★Made in U.S.A.
¹³⁄₁₆"
2 ⁹⁄₁₆"1 ¹⁄₈"
3 ¹⁄₂"
4 ⁵⁄₈"
1 ⁵⁄₈"
Fixture dimensions are nominal and conform to tolerances established by ANSI Standards, Z124.1.
