steute KF 1PW-MED GP11 User manual

Product name: KF 1PW-MED GP11
Part-number: 1442726
Created on: 12.11.2021 Revision of data sheet: - D042057
Page
1 / 3
steute Technologies
GmbH & Co. KG
Brückenstraße 91
32584 Löhne, Germany
Phone [phone]
Fax [phone]
[e-mail]
www.steute.com
Specification
 Base plate in RAL 7035 Lightgrey with stainless steel bracket
 3 m shielded cable
 Weight: 1,1 kg
Technical Data
Applied standards
IEC 60601-1 (Basic Safety)
IEC 60529 (Degrees of protection)
Note: see CSA
certificate for corresponding revision level.
Existing certifications CSA
CCC
Base plate GD-Al alloy / RAL 7035 Light grey
Pedal shockproof thermoplastic, self-extinguishing / black
Pedal enclosure shockproof thermoplastic, self-extinguishing / black
Degree of protection IPX8 (1m / 35 Min.) according to DIN EN 60529
Contact element and material micro switche / silver-plated
Connection type 3 m shielded cable (3xAWG20 C UL/CSA RAL 7035)
Mechanical lifetime The expected operating life of the foot switch is limited to 10 years or 1,000,000 switching cycles of the
actuating units, whichever comes first.

Product name: KF 1PW-MED GP11
Part-number: 1442726
Created on: 12.11.2021 Revision of data sheet: - D042057
Page
2 / 3
steute Technologies
GmbH & Co. KG
Brückenstraße 91
32584 Löhne, Germany
Phone [phone]
Fax [phone]
[e-mail]
www.steute.com
Electrical Ratings
Switching voltage (UB): max. 25 V AC / 60 V DC
Switching current (IB): max. 1 A
Switching capacity (PB): max. 30 W
Environmental Conditions
Storage/Transport Operating
Temperature range -40 °C up to +70 °C -10 °C up to +60 °C
Relative humidity 10 % up to 100 % 10 % up to 100 %
Air pressure 500 hPa – 1120 hPa 800 hPa – 1060 hPa
Mounting/Wiring
Wire the foot switches according to the specified wire colours/terminal labelling. Contact symbols are shown for a not actuated switch.
Maintenance
Depending on the environmental/operating conditions we recommend routine maintenance as follows:
 Check enclosure and connecting cable for damage and destructive dirt
 Check functional elements and actuating elements for free operation
 For only manual cleaning, use just a cloth impregnated with water and a mild detergent.
 Do not use cleaning agents which may damage the plastic surfaces such as detergents, abrasive cleansers or solvent-based cleaners (such as
benzine, stain remover).
 During cleaning, avoid wiping with a cloth under the pedal, because this may cause the springs to move out of position.
Disposal
 Observe national, local and legal regulations concerning disposal.
 Recycle each material separately.

Product name: KF 1PW-MED GP11
Part-number: 1442726
Created on: 12.11.2021 Revision of data sheet: - D042057
Page
3 / 3
steute Technologies
GmbH & Co. KG
Brückenstraße 91
32584 Löhne, Germany
Phone [phone]
Fax [phone]
[e-mail]
www.steute.com
General notes
The foot switch as a component of a medical device can be evaluated only together in the overall system of the customer. Ther
efore the conformity
evaluation including the classification of the overall system according to the Medial Device Directive 93/42/EEC respectively EU Medical Device
Regulation 2017/745 must be carried out at the customer. In addition, validation can also only be carried out by the customer in the overall system.
Furthermore, the intended use and the basic functions are verifiable only in interaction with the overall system. As a result, the customer must involve
the footswitch in his risk management, his usability analysis, the verification of the electromagnetic compatibility and, if applicable, the verification of the
biocompatibility.
Safety instructions
Despite careful production and inspection as well as redundant design of important components, an entirely safe function cannot be guaranteed at all
times guaranteed (in case of malfunction, for example, a switch contact can turn off incorrectly, or a spring may break).
A functional test must be performed before every operation.
Risk of injury due to incorrect handling!
 The plug connections must not be subjected to mechanical loads!
 Switch off terminal before cleaning or maintenance work!
 Test functions when device is switched back on!
 Moving actuating components (e.g. carrying handle) can be a crushing hazard!
 Tripping hazard!
If components with reed contacts or hall sensors are used, strong magnetic fields can result in unwanted influences to the system. Additionally,
magnetically conducting materials are to be kept away from the direct foot switch area!
The electrical connection may only be carried out by authorised personnel.
Components, esp
e
cially pedals or other actuating elements, may not be
dissembled
or dismembered under any circumstances! If this happens the
products need to be send back immediately.
Errors and omissions excepted.
