Argos Home Multicoloured Sideboard 453/4785 User manual

Assembly Instructions - Please keep for future reference
-
453/4785
Dimensions
Width - 120cm
Depth - 42cm
Height - 74cm
Important
Version 1 Date: 22/09/15
Multicoloured Sideboard
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
- Please read these instructions fully before starting assembly

1
Safety and Care Advice
Important –Please read these instructions fully before startingassembly
Note: if required the next
page can be cut out and used
as reference throughout the
assembly. Keep this page with
these instructions for future
reference.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
• This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance
Handy Hints
• Check you have all the
components and tools listed on
the following pages.
• Remove all fittings from the
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• During assembly do not stand
or put weight on the product,
this could cause damage.
• Assemble the item as close
to its final position (in the same
room) as possible.
• Assemble on a soft level
surface to avoid damaging the
unit or your floor.
• Parts of the assembly will be
easier with 2 people.
• To reduce
the likelihood of
damaging your
product please
ensure that your
power drill is set on a low torque
setting.
• Regularly check and ensure
that all bolts and fittings are
tightend properly.

Components - Panels
Please check you have all the panels listed below
If you have damaged or missing components, call the
Customer Helpline:
Argos = 0345 6400800
2
Left panel
(39.9 x 55.6cm)
1Right panel
(39.9 x 55.6cm)
2Middle right panel
(39.9 x 55.6cm)
3Middle panel
(39.8 x 17.4cm)
4
Top panel (120.1 x 40cm)
5
Drawer left x 2
(34 x 12.8cm)
16
Drawer right x 2
(34 x 12.8cm)
17
Left shelf (76.4 x 39.8cm)
7
Right shelf (38.8 x 39.8cm)
8
Middle left panel (39.8 x 36.6cm)
9
Front bottom panel x 2
(95.4 x 4.5cm)
19
Leg x 4 (7 x 15cm)
20
Bottom support
(7 x 15cm)
21
Large back panel
(78.4 x 58.6cm)
25
Small back panel
(41 x 58.6cm)
26
Drawer support
(32.7 x 6cm)
18
Pilot holes for
guidance only
Pilot holes for
guidance only
Pilot holes
for
guidance
only
Pilot holes for
guidance
only
Pilot
holes
for
guidance
only
Pilot
holes for
guidance
only
Large drawer front (79.4 x 28cm)
10
Small drawer front (47.9 x 28cm)
11
Small drawer back
(33.9 x 14.5cm)
13
Large drawer back
(66.6 x 14.5cm)
12
Small drawer bottom
(36.3 x 33.6cm)
15
Large drawer bottom
(69 x 33.6cm)
14
Left door panel
(53.9 x 40.1cm)
22
Middle door panel
(40.1 x 37.4cm)
23
Right door panel
(40.1 x 37.4cm)
24
Pilot holes for
guidance only
Pilot holes for
guidance only
Bottom panel (120.1 x 40cm)
6
Finished front edge
Finished front edge

A B C
D
G
E F
3
Ruler - Use this ruler to help correctly identify the screws
Tools required
0 5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 110 115 120 125 130 135 140 145 150 155 160 165 170
105
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1 2 3 4 5 6
Phillips screwdriver
(medium & large)
Flatblade screwdriver
(medium)
Small
hammer
Ruler/tape
measure
Drill
Eye protection
(when using a
hammer or glue)
7mm Suitable drill bit
(for use with wall plug)
The screws length is measured from the head to the point (30mm screw shown).
Please check you have all the fittings listed below
Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings
may be supplied than are required.
Components - Fittings
H
39mm Locking pin x 19
12mm Screw x 24 50mm Screw x 3015mm Screw x 24
30mm Screw x 10
30mm Dowel x 1112mm Locking nut x 9
15mm Locking nut x 10
I
J K L
Left outside runner x 2Right inside runner x 2Right outside runner x 2
Door hinge x 6
M N O
Nail x 30Left inside runner x 2 Door pad x 3
(This screw is included in
the runners bag)
(This screw is included in
the door hinges bag)

4
Assembly Instructions
a: Position the Left out-
side runners in from
front edge of the Left panel
and Middle panel .
2 2
2
J
J
Use Screws to fix the
Left outside runners
onto the Left panel
and Middle panel .
A
b: Position the Right out-
side runners in from
front edge of the Right
panel and Middle
right panel .
1
3
L
Use Screws to fix the
Right outside runners
onto the Right panel
and Middle right panel
.
A
L
Step 1
Continued on next page.
Attaching runners and
hinges
1
3
4
a:
b:
Pilot holes for
runner position
2 4
A A
J
A
2 Holes upside
31
A A A
L
2 Holes upside
42
J
31
L
L
A
A
A
L
A
A
A
1
3
Pilot holes for
runner position
Pilot holes for
runner position
A
J
A
A
2
A
J
A
A
4
Pilot holes for
runner position
Note: Repeat runner fixing on
reverse side.

Assembly Instructions
5
Step 1 - continued
Use Screws to fix the
Door hinges ‘back
plates’ onto the Left panel
.
B
I
Insert Dowels into the
Left panel and Middle
panel .
2
Use Screws to fix the
Door hinges ‘back
plates’ onto the Right
panel
and Middle right
panel .
B
I
Insert Dowels into the
Right panel and Middle
right panel .
1
3
1
3
H
2
4
H
c: Screw Locking pins
into the Left panel .
2
Note: Insert locking pins
as far as shown.
Do not over tighten.
E
d: Screw Locking pins
into the Right panel .
1
Note: Insert locking pins
as far as shown.
Do not over tighten.
E
E
E
c:
d:
H
E
E
H
B
B
I
I
B
B
I
I
E
E
I
B
H
I
2
3
1
B
I
B
I
B
I
H
H4
B
Note: Repeat door hinge fixing
on reverse side.

Assembly Instructions
a:
Step 2
6
b:
Continued on next page.
a: Use Screws to fix
Left shelf onto the
Middle panel .
C
7
4
Insert Dowels into the
Left shelf .
7
H
b: Use Screws to fix
Middle right panel onto
the Left shelf .
C
3
7
c:
c: Use Screws to fix
Right shelf onto the
Middle right panel .
C
8
3
Insert Dowels into the
Right shelf .
8
H
Attaching the middle
shelf panel
C
H
C
C
C
7
4
7
3
7
8
3
C
C
H

7
Assembly Instructions
Step 2 - continued
d:
a:
d: Use Screws to fix
Middle left panel onto
the Left shelf .
C
9
7
Step 3
Attaching the left and
right panel
a: Carefully locate the
Right panel onto the
Left shelf .
1
7
Insert 2 Locking nuts
into the Left shelf .
F
Use a screwdriver to turn
Locking nuts clockwise
to lock.
F
7
Continued on next page.
83
7
9
C
C
F
7
1
F
F

8
Continued on next page.
Assembly Instructions
Step 3 - continued
Step 4
a: Screw Locking pins
into the Top panel .
5
Note: Insert locking pins
as far as shown.
Do not over tighten.
Attaching top panel
E
E
E
E
E
E
E
a:
b:
b: Carefully locate the
Left panel onto the
Right shelf .
8
Insert 2 Locking nuts
into the Right shelf .
F
Use a screwdriver to turn
Locking nuts clockwise
to lock.
F
8
2
E
8
2
5
F
F
F

Assembly Instructions
Step 4 - continued
Step 5
a: Insert Dowels into
the Front bottom panel
.
9
b:
a:
b: Carefully locate the
Top panel onto the unit.
5
Insert 6 Locking nuts
into the unit.
F
Use a screwdriver to turn
Locking nuts clockwise
to lock.
F
H
19
b:
Continued on next page.
b: Position Legs onto
the Front bottom panel
.
20
19
Attaching bottom panel
5
1
3
2
F
19
19
20
20
F
F
H
H
F
F
F
F
X 2
X 2
