Snow Cube
18-2803-29
SNOW THROWERS
SNOW CUBE
A dual-stage snow thrower.
The snow thrower to perform in various snow conditions, easy-
to-use in recently fallen as well as hard and compact snow banks.
Equipped with a powerful dual-stage system. The snow is first
gathered with a toothed auger, which feed the snow into the fan
and then ejected about 10 metres through the chute.
The machine is comfortable to use with 7 gears (5 gears forward
and 2 gears reverse) and the direction of the chute is easily
adjusted from the handlebar. Reversable and adjustable skid shoes
to fit the terrain where the snow thrower operates.
Equipped with a 4-stroke engine. Working width is 56 cm.

Snow Cube (18-2803-29)
ENGINE
Engine GGP-engine SM 55
Power 171 cc
Cylinders 1
Overload protection Shear bolts
FUEL
Type of fuel Unleaded
Tank volume 2,8 l
SPEED CONTROL
Type of transmission Friction disc
Number of gears 5 forward, 2 reverse
WHEELS
Type of wheels SnowHog tyres
Wheel size Diameter 33 cm
Bearings Brass bushings
Tyre pressure 1,2 bar
Snow chains Accessory
VIBRATIONS & SOUND LEVELS
Sound power level 104 dB(A)
Vibrations 7,6 m/s2
CONTROLS
Choke Manual
Type of switch On/Off
Turnable chute Winch on handlebar
COLOUR & MATERIAL
Colour of chassis Yellow
Material of chassis Metal
MEASURES & WEIGHT
Weight 75 kg
Gross weight 85 kg
Package size WxHxL 62 x 68 x 89,5 cm
Type of package Cardboard box
Units on pallet 1
Working width 56 cm
Auger, diameter 23 cm
Impeller diameter 30 cm
Auger type Toothed
Auger house height 50 cm
OTHER FACTS
CE-mark Yes
Instructions for use 8218-2234-80
EAN bar code 731 332 180 09 63
