ST 1174 HST
18-2846-26
SNOW-THROWERS
ST 1174 HST
Semi-professional snow-thrower with hydrostatic speed control.
The snow-thrower easily works through very hard and icy snow-
drifts. Equipped with a powerful dual-stage system. The snow is
first collected with a saw-toothed spiral and then practically
ejected about 12 metres with a fan.
The machine is designed for users with high demands. The
machine has electric start, headlight (halogen), fuel gage, variable
speed (hydrostatic) and differential lock. Direction and height of
the ejector is quickly adjusted from the handle. The comfortable
handle can be operated with one hand only. Snow chains are avail-
able as accessory.
Equipped with a low-vibrating and silent 11,0 hp engine. Working
width 74 cm.

ST 1174 HST (18-2846-26)
ENGINE
Brand Briggs& Stratton Intek OHV
Power 11,5 hp/8,6 kW
Cylinders 1
FUEL
Type of fuel Unleaded
Tank volume 3,8 l
Fuel gauge Yes
SPEED CONTROL
Type of transmission Hydrogear hydrostatic
Number of gears Hydrostatic front and reverse
WHEELS
Type of wheels Maxi-grip tyres
Wheel size 40 x 17 cm
Bearings Ball bearings
Snow chains Accessory
VIBRATIONS & SOUND LEVELS
Sound power level 108 dB(A)
Vibrations 10,7 m/s2
CONTROLS
Electric start Yes, 230 V
Head light Integrated halogen light
Handle bar Yes
Choke Manual
Type of switch Plastic key
Throttle lever Yes, on motor
Turnable chute Horizontal and vertical controlled from handlebar
COLOUR & MATERIAL
Colour of chassis Yellow
Material of chassis Metal
MEASURES & WEIGHT
Weight 129 kg
Type of package Wodden frame, board on sides
Working width 74 cm
Capacity diameter 50 cm
Auger, diameter 30 cm, saw-teeth
Impeller diameter 30 cm
OTHER FACTS
CE-mark Yes
Instructions for use 8218-2217-03
EAN bar code 731 332 180 047 5
Other features Tool box with shear bolts
