STIHL FC-MM Instruction Manual

Original Instruction ManualPrinted on chlorine-free paper
Printing inks contain vegetable oils, paper can be recycled.
© ANDREAS STIHL AG & Co. KG, 2021 0458-481-0121. VA3.L20. 0000000577_012_GB
FC-MM
English
1
This instruction manual is protected by copyright. All rights reserved, especially the rights to reproduce, translate and process
with electronic systems.
Contents
Dear Customer,
Thank you for choosing a quality
engineered STIHL product.
It has been built using modern
production techniques and
comprehensive quality assurance.
Every effort has been made to ensure
your satisfaction and trouble-free use of
the product.
Please contact your dealer or our sales
company if you have any queries
concerning this product.
Your
Dr. Nikolas Stihl
MultiSystem 2
Guide to Using this Manual 2
Safety Precautions and Working
Techniques 2
Using the Unit 6
Approved MultiEngines 7
Mounting the MultiTool 8
Starting / Stopping the Engine 9
Storing the Machine 9
Maintenance and Care 10
Minimize Wear and Avoid Damage 10
Main Parts 11
Specifications 12
Maintenance and Repairs 12
Disposal 13
EC Declaration of Conformity 13

FC-MM
English
2
In the STIHL MultiSystem, various
MultiEngines and MultiTools are
combined to form a machine. In this
Instruction Manual, the functional unit of
MultiEngine and MultiTool is referred to
as a machine.
Accordingly, the instruction manuals for
the MultiEngine and the MultiTool
constitute the entire Instruction Manual
for the machine.
Always read both manuals carefully
before using your machine for the first
time and keep them safe for future
reference.
Pictograms
All the pictograms attached to the
machine are shown and explained in this
manual.
Symbols in text
WARNING
Warning where there is a risk of an
accident or personal injury or serious
damage to property.
NOTICE
Caution where there is a risk of
damaging the machine or its individual
components.
Engineering improvements
STIHL's philosophy is to continually
improve all of its products. For this
reason we may modify the design,
engineering and appearance of our
products periodically.
Therefore, some changes, modifications
and improvements may not be covered
in this manual.
Lend or rent your power tool only to
persons who are familiar with this model
and its operation – do not lend of rent
your power tool without the MultiEngine
and MultiTool user manuals.
The edger may only be used to cut
borders along paths, flower beds and
lawns.
The machine must not be used for any
other purposes – risk of accidents!
Only use attachments and accessories
that are explicitly approved for this
power tool model by STIHL or are
technically identical. If you have any
questions in this respect, consult your
dealer.
Use only high quality parts and
accessories. in order to avoid the risk of
accidents and damage to the machine.
MultiSystem
469BA028 KN
+
+
Guide to Using this Manual Safety Precautions and
Working Techniques
Special safety precau-
tions must be observed
when working with this
power edger because it
has a sharp cutting blade
that rotates at high
speed.
Always read and and
make sure you under-
stand both user manuals
(MultiEngine and
MultiTool) before using
your power tool for the
first time and keep them
in a safe place for future
reference. Non-compli-
ance with the user
manuals may cause seri-
ous or even fatal injury.

FC-MM
English
3
STIHL recommends the use of original
STIHL tools and accessories. They are
specifically designed to match the
product and meet your performance
requirements.
The deflector on this power tool cannot
protect the operator from all objects
thrown by the attachment (stones, glass,
wire, etc.). Ejected objects may also
ricochet and strike the operator.
Never attempt to modify your power tool
in any way since this may increase the
risk of personal injury. STIHL excludes
all liability for personal injury and
damage to property caused while using
unauthorized attachments.
Do not use a high-pressure washer to
clean the power tool. The solid jet of
water may damage parts of the unit.
Clothing and equipment
Wear proper protective clothing and
equipment.
Do not wear clothing which could
become trapped in wood, brush or
moving parts of the machine. Do not
wear a scarf, necktie or jewelry. Tie up
and confine long hair above your
shoulders.
WARNING
Wear "personal" sound protection, e.g.
ear defenders.
STIHL can supply a comprehensive
range of personal protective equipment.
Transporting the machine
Always stop the engine.
Carry your power tool by the handle,
attachment in front of you.
Do not touch hot parts of the machine -
risk of burn injury!
By vehicle: When transporting in a
vehicle, properly secure your machine to
prevent turnover, damage and fuel
spillage.
Before starting
Check that your power tool is properly
assembled and in good condition – refer
to appropriate chapters in the
MultiEngine and MultiTool user
manuals.
–Blade correctly and securely
mounted and in good condition
(clean, move freely, not warped)
–Inspect the deflectors for damage
and wear. Do not operate the
machine with a damaged deflector –
replace damaged parts.
–Never attempt to modify the controls
or safety devices
–Keep the handles dry and clean –
free from oil and dirt – this is
important for safe control of the
machine
–Swing the bike handle to the normal
operating position and tighten it
down firmly with the rotary knob.
See chapter on "Adjusting the Bike
Handle" in the MultiEngine user
manual.
To reduce the risk of personal injury, do
not operate your power tool if it is
damaged or not properly assembled!
Check the gearbox for correct position,
adjust if necessary. This helps reduce
the risk of injury from the MultiTool
rotating in the wrong direction.
Clothing must be sturdy
but allow complete free-
dom of movement. Wear
close-fitting clothes such
as a boiler suit, not a
loose jacket.
Wear steel-toed safety
boots with non-slip soles.
To reduce the risk of eye
injuries, wear close-fit-
ting safety glasses in
accordance with Euro-
pean Standard EN 166.
Make sure the safety
glasses are a snug fit.
Wear sturdy protective
gloves made of a resist-
ant material (e. g.
leather).
469BA001 KN

FC-MM
English
4
See also notes on "Mounting the
MultiTool".
If you use metal tools, position the
gearbox so that the axle is below the
drive shaft.
Use this position for:
–BF-MM cultivator
–BK-MM bolo tines
–FC-MM edger
–RL-MM aerator
–MF-MM dethatcher
Holding and Guiding the Machine
Make sure you always have good
balance and secure footing.
Always hold the unit firmly with both
hands on the handles.
Right hand on control handle, left hand
on grip on handlebar.
While working
In the event of impending danger or in
an emergency, switch off the engine
immediately by moving the slide control
/ stop switch/button to 0or STOP.
Within a wide area around the
workplace, there is a risk of accident by
ejected objects, therefore ensure that
there is no-one within a 15 m radius of
the machine. This distance must also be
maintained in relation to objects
(vehicles, window panes) – risk of
property damage! Even at a distance
over 15 m, danger cannot be ruled out.
The correct engine idle speed is
important to ensure that the attachment
stops moving when you let go of the
throttle trigger. Check and correct the
idle speed setting at regular intervals. If
the attachment still rotates when the
engine is idling, have your dealer check
your machine and make proper
adjustments or repairs – see
MultiEngine user manual.
To reduce the risk of injury from thrown
objects or contact with the attachment,
never operate the unit without a properly
mounted deflector designed specifically
for the unit and the attachment.
Always stand behind the deflector or to
one side of the machine during
operation – never in front of the
attachment.
Take special care in slippery conditions
– damp or ice on slopes or uneven
ground.
To reduce the risk of accidents or injury,
remove all obstacles and objects from
the work area.
Inspect the work area – solid objects
(stones, pieces of metal, etc.) may
damage the attachment.
Operate your power tool at normal
walking pace only.
469BA045 KN
5m (16ft)
The gear head becomes
hot during operation. To
reduce the risk of burn
injury, do not touch the
gear housing!
To avoid the risk of elec-
trocution, never use your
power tool in areas where
electrical lines are laid on
the surface or buried just
below the surface.Strik-
ing and damaging such
lines with the attachment
could cause serious or
even fatal injury.

FC-MM
English
5
Be extremely cautious when pulling the
power tool towards you because of the
risk of injury from contact with the
rotating attachment.
Make sure you always have good
balance and secure footing.
Be extremely cautious when changing
direction with the power tool – especially
on slopes.
On slopes, always work parallel to the
gradient to reduce the risk of injury from
slipping or contact with the attachment.
Never work on steep slopes because of
the risk of injury through loss of control
of the power tool.
Take particular care when working close
to fences, walls, stones, roots, trees and
areas of dense growth. Solid objects
may be ejected in your direction or
damage the attachment – risk of
accidents.
When working next to high scrub,
bushes and hedges, avoid harming
animals!
Be particularly alert and cautious when
wearing hearing protection because
your ability to hear warnings (shouts,
alarms, etc.) is restricted.
Take breaks when you start getting tired
or feeling fatigue – risk of accidents!
Work calmly and carefully – in daylight
conditions and only when visibility is
good. Proceed with caution, do not put
others in danger.
If your power tool is subjected to
unusually high loads for which it was not
designed (e.g. heavy impact or a fall),
always check that it is in good condition
before continuing work – see also
"Before Starting". Make sure the safety
devices are working properly. Never use
a power tool that is no longer safe to
operate. In case of doubt, contact a
dealer.
Do not touch the attachment while the
engine is running. If the attachment
becomes jammed by an obstruction,
switch off the engine immediately before
attempting to remove the obstruction –
otherwise, risk of injury!
Opening the throttle while the
attachment is blocked increases the
load and reduces engine speed. The
clutch then slips continuously and this
causes overheating and damage to
important components (e.g. clutch,
polymer housing components) – and this
can increase the risk of injury from the
attachment moving while the engine is
idling.
Check the sweeping attachments at
regular short intervals during operation
or immediately if there is a sudden
change in behavior:
–Shut off the engine, hold the
machine securely.
–Check condition and secure fitting;
watch out for cracks
–Replace a damaged cutting
attachment immediately, even if it
has only superficial cracks.
Clean the attachment and deflector at
regular intervals during operation.
–Shut off the engine
–Use gloves
–Remove grass, weeds, clumps of
soil, etc.
To reduce the risk of injury, shut off the
engine before changing the attachment.
Do not continue using or attempt to
repair damaged or cracked cutting
attachments by welding, straightening or
modifying the shape (out of balance).
If a rotating metal cutting attachment
touches a rock or another hard object,
sparks may be generated which may
possibly ignite combustible materials.
Also dried-out plants and brushwood are
combustible, above all in hot and dry
weather. If there is a risk of fire, do not
use metal cutting attachments in the
vicinity of combustible materials, dried-
out plants or brushwood. It is mandatory
that you ask the responsible forestry
office about the current fire hazard.
After finishing work
After finishing work or before leaving the
power tool unattended: Shut off the
engine.
After finishing work, clean dirt, soil and
plant residue off the attachment – wear
gloves to reduce the risk of injury.
Do not use any grease solvents when
cleaning.
After thoroughly cleaning, coat metal
surface of attachments with a corrosion
inhibitor.
Maintenance and Repairs
Service the machine regularly. Do not
attempt any maintenance or repair work
not described in the MultiTool and

FC-MM
English
6
MultiEngine instruction manuals. Have
all other work performed by a servicing
dealer.
STIHL recommends that you have
servicing and repair work carried out
exclusively by an authorized STIHL
servicing dealer. STIHL dealers are
regularly given the opportunity to attend
training courses and are supplied with
the necessary technical information.
Only use high-quality replacement parts
in order to avoid the risk of accidents
and damage to the power tool. If you
have any questions in this respect,
consult a servicing dealer.
STIHL recommends the use of original
STIHL replacement parts. They are
specifically designed to match your
model and meet your performance
requirements.
To reduce the risk of injury, always shut
off the engine before carrying out any
maintenance or repairs or cleaning the
machine.
Your FC-MM power edger MultiTool is
designed to produce sharp contoured
edges around lawns. It will cut almost all
types of grass, weeds and soft green
plants.
Preparations
If the soil is very dry, spray it with water
before you start work: this softens the
soil a little and also reduces the amount
of dust created. Slightly damp green
plants are easier to cut.
WARNING
Clear away all obstacles and solid
objects from the work area.
NPlan the best route for edging.
Operate the MultiEngine with FC-MM
edger in the forward direction only.
The blade may only be mounted and
operated in one position. Arrows on the
blade show the required direction of
rotation – see chapter on "Mounting the
MultiTool".
WARNING
Never work without the deflector!
The deflector ensures that cuttings and
other debris are directed away from the
machine and operator.
Using the Unit
481BA000 KN
481BA002 KN
481BA004 KN

FC-MM
English
7
Edging
NSecure the handlebar in the normal
operating position.
NStart the engine.
NStart the cut at no less than half
throttle and continue cutting at full
throttle.
NHold and guide your edger so that
the blade is vertical.
NCut steadily so that the engine is not
lugged down – do not apply force.
NCut at no more than a normal
walking pace.
NDo not push the blade into the
ground.
NAlways walk forwards when cutting,
do not pull the unit towards you.
NEdge at a steady pace to avoid
having to make several passes.
NUse the gunning sight (1) to line up
the blade on the edge.
Cleaning the blade
Pieces of grass or roots may become
tightly wrapped around blade mounting
during operation. Clean the blade as
follows:
–Shut off the engine.
–Wear work gloves.
–Pull the hitch pins out of the axle.
–Pull the blade off the axle.
–Remove pieces of roots, plants and
soil.
Refer to "Mounting the MultiTool" for
mounting instructions.
Only use MultiEngines supplied by
STIHL or expressly approved by STIHL
for use with the MultiTool.
This MultiTool may only be used in
combination with the STIHL MM 56
MultiEngine.
90°
481BA005 KN
481BA006 KN
1
Approved MultiEngines

FC-MM
English
8
Removing Existing MultiTools
WARNING
Wear gloves to reduce the risk of injury
from contact with sharp MultiTools
and/or hot surface of gearbox.
NRemove the hitch pins and pull the
MultiTools (if fitted) off the axle –
see also "Mounting the MultiTool" in
the instruction manual of the other
MultiTool.
NClean the gearbox if necessary.
Checking Position of Gearbox
WARNING
To reduce risk of injury from the
MultiTool rotating in the wrong direction,
check that position of gearbox is correct
and adjust if necessary.
The axle (1) must be below the shaft (2).
Direction of rotation (3) of MultiTool.
Adjusting Position of Gearbox
NLoosen clamp screws on gearbox.
NTurn the gearbox through 180°.
NLine up the gearbox in the correct
position.
NTighten down the two clamp screws
on the gearbox in the following
sequence:
–Tighten the first screw moderately.
–Tighten the second screw
moderately.
–Tighten down first screw firmly.
–Tighten down second screw firmly.
NOTICE
It must not be possible to rotate the
gearbox on the drive tube.
Mounting the MultiTool
The direction of rotation is marked with
arrows on the gearbox and cutting
blade. Make sure the arrows point in the
same direction.
NFit the two sleeves (4) on the right
and left.
NRotate the blade (5) on the right-
hand axle (viewed from engine) until
it can be pushed into position –
check the direction of rotation again
(arrows).
NPush the wheel (6) and washer (7)
onto the left-hand axle (viewed from
engine).
NInsert and engage both hitch
pins (8) in the holes in the axles –
fold the hitch pins flat against the
blade and wheel.
Mounting the MultiTool
481BA008 KN
2
469BA043 KN
1
3
481BA011 KN
8
481BA007 KN
6
5447
8

FC-MM
English
9
Starting the Engine
Always follow the starting procedure
described in the MultiEngine instruction
manual.
NSecure the handlebar in the normal
operating position.
NRetract the wheels, if fitted – see
chapter on "Wheels" in MultiEngine
instruction manual.
NRetract the spur, if fitted.
NCheck that the MultiTool is not
touching the ground or any other
obstacles. The unit must rest on the
engine flange and the support on
the frame.
NMake sure you have good balance
and secure footing – as shown in the
illustration.
WARNING
To reduce the risk of injury from contact
with the rotating attachment, always
stand to the side of the power tool, never
in front of the attachment.
NWith your left hand on the loop
handle, press the unit firmly against
the ground – do not touch the
throttle trigger or lockout lever.
NOTICE
Do not stand or kneel on the handlebar
or frame.
WARNING
The attachment may begin to move as
soon as the engine starts. For this
reason, blip the throttle after starting –
the engine returns to idling speed.
Now follow the starting procedure
described in the MultiEngine instruction
manual.
Stopping the Engine
NSee MultiEngine instruction manual.
For periods of 3 months or longer
NRemove, clean and inspect the
cutting blade.
NStore the machine in a dry, high or
locked location – out of the reach of
children and other unauthorized
persons.
Starting / Stopping the
Engine
469BA061 AS
469BA062 AS
Storing the Machine

FC-MM
English
10
The following intervals apply to normal
operating conditions only. If your daily
working time is longer or operating
conditions are difficult (very dusty work
area, etc.), shorten the specified
intervals accordingly.
All accessible screws and nuts
NRetighten if necessary
Wheel
NVisual inspection before starting
work
NReplace if necessary
Blade
NVisual inspection, check tightness
before starting work and after every
refueling stop
NHave checked for out-of-balance if
necessary, replace if out-of-balance
NReplace if damaged
Safety labels
NReplace illegible safety labels
Observing the instructions in this manual
and the MultiEngine manual helps
reduce the risk of unnecessary wear and
damage to the power tool.
The power tool must be operated,
maintained and stored with the due care
and attention described in these
instruction manuals.
The user is responsible for all damage
caused by non-observance of the safety
precautions, operating and maintenance
instructions. This includes in particular:
–Alterations or modifications to the
product not approved by STIHL.
–Using tools or accessories which
are neither approved or suitable for
the product or are of a poor quality.
–Using the product for purposes for
which it was not designed.
–Using the product for sports or
competitive events.
–Consequential damage caused by
continuing to use the product with
defective components.
Maintenance Work
All the operations described in the
chapter on "Maintenance and Care"
must be performed on a regular basis. If
these maintenance operations cannot
be performed by the owner, they should
be performed by a servicing dealer.
STIHL recommends that you have
servicing and repair work carried out
exclusively by an authorized STIHL
servicing dealer. STIHL dealers are
regularly given the opportunity to attend
training courses and are supplied with
the necessary technical information.
If these maintenance operations are not
carried out as specified, the user
assumes responsibility for any damage
that may occur. Among other parts, this
includes:
–Corrosion and other consequential
damage resulting from improper
storage.
–Damage to the product resulting
from the use of poor quality
replacement parts.
Parts Subject to Wear and Tear
Some parts of the power tool are subject
to normal wear and tear even during
regular operation in accordance with
instructions and, depending on the type
and duration of use, have to be replaced
in good time. Among other parts, this
includes:
–Blade
–Mounting hardware for blade
–Deflector
Maintenance and Care Minimize Wear and Avoid
Damage

FC-MM
English
11
1Blade
2Sleeve
3Wheel
4Washer
5Hitch pin
Main Parts
1
2
481BA009 KN
3
5
4

FC-MM
English
12
Attachment
Weight
Noise and Vibration Data
Noise and vibration data measurements
on power tools with the FC-MM
MultiTool include idling and rated
maximum speed with the same duration
of exposure.
For further details on compliance with
Vibration Directive 2002/44/EC see
www.stihl.com/vib/
Sound pressure level Lpeq to ISO 11201
Sound power level Lw to ISO 11789
Vibration measurement ahv,eq to
ISO 11789
The K-factor in accordance with
Directive 2006/42/EC is 2.0 dB(A) for
the sound pressure level and sound
power level; the K-factor in accordance
with Directive 2006/42/EC is 2.0 m/s2
for the vibration level.
REACH
REACH is an EC regulation and stands
for the Registration, Evaluation,
Authorisation and Restriction of
Chemical substances.
For information on compliance with the
REACH regulation (EC) No. 1907/2006
see www.stihl.com/reach.
Users of this machine may only carry out
the maintenance and service work
described in this user manual. All other
repairs must be carried out by a
servicing dealer.
STIHL recommends that you have
servicing and repair work carried out
exclusively by an authorized STIHL
servicing dealer. STIHL dealers are
regularly given the opportunity to attend
training courses and are supplied with
the necessary technical information.
When repairing the machine, only use
replacement parts which have been
approved by STIHL for this power tool or
are technically identical. Only use high-
quality replacement parts in order to
avoid the risk of accidents and damage
to the machine.
STIHL recommends the use of original
STIHL replacement parts.
Original STIHL parts can be identified by
the STIHL part number, the {
logo and the STIHL parts symbol K
(the symbol may appear alone on small
parts).
Specifications
Blade
Diameter: 230 mm
Edger with wheel: 0.8 kg
MM 56 with FC-MM: 91 dB(A)
MM 56 with FC-MM: 100 dB(A)
Handle,
left
Handle,
right
MM 56 with
FC-MM: 4.1 m/s25.1 m/s2
Maintenance and Repairs

FC-MM
English
13
Observe all country-specific waste
disposal rules and regulations.
STIHL products must not be thrown in
the garbage can. Take the product,
accessories and packaging to an
approved disposal site for environment-
friendly recycling.
Contact your STIHL servicing dealer for
the latest information on waste disposal.
ANDREAS STIHL AG & Co. KG
Badstr. 115
D-71336 Waiblingen
Germany
declare under our sole responsibility that
conforms to the relevant provisions of
Directive 2006/42/EC and has been
developed and manufactured in
compliance with the following standards
in the versions valid on the date of
production:
EN ISO 12100, ISO 11789 (in
conjunction with the specified MM 56
MultiEngine).
Technical documents deposited at:
ANDREAS STIHL AG & Co. KG
Produktzulassung
Done at Waiblingen, 03.02.2020
ANDREAS STIHL AG & Co. KG
pp
Dr. Jürgen Hoffmann
Head of Product Data, Regulations and
Licensing
Disposal
000BA073 KN
EC Declaration of Conformity
Designation: MultiTool
Make: STIHL
Series: FC-MM
Serial identification
number:
4601
Displacement
with MM 56: 27.2 cm3

www.stihl.com *04584810121*
0458-481-0121
0458-481-0121
englisch
G
