stilum ludo User manual

Mounting instructions for table tennis „ludo“
Artikel-Nr. 55 3010 401
© stilum GmbH, Gewerbegebiet Larsheck, 56271 Kleinmaischeid • Tel. [phone] • All rights and product modications reserved. State: 18.03.2020 p. 1
health
Diagram 1: Overall view

Mounting instructions for table tennis „ludo“
Artikel-Nr. 55 3010 401
© stilum GmbH, Gewerbegebiet Larsheck, 56271 Kleinmaischeid • Tel. [phone] • All rights and product modications reserved. State: 18.03.2020 p. 2
health
4500
2750
1500
R
2000
8000
OHNE SCHRIFTLICHE ZUSTIMMUNG DER CONRADI+KAISER GMBH DARF DIESE
TECHNISCHE UNTERLAGE WEDER VERVIELFÄLTIGT, NOCH DRITTEN MITGETEILT ODER
ZUGÄNGLICH GEMACHT WERDEN, NOCH IN SONSTIGER WEISE MISSBRÄEUCHLICH VER-
WENDET WERDEN. ZUWIDERHANDLUNGEN WERDEN URHEBERRECHTLICH VERFOLGT.
Oberflächen nach
DIN ISO 1302
Reihe 2
Zul. Abweichung
DIN 2768 - mH
1
ludo
Benennung
Gepr.
Werkstoff
Blatt
Datum
Projekt
Gez.
Zuschnitt
Zeichnungsnummer
Rev Änderung Datum
1:50
A3
Gewicht
Name
Name
Draufsicht
2120-00-00
752.17 Maßstab
Simonis 16.03.18
Gewerbegebiet Larsheck
56271 Kleinmaischeid
Deutschland
Diagram 2: Side view with dimension details „ludo“
Diagram 3: Top view
1. Select the play equipment location in consideration of the recommended play
area (see diagram 3: 8000 mm x 4500 mm).
2. Carry out excavation work for one foundation as shown in diagram 2.
After excavation, compress the foundation oor.
Note: The play equipment is built on the play level! Pay attention to items
marked „play level“ of play equipment!
3. Set up the concrete foundations acc. to the dimensions indicated with central,
horizontal reinforcement.
4. After a setting period of 10 - 14 days - depending on weather conditions and
foundation size - clean the foundation cover.
5. Align the pre-mounted table tennis on the foundation and screw it onto the
foundation using the dowels for heavy loads included in the delivery.
6. Fill up the existing gaps between the foundation and foundation hole with
excavated soil and compact and built an even ground level.
7. Cover the foundation with the choosed groundmaterial.
The foundation has to be constructed that thereby is no danger (stumble, jar).
It has to be guaranted that it would not be uncovered by erosion.
8. Do not allow children to use the equipment before the installation has been
nished.
Reinforcement plan: Concrete foundation with reinforcement
Main foundation: BSt 500S
Ever 4 stirrups Ø 8 mm lengthwise and cross
Concrete cover h´= 3 cm
Concrete quality class C 20/25
2500
300
2000
150
774
965
694
300
900
150
OHNE SCHRIFTLICHE ZUSTIMMUNG DER CONRADI+KAISER GMBH DARF DIESE
TECHNISCHE UNTERLAGE WEDER VERVIELFÄLTIGT, NOCH DRITTEN MITGETEILT ODER
ZUGÄNGLICH GEMACHT WERDEN, NOCH IN SONSTIGER WEISE MISSBRÄEUCHLICH VER-
WENDET WERDEN. ZUWIDERHANDLUNGEN WERDEN URHEBERRECHTLICH VERFOLGT.
Oberflächen nach
DIN ISO 1302
Reihe 2
Zul. Abweichung
DIN 2768 - mH
1
ludo
Benennung
Gepr.
Werkstoff
Blatt
Datum
Projekt
Gez.
Zuschnitt
Zeichnungsnummer
Rev Änderung Datum
1:20
A3
Gewicht
Name
Name
Fundamentplan
2120-00-00
204.92 Maßstab
Simonis 16.03.18
Gewerbegebiet Larsheck
56271 Kleinmaischeid
Deutschland
Beton
Concrete
Füllmaterial
Filling
Erde
Ground
Legende
2500
300
2000
150
774
965
694
300
900
150
OHNE SCHRIFTLICHE ZUSTIMMUNG DER CONRADI+KAISER GMBH DARF DIESE
TECHNISCHE UNTERLAGE WEDER VERVIELFÄLTIGT, NOCH DRITTEN MITGETEILT ODER
ZUGÄNGLICH GEMACHT WERDEN, NOCH IN SONSTIGER WEISE MISSBRÄEUCHLICH VER-
WENDET WERDEN. ZUWIDERHANDLUNGEN WERDEN URHEBERRECHTLICH VERFOLGT.
Oberflächen nach
DIN ISO 1302
Reihe 2
Zul. Abweichung
DIN 2768 - mH
1
ludo
Benennung
Gepr.
Werkstoff
Blatt
Datum
Projekt
Gez.
Zuschnitt
Zeichnungsnummer
Rev Änderung Datum
1:20
A3
Gewicht
Name
Name
Fundamentplan
2120-00-00
204.92 Maßstab
Simonis 16.03.18
Gewerbegebiet Larsheck
56271 Kleinmaischeid
Deutschland
Beton
Concrete
Füllmaterial
Filling
Erde
Ground
Legende

Mounting instructions for table tennis „ludo“
Artikel-Nr. 55 3010 401
© stilum GmbH, Gewerbegebiet Larsheck, 56271 Kleinmaischeid • Tel. [phone] • All rights and product modications reserved. State: 18.03.2020 p. 3
health
Attention: If the play equipment has been incompletely installed or partly dis-
mantled when carrying out maintenance and repair work, this may lead to particu-
lar risks of injury for the user. For this reason, make clearly visible that the equip-
ment shall not be used in such cases.
NOTE: Play equipment, which contain components made of stainless steel should
not come with „normal“ steel parts in contact. Those steel parts may rub o󰀨 and
leave small steel particles in combination with moisture brown rust stains.If such
corrosion occur on stainless steel parts, they are ne with an abrasive (240 grit) to
remove.
Please take care when transporting and setting up the fact that the components
are made of stainless steel with no „normal“ steel parts in contact.
In order to preserve a good visual appearance of your stilum playground equip-
ment over a long period one should take care of maintenance of the stainless
surface even despite of their corrosion resistance.
Especially areas, which can not be reached by rainfall should be frequently clea-
ned from dirt and deposits due to air pollution and dirt caused by the atmosphere.
Light soiling can easily be romoved by using a high pressure cleaner.
For persistent deposits use a clean cloth moistened with a special liquid cleaner
(e.g. on phosphoric acid) and rinse o󰀨 with clear water after a short application
time. During cleaning with mild abrasive components, only wipe over stainless
steel surface in polishing direction.
For heavily soiled surfaces, polishes can be used (e.g. for cleaning chrome on
cars) or for greasy and oily dirt alcoholic cleaning agents and solvents (e.g. ethyl
alcohol, isopropyl alcohol or acetone).
However, it should be noted that the dissolved soiling is not spread over the sur-
face again.
Do not use any chlorid or hydrochloric containing cleaning products nor scouring
powder, bleaching - or silver polish cleaner. Cleaning intervals depend on type and
degree of soiling as well as on demands made on optical characteristics. Therefore
cleaning is advisable at intervals of six to twelve months – whereby in the case of
strong soiling it is appropriate to clean the playground equipment at intervals of
three to six months.
