Stirling PA19W User manual

AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Model Number PA19W
Wi-Fi Portable Air Conditioner
(1.9kW Cooling)
INSTRUCTION MANUAL

2
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Welcome
Congratulations on choosing to buy a STIRLING®product.
All products brought to you by STIRLING®are manufactured to the highest
standards of performance and safety and, as part of our philosophy of customer
service and satisfaction, are backed by our comprehensive 3 Year Warranty.
We hope you will enjoy using your purchase for many years to come.

3
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Contents
02 Welcome
04 Warranty Details
05 General Safety Instructions
09 R290-Specific Safety Advice
11 Getting Started
12 Product Overview
15 Installation
17 Instructions
20 Wi-Fi Control
26 FAQs & Troubleshooting Guide
27 Other Useful Information
31 Repair and Refurbished Goods or Parts Notice

4
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Wi-Fi Portable Air Conditioner (1.9kW Cooling)
Warranty Details
The product is guaranteed to be free from defects in workmanship and
parts for a period of 36 months from the date of purchase. Defects that
occur within this warranty period, under normal use and care, will be
repaired, replaced or refunded at our discretion. The benefits conferred by
this warranty are in addition to all rights and remedies in respect of the
product that the consumer has under the Competition and Consumer Act
2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and to compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
YEAR WARRANTY
3
REGISTER YOUR PURCHASE AT www.aldi.com.au/en/about-aldi/product-registration/ TO KEEP UP-TO-DATE WITH IMPORTANT PRODUCT INFORMATION

5
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
General Safety Instructions
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
Read this manual thoroughly before first use, even if you are familiar with
this type of product. The safety precautions enclosed herein reduce the risk
of fire, electric shock and injury when correctly adhered to. Make sure you
understand all instructions and warnings. Keep the manual in a safe place
for future reference, along with the completed warranty card, your purchase
receipt and the original packaging. If you sell or transfer ownership of this
product, pass on these instructions to the new owner.
Always follow basic safety precautions and accident prevention
measures when using an electrical appliance, including the following:
Electrical safety and cord handling
• Electrical connection: The unit comes with a plug ready for connection to
your mains power outlet.
• Voltage: Before turning on the air conditioner, ensure the electrical voltage
and circuit frequency correspond to those indicated on the appliance.
• Socket: Ensure your electrical outlet is properly installed and earthed and
complies with your local electrical safety requirements.
• Moisture: To reduce the risk of electrocution, never operate the appliance
with wet hands; never submerge it in water or spill liquids into it. Do not use
it in a bathroom or laundry, or where it can be splashed with water.
• Power supply cord: Do not kink or damage the cord. Do not pull the cord
or place it near a heat source. Always unwind the cord completely to avoid
overheating. Run the cord in such a way so that no one will trip over it.
• Extension cord/adaptor: Do not use this appliance with an extension cord
or power adaptor.
• Damage: If the supply cord (or any other part of the appliance) is damaged,
do not use the appliance. A damaged power supply cord must be replaced
by the manufacturer or its service agent or a similarly qualified person in
order to avoid a hazard. Contact our after sales support centre.
• WARNING: Do not use when damaged! In case of damage, switch off the
appliance, unplug it and contact our after sales support centre. Do not pick
up or operate a damaged appliance, or after it malfunctions or has been
dropped or damaged in any manner.
• Switching on/off: Do not use the mains plug to start and stop the unit;
always use the POWER button to start and stop the unit.
• Disconnect: Turn off the unit first and then unplug it when it is not in use
and before maintenance or cleaning, but do not unplug it when it is in
operation, as this could create a spark and cause a fire. Grip by the plug,
do not pull by the cord when disconnecting.

6
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
• RCD: The installation of a residual current device (safety switch) is
recommended to provide additional safety protection when using electrical
appliances. It is advisable that a safety switch with a rated residual
operating current not exceeding 30mA be installed in the electrical circuit
supplying the appliance. See your electrician for professional advice.
Usage conditions and restrictions
• Intended use: This appliance is intended for air conditioning domestic
environments. It is not suitable for commercial, industrial or trade use. Do
not use it for any other purpose (such as drying clothes, cooling food, etc.),
and only use it as described in this manual.
• Common sense: These instructions are not intended to cover every
possible condition and situation. As with any electrical appliance, common
sense and caution are therefore always recommended when installing,
operating and maintaining the unit.
• No outdoor use: Do not use the unit outdoors. It is for indoor use only.
• Usage restriction: This appliance is not intended for use by persons
(including children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved.
• No external timer: This appliance is not intended to be used with an
external timer or a separate remote control system.
• WARNING: Do not cover! Do not cover the air conditioner or obstruct any
air inlet or outlet grilles. Obstructing these openings causes a fire hazard,
reduces the operating efficiency and may lead to malfunction or damage.
• Air outlets: Do not insert any objects, or your fingers, into the air outlet,
and make sure to warn children of the dangers.
• Children: Supervise children to ensure they do not play with the appliance.
Close supervision is necessary when any appliance is used by or near
children. Cleaning and user maintenance shall not be made by children
without supervision.
• Unattended: Do not leave the appliance unattended when in use.
• Attachments: The use of attachments not recommended or sold by the
manufacturer may cause fire, electric shock or injury.
• Start-up settings: Set the unit to maximum cooling and high speed
ventilation for the initial startup, then adjust the unit down to a more
comfortable setting as required.
General Safety Instructions (Cont.)

7
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Installation
• Proper installation: Install the appliance according to the instructions in
this manual and national wiring regulations. Improper installation may result
in the risk of fire, electric shock and/or injury.
• WARNING: Electric shock hazard! Before installation or servicing, ensure
the unit is switched off and disconnected from the power outlet to prevent
possible injury.
• The location: When deciding on an installation place, keep in mind that
the area must be flat, the air outlets must not be covered up, and there
must be a properly earthed 220~240V~ 50Hz power outlet nearby.
• Airflow: Do not direct the airflow onto plants or animals, as long and direct
exposure to cold air from the air conditioner could adversely affect them.
• Cold air exposure: Never remain directly exposed to the flow of cold air
for a long time, as direct and prolonged exposure to cold air from the air
conditioner could be dangerous for your health. Take particular care in
rooms where there are children, old, or sick people.
• Moving the appliance: When moving the air conditioner, always turn it off
first and disconnect the power supply, and move it slowly. Keep the unit
upward during transport and storage.
Cleaning and maintenance
• Disconnect: Make sure the appliance is disconnected from the power
supply when it will not be used for a long time and before carrying out any
cleaning or maintenance.
• Air filter: Keep the air filter clean. Do not use the unit without the air filter
fitted. Using it without air filter could cause an excessive accumulation of
dust or waste on the inner parts of the device with possible subsequent
failures.
• Service and repair: The air conditioner has no user-serviceable parts
contained inside. Do not attempt to disassemble, modify or conduct
repairs on this unit. It has been built in accordance with relevant safety and
performance standards. An electrical specialist must carry out all repairs.
Contact our after sales support centre for advice on service.
• Unplug the appliance immediately if you notice any smoke, odour or
strange sounds coming from the unit. Call for a service.
• Risk of fire: This appliance contains a flammable refrigerant. Do not open
the appliance. In case of damage or malfunction, turn off the appliance,
disconnect the power supply and call our after sales support centre for a
service.
General Safety Instructions (Cont.)

8
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
• Do NOT install/use the appliance in the following areas:
–outdoors or where water is likely to splash
–near a bath, shower, laundry basin or swimming pool
–in an area where oil is likely to splash
– near a hot gas or electric burner, or sources of fire
– near sources of heat, or exposed to direct sunlight
– in an area where furniture or other objects can obstruct the airflow
– in the presence of flammable substances or vapour such as alcohol,
insecticides, petrol, etc.
–at a dry cleaner’s premises.
• Clearances: There must be a clearance of at least 30cm between the
appliance and any walls, furniture, curtains or any other obstacles (refer to
Fig. 1, below). Maintaining this minimum 30cm clearance is essential; failure
to keep that distance can result in the unit malfunctioning or causing injury.
• Window application: The air exhaust can be installed in a vertical or
horizontal sliding window (refer to Fig. 2, below).
• Air exhaust installation instructions follow on pages 15–16. Keep the length
of the air exhaust hose to the minimum length necessary during operation.
• Upright position: Place the unit on a flat surface to reduce the risk of it tipping
over. Do not tilt the unit, always keep it upright during installation and use.
• Misuse: We accept no responsibility for any eventual injuries or damages
caused by improper installation, faulty use or failure to follow the instructions.
• Pressure specifications:
Permissible excessive operating pressure: discharge 2.6MPa, suction 1.0MPa.
Maximum allowable pressure: discharge 3.2MPa, suction 1.2MPa.
Fig. 1 Fig. 2
General Safety Instructions (Cont.)

9
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Important safety precautions concerning refrigerant R290
WARNING: Combustible & Dangerous
This symbol alerts you to take care as the appliance contains
a flammable refrigerant: R290 (propane). Take extra care when
installing the unit and when carrying out maintenance. R290 is
a colourless and odourless hydrocarbon gas. It is an efficient
refrigerant with a low Global Warming Potential (GWP) and no
potential for ozone depletion.
WARNING!
• The room in which this air conditioner is installed must have a minimum area
of more than 4m2. (This unit is designed for use in a room of approximately
10–14m2 size.)
• The appliance shall be stored in a well-ventilated area without continuously
operating ignition sources, such as open flames, an operating ignition gas
appliance or an operating electric heater. Do not expose the appliance to
high heat, sparks and open flames.
• Do not pierce or burn the appliance.
• Do not use means to accelerate the defrosting process or to clean, other
than those recommended by the manufacturer.
• Be aware that refrigerants may not contain an odour.
• The ratings of the fuse installed in the built-in control unit are T, 2AL, 250V~.
• This air conditioner has been fully charged with refrigerant at the factory.
Should a recharge become necessary, it may only be recharged by a
professional installer.
• Maintenance must only be carried out by properly qualified, authorised
personnel. If the appliance requires maintenance or service, contact our after
sales support centre.
• The service technician must strictly comply with:
– all safety instructions in the manual provided with the appliance
– all relevant provisions of gas-related local laws and regulations.
While R290 is highly flammable, there will be no risk of burning and explosion if
the appliance is properly installed and maintained following all instructions and
safety advice in the supplied manuals.
R290-Specific Safety Advice

10
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
R290-Specific Safety Advice (Cont.)
• After servicing the appliance, the service technician must:
– check that air cannot enter the refrigerant system
– check for refrigerant leaks when moving the air conditioner
– carry out a test cycle under controlled conditions after installing the unit and
record the operating data.
Disposal
• This air conditioner contains a flammable refrigerant, which must be
removed before disposal. Contact your municipal authorities for any codes
or regulations concerning the disposal of such materials.
• At the end of its working life, do not throw this appliance out with your
household rubbish. Electrical and electronic products contain substances
that can have a detrimental effect on the environment and human health
if disposed of inappropriately. Observe any local regulations regarding the
disposal of electrical consumer goods and dispose of it appropriately for
recycling and recovery of the refrigerant.

11
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Before you start
• Unpacking: This product has been packaged to protect it against
transportation damage. Unpack the appliance and keep the original
packaging materials in a safe place. It will help prevent any damage if the
product needs to be transported in the future, and you can use it to store
the appliance when it is not in use. In the event that the packaging is to be
disposed of, please recycle it where possible.
• Safe packaging disposal: Plastic wrapping can be a suffocation hazard for
babies and young children, so ensure all packaging materials are kept out of
their reach and disposed of safely.
• Inspection: Unwind the cord fully and inspect it for damage. Do not use if
any part of the appliance is damaged. In case of damage, contact our after
sales support centre for advice.
• Documentation: Read the manual to familiarise yourself with all parts and
operating principles of the portable air conditioner. Pay particular attention to
the safety instructions on the previous pages.
Electric shock hazard!
Before installation, cleaning or servicing, ensure the unit is switched off and
disconnected from the power outlet to prevent possible injury.
Getting Started

12
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Product Overview
Scope of delivery
A Portable air conditioner
1 Control panel (see page 14 for details)
2 Air intake grille with filter
3 Cold air outlet with louvre
4 Castor wheels (4, rear wheels not shown here)
5 Power cord and plug connection (cord and plug not shown here)
6 Exhaust air outlet for flexible hose connection
7 Air intake grille
8 Drainage outlet with plug
Front & left side view (Fig. 3) Rear view (Fig. 4)
1
2
4
3
6
7
5
8

13
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Product Overview (Cont.)
B Accessory parts (Fig. 5)
NOTE: Due to continued product improvement, images and illustrations in this
manual may vary slightly from the product purchased. All images in this manual
are for reference purposes only. Parts are not necessarily pictured to scale.
Flexible air exhaust hose
Exhaust hose connector
(window end)
Adjustable window slider (for
67.5cm – 123cm windows)
Remote control
Exhaust hose connector (hous-
ing adaptor) (air conditioner end)
2 Dowels
2 AAA-size batteries
(packaged separately)
Part Description

14
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Control panel (Fig. 6)
Product Overview (Cont.)
Remote control (Fig. 7)
NOTE:
Do not drop the remote control.
Do not place the remote control in a
location exposed to direct sunlight.
W. F.
W.F
WIFI
1 2 3 4 5
6 7 8 9 10 11 12 13
Remote control buttons
1 Fan speed button
2 Temperature up button
3 Mode button
4 Temperature down button
5 Timer button
6 Power button
1
2
3
4
5
6
Control panel buttons and indicators
1 Water full indicator
2 Fan speed indicators
3 Timer indicator
4 Temperature/timer display
5 Mode indicators
6 Wi-Fi indicator
7 Power button
8 Temperature up button
9 Temperature down button
10 Remote control signal receiver
11 Operation mode button
12 Fan speed button
13 Timer button

15
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Installation
Installing the air exhaust hose
IMPORTANT!
For best performance, keep the
length of the air exhaust hose to
the minimum length necessary
during operation.
Fig. 9
Fig. 10
• Insert the fixing clip of the
housing connector into the
openings at the back of the
air conditioner (Fig. 9).
• Fit the exhaust hose and
housing connectors to
the ends of the flexible air
exhaust hose, twisting them
into place (Fig. 8).
• For temporary installation
(in fan mode only), lead the
exhaust hose connector
(window end) out of an open
window (Fig. 10).
NOTE: Ambient air will still
be able to enter the room
this way. To cool the room
effectively, the window kit
must be properly installed.
Fig. 8

16
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Installing the window kit
Your window kit has been designed to fit most standard ‘horizontal’ and
‘vertical’ window applications, but for certain types of windows it may be
necessary for you to improvise/modify some aspects of the installation
procedure.
Installation (Cont.)
• Adjust the window slider to the length of a horizontally (or height of a
vertically) opening window (Fig. 11) and fix it with a dowel (Fig. 12).
Fig. 11
• Fit the slider to the bottom of the window sill (or to the side of the window, if
it opens vertically), then close the window.
• Fit the exhaust hose connector (window end) through the opening to the
outside (Fig. 13).
Fig. 12
Fig. 13

17
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Instructions
Using the portable air conditioner
• Before switching the unit on for the first time, make sure you have properly
installed the exhaust hose and window kit (see pages 7–8 and 15–16) and
inserted two AAA size batteries into the remote control (see page 28).
• Find a place for the air conditioner where there is a power outlet nearby.
• Install the exhaust hose through
the window kit so that the hot air is
expelled to the outside (Fig. 14).
• Ensure the rubber stopper at the
back of the appliance is properly in
place to block the drainage outlet.
• Plug the portable air conditioner
into a properly earthed 220–240V ~
50Hz mains socket and switch on
power to the outlet.
NOTE: Do not connect it to a multiple socket outlet that is also being used
for other electrical appliances. Do not connect it to an extension cord.
• Press the POWER button and the unit will start operation.
IMPORTANT INFORMATION
• Room size: It is important to use the right size air conditioner in the
room you want to cool. (This appliance is suitable for cooling rooms of
10m2–14m2size.)
• Exhaust hose: This MUST BE CONNECTED and hot air expelled to the
outside for the appliance to work properly. Keep the hose as short as
possible.
• Noise: As the compressor is inside the room, a portable air conditioner
makes more noise than a split system, where the compressor is outside.
• For best cooling efficiency, keep blinds and curtains closed during the
sunniest part of the day. Close off any fireplace damper, floor and/or wall
register so cool air does not escape through the chimney or duct work.
• Switching on/off: After switching on, allow 30 seconds for cool air to
flow through the louvres. Avoid starting the air conditioner soon after
switching off, and avoid switching it off immediately after switching on.
Allow at least 3 minutes in between switching the unit on and then off,
or vice versa.
• Moving the appliance: Take care when moving the appliance as conden-
sation water may spill out. Ensure the drip tray is empty before moving it.
Fig. 14

18
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Cooling mode
• Press the MODE button until the cooling mode indicator illuminates.
• Press the TEMP– or TEMP+ button repeatedly to set the desired room
temperature between 16°C and 31°C.
• Press the SPEED button to select the fan speed: high or low.
NOTE: For best cooling efficiency, make sure that:
* Curtains/blinds are closed if your room is directly exposed to the sun.
* The air conditioner is located away from any heat source.
Dehumidifying mode
• Press the MODE button until the dehumidifying mode indicator illuminates.
• The unit will automatically set the fan motor to low speed and maintain the
room temperature at 2°C lower than the current room temperature (within
the 16°C to 31°C range).
Fan mode
• Press the MODE button until the fan mode indicator illuminates.
• Press the SPEED button to select the fan speed: high or low.
Timer operation
The air conditioner has a 24 hour timer, which you can set to start the unit at
a later time, or to switch off the unit automatically.
On-Timer setting
• With the unit switched off (but power supplied), press the TIMER button
and then use the UP and DOWN buttons to select the number of hours after
which you want the unit to turn on. The selected number of hours will be
shown on the display.
Off-Timer setting
• Use the same procedure as above, but while the unit is switched on, to set
an auto-off time. The selected number of hours will be shown on the display.
Instructions (Cont.)

19
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Instructions (Cont.)
Water full alarm
Condensation water that forms during cooling will drop into an in-built drip
tray. When the water level in the drip tray is getting too full, an automatic
water level sensor illuminates the Water Full (W.F.) indicator on the control
panel to alert you that the drip tray needs to be emptied.
Should the W.F. indicator light up during operation, proceed as follows:
• Unplug the unit from the power supply.
• Place a pan under the water drainage outlet at the bottom of the unit.
• Remove the rubber stopper and drain all water out of the tray.
• Alternatively, attach a water drain hose (not supplied) to the drainage outlet
(Fig. 15) and lead the hose to the outside or into a tub or drain for water
drainage.
Drainage
outlet
Fig. 15

20
AFTER SALES SUPPORT
1300 886 649
[email protected]
AUS MODEL: PA19W PRODUCT CODE: 703227 11/2020
Wi-Fi Control
This STIRLING Black Edition Portable Air Conditioner features Wi-Fi
technology, which enables you to control the appliance remotely from wherever
you are — at work, at play or on the go — so that on your arrival your home is
comfortably cool. The portable air conditioner works in conjunction with your
mobile device, using your home Wi-Fi network router to communicate with the
air conditioner.
Controlling the air conditioner remotely is very easy. You will need:
• An Android smartphone or tablet, or an Apple iPhone or iPad.
• An internet connection at your home.
• A Wi-Fi network router set up at home.
• You must also have our STIRLING App installed or updated on your
smartphone or mobile device. This app is available from Google Play Store
or Apple App Store.
Initial set-up
Upon installation of your new portable air conditioner, or when you have
changed your mobile device or wireless router, you will have to set up the
communication channel between the devices. In order to do this, make sure
you have the STIRLING App installed on your mobile device, your Wi-Fi router
is switched on and your mobile device connected to your home Wi-Fi network.
• On your mobile device, tap on the [STIRLING ] app (Fig. WF1). It will
open and take you to the Login Page (Fig. WF2).
Fig. WF1 Fig. WF2
