Stober P Series User manual

P/PE/PH/PHQ/PHV gear units, geared motors
Operating manual
en-US
10/2019
ID 443149_en.00

Table of contents
ii
10/2019 | ID 443149_en.00
Table of contents
1 User information ....................................................................................................................................................... 4
1.1 Storage and transfer ................................................................................................................................................ 4
1.2 Original language ..................................................................................................................................................... 4
1.3 Formatting conventions........................................................................................................................................... 4
1.4 Terms ....................................................................................................................................................................... 5
1.5 Supporting documents............................................................................................................................................. 5
1.6 Limitation of liability ................................................................................................................................................ 5
1.7 Product names and brands ...................................................................................................................................... 5
1.8 Copyright notice....................................................................................................................................................... 5
2 General safety instructions........................................................................................................................................ 6
2.1 Intended use ............................................................................................................................................................6
2.2 Requirements for personnel .................................................................................................................................... 6
2.3 Prevention of personal injury .................................................................................................................................. 6
2.3.1 Mechanical hazards ................................................................................................................................ 6
2.3.2 Thermal hazards ..................................................................................................................................... 7
2.4 Prevention of property damage............................................................................................................................... 7
3 Product description ................................................................................................................................................... 8
3.1 Basic structure of P, PE ............................................................................................................................................ 8
3.2 Basic structure of PH, PHQ, PHV .............................................................................................................................. 9
3.3 PE type designation.................................................................................................................................................. 9
3.4 P2 – P9, PH3 – PH8, PHQ4 – PHQ8 type designation............................................................................................. 10
3.5 PH9 – PH10, PHQ9 – PHQ12, PHV9 – PHV10 type designation .............................................................................11
3.6 Nameplate ............................................................................................................................................................. 11
3.7 Mounting positions................................................................................................................................................ 12
3.8 Direction of rotation .............................................................................................................................................. 12
3.9 Reverse operation.................................................................................................................................................. 13
3.10 Ambient conditions................................................................................................................................................ 14
3.11 Other product features..........................................................................................................................................14
3.12 Additional documentation ..................................................................................................................................... 15
4 Transport and storage ............................................................................................................................................. 16
4.1 Transport ............................................................................................................................................................... 16
4.2 Storage................................................................................................................................................................... 16
4.2.1 Long-term storage ................................................................................................................................ 16
5 Installation .............................................................................................................................................................. 17
5.1 Cleaning agent and solvent.................................................................................................................................... 17

Table of contents
10/2019 | ID 443149_en.00
iii
5.2 Mounting the motor on a gear unit ....................................................................................................................... 17
5.2.1 Permitted tilting torques at the gear unit input ................................................................................... 18
5.2.2 Tolerances for the add-on motor ......................................................................................................... 18
5.2.3 Mounting the motor on a gear unit with ME/MEL/MF/MFL adapter .................................................. 19
5.2.4 Mounting the motor on a gear unit with MB adapter.......................................................................... 23
5.3 Mounting drive elements on a solid shaft .............................................................................................................23
5.4 Mounting drive elements on a flange shaft........................................................................................................... 24
5.5 Mounting the gear unit on the machine................................................................................................................26
5.6 Tightening torques................................................................................................................................................. 28
6 Commissioning ........................................................................................................................................................ 29
6.1 Before commissioning............................................................................................................................................ 29
6.2 During commissioning............................................................................................................................................ 29
7 Servicing.................................................................................................................................................................. 30
7.1 Cleaning ................................................................................................................................................................. 30
7.2 Inspection .............................................................................................................................................................. 30
7.3 Remedying faults ................................................................................................................................................... 31
7.3.1 Troubleshooting faults.......................................................................................................................... 31
7.4 Servicing................................................................................................................................................................. 31
7.5 Service.................................................................................................................................................................... 32
8 Removal and disposal.............................................................................................................................................. 33
8.1 Disassembly ........................................................................................................................................................... 33
8.2 Disposal.................................................................................................................................................................. 33

1 | User information
4
10/2019 | ID 443149_en.00
1 User information
This documentation is a part of the product. It applies to products in the standard design according to the corresponding
STOBER catalog.
1.1 Storage and transfer
As this documentation contains important information for handling the product safely and efficiently, it must be stored in
the immediate vicinity of the product until product disposal and be accessible to qualified personnel at all times.
Also pass on this documentation if the product is transferred or sold to a third party.
1.2 Original language
The original language of this documentation is German; all other language versions are derived from the original language.
1.3 Formatting conventions
Orientation guides in the form of signal words are used to emphasize specific information so that you are able identify it in
this documentation quickly.
Safety notes indicate special risks when handling the product and are accompanied by relevant signal words that express
the extent of the risk. In addition, warning notes for possible property damage and useful information are also indicated by
signal words.
DANGER!
Danger
This word with a warning triangle indicates that there is a considerable risk of fatal injury
▪ if the stated precautionary measures are not taken.
WARNING!
Warning
This word with a warning triangle means there may be a considerable risk of fatal injury
▪ if the stated precautionary measures are not taken.
CAUTION!
Caution
This word with a warning triangle indicates that minor personal injury may occur
▪ if the stated precautionary measures are not taken.
ATTENTION!
Notice
This indicates that damage to property may occur
▪ if the stated precautionary measures are not taken.

1 | User information
10/2019 | ID 443149_en.00
5
Information
Information indicates important information about the product or serves to emphasize a section in the documentation that
deserves special attention from the reader.
Embedded warning information
Embedded warning information is integrated directly into the instruction manual and is structured as follows:
SIGNAL WORD! Type of hazard, its cause and possible consequences of disregarding it! Measures for avoiding the hazard.
Signal words in embedded warning information have the same meaning as in the normal warning information described
previously.
1.4 Terms
This documentation describes both STOBER gear units and gear components of STOBER geared motors. For reasons of
clarity, the collective term drives is used for these.
1.5 Supporting documents
Separate documents apply to the drive components which can be attached to STOBER gear units, depending on the design.
These documents can be found by entering the serial number of the gear unit at https://id.stober.com or by scanning the
QR code on the nameplate of the gear unit.
Alternatively, you can find supporting documents at http://www.stoeber.de/en/downloads/. Enter the ID of the
documentation in the Search... field:
Drive components Operating manual ID
LM Lean motor 443048_en
EZ synchronous servo motor 443032_en
MB motor adapter with brake 441846_en
1.6 Limitation of liability
This documentation was created taking into account the applicable standards and regulations as well as the current state of
technology.
STOBER shall assume no responsibility for damage resulting from failure to comply with the documentation or from use
that deviates from the intended use of the product. This is especially true for damage caused by individual technical
modifications to the product or projecting and operation of the product by unqualified personnel.
1.7 Product names and brands
Product names that are registered as brands are not specifically identified in this documentation. Existing property rights
(patents, trademarks, protection of utility models) are to be observed.
1.8 Copyright notice
Copyright © STOBER. All rights reserved.

2 | General safety instructions
6
10/2019 | ID 443149_en.00
2 General safety instructions
There are risks associated with the product described in this documentation that can be prevented by complying with the
described warning and safety instructions as well as the included technical rules and regulations.
2.1 Intended use
The drives described in this documentation are intended for installation in industrial machines or systems.
The following are considered non-intended use:
§Any overloading of the drives
§Operation in ambient conditions that deviate from those described in the corresponding technical documentation
§Modifying or refitting the drives
§Using the drives for an application other than that defined during project configuration
Commissioning the machine in which the drives are installed is prohibited until it has been determined that the machine
corresponds to regional laws and guidelines. In particular, the (Machinery) Directive 2006/42/EC is to be observed in the
respective scope.
Operation of the drives in potentially explosive atmospheres is prohibited, unless they are expressly designed for this.
2.2 Requirements for personnel
All mechanical tasks that arise during the assembly, commissioning, maintenance and removal of the product may be
performed only by specialized personnel who hold a corresponding qualification in the field of metal technology.
All electrical tasks that arise during the assembly, commissioning, maintenance and removal of the product may be
performed only by electricians who hold a corresponding qualification in the field of electrical engineering.
Tasks that arise during transport, storage and disposal may be performed by personnel who have been instructed in the
suitable method for doing so.
Furthermore, personnel who handle the product must carefully read, understand and observe the valid regulations, legal
requirements and applicable basic rules as well as this documentation and the safety instructions it contains.
2.3 Prevention of personal injury
2.3.1 Mechanical hazards
WARNING!
Dangerous movements of machine parts!
Moving machine parts can cause serious injuries or even death!
üBefore starting the motor or drive:
▪ Install all protective devices necessary for operation.
▪ Make sure that no one is standing in the danger area or able to enter it unchecked.
▪ Leave the danger area.

2 | General safety instructions
10/2019 | ID 443149_en.00
7
WARNING!
Sinking or falling of gravity-loaded axes or vertical axes after switching off the motor due to gravity!
Falling gravity-loaded axes or vertical axes can cause serious injuries or even death!
▪ Be aware that the holding brake of the motor does not offer sufficient safety for persons that are in the hazard area
of gravity-loaded axes or vertical axes.
▪ Move gravity-loaded axes or vertical axes to their lowest position and lock or brace them mechanically before
allowing people to enter the danger area.
WARNING!
Unsecured feather keys or drive elements can be thrown due to the rotation of the input shaft!
Flying metal parts can cause serious injuries!
▪ Mount the provided drive elements properly or remove them before a test run.
2.3.2 Thermal hazards
CAUTION!
The surface of the drive can reach temperatures over 65°C during operation!
Touching the hot surface of the drive can cause severe skin burns!
▪ Do not touch the drive during operation or immediately afterward.
▪ Allow the drive to cool sufficiently before carrying out work on the drive.
▪ Wear protective gloves when working on the drive.
2.4 Prevention of property damage
ATTENTION!Damage to bearings and shafts due to improper assembly! Never use force when installing
machine elements with fittings, e.g. hitting power transmission elements, shafts or the motor or gear unit housing with a
hammer, but rather install them in accordance with the following instructions.
ATTENTION!Shaft seal rings can be damaged by solvents! Prevent shaft seal rings from coming into contact with
solvents when cleaning and degreasing unpainted surfaces.

3 | Product description
8
10/2019 | ID 443149_en.00
3 Product description
In this chapter, you can find product details that are relevant for assembly, commissioning and maintenance. Detailed
technical data on your gear unit/geared motor can be found in the order confirmation. You will find more product
information and dimensional drawings in the corresponding catalog (Additional documentation [}15]). The respective
separate technical documentation applies to the attached motors.
3.1 Basic structure of P, PE
Tab. 1: Basic structure of a P532 two-stage gear unit (left) and PE411 single-stage gear unit (right)
1 Solid shaft 2 Feather key (if present)
3 Output flange 4 Gear unit housing
5 Nameplate 6 ME motor adapter

3 | Product description
10/2019 | ID 443149_en.00
9
3.2 Basic structure of PH, PHQ, PHV
Tab. 2: Basic structure of a PH431 single-stage gear unit (left) and PHQ1232 two-stage gear unit (right)
1 Flange shaft 2 Output flange
3 Gear unit housing 4 Nameplate
5 ME motor adapter
3.3 PE type designation
In this chapter, you can find an explanation of the type designation for the gear unit types mentioned in the title.
Sample code
PE 4 1 2 S G R 0200 ME
Explanation
Code Designation Design
PE Type Planetary gear unit
4Size 4 (example)
1Generation Generation 1
1
2
Stages Single-stage
Two-stage
SHousing Standard
G
P
Shaft Solid shaft without feather key
Solid shaft with feather key
RBearing Standard bearing
0200 Transmission ratio (i x 10) i = 20 (example)
ME
MEL
Motor adapter Motor adapter with EasyAdapt coupling
Motor adapter with EasyAdapt coupling for large motors

3 | Product description
10
10/2019 | ID 443149_en.00
3.4 P2 – P9, PH3 – PH8, PHQ4 – PHQ8 type designation
In this chapter, you can find an explanation of the type designation for the gear unit types mentioned in the title.
Sample code
P 4 3 2 S G S S 0100 ME
Explanation
Code Designation Design
P
PH
PHQ
Type Planetary gear unit with solid shaft
Planetary gear unit with flange shaft
Planetary gear unit with flange shaft
4Size 4 (example)
3Generation Generation 3
1
2
3
Stages Single-stage
Two-stage
Three-stage
SHousing Standard
F
G
P
Shaft Flange shaft (PH, PHQ gear unit)
Solid shaft without feather key (P gear unit)
Solid shaft with feather key (P gear unit)
S
D
Z
V
Bearing Standard bearing
Axially reinforced bearing (P gear unit)
Radially reinforced bearing (P gear unit)
Reinforced bearing (PH/PHQ gear unit)
S
R
Backlash Standard
Reduced
0100 Transmission ratio (i x 10) i = 10 (example)
ME
MEL
MF
MFL
MB
Motor adapter Motor adapter with EasyAdapt coupling
Motor adapter with EasyAdapt coupling for large motors
Motor adapter with FlexiAdapt coupling
Motor adapter with FlexiAdapt coupling for large motors
ServoStop motor adapter with brake
EZ
LM
Motor EZ synchronous servo motor
LM Lean motor

3 | Product description
10/2019 | ID 443149_en.00
11
3.5 PH9 – PH10, PHQ9 – PHQ12, PHV9 – PHV10 type
designation
In this chapter, you can find an explanation of the type designation for the gear unit types mentioned in the title.
Sample code
PH 9 3 2 F 0200 ME
Explanation
Code Designation Design
PH
PHQ
PHV
Type Planetary gear unit with flange shaft
9Size 9 (example)
3Generation Generation 3
FShaft Flange shaft
0200 Transmission ratio (i x 10) i = 20 (example)
ME
MEL
MF
MFL
MB
Motor adapter Motor adapter with EasyAdapt coupling
Motor adapter with EasyAdapt coupling for large motors
Motor adapter with FlexiAdapt coupling
Motor adapter with FlexiAdapt coupling for large motors
ServoStop motor adapter with brake
EZ
LM
Motor EZ synchronous servo motor
LM Lean motor
3.6 Nameplate
An example gear unit nameplate is explained in the figure below.
1
2
345678910
Code Designation
1 Name of manufacturer
2 Type designation
3 Gear ratio of the gear unit
4 Serial number of the gear unit
5 Dimensions of the motor adapter (diameter of pilot/bolt circle/motor shaft)

3 | Product description
12
10/2019 | ID 443149_en.00
Code Designation
6 Customer-specific data
7 Lubricant specification
8 Lubricant fill volume
9 Date of manufacture (year/calendar week)
10 QR code (link to product information)
3.7 Mounting positions
The planetary gear unit can be installed in any mounting position. This does not include PHQ three-stage planetary gear
units, for which the lubricant fill volume depends on the mounting position. These planetary gear units must be installed in
the mounting position that was specified in the order.
EL1 EL5 EL6
Horizontal output Vertical downward output Vertical upward output
Tab. 3: Mounting positions of a PHQ three-stage planetary gear unit
3.8 Direction of rotation
The input and output shafts of the planetary gear unit rotate in the same direction.
Fig.1: Direction of rotation, using a P planetary gear unit as an example

3 | Product description
10/2019 | ID 443149_en.00
13
3.9 Reverse operation
If you want to operate the gear unit in cyclic reverse operation, observe the following information to ensure the lubrication
of the circulating gearing parts:
§PE planetary gear units can be operated in reverse operation without any additional steps.
§In vertical mounting positions (output shafts pointing up or down), the orientation of the output shaft is unimportant
when installing the machine.
§In horizontal mounting positions, the output shaft for P/PH/PHQ/PHV planetary gear units must be oriented as follows
when installing the machine. The marks or the position of the feather key indicate the center position of reverse
operation.
Fig.2: Orientation of the feather key (1) during reverse operation of P planetary gear units with solid shaft and feather key
Fig.3: Orientation of the mark (1) during reverse operation of P planetary gear units with shaft without feather key
Fig.4: Orientation of the mark (1) during reverse operation of PH/PHQ/PHV planetary gear units with flange shaft

3 | Product description
14
10/2019 | ID 443149_en.00
3.10 Ambient conditions
Standard ambient conditions for transport, storage and operation of the gear unit are described in this chapter. Deviating
ambient conditions for special designs are specified in the order confirmation. Ambient conditions for motors attached to a
gear unit can be found in the technical documentation of the motor.
Feature Description
Transport/storage surrounding temperature −10 °C to +50 °C
Surrounding operating temperature 0 °C to +40 °C
Installation altitude ≤ 1000 m above sea level
Notes
In order to prevent corrosion damage and damage to the shaft seal rings, protect the drive from the following influences:
§Environments with harmful oils, acids, gases, vapors, dust or radiation
§Extreme temperature fluctuations with high humidity
§Thawing or icing
§Strong UV radiation (e.g. direct sunlight)
§Presence of salt spray
§Sparks
In potentially explosive atmospheres, only gear units in an explosion-proof design in accordance with (ATEX) Directive
2014/34/EU may be used. Separate documentation applies to the explosion-proof design.
3.11 Other product features
Other features of gear units in the standard design can be found in the following table.
Feature Description
Maximum permitted gear unit temperature (on the surface
of the gear unit)
≤ 90°C
Paint Black RAL 9005
Lubricant Synthetic; for specification and quantity, see nameplate
Ventilation Gear unit housing closed on all sides, no ventilation
provided
Weight See order documents
Protection class IP65
With a geared motor, keep in mind that the motor protection class may be lower.

3 | Product description
10/2019 | ID 443149_en.00
15
3.12 Additional documentation
You will find more information about the product at http://www.stoeber.de/en/downloads/. Enter the ID of the
documentation in the Search... field.
Product combination Catalog title ID
Gear unit + MB motor adapter with brake Motor adapters with brake 441904
Gear unit + ME/MEL/MF/MFL motor adapter Servo gear units 443054_en
Gear unit + EZ synchronous servo motor EZ synchronous servo geared motors 442437_en
Gear unit + LM Lean motor Lean motors 443016_en
If you have questions about your drive that are not answered by this documentation, please contact STOBER Service
(Service [}32]).

4 | Transport and storage
16
10/2019 | ID 443149_en.00
4 Transport and storage
STOBER products are packaged carefully and delivered ready for installation. The type of packaging depends on the product
size and the transport method.
Observe the following information during transport and storage:
§Inspect the delivery for any transport damage immediately upon receiving it and report any transport damage
immediately. Do not put damaged products into operation.
§Check your delivery for completeness using the delivery note and report any missing parts to the supplier.
§Transport and store the product in the original packaging in order to protect it from damage. Remove the original
packaging and transport safety devices shortly before assembly.
Ambient conditions
The ambient conditions for transport and storage can be found in the chapter Ambient conditions [}14].
4.1 Transport
WARNING!
Suspended loads!
Loads that become loose and fall during the lifting process can cause serious injuries or even death!
▪ Observe the following instructions.
▪ Cordon off the danger zone and ensure that no one stands under the suspended loads.
▪ Wear safety shoes.
Lifting and transporting the drive may require lifting gear (e.g. a crane), depending on the weight. The weight of your drive
is specified in the accompanying delivery documents.
Lift and transport the drive as follows:
§Use lifting gear with a sufficient lifting capacity for the weight of the drive.
§Run hoist slings directly around the drive housing and secure the hoist slings from slipping.
In order to prevent the drive from falling or getting damaged during transport, observe the following:
§Do not lift or fasten the drive on the output shaft or attached parts.
§Fasten the motor installed on the gear unit as well and make sure that there is no diagonal pull.
4.2 Storage
Store the drive in a dry, dust-free environment in the original packaging at a storage temperature between −10°C and
+50°C.
4.2.1 Long-term storage
If you would like to store the drive for longer than 6 months, take the following steps to prevent corrosion damage:
1. Apply a suitable corrosion protection agent to unpainted surfaces, such as shaft ends or flange contact surfaces.
2. Completely fill the gear unit with lubricant. The lubricant specification can be found by entering the serial number of
the gear unit at https://id.stober.com or by scanning the QR code on the nameplate of the gear unit.
Before commissioning the gear unit, reduce the lubricant fill volume to the fill volume that is specified on the nameplate of
the gear unit.

5 | Installation
10/2019 | ID 443149_en.00
17
5 Installation
This chapter contains information on how to correctly mount standard STOBER drive designs and avoid injury to persons or
damage to property. Differing information for customer-specific designs is included in the order documents.
Observe the technical documentation of the motor for the assembly and electrical connection of the motor.
Inspect the drive for transport or storage damage. If the drive is damaged, do not install it and contact the STOBER Service
department.
The following tools and equipment are required for mounting the drive:
§If necessary due to the overall weight, lifting gear with appropriate fastening elements and sufficient lifting capacity
§Open-end wrench set
§Socket wrench set
§Long hexagon insert set
§Torque wrench
§Grease
§Cleaning agent or solvent
Information about the specific tools or equipment can be found in the respective chapter.
5.1 Cleaning agent and solvent
Upon delivery, unpainted surfaces of the drive are protected by a corrosion protection agent. The corrosion protection
agent must be removed from contact surfaces such as shaft ends and flange contact surfaces before assembly. STOBER
recommends removing the corrosion protection with a suitable cold cleaner (e.g. Carlofon Autocleaner) which, in contrast
to volatile solvents, is almost odorless and does not weaken the sealing lips of the shaft seal rings. Otherwise, you can use
commercially available solvents.
Be aware that all surfaces that come into contact with each other in a clamp connection must be degreased with a cold
cleaner or solvent for error-free torque transmission. Additional information can be found in the following chapters.
ATTENTION!Shaft seal rings can be damaged by solvents! Prevent shaft seal rings from coming into contact with
solvents when cleaning and degreasing unpainted surfaces.
5.2 Mounting the motor on a gear unit
This chapter contains information on how to mount a motor on a STOBER gear unit with a motor adapter. The motor
adapter type of your gear unit can be found on the nameplate of the gear unit. STOBER recommends using a motor with a
shaft without a feather key, since the keyway negatively affects smooth operation.
If you have a STOBER geared motor, you can skip this chapter.
ATTENTION!Damage to encoders, bearings and shafts due to improper assembly! Never use force when
mounting drive elements with fittings, e.g. hitting drive elements, shafts or the motor or gear unit housing with a hammer,
and instead install them in accordance with the instructions in the documentation.
Information
To make mounting the motor easier, stick to the following principal assembly order when possible:
▪ First mount the motor on the gear unit, then the geared motor on the machine
▪ Mount the motor on the gear unit with the motor shaft pointing down vertically in order to prevent unfavorable
shifting and tilting of the motor shaft.

5 | Installation
18
10/2019 | ID 443149_en.00
5.2.1 Permitted tilting torques at the gear unit input
If you mount a STOBER gear unit on the machine in a horizontal mounting position, check that the permitted tilting torque
is not exceeded on the gear unit input before mounting the corresponding motor. Information on the permitted tilting
torque can be found in the corresponding catalog (Additional documentation [}15]).
5.2.2 Tolerances for the add-on motor
This chapter describes tolerances for motors that are required for assembly on a STOBER gear unit with motor adapter.
Dimensional drawings of the motor adapter can be found in the corresponding catalog (Additional documentation [}15]).
Tolerances for shafts in accordance with DIN 748-1
Diameter [mm] Tolerance
≤ 50 ISO k6
> 50 ISO m6
Tolerances for centering diameter on the motor flange in accordance with EN 50347
Centering diameter [mm] Flange size [mm] Tolerance
≤ 230 65 – 300 ISO j6
> 230 350 – 500 ISO h6
Tolerances for radial runout, axial runout and concentricity in accordance with IEC 60072-1 (normal class)
Symbol Unit Explanation
kx µm Concentricity of the flange centering in relation to the shaft
pl µm Axial runout of the flange mounting surface in relation to the shaft
r µm Radial runout of the shaft end

5 | Installation
10/2019 | ID 443149_en.00
19
∅d [mm] r [µm]
d ≤ 10 30
10 < d ≤ 18 35
18 < d ≤ 30 40
30 < d ≤ 50 50
50 < d ≤ 80 60
Centering diameter [mm] Flange size kx [µm] pl [µm]
50 – 95 65 – 115 80 80
110 – 130 130 – 165 100 100
250 – 450 300 – 500 125 125
5.2.3 Mounting the motor on a gear unit with ME/MEL/MF/MFL adapter
This chapter describes the assembly of a motor on a STOBER gear unit with an ME/MEL/MF/MFL motor adapter.
Prerequisites
§Dimensional tolerances of the motor correspond to the requirements in the chapter Tolerances for the add-on motor
[}18]
§The permitted tilting torque on the gear unit input is not exceeded (see Permitted tilting torques at the gear unit input
[}18])
§Four screws of strength class 8.8 are available for mounting the motor on a gear unit. The minimum screw depth for
these screws is 1.6x the nominal diameter of the screw
§The necessary tools and aids are available (see Installation [}17])
§The information in the chapter Cleaning agent and solvent [}17] is observed
Procedure
In order to prevent unfavorable shifting or tilting of the motor shaft, STOBER recommends mounting the motor on the gear
unit with the motor shaft pointing down vertically.
1. Position the gear unit (5), if necessary with the aid of lifting gear, on a suitable support (1) so that the motor can be
mounted in a vertical position. Make sure that the weight of the gear unit is not supported on the output shaft.
2. Remove the transport cover of the motor adapter.
3. If a feather key is installed on the motor shaft, remove it.
4. Remove all corrosion protection from the motor shaft and contact surfaces of the motor and motor adapter.
5. Carefully remove any lubricant from the inner hole of the clamping hub (15) and, if available, the inner and outer
surface of the clamping sleeve (6) for the motor shaft.
6. Unscrew the threaded sealing plug (13).
7. Turn the clamping hub so that the locking screw (11) can be turned over the bore for the threaded sealing plug (13),
guide the hexagon insert (3) through the bore and insert it into the hexagon socket of the locking screw.
8. If a clamping sleeve (6) is necessary, insert the clamping sleeve into the inner hole of the clamping hub (15) as far as it
will go and turn the clamping sleeve so that the slot of the clamping sleeve coincides with the slot of the clamping hub
(10).

5 | Installation
20
10/2019 | ID 443149_en.00
9. If necessary, use two suitable attachment points to secure the motor with the lifting gear so that the motor shaft is
pointing down vertically.
10. Turn the motor in an axial position to the gear unit so that the nameplates are on the same side, if possible, and can
also be read after installation in the machine.
11. If the motor shaft has a keyway, position the motor shaft so that the keyway faces the slot of the clamping hub (10).
12. An elastic bellow coupling is installed in the MF/MFL motor adapter that can assume a slightly tilted position, as long
as the clamping hub is not connected with the motor shaft. Correct any existing tilt of the clamping hub before
inserting the motor shaft.
13. Carefully place the motor on the motor adapter (4) and make sure that the motor shaft is inserted (7) in the clamping
hub (15) so that it is centered and not at an angle.
14. If the motor shaft cannot be inserted into the clamping hub, do not use force and instead turn the locking screw (11)
counterclockwise one quarter rotation with the hexagon insert (3) (in this process, the clamping hub widens because
the cross pin (12) locks against the cylinder head of the locking screw). The size of the hexagon insert can be found on
the adhesive label (14) as well as in the following tables.
15. If necessary, repeat the previous step.
16. The contact surfaces of the motor flange and motor adapter flange must fit together without a gap. If this is not the
case, do not use force and instead check the dimensions of the motor.
17. Mount the motor on the motor adapter with screws (9). Tighten the screws evenly, with increasing torque and
alternating diagonally. The tightening torque can be found in the chapter Tightening torques [}28].
18. Insert the torque wrench (2) in the hexagon insert (3) and tighten the locking screw (11). The corresponding tightening
torque can be found in the following table and on the adhesive label on the motor adapter.
19. If the motor flange does not fully cover the bores or openings of the motor adapter, seal off the openings with a
suitable sealant. This maintains the protection class of the gear unit so that dust and water cannot get into the interior
of the motor adapter.
20. Plug the access hole with the threaded sealing plug (13) by screwing it in until it is flush with the surface of the motor
adapter.
