Stokke iZi Go by BeSafe User manual

Stokke®iZi Go™by BeSafe®
USER GUIDE UK/IE
GEBRAUCHSANWEISUNG DE
BRUGSANVISNING DK
KÄYTTÖOHJE FI
NOTICE D’UTILISATION FR
GEBRUIKSAANWIJZING NL
BRUKSANVISNING NO
BRUKSANVISNING SE

Warnings............................................................................................... 4
Introduction.......................................................................................... 9
Achtung................................................................................................. 22
Einleitung.............................................................................................. 28
Advarsel ................................................................................................ 42
Introduktion.......................................................................................... 47
Varoitus ................................................................................................. 60
Johdanto............................................................................................... 65
Avertissement....................................................................................... 78
Introduction.......................................................................................... 84
Waarschuwing...................................................................................... 98
Inleiding................................................................................................ 103
Advarsel ................................................................................................ 116
Introduksjon.......................................................................................... 121
Varning.................................................................................................. 134
Introduktion.......................................................................................... 139
USER GUIDE
Rearward-facing
Stokke®iZi Go™by BeSafe®
ECE R44 04
Tested and approved
Group Weight Age
0+ 0-13 kg 0-12 m
UK/IE
UK/IE
DE
DK
FI
FR
NL
NO
SE
User instruction.
Play movie.

Stokke® iZi Go™ by BeSafe® Stokke® iZi Go™ by BeSafe®
4 5UK/IE UK/IE
WARNING WARNING
WARNING
• It is important that you read this user manual BEFORE installing your seat. Incorrect
installation could endanger your child.
• KEEP this user manual with the seat for later use.
• It is NOT ALLOWED to mount the seat in a front passenger seat
WITH AN ACTIVATED AIRBAG.
• The seat can only be installed rearward-facing with a 3-point
car belt, approved according to UN/ECE Regulation No.16 or other equivalent
standards.
• Stokke® iZi Go™ by BeSafe® is approved for group 0+, rearward-facing from 0-13 kg.
• If the child weighs over 13 kg or his shoulder height reaches above the highest
position of the shoulder straps, you will need to change to a group 1 seat.
• The child must always be secured with the internal harness straps when seated
in the child seat.The same applies to carrying the seat and when using in
combination with a stroller.
• The seat cover contains magnets in the areas with the orange indications. Magnets
can inuence electronic equipment such as pacemakers.
• The seat must always be replaced following an accident. Although it may look
undamaged, in the event of another accident, it might not be able to protect your
child as well as it should.
• Prevent the seat from becoming trapped or weighed down by luggage, seats and/
or slamming doors.
• Before every use, make sure the harness is not damaged or twisted.
• Make sure you can t no more than one nger between the harness and your baby (1cm).
• Make sure the car safety belt buckle runs in a straight line and stays below the belt
hook of the seat.
WARNING
NO
OK
hip belt
shoulder
belt

Stokke® iZi Go™ by BeSafe® Stokke® iZi Go™ by BeSafe®
6 7UK/IE UK/IE
WARNING WARNING
WARNINGWARNING
• DO NOT use the seat positioned in the vehicle, with the carrying handle in a downward
position.The handle must be in the vertical carrying position while driving.
• Only use the seat on forward facing seats.
• DO NOT attempt to dismantle, modify or add any part to the
seat.The warranty will not be honoured if non-original parts or accessories are
used.
• DO NOT use anything, such as a cushion, to raise the child seat o the passenger
seat of the vehicle. In the event of an accident the seat will not be able to protect
your child properly.
• Make sure all passengers are informed about how to release your child in case of
emergency.
• An unoccupied child seat should always be fastened in the vehicle.
• Make sure luggage or other objects are properly secured. Unsecured luggage may
cause severe injuries to children and adults in the event of an accident.
• Never use the seat without the cover.The cover is a safety feature and may only be
replaced by an original BeSafe cover.
• We use EPS foam under the cover. Do not push or pull too hard against the foam,
since you might damage the foam.
• Do not use any aggressive cleaning agents; these may harm the construction
material of the seat.
• BeSafe advises that child seats should not be bought or sold second-hand.
• DO NOT use the seat for longer than 5 years.The quality of the material may
change with ageing.
• DO NOT use at home on a table or worktop, if your child is seated in the seat.
• When the child seat is mounted in the car check all the areas where the child seat
might touch the interior.We recommend using a (BeSafe) protection cover in
these places to avoid cuts, marks or discolouration on the interior of the vehicle,
especially in vehicles with leather or wooden interior.
• Make sure both 3-point-belt and child safety belt are tightened rmly, in order to
prevent any unwanted dislocation of child or the seat. Check frequently.
• All passengers must be fastened by a safety belt.
• Never use the two wheel function when the seat is attached to a Stokke® Xplory®.
• Always make sure the seat is properly attached when used on a stroller from Stokke.
Failure to attach properly could result in serious injury or death to your child.
• When the seat is attached to the chassis of a stroller from Stokke, the combination
should never be lifted up by the car seat.
WARNING

Stokke® iZi Go™ by BeSafe® 9 Stokke® iZi Go™ by BeSafe®
8WARNING
WARNING
• Always remove your child from the seat while making adjustments to the stroller
and/or the car seat.
• Always make sure the carrying handle is in the carrying position before carrying.
• If in doubt, consult either the child restraint manufacturer or the retailer.
(EN 12790-2009): Using the seat as a reclined cradle
• IMPORTANT! Keep this manual for future reference.
• Never leave the child unattended.
• Do not use the seat as reclined cradle once your child can sit unaided.
• This seat is not intended for prolonged periods of sleeping.
• It is dangerous to use this seat on an elevated surface.
• Always use the restraint system.
WARNING Do not use this product until you have thoroughly read and understood this user
guide. Stokke® advises that child seats shall not be bought or sold second hand.
Many seats sold through local advertising and car boot sales have been found to be
dangerous. DO keep this user guide in the pocket of the seat.
Contents
Warnings................................................................................................................... 4
Introduction.............................................................................................................. 9
Crucial parts.............................................................................................................. 10
Installation in the car................................................................................................ 11
Fitting your child in the Stokke® iZi Go™ by BeSafe®.............................................. 13
Removing the Stokke® iZi Go™ by BeSafe®............................................................. 17
Removing and retting the cover............................................................................. 17
Cleaning instructions................................................................................................ 17
Using the Stokke® iZi Go™ by BeSafe® with a stroller from Stokke......................... 18
Guarantee.................................................................................................................. 20
Point of Sale information.......................................................................................... 20
Introduction
EN 12790-2009
WARNING
UK/IE UK/IE
