Stratasys CleanStation DT3 User manual

DOC-01121 Rev. A
DT3 CLEANSTATION
USERGUIDE

DT3 CleanStation
DOC-01121 Rev. A 1-2
Copyright
Copyright©2015StratasysLtd.Allrightsreserved.
ThisdocumentationcontainsproprietaryinformationofStratasysLtd.This
informationissuppliedsolelytoassistauthorizedusersofthiscleaningsystem.
Nopartofthisdocumentmaybeusedforotherpurposes,anditmaynotbe
disclosedtootherparties.
Thespecificationsonwhichthisdocumentisbasedaresubjecttochangewithout
notice.
Nopartofthisbookmaybereproducedinanyformorbyanymeans,norstored
inadatabaseorretrievalsystem,withoutpriorpermissioninwritingfrom
StratasysLtd.
IfthisdocumentisdistributedasaPDFfile,youmayprintitforinternaluse.
October2015
DOC-01121Rev.A
Trademarks
StratasysisaregisteredtrademarkofStratasysLtd.
Allnamesofproductsandservicescitedinthisbookaretrademarksorregistered
trademarksoftheirrespectivecompanies.

DT3 CleanStation
DOC-01121 Rev. A 2-3
Contents
1 Introduction 4
1.1AboutthisGuide 4
1.2ForMoreInformation 4
2 Specifications 5
3 Safety Guidelines 6
3.1AlkalineCleaningSolutionSafetyInstructions 6
3.1.1PreparingtheAlkalineCleaningSolution 6
3.2WasteDisposal 6
4 Installation 7
4.1SelectingaLocation 7
4.2ConnectingtheDrainageHose 7
5 Operating Instructions 8
5.1FillingtheTank 8
5.2AddingAlkalineCleaningSolutiontotheTank 8
5.3PoweringOntheDT3CleanStation 9
5.4UsingtheControlPanel 9
5.4.1SettingtheTimer 10
5.4.2StartingtheCleaningCycle 10
5.4.3StoppingtheCleaningCycle 10
5.5RemovingPrintedModels 10
5.6DrainingtheTank 11
5.6.1DrainingWater 11
5.6.2DrainingAlkalineCleaningSolution 11
6 Maintenance 12
6.1GeneralMaintenance 12
6.2DisassemblingtheUnitforCleaning 12
6.2.1CleaningthePumpSuctionStrainer 12
6.2.2CleaningtheManifold 14
6.3Re-AssemblingtheCleaningStation 14
7 Troubleshooting 15
7.1TheControlPanelisBlankortheCleaningStationDoesNotRun 15
7.2PrintedModelsTakeaLongTimetoClean 16
7.3ErrorMessagesontheControlPanel 16
7.4TheDT3CleanStationStopsMid-Cycle 16

DT3 CleanStation
DOC-01121 Rev. A 3-4
1 Introduction
TheDT3CleanStationusesagitationandwater-flowtorapidlydissolvesoluble
supportmaterialfromprintedpartsandmodels.
1.1 About this Guide
Theinformationandrequirementsprovidedinthisdocumentensureproper
installationandoperationoftheDT3CleanStation.Thecustomerisresponsible
forpreparingthesiteasdescribedinthisdocument.Ifyouhaveanyquestions
abouttheinformationinthisdocument,contactyourStratasysrepresentative.
1.2 For More Information
FormoreinformationaboutStratasys,itstechnologies,products,andapplication
methods,visithttp://www.stratasys.com.Ifyouhaveanyquestionsaboutthe
informationpresentedinthisdocument,orifyouhaveanycommentsor
suggestionsforfutureeditions,pleasesendamessageto
[e-mail].

DT3 CleanStation
DOC-01121 Rev. A 3-5
2 Specifications
ThefollowingarethespecificationsoftheDT3CleanStation.
External Dimensions Centimeters Inches
Height 48.9 19.25
Width 59.7 23.5
Depth 54.6 21.5
Internal Dimensions  
Height 27.9 11
Width 31.1 12.25
Depth 25.4 10
Liquid Capacity Liters Gallons
 22.7 6
Weight Kilograms Pounds
Empty 28.6 63
Full 45.4 upto100(includingmodels)
Operating Temperature Celsius Fahrenheit
 4.4°Cto85°C 40°Fto185°F
Electrical Specifications  
PowerConsumption
USA:408watts
Europe:432watts
Japan:440watts
PowerRequirements
USA:110to120VAC,50/60Hz
Europe:220to240VAC50/60Hz
Japan:95to105VAC,50/60Hz
Fuses
USA:fuseclassCC5amp
Europe:fuseclassCC3amp
Japan:fuseclassCC6amp

DT3 CleanStation
DOC-01121 Rev. A 3-6
3 Safety Guidelines
Thefollowinggeneralguidelines,togetherwiththeinstructionsprovided
throughoutthisguide,ensureusersafetywhileoperatingandmaintainingthe
DT3CleanStation.If the system is not operated as specified, the user's
safety might be compromised!
• NeveroperatetheDT3CleanStationwhilethecoverisopen.
• Thepowercableshouldbeconnectedataneasilyaccessibleelectricsocket
neartheDT3CleanStation.
• DonotmovetheDT3CleanStationsothatthepowercablebecomestautor
disconnectsfromthepowersocket.
• AVACgroundfaultinterrupt(RCD)mustbeused.
• OnlyoperatetheDT3CleanStationwhenwearingneoprenegloves,safety
gogglesandaprotectivemask.
• Makesurethattheroomisproperlyventilated.Theventilationsystemshould
changetheairatleastfourtimeseveryhour.
• Removepartswiththesuppliedbasketorwithsteelorplastictongs.Donot
usealuminumtongswhenthecleaningsolutionisintheDT3CleanStation.
• NevermovetheDT3CleanStationwhenthereisliquidinthetank.
• Placingpartsinthetankraisestheliquidlevel.Monitortheliquidlevelofthe
tanktopreventoverflowing.
3.1 Alkaline Cleaning Solution Safety Instructions
Wearthefollowingprotectiveclothingwhenworkingwiththealkalinecleaning
solution:
• safetygoggles
• protectivemask
• nitrilegloves
• bootsorclosedshoes
Dependingonhowyouplantohandlethealkalinecleaningsolution,the
suggestedprotectiveclothinglistedabovemightnotbesufficient.Consult
yourcompanySafetyOfficerbefore handlingthesolution.
3.1.1 Preparing the Alkaline Cleaning Solution
Alwaysaddcausticsodatowater.Neverpourwaterontocausticsoda.Mixingit
withwatergeneratesheatthatcouldigniteothermaterials.SeeDOC-08380,
"WorkingwithAlkalineCleaningSolution".

3.2 Waste Disposal
Fullycuredmodelspresentnospecialsafetyorhealth-relatedissues.However,
checkiflocalregulationsregardcuredandpartiallycuredresinsashazardous
industrialwaste,andcomplywithallapplicableregulationsgoverningtheir
disposal.
Disposeofthealkalinecleaningsolutionaccordingtolocalregulations.

DT3 CleanStation
DOC-01121 Rev. A 3-7
4 Installation
4.1 Selecting a Location
Prepareaninstallationareathatmeetsthefollowingconditions:
• alevelandstablesurface,whichisabletobeartheloadofthecleaningstation
(45.4kg/100lbs)
• nearasinkordrain
• nearapowersocket
Donotplacetheunitsothatthepowercablebecomestightordisconnects
fromthepowersocket.
• atleast15cm(6inches)clearanceoneachside
• roomtemperaturebetween18°Cand25°C(65°F-77°F)
Recommendations:
• anon-slipfloorbecausewatermaydripfromcleanedmodels
• anearbysourceofwater
4.2 Connecting the Drainage Hose
Toconnectthedrainagehose:
1. Connectastandard¾"gardenhosetothehosefittingatthebackoftheunit.

Figure1Drainagevalveandhosefitting
2. Insertthedrainagehoseintoadrain,sink,orcontainer,accordingtolocal
wastedisposalregulations.

DT3 CleanStation
DOC-01121 Rev. A 3-8
5 Operating Instructions
Beforeoperatingthecleaningstation,putonneoprenegloves,mask,andsafety
goggles.
YoucancleanmodelsprintedwithSUP707withwateronly,oryoucanaddan
alkalinesolutiontothewaterforcleaningmodelsprintedwithSUP706.
5.1 Filling the Tank
Tofillthetankwithwater:
1. Closethedrainvalveattherearoftheunit(seeFigure1onthepreviouspage).
2. Disconnectthepowercord.
3. Makesurethatadrainagehoseisproperlyconnected(see"Connectingthe
DrainageHose"onthepreviouspage).
4. Fillthetankuntilthewaterreachesatleast2.54cm(1inch)belowthetopof
thetank.
Thisisapproximately23liters(6gallons).
Warning:
Addingtoomuchwatertothetankwillcauseittooverflow.
Fillthetankuntilatleast2.54cm(1inch)belowthetopofthetank.Ifyoufill
thetankmorethanthis,takeintoaccountthevolumeofthepartstobe
cleanedsothatitdoesn'toverflow.
Thereisawater-levelswitch2.54cm(1inch)belowthetopofthetank.If
thewaterleveldropsbelowthislevel,theDT3CleanStationwillnotpower
on.
5.2 Adding Alkaline Cleaning Solution to the Tank
AnalkalinecleaningsolutionisusedforcleaningmodelsprintedwithSUP706.
Thesolutionispreparedbyaddingsodiumhydroxide(NaOH)andsodium
metasilicate(Na2SiO3)tothewaterinthetank.SeeDOC-08380,"Workingwith
AlkalineCleaningSolution".
Warning:
Handlingthealkalinesolutioncanbedangerous.See"AlkalineCleaning
SolutionSafetyInstructions"onpage6.

DT3 CleanStation
DOC-01121 Rev. A 3-9
5.3 Powering On the DT3 CleanStation
Topower-ontheDT3CleanStation:
1. MakesurethatthepowerswitchonthefrontpanelisintheOff position.

Figure2Controlpanelandpowerswitch
2. Plugthecleaningstationintoanelectricalsocket.
3. Makesurethatthewaterlevelisnolowerthan2.54cm(oneinch)fromthe
topofthetank.
4. Pressthepowerswitchtoturniton.
Tostartthecleaningcycle,see"StartingtheCleaningCycle"onthenext
page.
5.4 Using the Control Panel
YouusethecontrolpaneltooperatetheDT3CleanStation.

Figure3Controlpanel
Warning:
Donotchangethefactorydefaultsettings.DoingsomightdamagetheDT3
CleanStation.Youcanchangethecleaningtime,ifnecessary.
Button Function
Set lPressandreleasetodisplaythewatertemperature.
lPressandholdtodisplaythelowtemperaturepoint.
Infinity lReturnsthedisplaytoHome.
lPressandholdtosetthecleaningtime.
Arrows
lUsetoincreaseanddecreasecleaningtime.
lWiththedisplayintheHomestate,holddowntheSet
buttonandpresstheup/downarrowstoadjustthetime.

DT3 CleanStation
DOC-01121 Rev. A 3-10
5.4.1 Setting the Timer
TheDT3CleanStationispresettorunforfourhours.
Tochangethecleaningtime:
1. PressandholdtheInfinity buttonuntilOPERappearsintheLEDdisplay.
2. PressthedownarrowtodisplayHOUR.
3. PressandholdtheSet buttonwhilepressingtheArrow buttonstoadjustthe
cleaninghours.
4. PressthedownarrowagaintodisplayMIN.
5. PressandholdtheSet buttonwhilepressingtheArrow buttonstoadjustthe
cleaningminutes.
6. PresstheInfinity buttontoexitthemenu.
5.4.2 Starting the Cleaning Cycle
Tostartthecleaningcycle,presstheinfinityanddownbuttons.
5.4.3 Stopping the Cleaning Cycle
TheDT3CleanStationstopsautomaticallywhenthetimercountsdowntozero.
Tomanuallystopthecleaningcycle:
• presstheinfinityanddownbuttons
or—
• turnthepower switchoff
Inthecaseofemergency,alsodisconnectthepowercable.
5.5 Removing Printed Models
Warning:
Alwayswearneoprenesafetygloves,amask,andsafetygoggleswhen
removingprintedmodelsfromtheDT3CleanStation.
1. Liftoutthebasket,orusestainlesssteelorplastictongstoremoveprinted
modelsfromtheDT3CleanStation.
Warning:
NeverusealuminumtongstoremoveprintedmodelsfromtheDT3
CleanStation.
2. Rinsetheprintedmodelsunderrunningwateruntiltheydonotfeelslippery.
3. Drythemodelswithpapertowels,orallowthemtoair-dry.

DT3 CleanStation
DOC-01121 Rev. A 3-11
5.6 Draining the Tank
5.6.1 Draining Water
Todrainwaterfromthetank:
1. Disconnectthepowercord.
2. Makesurethatthedrainagehoseisproperlyconnectedandthatitisdirected
intoasinkorsufficientlylargebucket.
3. Openthedrainagevalve.

Figure4Drainagehoseanddrainagevalve
4. Whenthetankisempty,closethedrainagevalve.
5.6.2 Draining Alkaline Cleaning Solution
Beforehandlingthealkalinesolution,read"AlkalineCleaningSolutionSafety
Instructions"onpage6.
Todrainalkalinesolutionfromthetank:
1. Disconnectthepowercord.
2. Makesurethatthedrainagehoseisproperlyconnectedandthatitisdirected
intoacontainer.
Donot directthedrainagehoseintoasink.
3. Openthedrainagevalve.
4. Disposeofthewasteaccordingtolocalregulations.

DT3 CleanStation
DOC-01121 Rev. A 3-12
6 Maintenance
Warning:
lAlwaysdisconnecttheDT3CleanStationfromtheelectricalsourcebefore
performinganymaintenanceprocedure.
lPutonneoprenegloves.Theremightbecausticsodaresidueintheunitoron
printingmaterialinsideit.
6.1 General Maintenance
• KeeptheDT3CleanStationcleanbywipingitdownwithadampclothafter
use.
• TheDT3CleanStationpumpandmotorarefactory-sealedanddonotrequire
anylubricationorsealreplacement.
6.2 Disassembling the Unit for Cleaning
Ifyounoticeasignificantdecreaseinwatercirculation,theremightbeabuild-up
ofprintingmaterialblockingthepumpsuctionstrainerormanifold.
6.2.1 Cleaning the Pump Suction Strainer
Warning:
Alwayswearneoprenesafetygloves,amask,andsafetygoggleswhen
cleaningthepumpsuctionstrainer.
Tocleanthepumpsuctionstrainer:
1. Removethetanklidanddryit.
2. Inspectthesuctionstrainerandremoveanymaterialdeposits(seeFigure5on
thenextpage.
Ifthesuctionstrainermeshbecomesexcessivelycoatedwithmaterial
deposits,itmightbenecessarytoreplaceit.ContactyourStratasys
representative.
3. Usinga7/16"socket,loosen(butdo not remove)thefour1/4"-20nuts
locatedbehindtheholesatthetopofthejetplate(seeFigure5onthenext
page).

DT3 CleanStation
DOC-01121 Rev. A 3-13
4. Removethejetplatebyliftingit.
5. Drythejetplate.

Figure5Cleaningthesuctionstrainer
Ifyoufindasignificantamountofmaterialdepositsinthesuctionstrainer,it
mightnotbenecessarytoalsocleanthemanifold.Ifso,continuewith"Re-
AssemblingtheCleaningStation"onthenextpage.

DT3 CleanStation
DOC-01121 Rev. A 3-14
6.2.2 Cleaning the Manifold
Tocleanthemanifold:
1. Usinga5/16"socket,loosenthehoseclampconnectingthemanifoldtothe
hose.
2. Usinga3/8"socket,removethetwo10-32nuts.
3. Completelyremovethepipeclampsandmanifold.
4. Removethematerialdepositsblockingthejetsbyeitherpullingitthroughthe
holes,orbyflushingthemanifoldwithwater.
Figure6Cleaningthemanifold
6.3 Re-Assembling the Cleaning Station
1. Re-installthemanifoldandtightenthehoseclamp.
2. Re-installthejetplatebyslidingitbetweenthewashersandthetank.
Note: Donotover-tightenthenuts.

DT3 CleanStation
DOC-01121 Rev. A 3-15
7 Troubleshooting
7.1 The Control Panel is Blank or the Cleaning Station Does
Not Run
• Checkthatthewaterlevelinthetankisnotbelowapproximately2.54cm
(1inch)fromthetopofthetank.
• Checkthatthecleaningstationispluggedintoawallsocketandthatthe
socketislive.
• Checkthatthecleaningstationisturnedon.
• Checkforablownfuse.
Whenreplacingfuses,alwaysdisconnecttheDT3CleanStationfromthe
wallsocketandkeepthepowercableinview,sothatitisnotaccidentally
pluggedbackin.
Tocheckandreplacethefuse:
1. Disconnecttheunitfromthewallsocket.
2. Locatethefusesbehindthetank.
3. Unscrewthefusecovers.

Figure7Fuses
4. Checkthefuseswithanohmmeter.
Note: Ablownfuseusuallyindicatesthatthereisanelectricalfault.
Tochecktheconditionofthewiring:
1. DraintheDT3CleanStationandtipitsothatitisrestingonitsleftside(when
viewedfromthefrontpanel).
2. Inspectthewiresunderthecleanstationandcheckthattheyareundamaged.

DT3 CleanStation
DOC-01121 Rev. A 3-16
7.2 Printed Models Take a Long Time to Clean
• Checkthecleaningsolutionwithahydrometerandchangethesolution,if
necessary.Forinstructionsonusingthehydrometer,seeDOC-08380,
"WorkingwithAlkalineCleaningSolution".
• Checkthatthesuctionstrainerandthemanifoldjetsareclearofmaterial
deposits(see"Maintenance"onpage12).
7.3 Error Messages on the Control Panel
Ifanerrorisdisplayed(suchasErr4orErr5),contactyourStratasys
representative.
7.4 The DT3 CleanStation Stops Mid-Cycle
• Checkthatthewaterlevelisatleast2.54cm(1inch)fromthetopofthetank.
• Checkthatthesuctionstrainerandthemanifoldjetsareclearofmaterial
deposits(see"Maintenance"onpage12).

www. stratasys.com
___
THE 3D PRINTING SOLUTIONS COMPANY
