Stratasys CleanStation DT3 User manual

1STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY1STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
Cleaning Station

2STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY2STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
Cleaning Stations
DT3 Clean Station–System available and used for
SUP707, for 260 platforms
•Active washing cell volume: 31 x 26 x 28 cm^3 ~ 22.5L
•Footprint: 60L x 54W x 49H cm^3
CS2P Clean Station–off-the-shelf system, for 350 & 500 platforms
•Active washing cell volume: 40 x 35 x 40 cm^3 ~ 60L .
•Footprint: 91L x 76W x 100H cm^3
Small size
Large size

3STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY3STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
OUTLINE
•Cleaning Station type
•Introduction and Spec
•Site Prep
•Operating steps
•Hardware overview
•Block Diagram
•Preparing the Solution
•Maintenance
•Installation
•Service

4
DT3

5STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY5STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
•OBJ-01330 - SUPER DT3 CLEAN STATION 95V-105V -JP
•OBJ-01331 - SUPER DT3 CLEAN STATION 120V -NA
•OBJ-01332 - SUPER DT3 CLEAN STATION 220-240V - EMEA
DT3 Part numbers

6STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY6STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
•Table/Counter that can bare 55kg/121lbs. Recommended table/counter high is 80cm,
which brings the DT3 to height of 129cm.
•30cm for maintenance around the DT3
• Pipe ¾ inch for the drain – should be provided by the customer
• Suitable ¾ inch drain for the waste according to the local regulations
•Power:
Site Prep

7STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY7STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
•The DT3 need to be filled with water manually.
•There is a water-level switch 2.54 cm (1 inch) below the top of the tank.
If the water level drops below this level, the DT3 CleanStation will not power
•DT3 can be used both for SU707 and SU706 models
•It is forbidden to use SU705 –Pump Damage
•It is forbidden to use SU706 with heavy or standard grid –Pump Damage
Operating steps

8STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY8STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
Front “panel”
Hardware Overview
Button Name Function
Toggle Timer set
Home Returns to home
Up/Down Arrow Increase/ Decrease time
+Home + Down Start/Stop

9STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY9STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
Back Panel
Hardware Overview

10 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY10 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
Hardware Overview

11 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY11 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
Manifold
Hardware Overview

12 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY12 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
Block Diagram
Fuse Line
Filter
Electrical Box
Pump
Controller
Fuse
R R
220V
12V
220V
110V
100V
R
Thermocouple
Fans
Main sw
Level sw

13 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY13 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
Selecting the location
•Leveled and stable table which can bear 55kg/100lbs
•Near sink or drain
•Near power socket
•Room temp should be 18°C -25°C
Connecting the Drainage Hose
• Connect a standard ¾" garden hose to the hose fitting at the back of the unit
•Insert the drainage hose into a drain, sink, or container, according to local waste disposal regulations.
Installation

14 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY14 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
Powering
•Connect the power cable
•Power on
Fill in the solution according to the
“Working with an Alkaline Cleaning Solution”
Application Note
Installation

15 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY15 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
•All replaceable parts could be reached from the bottom of the DT3
•The back cover panel is attached by push reverts
Servicing DT3

16 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY16 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
Replaceable parts :
•Electrical box
•Controller
•Fans
•Level switches
•Power switches
•Pump
•Fuses
•Back panel with fans
Servicing

17 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY17 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
Servicing

18
CS2P

19 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY19 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
•OBJ-01340 –CS2P 60L Cleaning Station 220V-240V 50/60HZ (EMEA)
•OBJ-01341 - CS2P 60L Cleaning Station 90V-110V 50/60HZ (NA&JP)
Part numbers

20 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY20 STRATASYS / THE 3D PRINTING SOLUTIONS COMPANY
•An industrial washing unit for PJ- soluble 706 support, serving PJ industrial printers- ObjetXXX and
Stratasys J750 (but not only)
•Cleaning cycle duration is pending the models geometry and estimated for full tray/small parts-
~6-8 hours.
•Active washing cell: 16”x18”x14” (401x457x360 mm)= 60 L
•Using Alkaline solution for cleaning SUP706 (Personal Protective Equipment needed)
•Solution preparation, measurement and evacuation is explained in the Application Notes.
• Requires a periodic evacuation of the solution to “Hazard waste” site (for average user ~6-8 weeks)
•Infrastructure needed: connection to water and drain.
Introduction
