Streamline CLAWFOOT N-100-60CFWH-DM Troubleshooting guide

streamlinebath.com
QUESTIONS ON PRODUCT, INSTALLATION, RETURNS? PLEASE CONTACT
(310) [e-mail]
READ ENTIRE INSTALLATION GUIDE
PRIOR TO INSTALLING THE BATHTUB
THIS BATHTUB SHOULD ONLY BE
INSTALLED BY A CERTIFIED PLUMBER
CAUTION! TWO PEOPLE ARE REQUIRED
TO LIFT THE BATHTUB
CLAWFOOT BATHTUB SERIES
OWNER'S MANUAL &
INSTALLATION GUIDE

These products must be installed by a fully insured and licensed plumber only.
Installation of any product by anyone other than fully insured and licensed plumber shall void limited warranty.
We are not responsible for any local code compliance for this product.
Building and plumbing codes may vary state-to-state.
Streamline shall not be held liable for any and all incidental damages or flood caused due to use of this product.
Streamline shall not beheld liable for any and all fees stemming from cost of installation, re-installation, removal,
subsequent damage, or transportation in a case of a product defect.
Please note:
Different bathtub models have different drain & clawfeet models. Please see the next page to determine which
drain or clawfoot model applies to the bathtub model that you have purchased.
Silicone
BathtubClawfeet
Adjustable Key Measuring Tape Safety GlassesPencil Level Bar
PRIOR TO INSTALLING
TOOLS REQUIRED
WHAT'S IN THEBOX
(Pre-installed)
Model A1840-0
DrainDrain
Model: N-DWF-CH
Model: N-DWF-GLD

DRAIN MODEL COMPATIBILITY
FREESTANDING BATHTUB
Model
Model A1840-0
N-DWF-CH
N-DWF-GLD
N-100-60CFWH-DM
N-101-68CFWH-DM
N-102-60CFRD-DM
N-103-68CFBL-DM
N-340-67CFWH-FM
N-341-59CFWH-FM
N-342-63CFWH-FM
N-343-55CFWH-FM
N-860-60CFGR-FM
N-861-68CFWH-FM
N-900-60CFWH-DM
N-901-68CFWH-DM
N-920-60CFWH-FM
N-921-68CFGR-FM
N-1120-59CFBL-DM
N-1121-67CFWH-DM
N-480-61FSHW-FM N-1020-62CFWH-FM
N-1021-62CFRD-FM
N-1080-59CFWH-FM
N-1081-67CFWH-FM
N-1100-59CFWH-FM
N-1101-67CFGR-FM
N-481-61FSBL-FM N-346-55CFWHIN-FM
N-347-59CFWHIN-FM
N-348-63CFWHIN-FM
N-349-67CFWHIN-FM
N-482-61FSRD-FM
N-344-59CFBL-FM
N-345-67CFBL-FM

WHAT'S INCLUDED IN THE CLAWFOOT BOX
Applicable models:
N-CFL11601-CH
N-CFL11601-WH
N-CFL11601-BL
N-CFL11601-GLD
ITEMNo. Qty
Leveling Feet
1
2
3
4
5
6
7
4
4
4
8
4
8
4
Metal Plate
Claw Feet
Washer With Small Diameter
Washer With Large Diameter
Nut
Hex Bolt
ITEMNo. Qty
Leveling Feet
1
2
3
4
5
6
7
8
4
1
4
14
9
12
16
4
Bolts
9 8
Hex Key
Claw Feet
Washer With Small Diameter
Washer With Large Diameter
Nut
Nut With Washer
Metal Plate
123
4567
8 9
123
4567
Applicable models :
N-CFL1775-CH N-CFL11603-BL
N-CFL11603-WH
N-CFLK36572-BL
N-CFLK36572-CH
N-CFLK36572-GLD
N-CFLK35672-WH
N-CFL46572-BL
N-CFL46572-WH
N-CFL46572-GLD
N-CFL46572-CH
N-CFL1775-WH
N-CFL1775-BL
N-CFL1775-GLD
N-CFL1912-CH
N-CFL1912-WH
N-CFL1912-BL
N-CFL1912-GLD
N-CFL11603-CH
N-CFL11603-GLD

DRAIN DIAGRAMS
Pop-Up Cover
ITEMNo.
O Ring
Strainer
Rubber Gasket
Flat Rubber Gasket
Cartridge
Tee
1
2
3
4
5
6
7
Model: A1840-0
Model: N-DWF-CH
Model: N-DWF-GLD
No ITEM Qty
1
2
3
4
5
6
7
8
10
11
12
13
14
15
16
17
16
17
9
Cover
Cover gasket
Cartridge
Strainer
Waste upper gasket
Waste lower gasket
Connector
Coupling nut
Nut
Washer
Tee
Pipe
Overflow body
Tapered rubber gasket
Overflow upper gasket
Overflow plate
Pin Bolt
Taic piece
Flange
1
1
1
1
1
1
1
Qty
1
1
1
1
1
1
1
1
1
3
3
1
1
1
1
1
1
1
1

CLAWFOOT DIRAGRAM
1
2
34
5
2
6
7
1
2
3
3
45
6
6
7
8
ITEMNo. Qty
Leveling Foot
Nut
Clawfoot
Hex Bolt
Washer With Large Diameter
Washer With Small Diameter
Metal Plate
1
2
3
4
5
6
7
1
2
1
1
1
2
1
ITEMNo. Qty
Leveling Foot
Metal Plate
Nut
Bolt
Washer With Small Diameter
Nut With Washer
Clawfoot
1
2
3
4
5
6
7
1
1
3
2
2
4
1
Washer With Large Diameter8 2
Applicable models:
Applicable models :
CFL1775-CH N-CFL11603-BL
N-CFL11603-WH
N-CFLK36572-BL
N-CFLK36572-CH
N-CFLK36572-GLD
N-CFLK35672-WH
N-CFL46572-BL
N-CFL46572-WH
N-CFL46572-GLD
N-CFL46572-CH
CFL1775-WH
CFL1775-BL
CFL1775-GLD
CFL1912-CH
CFL1912-WH
CFL1912-BL
CFL1912-GLD
N-CFL11603-CH
N-CFL11603-GLD
CFL11601-CH
CFL11601-WH
CFL11601-BL
CFL11601-GLD

BATHTUB INSTALLATION
1. Ensure that the floor at the installation site has sufficient floor support and is level.
2. Waterproofing the floor is highly recommended.
3. Determine the location of the drainpipe on the floor by taking measurements of the drain and waste
location underneath the unit. Clean the drain hole area in preparation of setting the drain. The area
should be dry & free from any debris.
4. Remove the bathtub from its box. It is recommended that the bathtub is carried by a minimum of
two people. Ensure to carry and set down the bathtub only in the upside-down position.

5. Gently place the bathtub in the upside-down position on a tarp or cardboard sheet in order to avoid
contact with any rough surface.
6. This step will be attaching the clawfeet to the bathtub. Please check the previous page to see which
clawfeet model is applicable to your bathtub.
a) Take (1) adjustable foot [#1], place it through
the hole in the clawfoot [#3], and screw (1) nut [#2]
at the bottom of the adjustable foot.
a) Take (1) adjustable foot [#1] and put it through (1)
metal plate [#2], using (1) nut [#3] to tighten the
adjustable foot at the bottom.
b) Take (1) bolt [#4] and (1) washer [#5] and
place them through the metal plate [#8].
c) Take the metal plate and slip it snug with the
clawfoot [#3].
b) Take (1) bolt [#4] and (1) nut with washer [#6]
and screw the nut onto the bolt approximately 1/4
of the length of the bolt.
Repeat Step 1 with the second bolt.
c) Take the bolt & nut & screw them into the clawfoot
as shown in the diagram below. Make sure to tighten
the bolt into the clawfoot using the provided hex key.
1
2
3
3
1
2
3
4
5
8
Applicable models :
N-CFL1775-CH
N-CFL1775-WH
N-CFL1775-BL
N-CFL1775-GLD
N-CFL1912-CH
N-CFL1912-WH
N-CFL1912-BL
N-CFL1912-GLD
Applicable models:
N-CFL11601-CH
N-CFL11601-WH
N-CFL11601-BL
N-CFL11601-GLD

d) Place the metal plate on top of the bolts
that are already on the bottom of the bathtub.
d) Remove the safety caps from the bolts on the
bathtub.
e) Place the metal plate [#2] over the bolts on the
bathtub as shown in the diagram below. Make sure
to adjust the metal plate so that it fits snug with the
bolts on the bathtub. This will help to ensure that the
clawfeet are placed correctly and are functioning
properly.
f) Take the clawfoot [#7] & align it with the bathtub,
ensuring that the top top bolts go through the opening
and are fit snug with both the bathtub & metal plate.
g) Take (1) washer [#8] and put it over the bolt
on the bathtub. Then take (1) nut [#3] and place
it over the washer, but do not tighten the bolt
completely. Repeat this step for the other bolt
on the bathtub.
e) Make sure to adjust the metal plate so that it fits
snug with the bolts on the bathtub. This will help to
ensure that the clawfeet are placed correctly and
are functioning properly.
f) Take (2) washers [#6] and place them over the
metal plates on the bathtub.
g) Put (1) nut [#2] over each of the metal bolts and
screw them on. Do not tighten yet.

h) Check to ensure that the clawfoot is aligned
properly with the bathtub and is sitting snug
against the bathtub.
Once this is done, use a wrench to tighten all
of the nuts.
h) Take (1) washer [#5] and place it over the bolt
on the metal plate. Then take (1) nut with washer
[#6] and screw it into the bolt. Do not tighten.
Repeat the same step for the lower bolt. Once
this is done, use a wrench to tighten all of the nuts.
i) Repeat the same procedure for the other 3 legs. i) Repeat the same procedure for the other 3 legs.
The following drain installation is applicable to drain models N-DWF-CH & N-DWF-GLD. Please skip to
step 12 for drain model A-1840-0.
7. Take the strainer, place silicone sealant around it, and then place it into the drain hole ensuring
a tight connection with the drain ell & gasket. Use silicone sealant. DO NOT use plumbers putty to seal.
Silicone
Sealant
Strainer
Gasket
Drain Ell
8. Insert the tailpiece into the trap inlet using the O-ring, coupling nut, & flange. The tailpiece may
need to be cut for proper fit. 1''-2'' of the tail piece shoudl fit inside the trap. Slip the flange over the tailpiece
and slide down to the floor.
O Ring
Coupling Nut
Flange
Trap Inlet
Tailpiece

9. Assemble the tee section to the tailpiece, overflow, & drain ell using the coupling nuts and O-rings
that are provided.
O Ring
Overow Ell
Tee
Coupling Nut
10 . Attach the tapered rubber gasket to the overflow ell. Align the overflow ell with the overflow hole &
secure the drain to the tub with overflow plate and screw provided.
11 . Make sure a watertight seal exists on all bath drain connections.
End home plumbing
Floor
Cover Drain Pipe
Tapered Rubber Gasket
Overow Plate

12. Put the rubber gasket (#4) onto the strainer (#3)
13. Put the rubber gasket and strainer through the pre-drilled drain hole.
14. Put the flat rubber gasket (#5) onto the connector (#7).
15. Connect the connector with the flat rubber gasket, strainer, and rubber gasket and tighten them by
hand. Then use a wrench to tighten the connector.
The installation steps below are for drain model A1840-0.
7
Strainer
Rubber Gasket
A1840-0
Flat Rubber Gasket
Connector
