READ ENTIRE INSTALLATION GUIDE
PRIOR TO INSTALLING THE BATHTUB
THIS BATHTUB SHOULD ONLY BE
INSTALLED BY A CERTIFIED PLUMBER
CAUTION! TWO PEOPLE ARE REQUIRED
TO LIFT THE BATHTUB
PEDESTAL BATHTUB SERIES
OWNER'S MANUAL &
INSTALLATION GUIDE

These products must be installed by a fully insured and licensed plumber only.
Installation of any product by anyone other than fully insured and licensed plumber shall void limited warranty.
We are not responsible for any local code compliance for this product.
Building and plumbing codes may vary state-to-state.
Streamline shall not be held liable for any and all incidental damages or flood caused due to use of this product.
Streamline shall not be held liable for any and all fees stemming from cost of installation, re-installation, removal,
subsequent damage, or transportation in a case of a product defect.
Please note:
Different bathtub models have different drain models. Please see the next page to determine which drain model
applies to the bathtub model that you have purchased.
Silicone
Bathtub
Drain
Adjustable Key
Measuring Tape Safety Glasses
Pencil
Level Bar
PRIOR TO INSTALLING
TOOLS REQUIRED
WHAT'S IN THE BOX
Model: N-DWF-CH
Model: N-DWF-GLD

DRAIN MODEL COMPATIBILITY
FREESTANDING BATHTUB
N-120-60FSWH-DM
N-121-60FSWH-DM
N-DWF-CH
N-DWF-GLD
N-180-60FSWH-DM N-200-60FSWH-FM
N-201-68FSWH-FM
N-960-60FSPRWH-DM
N-961-68FSBL-DM N-1140-60FSWH-FM N-1141-68FSBL-FM

DRAIN DIAGRAMS
No ITEM Qty
1
2
3
4
5
6
7
8
10
11
12
13
14
15
16
17
16
17
9
Cover
Cover gasket
Cartridge
Strainer
Waste upper gasket
Waste lower gasket
Connector
Coupling nut
Nut
Washer
Tee
Pipe
Overflow body
Tapered rubber gasket
Overflow upper gasket
Overflow plate
Pin Bolt
Taic piece
Flange
1
1
1
1
1
1
1
1
1
3
3
1
1
1
1
1
1
1
1
Model: N-DWF-CH
Model: N-DWF-GLD

BATHTUB INSTALLATION
1. Ensure that the floor at the installation site has sufficient floor support and is level.
2. Waterproofing the floor is highly recommended.
3. Determine the location of the drainpipe on the floor by taking measurements of the drain and waste
location underneath the unit. Clean the drain hole area in preparation of setting the drain. The area
should be dry & free from any debris.
4. Remove the bathtub from its box. It is recommended that the bathtub is carried by a minimum of
two people. Ensure to carry and set down the bathtub only in the upside-down position.

5. Gently place the bathtub in the upside-down position on a tarp or cardboard sheet in order to avoid
contact with any rough surface.
6. Loosen the nuts & washers from the metal frame. Adjust the leveling feet to align with the bathtub’s
bottom as well as the floor and then tighten the washer and nuts.
7. Ensure to mark all positions of leveling legs on the floor using a pencil. Move the bathtub into the
desired location near the drainpipe.

8. Take the strainer, place silicone sealant around it, and then place it into the drain hole ensuring
a tight connection with the drain ell & gasket. Use silicone sealant. DO NOT use plumbers putty to seal.
9. Insert the tailpiece into the trap inlet using the O-ring, coupling nut, & flange. The tailpiece may
need to be cut for proper fit. 1''-2'' of the tail piece shoudl fit inside the trap. Slip the flange over the tailpiece
and slide down to the floor.
10. Assemble the tee section to the tailpiece, overflow, & drain ell using the coupling nuts and O-rings
that are provided.
Silicone
Sealant
Strainer
O Ring
Coupling Nut
Flange
Trap Inlet
O Ring
Overow Ell
Tee
Coupling Nut
Tailpiece
Gasket
Drain Ell

11 . Attach the tapered rubber gasket to the overflow ell. Align the overflow ell with the overflow hole &
secure the drain to the tub with overflow plate and screw provided.
12 . Make sure a watertight seal exists on all bath drain connections.
End home plumbing
Floor
Cover Drain Pipe
Tapered Rubber Gasket
Overow Plate

All parts of the pedestal have already been installed by the manufacturer prior to shipment. Below
instructions are demonstrating how to replace them if repair is needed.
NO. ITEM Qty.
1
2
3
4
5
12
2
2
1
6
Self tapping screw
Nut
Metal plate
Bolt
Adjustable leg
1
4
2
5
3
Bathtub is pictured upside down
PEDESTAL INSTALLATION AND REPLACEMENT

SINGLE HANDLE FREESTANDING
TUB&SHOWER FAUCET
H-140-TFMSHCH

RECOMMENDED TOOLS
THE TOOLS MIGHT BE APPLIED TO THE FOLLOWING PLACES:
Screwdriver Channel Locks Goggles
Adjustable Wrench Teflon tape Allen key
WARNING:
Please keep the
tool for future use!
Hammer
ATTENTION:
for easy installation, you will need:
1. To read all the installation instruction completely before
beginning.
2. To read all the warning, attention and maitenance
information.

FAUCET INSTALLATION
2. Align the base ①with the holes exactly as shown.
1. Drill one hole of 130mmx130mm max and drill 3 holes with 80mm diameter as shown.
3. Insert the expansion anchors ①into the holes on the base ②with a hammer, tighten with
adjustable wrench.
80
mm
1
HOT WATER
COLD WATER
MAX 130mm
1
2

4. Tighten the shower holder ①into faucet body ④with a screw ②and Allen key ③.
5. Slide the flange ④into the welded rack ③as shown, and connect the flexible hose ②to the faucet
body ①, Then assemble the welded rack ③to the faucet body ①and fix it with screws ⑤.
6. Connect flexible hose ①to the connector ②correctly as shown,tighten with adjustable wrench.
INSTALLATION
LOCATION
1234
1
2
3
4
5
1
2
HOT WATER
COLD WATER

7. Insert 3 screws ②into holes on the plate ④, Tighten with Allen key ③.Cover it with flange ①.
8. Assemble the shower hose ③to hand shower ②and connector under the shower holder ①as
shown. Then finish the installation of the faucet.
4
3
2
1
1
2
3

CHECKING AND TESTING
2. Check all connections at arrows for leaks, re-tighten it if necessary.
BUT DON'T OVERTIGHTEN
1. Remove the aerator ②with aerator wrench, take out the o-ring ①too.Turn the faucet handle all the
way on, turn on hot and cold water supply and flush water lines for one minute. Reinstall aerator
with aerator wrench.
1
2

MAINTENANCE
A. If there is splash or low flow rate,please remove the aerator with the wrench and clean the debris.
B. If faucet leaks from the handle or drips from spout, please replace cartridge following the following
steps:
1. Remove the handle screw with Allen key ③, take out the handle ①, then remove the trim cap ④.
2. Unscrew the cartridge locknut ①with Adjustable Wrench, then take out the old cartridge ②.
3. Place a new cartridge in the cartridge seat, then screw the cartridge locknut and assemble the handle
by securing the screws.
1
2
3
4
1
2

CLEANING AND CARE
PARTS LIST
Daily cleaning and care are required in order to keep the product shining and properly working.
1. Clean it with water and dry it with soft cloth.
2. Clean the product with gentle liquid or glass cleaner.
3. Don't use acid cleaner.
4. Don't clean with abrasive material, abrasive paper or knife.
