Streamline DROP-IN Series Troubleshooting guide

streamlinebath.com
QUESTIONS ON PRODUCT, INSTALLATION, RETURNS? PLEASE CONTACT
1(310)-935-0028
[e-mail]
READ ENTIRE INSTALLATION GUIDE
PRIOR TO INSTALLING THE BATHTUB
THIS BATHTUB SHOULD ONLY BE
INSTALLED BY A CERTIFIED PLUMBER
CAUTION! TWO PEOPLE ARE REQUIRED
TO LIFT THE BATHTUB
DROP-IN BATHTUB SERIES
OWNER'S MANUAL &
INSTALLATION GUIDE

These products must be installed by a fully insured and licensed plumber only.
Installation of any product by anyone other than fully insured and licensed plumber shall void limited warranty.
We are not responsible for any local code compliance for this product.
Building and plumbing codes may vary state-to-state.
Streamline shall not be held liable for any and all incidental damages or flood caused due to use of this product.
Streamline shall not be held liable for any and all fees stemming from cost of installation, re-installation, removal,
subsequent damage, or transportation in a case of a product defect.
Silicone
Bathtub
Leveling Feet
Drain
Adjustable Key
Measuring Tape Safety Glasses
Pencil
Level Bar
PRIOR TO INSTALLING
TOOLS REQUIRED
WHAT'S IN THE BOX
Model: N-DWF-CH
Model: N-DWF-GLD

DRAIN MODEL COMPATIBILITY
FREESTANDING BATHTUB
N-DWF-CH
N-DWF-GLD
R-5520-67CIDIWH R-5540-71CIDIWH R-5560-59CIDIWH
R-5561-63CIDIWH R-5562-67CIDIWH R-5580-59CIDIWH
R-5582-67CIDIWHR-5581-63CIDIWH R-5600-59CIDIWH R-5601-67CIDIWH
R-5621-67CIDIWHR-5620-59CIDIWH R-5622-71CIDIWH
R-5661-67CIDIWHR-5660-59CIDIWH R-5662-71CIDIWH
R-5640-67CIDIWH

DRAIN DIAGRAM
LEVELING FOOT DIAGRAM
WHAT’S INCLUDED:
Model: N-DWF-CH
Model: N-DWF-GLD
No ITEM Qty
1
2
3
4
5
6
7
8
10
11
12
13
14
15
16
17
16
17
9
Cover
Cover gasket
Cartridge
Strainer
Waste upper gasket
Waste lower gasket
Connector
Coupling nut
Nut
Washer
Tee
Pipe
Overflow body
Tapered rubber gasket
Overflow upper gasket
Overflow plate
Pin Bolt
Taic piece
Flange
1
1
1
1
1
1
1
1
1
3
3
1
1
1
1
1
1
1
1
ITEMNo. Qty
Retaining Screw
1
2
3
4
5
1
1
2
1
1
Washer
Nut
Feet
Adjustable Feet
1
1
4 4 8 4 4
2
2
3
3
4
4
3
5
5
Qty:
ITEMS
No.

BATHTUB INSTALLATION
1. Prepare the site where the bath will be installed by waterproofing the floor and determining the
location of the drain pipe. Please refer to pictures 1, 2, 3 for recommended methods of installation
for this bathtub model.
2. Take (1) adjustable foot [#5] and (1) nut [#3] and screw the nut halfway on foot.
3. Screw the adjustable foot with the nut into the leveling foot.
4. Take (1) retaining screw [#1] and put it through the hole at the top of the foot. Then take (1) washer
[#2] and place it on the screw and secure with (1) nut [#3].
5. Take the assembled leveling foot (#4) and place it into the opening on the bathtub [see diagram].
Once inserted, secure and tighten all the bolts to ensure stability. A wrench may be required.
Repeat steps 2-5 for the other 3 leveling feet.

6. Ensure to mark all positions of leveling legs on the floor using a pencil. Move the bathtub into the
desired location near the drainpipe.
7. Take the strainer, place silicone sealant around it, and then place it into the drain hole ensuring
a tight connection with the drain ell & gasket. Use silicone sealant. DO NOT use plumbers putty to seal.
8. Insert the tailpiece into the trap inlet using the O-ring, coupling nut, & flange. The tailpiece may
need to be cut for proper fit. 1''-2'' of the tail piece shoudl fit inside the trap. Slip the flange over the tailpiece
and slide down to the floor.
Silicone
Sealant
Strainer
O Ring
Coupling Nut
Flange
Trap Inlet
Tailpiece
Gasket
Drain Ell

9. Assemble the tee section to the tailpiece, overflow, & drain ell using the coupling nuts and O-rings
that are provided.
O Ring
Overow Ell
Tee
Coupling Nut
10 . Attach the tapered rubber gasket to the overflow ell. Align the overflow ell with the overflow hole &
secure the drain to the tub with overflow plate and screw provided.
11 . Run water into the bath and check the bath drain connections for leaks. Seal the connection between
the bath rim and the finished tiled wall using silicone sealant.
Tapered Rubber Gasket
Overow Plate
