Strobel KA-ED Operating instructions

Operating and Mechanic's Instructions and Spare Parts Catalogue
for
Strobel – Roll Padder Electronic
KA-ED
Version: 22

Im Zeichen der Qualität
ou nd the Strobel trademark on every Strobel
machine leaving our works. And with good reason.
This symbol is a guarantee of the high quality of
our products. Quality which creates trust – trust
in our technology, our service and, not least of all,
in our good name.
ie nden die Strobel-Schutzmarke auf jeder
Strobel-Maschine, die unser Werk verlässt.
Und das aus gutem Grund. Denn dieses Zeichen
garanert Ihnen die hohe Qualität unserer
Produkte. Qualität, die Vertrauen scha – in unsere
Technik, unseren Service und nicht zuletzt in unseren
guten Namen.
S
Y
The sign of quality

trobel clients know that they can expect a parcularly high
standard of performance from our company and our machines.
Now you have seled for one of our products. For us this is a
source of encouragement and of obligaon to Jusfy your trust.
If you wish to prot from the performance and eciency of your
Strobel machine as long as possible, exact handling and tho-
rough care is necessary. For this reason we kindly request that
you read the operang instrucons closely.
It provides all the informaon you need for trouble free
operaon.
And if you do happen to need a spare part the enclosed spare
parts list gives a complete overview. It is clearly
classied according to components so that you can nd the
required part quickly and easily. In order to avoid errors we
request you to quote machine class, machine number and part
number completely on your spare part order.
We wish you lots of success in your work with your new Strobel
machine.
S
A decision with future
Spezialmaschinen GmbH

Garantiekarte/Warranty Sheet
Siemensstraße 3
D-82178 Puchheim
Tel.: [phone]
Fax: [phone]
[email protected]
Maschinenklasse/Machine class:
Serien-Nr./Serial No:
Auftrags-Nr./Oreder Confrimation No:
Lieferdatum/Delivery Date:
Rechnungs-Nr./Invoice No:
Rechnungsdatum/Invoice Date:
Beanstandung/Complaint:
Datum/Date Unterschrift/Signature:
Bitte nicht vom Kunden ausfüllen/To be filled out by Strobel:
Datum
Bemerkung
EXA:
ETA:
PROD:
EXA:
BH:

1 BA_KA-ED_A22_190313_en.doc
TABLE OF CONTENTS
1General notes on safety ............................................................................................................. 5
2General ....................................................................................................................................... 7
2.1 Operating instructions ...................................................................................................... 7
2.2 Class identification, serial number and orientation of the machine................................ 7
2.3 Intended use of the machine............................................................................................ 7
2.4 Technical data of the machine.......................................................................................... 8
3Installation and commissioning................................................................................................ 10
3.1 Lubrication (Fig. 2) .......................................................................................................... 11
3.2 Transit support................................................................................................................11
3.3 Direction of rotation of the machine..............................................................................11
3.4 Motor drive by tooth-belts .............................................................................................12
3.4.1 Tension of the tooth-belt (Fig. 3) .....................................................................12
3.4.2 Checking the tooth-belt for the carriage drive................................................. 13
3.4.3 Positions of the machine ..................................................................................14
3.5 Pneumatic connection ....................................................................................................16
3.6 Power supply................................................................................................................... 16
3.7 Check light barriers ......................................................................................................... 16
4Notes on use and maintenance ...............................................................................................17
4.1 Needles and threads....................................................................................................... 17
4.2 Inserting the needle (Fig. 7)............................................................................................17
4.3 Thread monitor............................................................................................................... 18
4.4 Threading (Fig. 8a + b) ....................................................................................................19
4.5 Operating element in the distribution box..................................................................... 19
4.5.1 Main switch S0 (Fig. 9)...................................................................................... 20
4.6 Operating elements in the switch box............................................................................ 20
4.6.1 START button S4 (Fig. 10) .............................................................................20
4.6.2 STOP button S5 (Fig. 10)............................................................................... 21
4.6.3 Toggle switch S6 (Fig. 10)..................................................................................21
4.6.4 Light L2 (yellow) (Fig. 10) .................................................................................. 21
4.6.5 Button “1” on the V810 operating control (Fig. 10)......................................... 22
4.6.6 Button “2” on the V810 operating control (Fig. 10)......................................... 22
4.6.7 Button “3” on the V810 operating control (Fig. 10)......................................... 22
4.6.8 Button “4” on the V810 operating control (Fig. 10)......................................... 22
4.7 Inserting the sewing material (Fig. 11 + Fig. 16b)...........................................................23
4.8 Setting the stitch depth (Fig. 10 + Fig. 12a)....................................................................24
4.9 Digital stitch depth display (Fig. 10) ...............................................................................25
4.10 Setting the seam distance (Fig. 13)................................................................................. 25
4.11 Setting the stitch length (Fig. 12b) ................................................................................. 26
4.12 Finetuning the upper transport (Fig. 14)........................................................................ 27

2 BA_KA-ED_A22_190313_en.doc
4.13 Function sequence..........................................................................................................28
4.13.1 Main switch S0 on............................................................................................. 28
4.13.2 Close clamping device, lapel part is inserted ................................................... 28
4.13.3 Start of the automatic sewing process............................................................. 28
4.13.4 Retraction of the carriage (only once after the start)......................................28
4.13.5 Sewing a blind stitch .........................................................................................29
4.13.6 Retraction of the carriage................................................................................. 29
4.13.7 End of the sewing program (S10 “light” and S8 “light”) ..................................29
4.14 +Machine maintenance (Fig. 16a) .................................................................................. 30
5Notes on repair and adjustment.............................................................................................. 31
5.1 The edge distance at stitch start and at the stitch end (Fig. 16).................................... 31
5.2 Setting the light barriers (Fig. 16a + Fig. 17)...................................................................33
5.3 Setting the plunger lifting (Fig. 18) ................................................................................. 35
5.4 Setting the helipot (Fig. 20) ............................................................................................37
5.5 Setting of basic switch S3 (Fig. 21).................................................................................. 38
5.6 Setting of end switch S2 (Fig. 22)....................................................................................39
5.7 Setting of switch S7 (Fig. 23)........................................................................................... 40
5.8 Setting the clamping device and the cover panel ..........................................................41
5.8.1 Setting the clamping device (Fig. 24)................................................................ 41
5.8.2 Setting the cover plate (for the light barrier) (Fig. 28).....................................43
5.9 Differential feed, rear ..................................................................................................... 44
5.9.1 Setting the Differential feed, rear (Fig. 26) ...................................................... 44
5.9.2 Rear differential transport drive (Fig. 27).........................................................46
5.9.3 Surface pressure start-up reel (Fig. 28) ............................................................ 47
5.10 Setting the stitch distance and length............................................................................ 48
5.10.1 Setting the side transport (Fig. 29)...................................................................48
5.10.2 Setting the stitch distance (Fig. 13) .................................................................. 48
5.11 Setting the needle stroke (Fig. 30a + b).......................................................................... 49
5.12 Loop stroke (Fig. 31)........................................................................................................49
5.12.1 Setting the loop stroke (Fig. 32) ....................................................................... 50
6LASER (optional features) (Fig. 34)...........................................................................................51
6.1 General............................................................................................................................51
6.1.1 Setting of the lasers: "Stitch start" (1).............................................................. 51
6.1.2 Setting of the lasers: "First stitch" (2)...............................................................51
7Problems during sewing and possible solutions...................................................................... 53

3 BA_KA-ED_A22_190313_en.doc
Appendix
Citcuit diagrams
Mains connection, sewing machine lamp of the sewing machine:
258.00.26 Mains connection plan ABB221A Cl. KA-ED from version 22
(with sewing machine lamp gen.)
Connecting the sewing machine:
258.10.13 Electrical circuit diagram, general Cl. KA-ED from version 22
258.10.08 Electrical circuit diagram, switch box KA 22 Cl. KA-ED
as of version 22 and up
258.30.17 Assembly plan AB221A Cl. KA-ED from version 22
258.30.18 Assembly plan, distribution box cables Cl. KA-ED from version 22
258.21.55 Table wiring distribution box Cl. KA-ED from version 22
Option Laser positioning:
258.21.49 Electrical connection plan Laser positioning Cl. KA-ED
from version 22
Connecting Pneumatic:
259.00.40 Pneumatic circuit diagram Cl. KA-ED as of version 22
259.10.40 Pneumatic construction circuit diagram
Cl. KA-ED as of version 22
Strobel – Switchable functions (DC1500-AB221A)
Strobel – Parameter list (DC1500-AB221A)
Subject to change without prior notice

4 BA_KA-ED_A22_190313_en.doc
Fig. 1

5 BA_KA-ED_A22_190313_en.doc
1General notes on safety
Manuals and additional information can be found on the STROBEL website at:
http://www.strobel.biz
Every person in charge of setting up, operating, servicing and repairing the machine
must first read and understand the operating instructions and particularly the safety
instructions before starting up the machine.
Failure to comply with the following safety instructions can lead to bodily injury or
damage to the machine.
1. The machine must only be operated by persons familiar with the relevant
operating instructions and who have been instructed accordingly.
2. Before commissioning also read the notes on safety and the operating
instructions of the sewing drive manufacturer.
3. Only use the machine in the intended manner and never without the provided
guards. Always observe the pertinent safety regulations.
4. Switch off the main switch or pull the power plug for threading, changing the
reels, exchanging sewing tools such as needle, gripper, needle plate, transport
devices, possibly cutter and cutting block, for cleaning and when leaving the
workplace as well as for maintenance.
5. General maintenance tasks may be carried out only by properly trained persons
in accordance with the operating instructions.
6. Repair work, retrofitting and maintenance may be carried out only by
technicians or specially trained personnel.
7. When servicing or repairing pneumatic equipment, the machine must be
disconnected from the pneumatic supply. Exceptions are only allowed for
adjustment work and tests of functionality performed by specially trained
technicians.
8. Only specially qualified technicians may work on the electrical equipment.
9. It is forbidden to work on electrically live components! Exemptions are covered
by the EN50110 (DIN VDE0105) regulations.
10. Any retrofitting or alterations to the machine may only be performed under
strict compliance with all pertinent safety regulations.
11. Only use our approved spare parts when servicing and/or repairing the machine.
12. It is forbidden to operate the sewing head until it is determined that the entire
sewing unit complies with EU provisions.

6 BA_KA-ED_A22_190313_en.doc
13. It is essential that you observe and follow these instructions as well as the
generally valid safety regulations.
14. Warning instructions given in the operating instructions that pertain to
especially dangerous parts of the machine must be indicated at these positions
using a safety symbol.
Warning instructions given in the operating instructions that pertain to special
injury hazards for operating personnel or technicians must be indicated at these
positions using a safety symbol.

7 BA_KA-ED_A22_190313_en.doc
2General
2.1 Operating instructions
Any person involved in the installation, operation, maintenance and repair of the
machine must have read and understood the operating instructions and in particular
the safety instructions before starting the machine.
2.2 Class identification, serial number and orientation of the
machine
The operating side of the machine is the basis for orientation for descriptions referring
to sides.
The class identification (type) is located on the right hand side of the machine stand;
the serial and model number (after the dash) are stamped into the base plate's front
surface on the back as well as on the type sign on the back side of the machine stand.
2.3 Intended use of the machine
For automatic roll padding of right and left lapels, completely mirrored and not
warped.
The Strobel roll padder consists of a left and a right machine. Both machines operate
independently from each other.
The longest possible stitch length at the lapel roll line is 58 cm, the shortest stitch at
the lapel tip is about 3 cm.
The shape of the lapel can be user-defined. The edges are scanned automatically by
light barriers.
The edge distance at stitch start (10 mm – 25 mm) and at the stitch end
(10 mm – 50 mm) can be freely set.
The distance between the seams can also be freely set up to about 16 mm.

8 BA_KA-ED_A22_190313_en.doc
2.4 Technical data of the machine
Empfohlene Nennstichzahl /
Recommended rated speed
2800 min-1
Stichlänge / stitch length 6,5 mm
Obertransport & differenzierbarer
Wagentransport / top feed & differential
carriage transport
starrer Drücker / fixed plunger
Stichplattenöffnung / needle plate opening 6,0 mm
Stichtiefenanzeige / stitch depth display digital display
Nahtabstand / seam distance 4 - 15 mm
Nadelsystem / needle system
Nadelstärke / needle size
GROZ-BECKERT 4669 EEO
80/12
Fadenspannung / thread tension
Faden / thread
Auslieferzustand / delivery condition 9 cn
Polyester, endlos gezwirnt / polyester
continuous filament 200/2
2 Nähköpfe / 2 sewing units
Fadenwächter / thread monitor
Laser Positionierung / laser positioning optional
Halogen Nählicht / Halogen sewing light

9 BA_KA-ED_A22_190313_en.doc
Technischer Auslieferzustand / delivery condition:
Gesamtleistung / power consumption
2 x 1040 W
Stromanschluss / electricity
190 - 240 V / 50-60 Hz
Zahnriemenprofil / toothed belt profile
HTD 5M-9
Zahnriemenscheibe Maschine /
toothed belt pulley/machine
Z = 38
Zahnriemen - Scheibe Wagen /
tooth belt - wheel carriage
Z = 40 -HTD 5M-15-HP
kürzeste Naht / shortest seam
3 cm
max. Reverslänge / max. lapel length
63 cm
max. Nahtlänge / max. seam length
55 cm
Tagesleistung / daily output (8 h)
500 - 1050 Sakkos / pair of lapels
Stichart / stitch type
Einfaden-Kettenstich-Blindstich Typ 103 /
single thread chain stitch type 103
Anschluss pneumatisch / pneumatic connection
5 - 6 bar
Luftverbrauch, Mittelwert /
avarage air consumption
2 x 475 l / h
Gewicht ohne Verpackung /
weight without packaging
2 x 158 kg
Arbeitsgeräusch / operating noise at 2800 min-1
nach DIN 45635-48-1 KL3
LpAm 77 dB(A)

10 BA_KA-ED_A22_190313_en.doc
3Installation and commissioning
The S0 main switch is located on the distribution box below the tabletop (Fig. 1). The
stop button S5 is located in the control box over the tabletop (Fig. 10).
CAUTION! Danger of injury!
The machine's carriage run extends beyond the outer edge of the
machine during operation. Make sure that this area is not accessible,
because otherwise there is a risk of injury.
The machine may not be operated without protective panels (belt
protection) for the upper part and for the motor (beneath the table
top). Otherwise there is a risk of fingers being caught, bodily injuries
and clothing being drawn in.
ATTENTION!
Don´t use as a handle!
Proceed as follows for installation: unpack and clean machine.

11 BA_KA-ED_A22_190313_en.doc
3.1 Lubrication (Fig. 2)
ATTENTION!
The machine must be oiled before first start. The maintenance
instructions according to the operating instructions must be
followed!
On the machine head all the points marked red.The lids (1) and (2) need to be screwed
off for this.
Fig. 2
3.2 Transit support
Remove carriage lock. Unscrew an angle bracket each at the bottom side of the
carriage.
3.3 Direction of rotation of the machine
Right machine half:
The correct rotation of the handwheel is counter-clockwise (left run) when
looking at it.
Left machine half:
The correct rotation of the handwheel is clockwise (right run) when looking at
it.Motor drive by tooth-belts

12 BA_KA-ED_A22_190313_en.doc
3.4 Motor drive by tooth-belts
3.4.1 Tension of the tooth-belt (Fig. 3)
CAUTION! Danger of injury!
Before testing the tooth-belt tension it is essential to switch off the
machine by the main switch S0 and to disconnect the power plug.
The machine may not be operated without belt protection for the
motor.
The tooth-belt should not be tensioned too tight. You should be able to compress it
easily with your thumb by about 5 mm.
Too little or to great tooth-belt tension can be bad for the machine's positioning and
thus impair the function sequence.
Tension the tooth-belt (Fig. 3):
-Loosen the upper and lower fastening screws (1), (2) on the machine upper part.
-Pull motor out a little and slightly tighten the lower fastening screw (2).
-Tension the tooth-belt by swivelling the motor.
-Tighten the upper and lower fastening screws (1), (2) again.
Fig. 3

13 BA_KA-ED_A22_190313_en.doc
3.4.2 Checking the tooth-belt for the carriage drive
CAUTION! Danger of injury!
To check the tooth-belt, switch off the machine electrically and pull
out the power plug.
The machine may not be operated without front panels and back
wall.
Checking the tooth-belt tension (Fig. 4):
-Switch off power switch S0 and pull the power plug.
-Unscrew front panel and rear wall from the frame.
-The tooth-belt (1) should not be tensioned too tight. You should be able to
compress it easily with your thumb by about 5 mm. If the belt is too loose or too
tight, the function sequence is impaired. If the belt is too tight,
it will wear too quickly. In either case the machine will operate slower. The
carriage may bend if the tooth-belt is too tight.
In case the belt tension is not OK, tension the belt properly.
-Loosen central fastening of the drive
unit Hexagonal screw M16x80 (2)
Hexagonal nut M16 (3)
-Loosen the fastening screw (4)
-The drive unit can now be swivelled around the central fastening. Tighten the
belt and retighten the fastening screw. Retighten the central fastening.
-Screw front panel and rear wall to the frame.
-Plug in power plug and switch on main switch S0.

14 BA_KA-ED_A22_190313_en.doc
Fig. 4
3.4.3 Positions of the machine
CAUTION! Danger of injury!
Danger of injury by clothing or hair being drawn in as well as danger
of fingers being caught, and needle piercing!
When checking positions while the machine is turned on, keep
fingers and hands away from moving parts.
The machine needs a needle position and a reference position.
Reference position (Fig. 5):
The reference position needs to be set so that the needle's point is aligned with
the inner edge of the needle glide washers in the stitch-in direction.

15 BA_KA-ED_A22_190313_en.doc
Fig. 5
Cutting position: (Fig. 6):
After the looper has taken up the loop, the looper needs to be moved so far so that
the thread of the loop on the needle side hangs on the cloth retainer and the other
side slides in the groove of the cloth retainer. This way the loop half to be cut is placed
on the cutter and is cut across the blade when the carriage retracts.
Fig. 6
This can be simulated by stopping the machine in the stitch with button 1 of the
operating control V810 and activating the solenoid 1V1 by hand. Now the coupling has
to be switched off by toggle switch S6 (Fig. 10) and the carriage pushed back by hand a
little.

16 BA_KA-ED_A22_190313_en.doc
3.5 Pneumatic connection
Each half of the machine is separately connected pneumatically by an 8/6-PA hose to a
connector plug. The maintenance unit is set to 5 to 6 bar operational pressure.
Minimum operational pressure 5 bar.
3.6 Power supply
CAUTION! Danger of injury!
Work on the electrical equipment may be done only by electricians or
properly trained technicians. The exists the risk of fatal electrical
shock.
The electrical connection is separate for each machine half.
ATTENTION!
Before connecting the machine electrically be sure that the local
network voltage and the net frequency corresponds to the machine.
Network voltage and network frequency can be found on the type
sign on the back side of the machine stand.
If network voltage and frequency are not compatible, the electrical
installation of the machine will be destroyed.
3.7 Check light barriers
-Mirror (1) (S8-1) and (2) (S8-2) along the entire length and check for damages.
(Fig. 12a)
-Push carriage manually to the middle.
-Switch on main switch S0.
-Press the START button S4 (carriage moves to basic position).
-Press START button S4 again (clamping device closes).
-Switch toggle switch S6 to “ ” position (“0” position) (carriage can be moved
freely by hand) (Fig. 10).
-Keep an eye on the LED of the light barriers S8-1 and S10 and push the carriage
through slowly by hand. The LED’s should bit lit without interruption along the
entire length; otherwise re-adjust
(see point “5.2 Setting the light barriers (Fig. 16a + Fig. 17)”).
Machine is ready for sewing.
