Strong SM-RAZOR-ART1-M User manual

SM-RAZOR-ART1-M
Strong™ Razor Series Articulating Mount for Medium Displays
INSTRUCTION MANUAL
SM-RAZOR-ART1-M
Installation Manual
Strong™ Razor Single ArmArticulating Mount
For Medium Flat-Panel TVs

Pg. 2
SM-RAZOR-ART1-M Installation Manual
© 2013 Strong®
CAUTION: This wall mount is intended for use only with the maximum weight
of 50 lbs./22.67 kg. Use with heavier than the maximum weight
indicated may result in instability causing possible injury.
1. Warnings
• Installationofthisproductshouldbedonebyaqualiedprofessional.
• Donotbegininstallationbeforereviewingandunderstandingtheseinstructions.
• Ensurethemountingwallusedcansafelysupport4timesthecombinedweightofthemountandchosendisplay.
• Undernocircumstancesshouldthisproductbemountedtometalstuds.
• Themanufacturerdoesnotacceptresponsibilityforincorrectinstallation.
3. Optional Accessories
• Dual Stud Mounting Bracket (SM-RAZOR-ART1-BKT-20) - For use when mounting location must be between
two studs 16” to 20” apart.
4. Package Contents
4.1. Mount & Accessories
2. Tools Required
• PowerDrill
• 1/4”DrillBit
• PhillipsHeadScrewDriver
• Level
• 1/2”(13mm)SocketWrench
• StudFinder(optional,recommendedforwoodstudmounting)
• ZipTies(forwiremanagement)
• 5/16”MasonryDrillBit(concretemountingonly)
• Hammer(concretemountingonly)
WallArmAssembly(1) SingleStudWall
Bracket(1)
TVPlate(1)

Pg.3
SM-RAZOR-ART1-M Installation Manual
www.snapav.com Support: 866.838.5052
4.2. Hardware
Bag1
Bag2
Bag3
Bag4
(T1)Small4mm
AllenKey(1)
(Y)LatchingClip(1)
(T2)Large4mm
AllenKey(1)
(Z)M5x8Countersunk
Screw (3)
(T3)8mmSocket
Wrench (1)
(A)PhillipsHead
MachineScrew,
M4x10(4)
(B)PhillipsHead
MachineScrew,
M4x20(4)
(C)PhillipsHead
MachineScrew,
M4x30(4)
(D)PhillipsHead
MachineScrew,
M5x10(4)
(E)PhillipsHead
MachineScrew,
M5x20(4)
(F)PhillipsHead
MachineScrew,
M5x30(4)
(I)PhillipsHead
MachineScrew,
M6x10(4)
(J)PhillipsHead
MachineScrew,
M6x20(4)
(K)PhillipsHead
MachineScrew,
M6x30(4)
(L)PhillipsHead
MachineScrew,
M8x10(4)
(M)PhillipsHead
MachineScrew,
M8x20(4)
(N)PhillipsHead
MachineScrew,
M8x30(4)
(O)PhillipsHead
MachineScrew,
M8x40(4)
(V)Washer,M5,
6.5x18x2(2)
(W)M5Locknut(2)
(G)SmallNylonSpacer,
OD12xID5.5x5(8)
(H)M5Washer,
M5x12x1(16)
(Q)M8washer,
M8x19x2(8)
(X)M5NylonWasher
5.5x18x2(2)
(S)Washer
9.5x21x2(3)
(U)ConcreteAnchor
10x80(3)
(R)M8x90LagBolt(3)
(P)LargeNylonSpacer,
OD15xID8.5x5(8)

Pg.4
SM-RAZOR-ART1-M Installation Manual
© 2013 Strong®
5. Installation
Step 1. Install the Display Adapter Plate
Step 2. Determine the Correct Mounting Height
A. Carefullylaythedisplayface-downonasoftsurface.
B. Locate the four mounting holes in the back of the
displayhousing.Trytothreadscrews(AthroughN)in
until the correct thread is found for the holes.
C. Lay the adapter plate over the holes in the display
(directionalarrowfacingup),andchecktheclearance
betweentheTVandtheplate.Makesurethemounting
holes match up properly to four of the holes in the
adapter plate. The adapter plate should be centered
on the back of the display.  See the available VESA
patterns in Figure 1.
D. If the plate won’t sit at against the back of the
television,spacers(GandP)andwashers(HandQ)
may be placed between the display and the plate as
needed.
E. Fasten the plate to the display using a #2 Phillips
screwdriver. Use screws long enough to thread
securely into the display without bottoming out.
A. Decidetheheightwherethetopedgeofthedisplayshould
beonceinstalled.(Height)
B. Measure and record the distance between the top of the
displayand thetopofthedisplay adapterplate (Figure3).
Makesuretomeasurefromtheatareaontopoftheplate,
notthecurvedarea.(DimensionA)
C. InsertDimensionAintotheformula:
D. MarktheWallPlateScrewheightatthecenterlineofthemountlocation.(Figure4)
(Height) – 1/4” – (A) = Wall Plate Screw Height
(Used in Step 3, next page)
Note:  The adapter plate (Figure 1) is designed for use
with these VESA patterns: 100x100, 100x200, 200x100,
and 200x200.
Warning: Over-tightening can damage the bolts or the
display and is not covered under warranty.  Make sure
the fasteners are tight enough not to rattle loose while the
mount is in use.
Important! If the optional Dual Stud Mounting Bracket (SM-RAZOR-ART1-BKT-20) is being used to hang the mount
on the wall, refer to the SM-RAZOR-ART1-BKT-20 manual (included with the bracket) to complete Step 2.
Figure 1.
Figure 2.
Figure 3.
200
100
100
200
A
Measure from
flat edge of plate
to top of TV
Example:
60” – 1/4” – 6 1/2” = 53 1/4” (Wall Plate Screw Height)
Desired Display Height = 60”
Dimension A (measured) = 6 1/2”

Pg. 5
SM-RAZOR-ART1-M Installation Manual
www.snapav.com Support: 866.838.5052
Step 3. Install the Mounting Bracket on the Wall
A. For Mounting on a Stud Wall
1. Locateastudtomountthebracketon.Markthecenterline
of the stud on the wall.  The use of a stud nder is highly
recommended.
2. Usingalevelforguidance,holdthebracketonthewalland
mark the mounting holes that will be used. The holes will be
centeredontheheightmarkfromStep2.Besurethatthe
arrows on the bracket face up toward the ceiling.
3. Pre-drilltheholestoadepthof31/2”usinga1/4”drillbit.Be
sure to drill into the center of the stud.
4. Insert the lag screws (R) through the washers (S) and the
wallplate,andthreadthemintotheholesinthewall.Tighten
theboltssothebracketisrmlyattachedtothewall.
Warning:Over-tighteningcandamagethebolts,greatlyreducing
theirholdingstrength.Donotover-tighten!
Screw Holes:
-ø1/4"
-Depth 3 1/2"
(R) x2
(S) x2
Wall Plate
Screw Height
Mark (From
Step 2)
Figure 4.
Single Stud Bracket
Important! If the optional Dual Stud Mounting Bracket (SM-RAZOR-ART1-BKT-20) is being used to hang the mount
on the wall, refer to the SM-RAZOR-ART1-BKT-20 manual (included with the bracket) to complete Step 3.

Pg. 6
SM-RAZOR-ART1-M Installation Manual
© 2013 Strong®
B. For Mounting on a Concrete Wall
Important! If the optional Dual Stud Mounting Bracket SM-RAZOR-ART1-BKT-20 is being used to hang the
mount on the wall, refer to the SM-RAZOR-ART1-BKT-20 manual (included with the bracket) to complete
Step 3.
Warning! For Concrete or Cinder Block Mounting:
Cinder block must meet ASTM C-90 specications.
Concrete must be 2000 psi density minimum. Lighter
density concrete may not hold concrete anchor. Verify
that there is a minimum of 1-3/8” of concrete thickness
to be used for the included concrete wall anchors.
Do not drill into mortar joints! Be sure to mount in a
solid part of the block, generally 1” minimum from the
side of the block.
It is suggested that a standard electric drill on slow
setting is used to drill the hole instead of a hammer
drill, to avoid breaking out the back of the hole when
entering a void or cavity.
Make sure that the supporting surface will safely
support the combined load of the equipment and all
attached hardware and components.
1. Usingalevelforguidance,holdthebracketonthewalland
mark the mounting holes that will be used. The holes will be
centeredonthe heightmarkfrom Step2.Be surethatthe
arrows on the bracket face up toward the ceiling.
2. Pre-drill the holes using a 5/16” masonry drill bit to a depth of
31/2”.Inserttheconcretewallanchors(U)andtapthemin
with a hammer if necessary.
3. Insert the lag screws (R) through the washers (S) and the
wallplate,andthreadthemintothewallanchors(U).Tighten
theboltssothebracketisrmlyattachedtothewall.
Warning:Overtighteningcandamagethebolts,greatlyreducing
theirholdingstrength.Donotover-tighten!
Figure 5.
Figure 6.
Figure 7.
Drill holes and
insert anchors.
Place wall arm
assembly plate
over anchor and
secure with
bolt.
Tighten all
bolts.
Wall Arm
Concrete
Wall
Flange Bolt
Figure 3
Correct
concrete
concrete
plaster/
drywall plaster/
drywall
Incorrect
CutawayView
Figure 2
(R) x3
(S) x3
Screw Holes:
-ø5/16"
-Depth 3 1/2"
Wall Plate
Screw Height
Mark (From
Step 2)

Pg. 7
SM-RAZOR-ART1-M Installation Manual
www.snapav.com Support: 866.838.5052
Step 4. Attach the Arm Assembly to the Wall Plate
Step 5. Attaching the Display to the Arm Assembly
A. Loosenthetwoupperclampingscrewsonthearmassembly.
B. Alignthearmassemblywiththetopandbottomrailofthewallplate.
C. Slidethearmassemblyintopositionwhileloweringandpushingittowardthewall.Loosentheupperclamping
bolts more if the assembly will not clip onto the rail.
D. Tightentheupperandlowerclampingboltsusingthesmall4mmAllenwrench(T1).
E. IftheSM-RAZOR-ART1-BKT-20isbeingused,thewallbracketendcoverscannowbeinstalled.
1. Liftthedisplayandplaceitontheendofthearmassemblyas
shown in Figure 10.
2. SecurethedisplayusingthetwoNylonwashers(X),twometal
washers (V), and lock nuts (W).  Be sure to place the Nylon
washer between the mount and the metal washer. This will allow
for easier tilt adjustments later.
3. Tightenthenutswiththe8mmsocketwrench(T3).
Figure 8. Figure 9.
Tighten
Screws
Raise Block
Assembly
Tighten
Screws
(X) (V) (W)
Figure 10.

Pg.8
SM-RAZOR-ART1-M Installation Manual
© 2013 Strong®
6. Adjusting Display Position
6.1. Horizontal Level Adjustments
6.2. Vertical Position Adjustments
1. Loosenthetwolockingnuts(W)atthebottomofthearmassemblyendplateusingthe8mmsocketwrench(T3).
(Figure11)
2. Placealevelontopofthedisplay,androtatethedisplayuntilitishorizontallylevel.(Figure12)
3. Tightenthelockingnutsatthebottomofthearmassemblyendplateandthenloosenthem¼turn.Thiswillallow
for the display to be positioned with minimal effort.
4. Afteradjustmentiscomplete,tightenthenuts.
Theverticalpositionofthedisplaycanbeadjusted+/-3/8”fromthepre-adjustedcenteredposition.Thisisachieved
bytightening(up)orloosening(down)theverticaladjustmentscrewlocatedonthearmplate.
1. Extendthearmtoaccesstheverticalpositionadjustment.
2. Loosenthefourlock-nutsontherearofthearmplateusingthe8mmsocketwrench(T3).(Figure13)
3. UsingtheLarge4mmAllenwrench(T2),tightentheadjustmentscrewtoraisethedisplay,orloosenthescrew
tolowerthedisplay.(Figure14)
4. Tightenthefourlocknutsontherearofthearmplateusingthe8mmsocketwrench(T3).
Figure 11. Figure 12.
Horizontal Level
Adjustment Nuts (W)
+/- 4°
Figure 13. Figure 14.
Lock Nuts
Large 4mm Allen Key (T2)

Pg.9
SM-RAZOR-ART1-M Installation Manual
www.snapav.com Support: 866.838.5052
6.3. Adjusting Home Position (Fully Retracted)
6.4. Tilt Adjustments
The mount includes a home position latch that
secures the arm to the wall mount. This prevents
the display from being pushed away from the wall
due to cabling.
Note: Only the TV Plate side of the latch is pre-
installed. The home position latch clip requires
installation and adjustment.
Tilt adjustments usually do not require loosening
any bolts or screws. The tilt plate fasteners have
been pre-adjusted for easy adjustment with most
TVs.However, heavierTVs may sag due to the
extra weight.
Ifthisoccurs,evenlytightenthelocknutsoneach
side of the end plate using the small 4mmAllen
Wrench (T1) until the display no longer sags.
(Figure16)
1. Extendthearmoutawayfromthewall.
2. Attach the home position latch (Y) to the
wall arm assembly using the three screws
(Z) as shown in Figure 15. Use a #2 Phillips
screwdriver to adjust the screws.
3. Leavethescrewslooseenoughtobeableto
adjust the latch and set it at the top of its travel.
4. Pushthedisplaybacktothewall.
5. Ifno“click”isheardasthearmispushedat,
adjust the latch downward and test again.
6. Repeatthesestepsuntila“click”isheardandthedisplaylatchescompletelytothewallmount.
7. Afterthelatchissetcorrectly,tightenthescrewscompletely.
Figure 15.
Figure 16.
(Y) x1
(Z) x3
11° 5°
Tilt Adjustment Nuts
(2 per side)

Pg. 10
SM-RAZOR-ART1-M Installation Manual
© 2013 Strong®
7. Specifications
8. Dimensions
Finish Type PowderCoated,MatteFinish
Product Weight 13.30lbs.
Maximum Display Load 50lbs.(22.67kg)
Minimum Mounting Pattern 100x100VESA
Maximum Mounting Pattern 200x200VESA
Retracted On-Wall Thickness (inches) 1.65”
Maximum Extension (inches) 21.25”
Pan/Swivel Range 180°
Tilt Angle Range -11°,+5°
Certications UL
22.21in.
13.94in.
1.71in.

Pg. 11
SM-RAZOR-ART1-M Installation Manual
www.snapav.com Support: 866.838.5052
Lifetime Limited Warranty
Strong™MountshaveaLifetimeLimitedWarranty.Thiswarrantyincludespartsandlaborrepairs
on all components found to be defective in material or workmanship under normal conditions of
use.Thiswarrantyshallnotapplytoproductswhichhavebeenabused,modiedordisassembled.
ProductstoberepairedunderthiswarrantymustbereturnedtoSnapAVoradesignatedservice
centerwithpriornoticationandanassignedreturnauthorizationnumber(RA).
Lifetime
Phone: (866)838-5052
Email: [e-mail]
9. Warranty
10. Contacting Technical Support

©2013STRONG™
130820-1600
