Stuv EURO 5000 User manual

www.stuv.de 1
LOCKING SYSTEM EURO 5000
3.31.50XX.0
with pro le-cylinder and 3 keys
Date of issue 06/2017 • All speci cations are approximate • Errors and changes excepted product photos are for illustration purposes only
Housing, Cap Plastic, dyed
Handle Stainless steel
Inside guide Plastic, dyed
Outside guide Zinc die-casting, plated
Conformity of the materials all materials used are RoHS and REACH compliant
MATERIALS & SURFACE
Available options:
• door thicknesses 52 - 60 mm, 72 - 80 mm, 82 - 90 mm, 92 - 100 mm, 102 - 110 mm, 112 - 120 mm, 132 - 140 mm, 152 - 160 mm
• electronic status indicator pro le-cylinder
• electronic status indicator inside handle
• Multiple Locking System Euro 5000
• Locking System Euro 5000 single with latch
MADE
IN
GERMANY
LOCKING SYSTEM EURO 5000
FEATURES
Operation angle 90°
Mounting 16 x Countersunk screw M5
Temperature range -40°C up to +80°C
Cap luminescent
Model right hand and left hand mountable
Tested up to 200.000 cycles

www.stuv.de 2
ASSEMBLY INSTRUCTIONS
3.31.50XX.0
01
Insert the outside guide (Pos. 5) into the corresponding drill hole of the door and mount with 8x countersunk screws M5 on the door
outer side. Depending on right or left version, attention must be paid to the marking „TOP RH“ or „TOP LH“ when installing the
outer guide.
02
Insert the inside guide (Pos.6) into the corresponding drill hole of the door and mount with 8x countersunk screws M5 on the inside
of the door. Depending on right or left version, attention must be paid to the marking „TOP RH“ or „TOP LH“ when installing the
inside guide.
03 Turn the outside handle (Pos.1) 45° (to the right or left) to the vertical position completely and insert it into the outer guide (Pos.5).
Return the handle to the vertical position. Now the outside handle (Pos.1) is secured against being pushed out.
04 Insert the stop bolt (Pos.3) into the inside handle (Pos.2), making sure the „RH“ and „LH“ positions are according to door position.
05 Press the hexagon socket screw (Pos.8) with the washer (Pos.7) into the inside handle (Pos.2). The hexagon socket screw (Pos.8)
must not be above the tolerance compensation (Pos.10) (Fig.1, Page 4).
06 Ensure that the tolerance compensation (Pos.10) is screwed back enough that the nose of the tolerance compensation (Pos.10)
rests against the stop of the inside handle (Pos.2) (Fig.4, Page 4).
07
Position the inside handle (Pos.2) horizontally through the inner guide via the square shaft (Pos.4) of the ouside handle (Pos.1).
Press with slight pressure on the inner guide (Pos.6) so that there is no margin between the inside handle (Pos.2) and the inside
guide (Pos.6).
08 Screw the hexagon socket screw (Pos.8) clockwise until the tolerance compensation (Pos.10) comes to rest on the square shaft
(Pos.4) (Fig.2, Page 4).
09 Press in the hexagon socket screw (Pos.8) so that it strikes in the square shaft hole (Fig.3, Page 4).
10
Screw the hexagon socket screw (Pos.8) into the square shaft (Pos.4) and thereby secure the inside handle (Pos.2). When tighten-
ing the hexagonal screw (Pos.8), make sure that the side anks of the hexagon head are horizontal so that the cap (Pos.9) can be
clipped into the inside handle (Pos.2).
11 Then clip the cap (Pos.9) into the inside handle (Pos.2).
ASSEMBLY
SAFETY NOTICE
For safety reasons a second person must be on the outside of the door when testing the emergency
escape function with the door installed
PROFILE CYLINDER REPLACEMENT
When changing the prole half cylinder, make sure that the locking lug is in 90° position (3 o‘clock)

www.stuv.de 3
ASSEMBLY INSTRUCTIONS
3.31.50XX.0
When changing the prole
half cylinder, make sure
that the locking lug is in 90°
position (3 o‘clock)
Cap
Hexagon socket screw
Washer
Inside handle
Inside guide
Stop bolt
Outside handle
Outside guide
Square shaft
Inside guide
Stop bolt
Inside handle
Figure Z

www.stuv.de 4
TOLERANCE COMPENSATION
3.31.50XX.0
Tolerance compensation nose
7 8 10
Inner lever nose (Pos.2)
Tolerance compensation nose (Pos.10)
Fig 1
Fig 2
Fig 3
Inside handle
Washer Hexagon socket screw Tolerance compensation Square shaft
Fig 4

www.stuv.de 5
DRILLING PATTERN
3.31.50XX.0
Door Door
InsideOutside
Frame Frame
Inside
Outside
Door
