2002 IMPREZA SERVICE MANUAL
NEW CAR INFORMATION SECTION
FOREWORD
This manual has been prepared to provide information
for the construction, operation and other technical de-
tails of SUBARU vehicles.
Read this manual thoroughly and make the most of it
to give better service to your customers and improve
your knowledge of vehicle maintenance.
QUICK REFERENCE INDEX
Emission Control
(Aux. Emission Control Devices) EC (TURBO)
Mechanical ME (TURBO)
Differentials DI
Manual Transmission
and Differential 6MT
Control System CS
Clutch CL
Front Suspension FS
Rear Suspension RS
Drive Shaft System DS
ABS ABS
Brakes BR
Instrumentation/Driver Info IDI
Fuel Injection (Fuel System) FU (TURBO)
Intake (Induction) IN (TURBO)
Specifications SPC
W1841GE
All information, illustration and specifications con-
tained in this manual are based on the latest product
information available at the time of publication ap-
proval.
FUJI HEAVY INDUSTRIES LTD.

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. foreword
FOREWORD
All right reserved. This book may not be reproduced or
copied, in whole or in part, without the written permis-
sion of FUJI HEAVY INDUSTRIES LTD., TOKYO JA-
PAN
SUBARU, and are trademarks of FUJI
HEAVY INDUSTRIES LTD.
Copyright 2001 FUJI HEAVY INDUSTRIES LTD.

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_00
Page
1. Impreza 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SPC
SPECIFICATIONS SPC

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_01
IMPREZA
Specifications
SPC-2
1. Impreza
A: DIMENSIONS
Model Sedan Wagon OUTBACK STi
Overall length mm (in) 4,405 (173.4)
Overall width mm (in) 1,730 (68.1) 1,695 (66.7) 1,710 (67.3) 1,730 (68.1)
Overall height (at CW) mm (in) 1,440 (56.7) 1,465 (57.7),
1,485 (58.5)L4
1,475 (58.1),
1,495 (58.9)L41,440 (56.7)
Compartment Length mm (in) 1,890 (74.4) 1,845 (72.6) 1,890 (74.4)
Width mm (in) 1,380 (54.3)
Height mm (in) 1,180 (46.5),
1,125 (44.3)L5
1,200 (47.2),
1,150 (45.3)L5
1,200 (47.2),
1,150 (45.3)L51,180 (46.5)
Wheelbase mm (in) 2,525 (99.4)
Tread Front mm (in) 1,485 (58.5) 1,460 (57.5)L1,
1,465 (57.7) 1,460 (57.5) 1,490 (58.7)
Rear mm (in) 1,475 (58.1),
1,480 (58.3)L3
1,450 (57.1)L1,
1,455 (57.3) 1,455 (57.3) 1,480 (58.3)
Minimum road
clearance
Without catalytic
converter
mm (in) 150 (5.9),
155 (6.1)L2
150 (5.9),
155 (6.1)L2160 (6.3) —
With catalytic
converter
mm (in) 150 (5.9),
155 (6.1)L3
150 (5.9),
155 (6.1)L3160 (6.3) 155 (6.1)
L1:1.6 L
L2:2.0 L
L3:2.0 L Turbo
L4:With roof rail
L5:With sun roof
B: ENGINE
Model 1.6 L Non-Turbo
2.0 L Turbo 2.0 L 2.5 L STi
Engine type Horizontally opposed, liquid cooled, 4-cylinder, 4-stroke gasoline engine
Valve arrangement Overhead camshaft type
Bore x Stroke mm (in) 87.9 x 65.8
(3.461 x
2.591)
92 x 75
(3.62 x 2.95)
99.5 x 79
(3.92 x 3.11)
92 x 75
(3.62 x 2.95)
Displacement cm3(cu in) 1,597 (97.45) 1,994 (121.67) 2,475
(151.02)
1,994
(121.67)
Compression ratio 10.0 ±0.2 8.0 ±0.2 10.0 ±0.2 8.0 ±0.2
Firing order 1 — 3 — 2 — 4
Idle speed at Park/Neutral
position
rpm 700 ±100 750 ±100 700 ±100 700 ±100
Maximum output kW (HP)/rpm 70 (94)/5,200 92
(123)/5,600
160
(215)/5,600
112
(150)/5,600
195
(261)/600
Maximum torque N.m (kgf-m, ft-lb)/rpm 143 (14.6,
105.5)/3,600
184 (18.8,
136.0)/3,600
292 (29.8,
215.4)/3,600
223 (22.7,
164.5)/3,600
343 (35.0,
253.0)/4,000

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_01
IMPREZA
Specifications
SPC-3
C: ELECTRICAL
Model 1.6 L Non-Turbo
2.0 L Turbo 2.0 L 2.5 L STi
Ignition timing at idling speed BTDC/rpm
5°±10°/700 10°±10°/700 12°±10°/750
MT: 10°±
10°/700
AT: 15°±
10°/700
12°±10°/700
Spark plug Type and
manufacturer
Without OBD NGK: BKR6E
(without cata-
lyst)
CHAMPION:
RC8YC4
(with catalyst)
NGK:
BKR6E-11
(with catalyst)
NGK: BKR6E
(without cata-
lyst)
CHAMPION:
RC10YC4
(with catalyst)
NGK:
BKR5E-11
(with catalyst)
—
NGK: BKR6E
(without cata-
lyst)
CHAMPION:
RC10YC4
(with catalyst)
NGK:
BKR5E-11
(with catalyst)
—
With OBD CHAMPION:
RC8YC4
CHAMPION:
RC10YC4
CHAMPION:
RC10YC4
Alternate
NGK:
BKR6E-11
Alternate
NGK:
BKR5E-11
NGK: PFR6G Alternate
NGK:
BKR6E-11
NGK: PFR6G
Generator 12V —75A
Battery Type and
capacity (5HR)
For Europe
and South
America 12V —48AH
(55D23L)
MT: 12V —48AH (55D23L)
AT: 12V —52AH (65D23L)
MT: 12V —
48AH
(55D23L)
AT: 12V —
52AH
(75D23L)
12V —48AH
(55D23L)
Others 12V —27AH (34B19L) —

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_01
IMPREZA
Specifications
SPC-4
D: TRANSMISSION
Model 1.6 L Non-Turbo
2.0 L Turbo 2.0 L 2.5 L STi
Transmission type 5MT 4AT 5MT 4AT 5MT 4AT 5MT 4AT 6MT
Clutch type DSPD TCC DSPD TCC DSPD TCC DSPD TCC DSPD
Gear ratio 1st 3.454 2.785 3.454 2.785 3.454,
3.166L12.785 3.454 2.785 3.636
2nd 2.062 1.545 2.062 1.545 1.947,
1.882L11.545 2.062 1.545 2.375
3rd 1.448 1.000 1.448 1.000 1.366,
1.296L11.000 1.448 1.000 1.761
4th 1.088 0.694 1.088 0.694 0.972 0.694 1.088 0.694 1.346
5th
0.825 —0.825 —0.738 —0.871,
0.780L1—
0.971,
1.062
L1
6th
— — — — — — — —
0.756,
0.842
L1
Reverse 3.333 2.272 3.333 2.272 3.333 2.272 3.333 2.272 3.545
Dual range 1.447 —1.447 — — — — — —
Reduction
gear (Front
dri e)
1st reduction Type of gear —Heli-
cal —Heli- cal —Heli- cal —Heli- cal —
drive) Gear ratio —1.000 —1.000 —1.000 —1.000 —
Final
reduction
Type of gear Hypo-
id
Hypo-
id
Hypo-
id
Hypo-
id Hypoid Hypo- id Hypoid Hypo- id
Hypo-
id
Gear ratio 4.111 4.444 3.900 4.111 3.900,
4.444L14.111 3.700, 4.111L14.111 3.900
Reduction
gear (Rear
dri e)
Transfer
reduction
Type of gear Heli-
cal —Heli- cal —Helical —Helical —Heli- cal
drive) Gear ratio
1.000 —1.000 —1.100,
1.000L1—1.000 —
1.100,
1.000
L1
Final
reduction
Type of gear Hypo-
id
Hypo-
id
Hypo-
id
Hypo-
id Hypoid Hypo- id Hypoid Hypo- id
Hypo-
id
Gear ratio
4.111 4.444 3.900 4.111 3.545,
4.444L14.111 3.700, 4.111L14.111
3.545,
3.900
L1
5MT:5-forward speeds with synchromesh and 1-reverse
4AT:Electronically controlled fully-automatic, 4-forward speeds and 1-reverse
6MT:6-forward speeds with synchromesh and 1-reverse
DSPD:Dry Single Plate Diaphragm
TCC:Torque Converter Clutch
L1:Australia spec vehicle
E: STEERING
Model Turbo 2.0 L, 2.5 L OUTBACK OTHERS STi
Type Rack and Pinion
Turns, lock to lock RHD: 2.7
LHD: 3.0 3.0 3.2 2.7
Minimum turning
il
m (ft) Curb to curb 11.0 (36.1) 10.8 (35.4) 10.4 (34.1) 11.0
g
circle Wall to wall 12.0 (39.4) 11.6 (38.1) 11.2 (36.7) 12.0

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_01
IMPREZA
Specifications
SPC-5
F: SUSPENSION
Front Macpherson strut type, Independent, Coil spring
Rear Dual-link type, Independent, Coil spring
G: BRAKE
Model 1.6 L Non-Turbo 2.0 L, 2.5 L Turbo 2.0 L, STi
Service brake system Dual circuit hydraulic with vacuum suspended power unit
Front Ventilated disc brake
Rear Drum brake Disc brake Ventilated disc brake
Parking brake Mechanical on rear brakes
H: TIRE
Rim size 14 x 5 1/2JJ 15 x 6JJ 16 x 6 1/2JJ 17 x 7JJ 17 x 7 1/2JJ
Tire size 175/70R14 84T
185/70R14 88H
185/65R15 88H
195/60R15 88H
P205/55R16 89V
205/50R16 87V 215/45R17 87W 225/45R17 90W 215/45R17 87W
Type Steel belted radial, Tubeless
I: CAPACITY
Model 1.6 L Non-Turbo 2.0 L Turbo 2.0 L 2.5 L STi
5MT 4AT 5MT 4AT 5MT 4AT 5MT 4AT 6MT
Fuel
tank
ȏ(US gal, Imp gal) 50 (13.2, 11.0) 60 (15.9, 13.2)
Engine
oil
Total
capacity
ȏ(US qt,
Imp qt) 4.0 (4.2, 3.5) 4.5 (4.8, 4.0) 4.0 (4.2, 3.5) 4.5 (4.8, 4.0)
Engine oil
amount for refill
ȏ(US qt,
Imp qt) Approx. 4.0 (4.2, 3.5) Approx. 4.5
(4.8, 4.0)
Approx. 4.0
(4.2, 3.5)
Approx.
4.5
(4.8,
4.0)
Transmission gear oil ȏ(US qt,
Imp qt)
3.5 (3.7,
3.1),
4.0 (4.2,
3.5)L1
—
3.5 (3.7,
3.1),
4.0 (4.2,
3.5)L1
—3.5 (3.7,
3.1) —3.5 (3.7, 3.1) —4.1 (4.3, 3.6)
Automatic transmission
fluid
ȏ(US qt,
Imp qt) —8.4 (8.9, 7.4) —8.4 (8.9, 7.4) —9.3 (9.8, 8.2) —9.3 (9.8, 8.2) —
AT differential gear oil ȏ(US qt,
Imp qt) —1.2 (1.3, 1.1) —1.2 (1.3, 1.1) —1.2 (1.3, 1.1) —1.2 (1.3, 1.1) —
AWD rear differential
gear oil
ȏ(US qt,
Imp qt) 0.8 (0.8, 0.6) 1.0 (1.1, 0.9)
Power steering fluid ȏ(US qt,
Imp qt) 0.7 (0.7, 0.6)
Engine coolant ȏ(US qt,
Imp qt)
7.4 (7.8,
6.5)
7.3 (7.7,
6.4)
7.0 (7.4,
6.2)
6.9 (7.3,
6.1)
7.7 (8.1,
6.8)
7.7 (8.1,
6.8)
7.0 (7.4,
6.2)
6.9 (7.3,
6.1)
7.7 (8.1,
6.8)
L1:Dual range

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_01
IMPREZA
Specifications
SPC-6
J: WEIGHT
1. LHD VEHICLE
Sedan
Option codeL1 EC K4 K0 KS
Model 1.6 L
AWD
TS
5MT 4AT 5MT 4AT 5MT 4AT 5MT 4AT
Curb weight (C.W.) Front kgf (lb) 730
(1,609)
750
(1,654)
750
(1,654)
770
(1,698)
750
(1,654)
770
(1,698)
740
(1,631)
760
(1,676)
Rear kgf (lb) 520
(1,146)
520
(1,146)
520
(1,146)
520
(1,146)
520
(1,146)
520
(1,146)
535
(1,179)
535
(1,179)
Total kgf (lb) 1,250
(2,755)
1,270
(2,800)
1,270
(2,800)
1,290
(2,844)
1,270
(2,800)
1,290
(2,844)
1,275
(2,810)
1,295
(2,855)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
Rear kgf (lb) 890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
890
(1,962)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,700
(3,748)
1,700
(3,748)
1,700
(3,748)
1,700
(3,748)
1,700
(3,748)
1,700
(3,748)
1,700
(3,748)
1,700
(3,748)
Option Air conditioner — — ffffff
Cruise control ————————
ABS ————————
Aluminium wheel ————————
Rear spoiler ————————
Spoiler pac ————————
L1:For option code, refer to ID section. <Ref. to ID-5, Option code.>

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_01
IMPREZA
Specifications
SPC-7
Option codeL1 EC K4 K0 KS
Model 2.0 L
AWD
GX
5MT 4AT 5MT 4AT 5MT 4AT 5MT 4AT
Curb weight (C.W.) Front kgf (lb) 745
(1,643)
770
(1,698)
765
(1,687)
790
(1,742)
760
(1,676)
795
(1,753)
750
(1,653)
780
(1,720)
Rear kgf (lb) 535
(1,179)
530
(1,168)
530
(1,168)
525
(1,157)
525
(1,157)
530
(1,168)
550
(1,213)
545
(1,202)
Total kgf (lb) 1,280
(2,822)
1,300
(2,866)
1,295
(2,855)
1,315
(2,899)
1,285
(2,833)
1,325
(2,921)
1,300
(2,866)
1,325
(2,921)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
Rear kgf (lb) 910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,760
(3,880)
1,760
(3,880)
1,760
(3,880)
1,760
(3,880)
1,760
(3,880)
1,760
(3,880)
1,760
(3,880)
1,760
(3,880)
Option Air conditioner — — f f f f f f
Cruise control ————————
ABS — — f f f f —f
Aluminium wheel — — f f — — f f
Rear spoiler ——————f f
Spoiler pac ————————
Option codeL1 EC
Model 2.5 L 2.0 L Turbo
AWD
RS WRX STi
5MT 4AT 5MT 6MT
Curb weight (C.W.) Front kgf (lb) 760 (1,676) 785 (1,731) 815 (1,797) 875 (1,929)
Rear kgf (lb) 535 (1,179) 530 (1,168) 550 (1,213) 575 (1,268)
Total kgf (lb) 1,295 (2,855) 1,315 (2,899) 1,365 (3,009) 1,450 (3,197)
Maximum permissible
axle weight (M P A W )
Front kgf (lb) 930 (2,050) 930 (2,050) 970 (2,138) 1,030 (2,271)
axle weight (M.P.A.W.) Rear kgf (lb) 910 (2,006) 910 (2,006) 920 (2,028) 920 (2,028)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,780 (3,924) 1,780 (3,924) 1,850 (4,079) 1,880 (4,145)
Option Air conditioner — — — —
Cruise control — — — —
ABS f f f f
Aluminium wheel — — — —
Rear spoiler — — — —
Spoiler pac — — — —
L1:For option code, refer to ID section. <Ref. to ID-5, Option code.>

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_01
IMPREZA
Specifications
SPC-8
Wagon
Option codeL1 EC K4 K0 KS
Model 1.6 L
AWD
TS
D/R 4AT D/R 4AT D/R 4AT D/R 4AT
Curb weight (C.W.) Front kgf (lb) 735
(1,620)
750
(1,654)
755
(1,664)
770
(1,698)
755
(1,664)
770
(1,698)
745
(1,642)
760
(1,676)
Rear kgf (lb) 545
(1,202)
545
(1,202)
545
(1,202)
545
(1,202)
545
(1,202)
545
(1,202)
560
(1,235)
560
(1,235)
Total kgf (lb) 1,280
(2,822)
1,295
(2,855)
1,300
(2,866)
1,315
(2,900)
1,300
(2,866)
1,315
(2,900)
1,305
(2,877)
1,320
(2,911)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 900
(1,984)
900
(1,984)
900
(1,984)
900
(1,984)
900
(1,984)
900
(1,984)
900
(1,984)
900
(1,984)
Rear kgf (lb) 910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
910
(2,006)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,730
(3,814)
1,730
(3,814)
1,730
(3,814)
1,730
(3,814)
1,730
(3,814)
1,730
(3,814)
1,730
(3,814)
1,730
(3,814)
Option Air conditioner — — ffffff
Cruise control ————————
ABS ————————
Aluminium wheel ————————
Rear spoiler ————————
Spoiler pac ————————
D/R Dual range
L1:For option code, refer to ID section. <Ref. to ID-5, Option code.>

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_01
IMPREZA
Specifications
SPC-9
Option codeL1 EC K4 K0 KS
Model 2.0 L
AWD
GX
D/R 4AT D/R 4AT D/R 4AT D/R 4AT
Curb weight (C.W.) Front kgf (lb) 755
(1,664)
770
(1,698)
775
(1,709)
790
(1,742)
780
(1,720)
795
(1,753)
760
(1,676)
780
(1,720)
Rear kgf (lb) 570
(1,257)
565
(1,246)
565
(1,246)
560
(1,235)
570
(1,257)
565
(1,246)
580
(1,279)
575
(1,268)
Total kgf (lb) 1,325
(2,921)
1,335
(2,944)
1,340
(2,955)
1,350
(2,977)
1,350
(2,977)
1,360
(2,999)
1,340
(2,955)
1,355
(2,988)
Maximum permissible
axle weight (M.P.A.W.)
Front kgf (lb) 920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
Rear kgf (lb) 960
(2,116)
960
(2,116)
960
(2,116)
960
(2,116)
960
(2,116)
960
(2,116)
960
(2,116)
960
(2,116)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,800
(3,969)
1,800
(3,969)
1,800
(3,969)
1,800
(3,969)
1,800
(3,969)
1,800
(3,969)
1,800
(3,969)
1,800
(3,969)
Option Air conditioner — — f f f f f f
Cruise control ————————
ABS — — f f f f —f
Aluminium wheel — — f f — — f f
Rear spoiler ————————
Spoiler pac ————————
Option codeL1 EC K4
Model 2.0 L Turbo
AWD
WRX
5MT
Curb weight (C.W.) Front kgf (lb) 805 (1,775) 825 (1,819)
Rear kgf (lb) 585 (1,290) 585 (1,290)
Total kgf (lb) 1,390 (3,065) 1,410 (3,109)
Maximum permissible
axle weight (M P A W )
Front kgf (lb) 970 (2,138) 970 (2,138)
axle weight (M.P.A.W.) Rear kgf (lb) 950 (2,094) 950 (2,094)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,860 (4,101) 1,860 (4,101)
Option Air conditioner —f
Cruise control — —
ABS f f
Aluminium wheel — —
Rear spoiler — —
Spoiler pac — —
D/R Dual range
L1:For option code, refer to ID section. <Ref. to ID-5, Option code.>

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_01
IMPREZA
Specifications
SPC-10
2. RHD VEHICLE
Sedan
Option codeL1 EK K1
Model 1.6 L
AWD
TS
5MT 4AT 5MT 4AT
Curb weight (C.W.) Front kgf (lb) 735 (1,621) 755 (1,665) 750 (1,654) 770 (1,698)
Rear kgf (lb) 520 (1,146) 520 (1,146) 520 (1,146) 520 (1,146)
Total kgf (lb) 1,255 (2,767) 1,275 (2,811) 1,270 (2,800) 1,290 (2,844)
Maximum permissible
axle weight (M P A W )
Front kgf (lb) 890 (1,962) 890 (1,962) 890 (1,962) 890 (1,962)
axle weight (M.P.A.W.) Rear kgf (lb) 890 (1,962) 890 (1,962) 890 (1,962) 890 (1,962)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,700 (3,748) 1,700 (3,748) 1,700 (3,748) 1,700 (3,748)
Option Air conditioner — — f f
Cruise control — — — —
ABS f f — —
Aluminium wheel — — — —
Rear spoiler — — — —
Spoiler pac f f — —
Option codeL1 EK K1
Model 2.0 L
AWD
GX
5MT 4AT 5MT 4AT
Curb weight (C.W.) Front kgf (lb) 765 (1,687) 790 (1,742) 770 (1,698) 795 (1,753)
Rear kgf (lb) 535 (1,179) 530 (1,168) 535 (1,179) 530 (1,168)
Total kgf (lb) 1,300 (2,866) 1,320 (2,910) 1,305 (2,877) 1,325 (2,921)
Maximum permissible
axle weight (M P A W )
Front kgf (lb) 920 (2,028) 920 (2,028) 920 (2,028) 920 (2,028)
axle weight (M.P.A.W.) Rear kgf (lb) 910 (2,006) 910 (2,006) 910 (2,006) 910 (2,006)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,760 (3,880) 1,760 (3,880) 1,760 (3,880) 1,760 (3,880)
Option Air conditioner f f f f
Cruise control — — — —
ABS f f f f
Aluminium wheel f f — —
Rear spoiler f f — —
Spoiler pac f f — —
L1:For option code, refer to ID section. <Ref. to ID-5, Option code.>

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_01
IMPREZA
Specifications
SPC-11
Option codeL1 KA
Model 2.0 L 2.0 L Turbo 2.5 L 2.0 L
Turbo
AWD
GX WRX RS STi
5MT 4AT 5MT 4AT 5MT 4AT 6MT
Unladen mass (U. M.) Front kgf (lb) 750
(1,654)
775
(1,709)
830
(1,830)
855
(1,885)
780
(1,720)
805
(1,775)
895
(1,973)
Rear kgf (lb) 535
(1,179)
530
(1,168)
560
(1,235)
555
(1,224)
540
(1,191)
535
(1,179)
575
(1,268)
Total kgf (lb) 1,285
(2,833)
1,305
(2,877)
1,390
(3,065)
1,410
(3,109)
1,320
(2,910)
1,340
(2,954)
1,470
(3,241)
Gross vehicle mass
(G. V. M.)
Front kgf (lb) 920
(2,028)
920
(2,028)
970
(2,138)
970
(2,138)
930
(2,050)
930
(2,050)
1,030
(2,271)
Rear kgf (lb) 910
(2,006)
910
(2,006)
920
(2,028)
920
(2,028)
910
(2,006)
910
(2,006)
920
(2,028)
Total kgf (lb) 1,760
(3,880)
1,760
(3,880)
1,850
(4,079)
1,850
(4,079)
1,780
(3,924)
1,780
(3,924)
1,880
(4,145)
Option Air conditioner ——f f f f f
Cruise control f f f f f f f
ABS f f f f f f f
Aluminium wheel — — — — — — —
Rear spoiler ——f f f f —
Spoiler pac — — — — — — —
Option codeL1 EK
Model 2.0 L Turbo
AWD
WRX STi
5MT 6MT
Curb weight (C.W.) Front kgf (lb) 830 (1,830) 895 (1,973)
Rear kgf (lb) 560 (1,235) 575 (1,268)
Total kgf (lb) 1,390 (3,065) 1,470 (3,241)
Maximum permissible
axle weight (M P A W )
Front kgf (lb) 970 (2,138) 1,030 (2,271)
axle weight (M.P.A.W.) Rear kgf (lb) 920 (2,028) 920 (2,028)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,850 (4,079) 1,880 (4,145)
Option Air conditioner f f
Cruise control — —
ABS f f
Aluminium wheel — —
Rear spoiler f—
Spoiler pac — —
L1:For option code, refer to ID section. <Ref. to ID-5, Option code.>

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_01
IMPREZA
Specifications
SPC-12
Wagon
Option codeL1 EK K1
Model 1.6 L
AWD
TS
D/R 4AT D/R 4AT
Curb weight (C.W.) Front kgf (lb) 740 (1,631) 755 (1,664) 755 (1,664) 770 (1,698)
Rear kgf (lb) 545 (1,202) 545 (1,202) 545 (1,202) 545 (1,202)
Total kgf (lb) 1,285 (2,833) 1,300 (2,866) 1,300 (2,866) 1,315 (2,900)
Maximum permissible
axle weight (M P A W )
Front kgf (lb) 900 (1,984) 900 (1,984) 900 (1,984) 900 (1,984)
axle weight (M.P.A.W.) Rear kgf (lb) 910 (2,006) 910 (2,006) 910 (2,006) 910 (2,006)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,730 (3,814) 1,730 (3,814) 1,730 (3,814) 1,730 (3,814)
Option Air conditioner — — f f
Cruise control — — — —
ABS f f — —
Aluminium wheel — — — —
Rear spoiler — — — —
Spoiler pac — — — —
Option codeL1 EK K1
Model 2.0 L
AWD
GX
D/R 4AT D/R 4AT
Curb weight (C.W.) Front kgf (lb) 775 (1,709) 790 (1,742) 780 (1,720) 795 (1,753)
Rear kgf (lb) 570 (1,257) 565 (1,246) 570 (1,257) 565 (1,246)
Total kgf (lb) 1,345 (2,965) 1,355 (2,987) 1,350 (2,977) 1,360 (2,999)
Maximum permissible
axle weight (M P A W )
Front kgf (lb) 920 (2,028) 920 (2,028) 920 (2,028) 920 (2,028)
axle weight (M.P.A.W.) Rear kgf (lb) 960 (2,116) 960 (2,116) 960 (2,116) 960 (2,116)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,800 (3,968) 1,800 (3,968) 1,800 (3,968) 1,800 (3,968)
Option Air conditioner f f f f
Cruise control — — — —
ABS f f f f
Aluminium wheel f f — —
Rear spoiler — — — —
Spoiler pac f f — —
D/R Dual range
L1:For option code, refer to ID section. <Ref. to ID-5, Option code.>

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_01
IMPREZA
Specifications
SPC-13
Option codeL1 KA
Model 2.0 L 2.0 L Turbo
AWD
GX OUTBACK WRX
D/R 4AT D/R 4AT 5MT 4AT
Unladen mass (U. M.) Front kgf (lb) 760
(1,676)
775
(1,709)
750
(1,653)
765
(1,687)
825
(1,819)
850
(1,874)
Rear kgf (lb) 570
(1,257)
565
(1,246)
570
(1,257)
570
(1,257)
585
(1,290)
585
(1,290)
Total kgf (lb) 1,330
(2,932)
1,340
(2,954)
1,320
(2,910)
1,335
(2,943)
1,410
(3,109)
1,435
(3,164)
Gross vehicle mass
(G. V. M.)
Front kgf (lb) 920
(2,028)
920
(2,028)
920
(2,028)
920
(2,028)
970
(2,138)
970
(2,138)
Rear kgf (lb) 960
(2,116)
960
(2,116)
960
(2,116)
960
(2,116)
950
(2,094)
950
(2,094)
Total kgf (lb) 1,800
(3,968)
1,800
(3,968)
1,800
(3,968)
1,800
(3,968)
1,860
(4,101)
1,860
(4,101)
Option Air conditioner ————f f
Cruise control f f f f f f
ABS f f f f f f
Aluminium wheel — — — — — —
Rear spoiler — — — — — —
Spoiler pac — — — — — —
Option codeL1 EK
Model 2.0 L Turbo
AWD
WRX
5MT
Curb weight (C.W.) Front kgf (lb) 825 (1,819)
Rear kgf (lb) 585 (1,290)
Total kgf (lb) 1,410 (3,109)
Maximum permissible
axle weight (M P A W )
Front kgf (lb) 970 (2,138)
axle weight (M.P.A.W.) Rear kgf (lb) 950 (2,094)
Maximum permissible
weight (M.P.W.)
Total kgf (lb) 1,860 (4,101)
Option Air conditioner f
Cruise control —
ABS f
Aluminium wheel —
Rear spoiler —
Spoiler pac —
D/R Dual range
L1:For option code, refer to ID section. <Ref. to ID-5, Option code.>

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. SPC_01
IMPREZA
Specifications
SPC-14
MEMO

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. FU T00
Page
1. General
2. Air Line 2
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3. Fuel Line
4. Sensors and Switches 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5. Control System 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6. On-board Diagnosis System
FU
TURBO
FUEL INJECTION
(FUEL SYSTEM) FU (TURBO)

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. FU T02
AIR LINE
Fuel Injection (Fuel System)
FU-2
2. Air Line
G: TUMBLE GENERATOR VALVES
2. STi MODEL
The STi model’s engine is not provided with a tumble generation control function. Although it is
fitted with a tumble generator housing, there are no sensor and valve actuator on the housing.

W1841GE 02 MY IMPREZA New Car Information 欧州 Gr. FU T04
SENSORS AND SWITCHES
Fuel Injection (Fuel System)
FU-3
4. Sensors and Switches
D: EXHAUST GAS TEMPERATURE SENSOR
2. STi MODEL
The STi model is not provided with an exhaust gas temperature sensor.
I: VARIABLE VALVE TIMING CAMSHAFT POSITION SENSORS
NOTE:
The variable valve timing camshaft position sensors are installed only on the STi model’s engine.
DThe variable valve timing camshaft position sensors are installed one each on the rear ends of
the right and left bank cylinder heads.
DThe sensor detects the amounts of the advance and retard angles of the intake valves caused
by the effect of the variable valve timing system using the variation in the air gap between the sen-
sor and a boss provided on the rear end of each intake camshaft. The sensor’s internal construc-
tion and operation are same as those of the crankshaft position sensor.
