I-9106 Intelligent Linear Cable Heat Detector
Installation and Operation Manual The Intelligent Solution
CONTENTS
I General.............................................................................................................. 1
II Features ............................................................................................................ 1
III Technical Specifications..................................................................................... 1
IV Structure and Operation Principle...................................................................... 2
V Mounting and Wiring.......................................................................................... 3
VI Designs and Applications................................................................................... 8
VII Testing............................................................................................................. 10
VIII Troubleshooting................................................................................................11
IX Maintenance.....................................................................................................11
X Cautions ..........................................................................................................12
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
I-9106 Intelligent Linear Cable Heat Detector
Installation and Operation Manual The Intelligent Solution
Page 1
I General
I-9106 Intelligent Linear Cable Heat Detector （the detector）consists of I-9106
Intelligent Linear Cable Heat Detector Interface（the interface）, P-9106 Intelligent
Linear Cable Heat Detector Terminal (the terminal) and series linear heat cables. It is a
fixed temperature detector well designed and developed by GST, with the features of
easy mounting and stable operating.
The detector is linear heat detector, especially used to predict an early fire occurring to
power cable and control cable in tunnels. It is applicable to power plants, transformer
substations, steel mills, chemical factories and ancient buildings.
II Features
1. Stable structure, strong stretching resistance and vibration resistance.
2. It has the privilege in the adverse conditions such as damp, dust, oil and corrosive
gas exist while other type of detectors cannot be applied.
3. With good anti-interference ability, grounding measures, isolation test and software
anti-interference techniques , the detector can be used to the place where affected
by the strong electromagnetic field.
4. The detector can work normally when its loop is extended up to 1km. The heat
cable can be lengthened to 400m and work normally, which is applicable to indoors,
outdoors, acid-proof and explosion-proof places.
5. The fire and fault conditions can be transmitted to the fire alarm control panel
through non-polarized two loop.
6. Optional Single/Double Loop: The interface can connect with two heat cables. If
only one heat cable is needed in the field, the single loop can be set by hand held
programmer.
III Technical Specifications
1 The terminal and the interface
(1) Wiring: Two-wire
(2) Operating Voltage: Loop 24V (16V～28V)
(3) Operating Current: Standby current≤3mA Alarm current≤5mA
(4) Capacity（or output capacity）: 2 heat cables（≤400m）
(5) Programming: Electric programming within 1～241.
(6) Operating Environment: Temperature: -10℃～+50℃
Relative Humidity ≤95%, non condensing
(7) Ingress Protection Rating: IP55
(8) Material and color of the housing:
the interface : Die casting aluminum alloy, silver gray
the terminal: ABS, pale gray
(9) Weight: the interface: 1kg the terminal: 0.175kg
(10) Mounting Hole Spacing: the interface: 155mm or 60mm the terminal: 95mm
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
I-9106 Intelligent Linear Cable Heat Detector
Installation and Operation Manual The Intelligent Solution
Page 2
2 Linear Heat Cable
(1) Response time ≤20s（heat within 1m）
(2) Operating Environment Temperature: T: -40℃≤T≤Rated action temperature
falling down 30％
(3) Insulated resistance≥500MΩ
(4) Maximum curve radius: 150mm
(5) Anti-voltage ability: 500VAC, for 1 minutes
(6) Relative error: Action temperature error±10％
IV Structure and Operation Principle
1 Dimension
a) Fig. 1 shows the interface with 172mm×246mm×77mm.
I-9106
Intelligent LinearCable Heat
DetectorInterface
Loop1 Loop2
Fig. 1 Dimension of the interface
b) Fig. 2 shows the terminal with 105mm×109mm×54mm.
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
I-9106 Intelligent Linear Cable Heat Detector
Installation and Operation Manual The Intelligent Solution
Page 3
P-9106 End of Line Unit
GWDL1,GWDL2：Connecting
with sensor cable,non-polarized
Production Date：
Batch No：
Serial No：
Fig. 2 Dimension of the terminal
2 Operation Principle
The interface has a built-in microprocessor and be programmed electronically. It can
connect the detector to fire alarm system through signal two loops. Each interface can
connect with two heat cables, with the first end of the heat cable connected with the
interface and the last end connected with the terminal. Each loop of the heat cable
occupies one address point.
The linear heat cable is a part of sensor component in a field fire alarm system. The heat
cable is made up of two twisted flexible steel wires. Each wire is coated with isolation
material. In normal monitoring state, the resistance of each steel wire is indefinite, and
the heat cable has a tiny standby current because of the terminal resistance. When the
ambient temperature rise up to rated action temperature, the isolation material between
the steel wires melted, which make the two twisted wires shorted on a certain point. At
the time, the standby current in the heat cable will be increased, the interface will check
such a change and transmit it to the fire alarm control panel.
The terminal is a special accessory, connected to the end of the heat cable without
connecting with fire alarm control panel. The terminal has fire test device, convenient for
simulation fire test on the detector.
V Mounting and Wiring
Wiring: Please disconnect the power of the loop before installing the devices.
1 The Interface
(1) There are ways to mount the interface. One is wall-mounted, the other is
rack-mounted.
a. Fix the interface to the wall with two M6×60 expansion bolts. Top view of the
mounting is shown in Fig. 3.
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
I-9106 Intelligent Linear Cable Heat Detector
Installation and Operation Manual The Intelligent Solution
Page 4
Fig. 3 Top view of the interface
b. Rack mounted: Remove the mounting board from the back cover, then fix
the back cover to the rack with M4×12. Fig. 4 shows its mounting.
Fig. 4 Mounting the rack
(2) Wiring of the interface
Fig. 5 shows the terminals of the interface.
Z1 Z2 Z3 Z4 GWDL1 GWDL2 GWDL3 GWDL4
Fig. 5 Terminals of the interface
Z1, Z2: to the loops of the fire alarm control panel.
Z3, Z4: Transfer the loop of the fire alarm control panel.
GWDL1, GWDL2: to heat cable I, non-polarized.
GWDL3, GWDL4: to heat cable II, non-polarized.
The wiring procedure of the interface:
Before wiring, take off the six bolts and remove the cover.
Put the heat cable in the cable socket, and connect to the corresponding
terminals.
Put on the cover.
Screw the cover securely.
There are two cable sockets on the top and bottom of the interface. These two
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
I-9106 Intelligent Linear Cable Heat Detector
Installation and Operation Manual The Intelligent Solution
Page 5
cable sockets on the top are to connect with loops, those ones on the bottom with
heat cable. When the interface connects with incomings and outgoings, remove the
waterproof plug, replaced with spare cable socket to connect with another pair of
loops.
Z1, Z2, Z3 and Z4 adopts copper core cable thread with cross section not less
than 1.0mm2 andexternal diameter ∅8mm～∅10mm. The product needs the cable
with ∅8mm～∅10mm to meet the requirement of water-proof. We advise not to
use twisted pair or solid wire. It they have to be used, please enwind those part
which is to go through the interface to ∅8mm～∅10mm rude material belt.
2 The terminal
The terminal can be fixed to the cable support rack with ∅6 plastic expansion bolts
（See Fig. 6）. Mounting hole spacing is 95mm.
P-9106 End of Line Unit
GWDL1,GWDL2：Connecting
with sensor cable,non-polarized
Production Date：
Batch No：
Serial No：
Fig. 6 Mounting of the terminal
Terminals of the terminal are shown in Fig. 7.
GWDL1 GWDL2
Fig. 7 Terminals
GWDL1, GWDL2 connects with heat cable, non-polarized.
3 Linear Heat Cable
There are three methods for cable heat wiring: Line type, cycle type and similar sine
wave type.
（1） Mounting below the ceiling
When the heat cable is mounted Indoors, its distance from the ceiling or side
wall should not be more than 0.5m ( 0.2m～0.3m is acceptable), shown in
Fig. 8.
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
I-9106 Intelligent Linear Cable Heat Detector
Installation and Operation Manual The Intelligent Solution
Page 6
Ceiling and
Supporting
Wire
Retaining Clip
Linear Heat
Cable
Fig. 8Mounting of the Linear Heat Cable
The spacing between heat cables and with walls are shown in Fig. 9.
2m
2m
4m2m2m2m2m4m
The Terminal
Heat Cable
wall
Fig. 9 Mounting of the Linear Heat Cable
（2） Mounting on the cable tray or support rack
When the heat cable is mounted on the cable tray or support rack, it should be
mounted on the protection cover of monitored power cable and control cable,
adopting contact mounting as much as possible. Fig. 10 shows the specific
mounting.
Heat Cable
Retaining
Clip
Cable Tray
Fig. 10 Mounting of the Linear Heat Cable
Note: Retaining clip should be plastic and flameproof.
Heat cable length＝Cable tray length × coefficient of Multiplying Power (this
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
I-9106 Intelligent Linear Cable Heat Detector
Installation and Operation Manual The Intelligent Solution
Page 7
should be made according to Table 1).
Table 1
Tray Width （m）Coefficient of Multiplying Power
1.2 1.75
0.9 1.50
0.6 1.25
0.5 1.15
0.4 1.1
When the heat cable is mounted on the power cable in sane wave type, the
number of retaining clip can be calculated by the formula:
The number of retaining clip＝The number of half sine wave×2＋1
（3） Mounting on the conveyer
There are two designs.
If the conveyer’s width is not over 3m, it can be protected by a heat cable as long
as the conveyer. The heat cable should be fixed to the appurtenance where
locates 2.25m over the conveyer center. The appurtenance can be a supporting
wire or any existing fixings. The supporting wire can provide a strutting piece and
it can be tightened by a screw every 75m. In order to prevent the heat cable falling,
firmly clip the supporting wire and heat cable every 4m～5m with a fastener. It’s
recommended that the supporting wire be aφ2 stainless steel rope, each not be
over 150m long (galvanized steel ropes can be used as a replacement ). The
mounting method is shown in Fig. 11.
Retaining
Clip Supporting Wire
the
Terminal
Box
Trunbuckle
Screw
Conveyer Linear Cable Heat Detector
2.25m
Fig. 11 Mounting of the Heat Cable
The heat cable can be mounted on the two sides of the conveyer. Connect the
heat cable through heat-conductive board and roller bearing to detect over-heat
because of bearing friction and coal powder accumulating. Please install it
according to the field situation but do not affect operation and maintenance.
Mounting is shown in Fig. 12.
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
I-9106 Intelligent Linear Cable Heat Detector
Installation and Operation Manual The Intelligent Solution
Page 8
Fig. 12 Mounting of the Heat Cable
（4） Mounting on the Power Control Equipment
Take the heat cable mounting on the dynamo panel as an example. The whole
devices can be secured by reliable string prick. In case the ambient temperature
is suitable for the heat cable, transformer, switch, and main power distribution
device resistors can be mounted by the same method. See Fig. 13.
Dynamo Control Panel
Prick Utensil Heat Cable
Fig. 13Mounting of the Heat Cable
（5） Mounting on the Other Places
The heat cable can be mounted in dust collector, bag room, cooling tower,
municipal facilities and high warehouse. Its mounting method can be the same
as mounting under the ceiling. When mounting near or contacting the protected
device, refer to mounting in cable tray.
VI Designs and Applications
1 Applications
The detector is used to predict an early fire warning on power cable and control cable in
Retaining Clip
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
I-9106 Intelligent Linear Cable Heat Detector
Installation and Operation Manual The Intelligent Solution
Page 9
tunnels. It is applicable to power plant, transformer substation, steel mills, chemical
factories and ancient buildings. Those places can be classified as follows according to
the protected subjects.
（1）Switching Equipment: Switches, transformers, substations, dynamo control
centers and resistor chains etc.
（2）Cable bridge shelf, cable tunnels, intermediate layer of cable, cable trench,
and cable shaft etc.
（3）Strap transmission, automated assembly line.
（4）Floating tanks producing and storing chemical products.
（5）Highway and railways tunnels.
（6）Cold store, high density goods warehouse, liquor storehouse, articles house
and etc.
（7）Hydraulic pressure stations, lubricant oil store, oil tube corridor and liquid
–immersed regulator.
（8）Cooling tower, dust collector and etc.
（9）Do use Explosion-proof linear heat detector in the places where exists
gunpowder, blasting explosive, ammunition igniters.
2 Design Reference
When designing, select the specifications of the linear cable heat detector
according to the ambient mounting environment. Generally, select the rated action
temperature, if the highest temperature is above 30 in mounting place.℃The
interface with the first end of the heat cable enclosed should be located where the
detector is. Wiring of the heat cables should be referred to the characters of the
protected subject to make it in best condition. And the terminal should be far from
the electromagnetic field.
3 Applications
The detector is made up of the interface, the terminal and heat the cable, shown in
Fig. 14.
the Terminal
GWDL2
GWDL1
Heat Cable I
Interface N
GWDL4
GWDL3
GWDL2
GWDL1
the Terminal
the Terminal
GWDL4
GWDL3
GWDL2
GWDL1
GWDL4
GWDL3
GWDL2
GWDL1
Non-polarized Loop
Z2
Z1
Z1 Z2 Z3 Z4
Z1 Z2 Z3 Z4
………
Heat Cable II
Heat Cable I
Fig. 14 Composition of the Detector
Note: Interface 1 connects with two heat cables and Interface N connects
with a single heat cable.
4 Operations
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
I-9106 Intelligent Linear Cable Heat Detector
Installation and Operation Manual The Intelligent Solution
Page 10
(1) The address number of the interface should be programmed by hand held
programmer by project’s request before it is used to the system. The interface
is defaulted two loop, so it has two address numbers-- ×× and ×× +1. If the
address number is required to change, modify the address number of Loop I ，
and that of Loop II will be added to 1 automatically.
(2) When there only needs one heat cable, change the device type of the interface
from 8 to 18. See Hand Held Programmer Installation and Operation Manual
for details.
(3) After wiring and installation, power on the fire alarm control panel and enter
system commission state. First check whether all the interfaces registered and
write unregistered interface down to find faults. As for the registered interfaces,
they are defined as linear heat cable with device type 8 through fire alarm
control panel. See Fire Alarm Control Panel Installation and Operation Manual
for the specific definitions.
(4) All the interfaces, other detectors, modules are registered, power on the
system and make it in normal condition. At the time, the interface should not
report fault or alarm.
(5) The detector is made up of the interface, the terminal and heat cable. Fig. 14
shows its system composition.
VII Testing
Instructions: After installation and commission, register the devices through the fire
alarm control panel then check whether all the interfaces registered and write
unregistered interface down to find faults. As for the registered interfaces, make
simulation and manual fire test. When short condition occurs to the heat cable, the
address number of related interface will transmit such a status to the fire alarm control
panel which generates fire alarms.
1. Before testing, notify the proper authorities that the system is going to be
maintenance and out of service temporarily. Disable the zone or system
undergoing maintenance to avoid unwanted alarms.
2. Manual Fire Test: Remove the commission tool, put its Commission Zone close to
Fire Test position on the upper part of the terminal. Check whether the red LED is lit.
Remove the commission tool to clear fire condition, the system goes back in normal
monitoring state. Fig. 15 shows the fire test.
Fire
Test
Fig. 15 Fire Test
3. Simulation Fire Test: Put a part of curved cable into boiling water over 0.3m from
the terminal. The cable length in the water is 1m, and fire alarm should be given in
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
I-9106 Intelligent Linear Cable Heat Detector
Installation and Operation Manual The Intelligent Solution
Page 11
40s. Before testing, 3m～5m lengthened heat cable should be reserved for test.
4. Cut the cable which is put in the water and connect the terminal again, the system
will reset to the normal monitoring state
5. Check its wiring again when an interface fails to the test, then test it once more. If it
still fails, please return it for repair.
VIII Troubleshooting
1 Registration Fault: When registering the detector on fire alarm control panel, if
some interfaces cannot be registered, repair according to the following steps.
（1） Read the code by hand held programmer. Check the address number,
device type, to see whether they meet the design requirement or the code is
repeated. If the programmer fails to read codes, so it’s certain that there are
problems with the interface. If there is no problem with the address number and
device type, check the loop voltage and impedance, see if there is circuit fault.
（2） For the interface with fault, please contact local office of GST or GST
Company.
2 The interface gives fault: When the FACP is in normal monitoring state, if the fault
occurs on the interface, repair by the following steps.
（1） When the FACP is on, check the yellow Fault LED, if lit, there is fault on
the heat cable or its testing circuit and the terminal. If the Fault LED is not on,
press “Clear” on the FACP to see if the Red LED flashes when polling, if the Red
LED stops flashing, there is fault on the interface.
（2） Turn off the FACP. As for the interface with fault on the heat cable and the
terminal, check if circuit of the heat cable is open and check the resistor
between two connection poles. If it is 10KΩ, it is normal; if infinite, the terminal is
damaged.
（3） If there is not open circuit on the heat cable and the terminal after
checking, the interface is in trouble, please return it for repair.
3 The interface gives false alarm: When the FACP is in normal monitoring state, if the
interface of the detector alarms falsely, repair by the following steps.
（1） Turn off the FACP: First separate the heat cable and the terminal. Check if
their circuits are shorted separately. If the short circuit occurs to the terminal,
check the internal components; if the short circuit occurs to the heat cable,
please repair the heat cable.
（2） If short circuit is found on neither heat cable nor the terminal, please
return the interface for repair.
IX Maintenance
Measure the insulating resistor with 500VMΩmeter between the two-core cables every
half year. The resistance should be over 500MΩ( turn off the power and disconnect the
two ends of the heat cable when testing). If the value is below 500MΩ, replace the heat
cable.
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
I-9106 Intelligent Linear Cable Heat Detector
Installation and Operation Manual The Intelligent Solution
Page 12
1 Each loop should be tested once every year for manual fire alarm or simulation fire
alarm.
2 Every five years, each time should be made bulge test without breakage. If there is
breakage, replace the heat cable.
3 Check damage of the heat cable irregularly and take measures for those with
damaged outer sheathing.
X Cautions
1 The interface is defaulted double loop (device type is 8), which can be connected
with two heat cables. When one heat cable is required, the interface should be set
single one（device type is 18）. The cable heat can connect with any loop of terminals.
2 The enclosure of the fire alarm control panel should be grounded. When the
interface and the terminal are mounted indoors, fix them on the wall or metal bracket in
field. When mounted in open air, add rain-proof enclosure.
3 The heat cable mustn‘t be curved forcedly or twisted when mounting. Curve radius
of the heat cable should be over 15cm. Protect the sheathing against damage. And
package it properly to avoid squeeze.
4 The detector should be stored in the ventilation rooms where ambient temperature
is 0℃～45℃, with relative humidity 75%.
5 The interface should be mounted far away from strong electromagnetic zone. If the
loops are not galvanized, they must adopt shielded cable, with its shielded layer
connected with ground through earth terminal inside the interface. The interface has two
pairs of terminals for loops inside so that the loops can be divided inside the interface.
Connect with ground at dividing point to make sure Uniformity and continuity.
6 The terminal should be mounted away from strong electromagnetic field.
HTTP://GSTRU.RUE-MAIL: [email protected]

HTTP://WWW.HOMBI.RU
GST China
Gulf Security Technology Co., Ltd.
No. 80, Changjiang East Road, QETDZ, Qinhuangdao, Hebei,
P. R. China 066004
Tel: [phone]
Fax: [phone]
Email: [email protected]om.cn
www.gst.com.cn
GST UK
Global System Technology PLC
Lion Court, Staunton Harold Hall,
Melbourne Road, Ashby de la Zouch,
Leicestershire,
England LE65 1RT
Tel: [phone]
Fax: [phone]
Email: [e-mail]
www.gst.uk.com
GST Dubai
Global System Technology PLC
PO Box 17998 Unit ZA04 JEBEL ALI Free Zone,
Dubai, UAE
Tel: [phone]
Fax: [phone]
Email: [e-mail]
www.gst.uk.com
HTTP://GSTRU.RUE-MAIL: [email protected]
