Sumake LSG-60HM User manual

SUMAKE PNEUMATIC TOOLS
Low Profile Self Generated Vacuum Air Orbital
Sander W/6"-Muiltihole Hook Pad
LSG-60HM
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
Specification:
Free Speed
11,000 r/min
Orbit Diameter
5 mm
Sanding Pad
6”(150 mm)
Air Consumption
15 CFM (430 L/min)
Length
10.4” (265 mm)
Air Inlet (PT)
1/4” (6.35 mm)
Air Hose (I.D.)
1/4” (6.35 mm)
Air Pressure
90 psi (6.3 bar)
Net Weight
2.04 lbs (0.92 kg)
Noise and Vibration:
Vibration
EN ISO 28927-3
Noise
EN ISO 15744
Remark
Load:
2.08 m/s²
Sound Pressure Level
load: 82.5 dB(A)
Please always
wear ear
protector at
environment
noise level > 80
dB(A) due to
risk of impaired
hearing!
Sound power level
load: 93.5 dB(A)
Uncertainty
K= 1.5 m/s²
Uncertainty
K= 3dB
LSG-60HM-S-1512B-XPF

LSN(C)(G)-P-2008H-XP
LOW PROFILE SELF GENERATED VACUUM AIR ORBITAL SANDER W/ 5"(6") -MUILTIHOLE HOOK PAD
LOW PROFILE NON-VACUUM AIR ORBITAL SANDER W/ 5"(6") HOOK (VINYI) PAD
LSN-50(60)H(V)
LSC-50(60)H(V)
LSC-50(60)HM
LOW PROFILE CENTRAL-VACUUM AIR ORBITAL SANDER W/ 5"(6") HOOK (VINYI) PAD
LOW PROFILE CENTRAL-VACUUM AIR ORBITAL SANDER W/ 5"(6") -MUILTIHOLE HOOK PAD
LOW PROFILE SELF GENERATED VACUUM AIR ORBITAL SANDER W/ 5"(6") HOOK (VINYI) PAD
LSG-50(60)H(V)
LSG-50(60)HM

PARTS LIST
No. Parts No. Description Q'ty No. Parts No. Description Q'ty
1 XPA0040 External Retaining Ring 1 50LVJ0SY 5" Low Profile Screen Vac J-Hook Pad [LSC-50HM] 1
2 XPA0021 10x26x8 Bearing -2 Shields 1 60LNJ00 6" Non-Vac Vinyl Face Pad [LSN-60H] 1
3 XPB0017 Rear Endplate 1 60LVM06 6" Low Profile Screen Vac J-Hook Pad [LSC-60H] 1
4 XPA0005 20 Mm Cylinder Assembly 1 60LVJ0S 6" Low Profile Screen Vac J-Hook Pad [LSC-60HM] 1
5 XPA0042 5mm x 2.0mm O-Ring 1 50LVM05 5" Vac Hook Face Pad [LSG-50H] 1
6 XPB0005 Machined Rotor 1 60LVJ0S 6" Vac Hook Face Pad [LSG-60HM] 1
7 XPA0010 Vane 5 36 XPA0008 Valve Stem Assembly 1
8 XPA0041 3mm x 13mm Woodruff Key 1 37 XPA0015 Valve Sleeve 1
9 XPG0001 Front Endplate 1 38 HN2-04CA M4 Nut 1
10 XP50059 15 x 32 x 9 Bearing - 2 Shields 1 39 S6-0430A Hex.Socket Button Head Screw (M4x30) 1
11 XPA0045 39.4mm x 3.1mm O-Ring 1 40 XPF0003 Speed Control 1
12 XPF0002 Lock Ring 1 41 PW1-050D Plain Washer (M5x10L) 1
13 XPG0002 Cooling Fan 1 42 S6-0520A Hex. Socket Button Head Screw (M5x20) 1
14 XPF0067 Small Spacer-Cooling Fan 1 43 XPF0008 Muffler Cap 1
15 XPF0068 Large Spacer-Cooling Fan 1 44 XPF0011 Muffler Insert 1
16 XPF0020 Front Bearing Dust Shield 1 45 XPF0012 O-Ring (20mm x 1mm NBR70) [LSG-60HM] 1
XPG0003 5" 5mm Orbit Non-Airshield Plus Tm Shaft Balancer [LSN/LSC/LSG-50] 146 XPF0009 Sgv Exhaust Cap [LSG-60HM] 1
XPG0004 5" 2.5mm Orbit Non-Airshield Plus Tm Shaft Balancer [LSN/LSC/LSG-50] 147 XPF0010 Variable Exhaust 1
XPG0005 6" 5mm Orbit Non-Airshield Plus Tm Shaft Balancer [LSN/LSC/LSG-60] 148 XPF0054 Logo Insert - End Cap [SUMAKE] 1
XPG0006 6" 2.5mm Orbit Non-Airshield Plus Tm Shaft Balancer [LSN/LSC/LSG-60] 149 XPG0011 End Cap 1
18 XPA0938 12x28x16 Double Row Angular Contact Bearing - 1 Seal 1 50 XPA2475 Inlet Bushing Assembly 1
19 XPA0016 Spacer 12.1 ID x 18.0 OD x 0.2 THK 1 51 S6-0410A Hex.Socket Button Head Screw (M4x10) 3
20 XPA2542 Spindle Bearing Dust Shield 1 52 XPG0012 Exhsust Chamber 1
21 XPA0017 Belleville Wasfer 1 53 XPA2204 9.5mm x 1.0mm O-Ring 1
22 XPA0018 Retaining Ring 1 54 XPA2484 24mm x 1.0mm O-Ring 1
23 XPB0018 Spindle 1 55 XPF0013 Internal Muffler 1
24 XPG0007 Grip (75mm) Black 1 56 XPA0009 Valve Seat 1
25 XPA0039 Internal Retaining Ring 2 57 XPA0007 Valve 1
26 XPF0001 Speed Control (Preset) 1 58 XPF0094 Valve Spring 1
27 XPA0043 9mm x 1.5mm O-Ring 3 59 XPF0015 Non-Vacuum Cover (LSN) 1
28 XPF0057 Throttle Lever For 12,000 rpm, 5mm(3/16") Orbit Sander [SUMAKE] 1 XPG0013 5" Sgv Swivel Exhaust Fitting - 1" / 28mm Host [LSG-50H(HM)] 1
29 XPA0031 Lever Spring Pin 1 XPG0015 6" Sgv Swivel Exhaust Fitting - 1" / 28mm Host [LSG-60H(HM)] 1
30 XPG0021 Machined Housing 1 XPG0014 5" Cv Swivel Exhaust Fitting - 1" / 28mm Host [LSC-50H(HM)] 1
31 XP52028 5" / 6" Non-Vacuum Shroud (LSN) 1 XPG0016 6" Cv Swivel Exhaust Fitting - 1" / 28mm Host [LSC-60H(HM)] 1
32 XP52016 5" Cv Sgv Shroud [LSN-50/LSC-50/LSG-50] 1 65 XPA0778 1" / 28mm Hose Seal [LSG] 1
33 XP62006 6" Cv Sgv Shroud [LSN-60/LSC-60/LSG-60] 1 66 XPA0412 Φ1" Vac Hose To Double Bag Fitting And Airline Assembly [LSG] 1
34 XPA0022 24mm Pad Wrench 1 67 XPC0110 Vacuum Bag [LSG] 1
50LNJ00 5" Non-Vac Vinyl Face Pad [LSN-50H] 1 68 XPC0109 Vacuum Bag Insert [LSG] 1
50LNV00 5" Non-Vac Vinyl Face Pad [LSN-50V] 1
LSN(C)(G)-P-2008H-XP
17
62
LSN-50(60)H(V)
LOW PROFILE NON-VACUUM AIR ORBITAL SANDER W/ 5"(6") HOOK (VINYI) PAD
35
LSG-50(60)HM
LOW PROFILE SELF GENERATED VACUUM AIR ORBITAL SANDER W/ 5"(6") -MUILTIHOLE HOOK PAD
LOW PROFILE CENTRAL-VACUUM AIR ORBITAL SANDER W/ 5"(6") HOOK (VINYI) PAD
LSC-50(60)HM
63
35
LOW PROFILE CENTRAL-VACUUM AIR ORBITAL SANDER W/ 5"(6") -MUILTIHOLE HOOK PAD
LSG-50(60)H(V)
LOW PROFILE SELF GENERATED VACUUM AIR ORBITAL SANDER W/ 5"(6") HOOK (VINYI) PAD
LSC-50(60)H(V)

ECDECLARATION OF CONFORMITY
We: SUMAKE INDUSTRIAL CO., LTD.
4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan
declare in sole responsibility that the equipment
Equipment：LOW PROFILE SELF GENERATED VACUUM AIR ORBITAL SANDER
W/6"-MUILTIHOLE HOOK PAD
Model/ Serial No.：LSG-60HM
to which this declaration applies, complies with these normative documents:
Machinery Directive: 2006/42/EC
and conforms to the following EN standard,
EN ISO 12100: 2010
EN ISO 11148-8:2011
Name and Signature/Position Date and Place
2022/7/1
Mike Su –Managing Director Taipei, Taiwan
LSG-60HM-D-2207B-XPF

INSTRUCTION MANUAL
ITEM NO.:LSN-50H(V), LSN-60H(V)
LOW PROFILE NON-VACUUM AIR ORBITAL SANDER W/ 5”(6”) HOOK(VINYI) PAD
ITEM NO.: LSC-50H(HM)(V), LSC-60H(HM)(V)
LOW PROFILE CENTRAL-VACUUM AIR ORBITAL SANDER
W/ 5”(6”) HOOK(MULTIHOLE HOOK)(VINYI) PAD
ITEM NO.: LSG-50H(HM)(V), LSG-60H(HM)(V)
LOW PROFILE SELF GENERATED VACUUM AIR ORBITAL SANDER
W/ 5”(6”) HOOK(MULTIHOLE HOOK)(VINYI) PAD
LSN(C)(G)-I-1611D-XP

1
Work Stations
The tool is intended to be operated as a hand held tool. It is always recommended that the tool be used when standing on a solid floor.
It can be in any position but before any such use, the operator must be in a secure position having a firm grip and footing and be aware
that the sander can develop a torque reaction. See the section "Operating Instructions".
Putting the Tool into Service
Use a clean lubricated air supply that will give a measured air pressure at the tool of 90 PSI (6.3 bar) when the tool is running with the
lever fully depressed. It is recommended to use an approved 3/8 in. (10 mm) x 25 ft (8 m) maximum length airline. It is recommended
that the tool be connected to the air supply as shown in Figure 1.
Do not connect the tool to the airline system without incorporating an easy to reach and operate air shut off valve. The air supply
should be lubricated. It is strongly recommended that an air filter, regulator and lubricator (FRL) be used as shown in Figure 1 as this
will supply clean, lubricated air at the correct pressure to the tool. Details of such equipment can be obtained from your supplier. If such
equipment is not used then the tool should be manually lubricated
To manually lubricate the tool, disconnect the airline and put 2 to 3 drops of suitable pneumatic motor lubricating oil such as Fuji Kosan
FK-20, Mobil ALMO 525 or Shell TORCULA® 32 into the hose end (inlet) of the machine. Reconnect tool to the air supply and run tool
slowly for a few seconds to allow air to circulate the oil. If the tool is used frequently, lubricate it on a daily basis or lubricate it if the tool
starts to slow or lose power.
It is recommended that the air pressure at the tool be 90 PSI (6.3 Bar) while the tool is running so the maximum r/min is not exceeded.
The tool can be run at lower pressures but should never be run higher than 90 PSI (6.3 Bar). If run at lower pressure the performance
of the tool is reduced.
Operating Instructions
1. Read all instructions before using this tool. All operators must be fully trained in its use and aware of these safety rules. All
service and repair must be carried out by trained personnel.
2. Make sure the tool is disconnected from the air supply. Select a suitable abrasive and secure it to the back-up pad. Be careful
and center the abrasive on the back-up pad.
3. Always wear required safety equipment when using this tool.
4. When sanding always place the tool on the work then start the tool. Always remove the tool from the work before stopping. This
will prevent gouging of the work due to excess speed of the abrasive.
5. Always remove the air supply to the sander before fitting, adjusting or removing the abrasive or back-up pad.
6. Always adopt a firm footing and/or position and be aware of torque reaction developed by the sander.
7. Use only correct spare parts.
8. Always ensure that the material to be sanded is firmly fixed to prevent its movement.
9. Check hose and fittings regularly for wear. Do not carry the
tool by its hose; always be careful to prevent the tool from
being started when carrying the tool with the air supply
connected.
10. Dust can be highly combustible. Vacuum dust collection
bag should be cleaned or replaced daily. Cleaning or
replacing of bag also assures optimum performance.
11. Do not exceed maximum recommended air pressure. Use
safety equipment as recommended.
12. The tool is not electrically insulated. Do not use where
there is a possibility of coming into contact with live
electricity, gas pipes, water pipes, etc. Check the area of
operation before operation.
13. Take care to avoid entanglement with the moving parts of
the tool with clothing, ties, hair, cleaning rags, etc. If
entangled, it will cause the body to be pulled towards the
work and moving parts of the machine and can be very
dangerous.
14. Keep hands clear of the spinning pad during use.
15. If the tool appears to malfunction, remove from use im-
mediately and arrange for service and repair.
16. Do not allow the tool to free speed without taking precau-
tions to protect any persons or objects from the loss of the abrasive or pad.

2
Back-Up Pads
SUMAKE back-up pads are perfectly mated for use on the SUMAKE. Constructed from premium, industrial-quality materials and
featuring a riveted fiberglass and steel hub with molded urethane, their durability and precise construction are the ideal complement to
the performance of the SUMAKE. See "Product Configuration/Specifications" Table for the correct replacement pad for a particular
model.
Service Tools and Accessories
When an SUMAKE two handle needs to be serviced, we offer a tool kit to make the disassembly/assembly fast and easy. The Service
Tools are highly recommended for use with the Overhaul Service Kit.
NOTICE: To receive any expressed or implied warranty, the tool must be repaired by an authorized SUMAKE Service Center. The 5in.
and 6in Random Orbital Sanders Service Instructions section provided are for use after completion of the warranty period.
Description Part #
5in. low profile, non-vacuum, vinyl face 50LNV00
5in.low profile, non-vacuum, hook face 50LNM00
5in. low profile, vacuum, 6 holes, hook 50LVM06
5in. low profile, vacuum, 6 holes, J hook 50LVJS6
5in. low profile, vacuum, vinyl face 50LVV05
5in. low profile, vacuum, hook face 50LVM05
5in. low profile, screen vacuum, J hook face 50LVJ0S
6in. low profile, non-vacuum, vinyl face 60LNV00
6in. low profile, non-vacuum, hook face 60LNM00
6in. low profile. screen vacuum, J hook face 60LVJ0S
6in. low profile, vacuum, vinyl face 60LVV06
6in. low profile, vacuum, hook face 60LVM06

3
Overhaul Service Kit
The XPF0036 SUMAKE Overhaul Service Kit contains all the replacement parts that naturally wear over time and a straightforward
manual to make servicing an SUMAKE sander simple. Overhauling the Random Orbital Sander can be made even easier with the use
of the above Service Tools. The Service Tools also reduce the chance of improper assembly.
XPF0036 Overhaul Service Kit for 12,000 r/min 5” & 6” ROS Contents
Part No. Description Qty.
XPA0040 External Retaining Ring 1
XPA0021 Bearing 1
XPA0042 O-Ring 1
XPB0005 Rotor 1
XPA0010 Vanes 1
XPA0041 Key 1
XP50059 Bearing 1
XPA0937 Shim 1
XPA0938 Bearing 1
XPA0016 Spacer 1
XPA0008 Valve Stem Assembly 1
XPA0043 O-Ring 1
XPA0039 Internal Retaining Ring 1
XPG0012 Exhaust Chamber 1
XPA2204 9.2mm x 1.0mm O-Ring 1
XPA2484 2.4mm x 1.0mm O-Ring 1
XPF0013 Bronze Muffler 1
XPF0008 Muffler Cap 1
XPF0011 Muffler 1
XPA0009 Valve Seat 1
XPA0007 Valve 1
XPA0014 Valve Spring 1
XPB0118 Rotor 1

4
Sander Spare Parts Kits
Low Profile Random Orbital Sander Service Instructions
NOTICE: To receive any expressed or implied warranty, tool must be repaired by an authorized service center.
The 5”(127mm) and 6”(150mm) Orbital Sander service instructions section provided is for use after completion of the warranty period.
DISASSEMBLY INSTRUCTIONS
Changing Grips:
1. The Grip has two “tabs” that wrap around the wrap of the sander under the inlet and exhaust. Use a small screwdriver to pick out
in of the “tabs” of the Grip, and then continue to go underneath the Grip with the screwdriver and pry the grip off of sander. To
install a new Grip, hold the grip by the tabs making them face outward, align the Grip and slide it under the Throttle Lever them
press the Grip down until it seats onto the top of the sander. Make sure the two “tabs” seat under the inlet and exhaust.
Motor Disassembly
1. Lightly secure the tool in a vise using the XPA0026 soft Collar or padded jaw vice and remove the pad with the 24mm pad
wrench them remove the shroud or skirt (which-ever apples)
2. Remove the lock ring with the XPA0025 Motor lock ring wrench/Spindle Puller Tool. The moor assembly can now be lofted out of
the housing.
3. Secure the motor assembly by clamping the 5”(127mm) or 6”(150mm) shaft balancer in a padded jaw vise and remove the
retaining ring and the o-ring from the cylinder.
4. Remove the rear end plate. This may require supporting the rear endplate with a bearing separator and lightly pressing the shaft
through the bearing and rear end plate. Remove cylinder and the vanes and rotor set from the shaft of the shaft balancer.

5
Remove the key then press off the front end plate(with bearing), o-ring and the lock ring. It may be necessary to remove the
bearing with a bearing separator if it came out of front end plate and stuck to the shaft of the shaft balancer.
5. Remove and discard dust shield from the shaft balancer.
6. Remove the bearing from the endplates by using the XPA0036 bearing removal tool to press out the bearings.
Shaft Balancer and Spindle Disassembly:
1. Grip the shaft end of the shaft balancer in a padded vise. With a thin screwdriver pick out the slotted end of the Retaining Ring
and peel out
2. Screw the threaded end of the XPA0025 Motor Lock Ring Wrench/Spindle Puller Tool into the Spindle until hand tight. Apply a
gentle heat from a propane torch or hot air gun to the large end of the Balancer shaft until it is about 100℃(212℉) to soften the
adhesive. Do not over heat. Remove the spindle assembly by using the slider to give sharp outward blows to the spindle. Allow
the parts to cool so they are safe to handle. Follow one of the appropriate directions below.
If the Bearing come out with the spindle, use a small Bearing Separator to remove it. Move onto step 3.
If the Bearing stays in the Shaft Balancer. Follow steps A - D below.
Procedure for removal of the Bearings from the Shaft Balancer:
A. Position the Set Screw in the top of the XPA0059 12 mm ID Bearing Puller.
B. Make sure the Retaining Ring is removed, then press the Bearing Puller into the I.D. of Bearing until the Bearing Puller hits
the bottom of the Shaft Balancer.
C. Thread the Set Screw down until it hits the bottom of the Shaft Balancer or becomes very tight. Grip the shaft end of the
Shaft Balancer in a padded vise.
D. Screw the threaded end of the XPA0025 Motor Lock Ring Wrench/Spindle Puller Tool into the Bearing Puller until hand
tight. Apply a gentle heat from a propane torch or hot air gun to the large end of the Shaft Balancer to re-heat it until it is
about 212℉(100℃) to soften the adhesive. Do not over heat. Remove the Bearing by using the slider to give sharp
outward blows to the Bearing Puller. Allow the Bearing Puller, Bearing and Shaft Balancer to cool. After cooling, unthread
the T-6 Motor Lock Ring Wrench/Spindle Puller Tool from the Bearing Puller. Back off the set screw. Secure the Bearing
Puller and Bearings in a Bearing Separator and press out the Bearing Puller.
3. The SUMAKE components are held in place by the light press fit of the Retainer. These components can be damaged during
removal and may need to be replaced if removed. To remove the Retainer, use an O-ring pick or a #8 sheet metal screw to grip
and pull out the Retainer. Remove the Valve and Filter from the bore in the Shaft Balancer. If the Retainer and Valve were not
damaged, they can be reused. However, the filter should be replaced on re-assembly.
4. Remove the bearing from the Spindle. Remove the Spacer. Dust Shield and Washer from the Spindle. Discard Dust Shield.
Housing Disassembly:
1. For Non-Vacuum (LSN) and Central Vacuum (LSC) machines follow the steps outlined in Section I below. For Self Generated
Vacuum (LSG) machines follow the steps outlined in Section “C”
A. This section is for LSN and LSC machines.
(a) Unscrew the Muffler Housing from the Housing.
(b) Remove the Bronze Muffler from the Muffler Housing and remove the Muffler insert from the cavity of the Muffler
Housing.
(c) For LSN machines move onto (d). For LSC machines move onto Section “B”
(d) Remove the LSN Shroud. Move onto Step 2.
B. This section continued from Section I for LSC Exhaust machines:
(a) Remove the Screw, Washer and Nut.
(b) Remove the Φ1”(28mm). LSC Swivel Exhaust Assembly or the Φ3/4”(19mm) LSC Swivel Exhaust Assembly from the
Shroud or Screen Abrasive Shroud.
(c) Remove the Shroud or Screen Abrasive Shroud from the Housing. Move onto Step 2.
C. This section is for LSG Exhaust machines:
(a) Unscrew the LSG Retainer with an 8 mm hex wrench.
(b) Remove the Φ1”(28mm) Hose LSG Swivel Exhaust Assembly from the Housing and LSG Skirt Adapter or LSG Shroud
Adapter.
(c) Pull the LSG Retainer out of the bore of the Swivel Exhaust Assembly and remove the two O-rings.
(d) Remove the Vacuum Shroud or Vacuum Skirt from the Housing. Move onto step 2.
2. Place the Speed Control to the midway position and remove the Retaining Ring.
NOTE: If the machine is a vacuum model, the vacuum exhaust must be removed (see Section 1 above for removal) before
the Retaining Ring can be removed with lock ring pliers. The Speed Control will now pull straight out. Remove the O-ring.
3. Unscrew the Inlet Bushing Assembly from the Housing. Remove the Valve Spring, Valve, Valve Seat, Valve Stem and O-ring.

6
4. Press out the Spring Pin from the Housing and remove the Throttle Lever.
ASSEMBLY INSTRUCTIONS
NOTE:All assembly must be done with clean dry parts and all bearings are to be pressed in place by the correct tools and procedures
as outlined by the bearing manufacturers.
Housing Assembly:
1. Install Throttle Lever into Housing with the Spring Pin.
2. Lightly grease the O-ring and place it on the Speed Control. Install Valve Stem. O-ring (cleaned and lightly greased) and insert
the Speed control into the Housing in the midway position. Install the Retaining Ring.
CAUTION: Make sure the Retaining Ring is completely snapped into groove in the Housing.
3. Install the Valve Seat, the Valve and the Valve Spring. Coat the threads of the Bushing Assembly with 1 or 2 drops of Luctite®
222 or equivalent non-permanent pipe thread sealant. Screw the assembly into the Housing. Torque to 60 in/lbs (6.77 Nm.)
4. For LSN and LSC machines follow the steps outlined in Section I below. For LSG machines follow the steps in Section “D”.
A. This section is for LSC and LSN
(a) Place a clean felt Muffler all-the-way into the chamber of the Muffler Housing. Press the Bronze Muffler onto the Muffler
Housing.
(b) Screw the Muffler Housing assembly into the Housing until hand tight. Use a 21 mm socket/torque wrench combination to
torque the Muffler Housing. Torque to 20 in/lbs (2.25 Nm). For LSN machines move onto C. For LSC machines move
onto Section “B”.
(c) Install the Non-Vacuum Shroud onto the Housing by working the shroud over and around the bottom of the housing
flanges. Make sure the line up slots (on the Housing) and tabs (on the Shroud) are engaged. Move onto the "Spindle.
SUMKAE and Shaft Balancer Assembly Section.
B. This section continued from Section I for LSC Exhaust machines:
(a) For 5”(125mm) and 6”(150mm) machines:
(1) Install the 5”(125mm) or 6”(150mm) Shroud or 6”(150mm) Screen Abrasive Shroud onto the Housing by working the
shroud over and around the bottom of the housing flanges. Slide the inlet end of the Φ1”(28mm) LSC Swivel Exhaust
Assembly or the Φ3/4”(19mm) LSC Swivel Exhaust Assembly into the exhaust port of the Shroud or Screen Abrasive
Shroud until it hits the stop on the Swivel Exhaust Assembly.
NOTE: For installation of Shrouds and Skirts make sure the line up slots (on the Housing) and tabs (on the
Shroud or Skirt) are engaged. Make sure that the key on the Swivel Exhaust Assembly bracket is aligned and
engaged with the keyway on the Housing.
(b) Place the Washer over the Screw. Thread the screw into the mounting hole of the Swivel Exhaust Assembly and Housing
until the end of the screw is flush with the inside surface of the Housing. Place the Nut into the cavity of the Housing and
thread the Screw into the Nut until tight. Move onto the "Spindle. SUMAKE and Shaft Balancer Assembly" Section.
C. This section for LSG Exhaust machines:
(a) Install the Shroud or LSG Vacuum Skirt onto the Housing by working the shroud or skirt over and around the bottom of
the housing flanges. Make sure the line up slots (on the Housing) and tabs (on the Shroud or Skirt) are engaged.
(b) Attach the LSG Skirt Adapter or LSG Shroud Adapter to the exhaust port of the Shroud or LSG Skirt.
(c) Clean and lightly grease the two O-rings and place them in the two grooves in the LSG Retainer.
(d) Put the LSG Retainer into the mounting hole of the Φ1”(28mm) Hose LSG Swivel Exhaust Assembly.
(e) Push the Φ1”(28mm) Hose LSG Swivel Exhaust Assembly into the exhaust port of the LSG Skirt Adapter or LSG Shroud
Adapter. Screw the LSG Retainer into the threaded exhaust port on the Housing with an 8mm Hex Wrench. Torque to 45
in/lbs (5.08 Nm.).
Spindle, SUMAKE and Shaft Balancer Assembly:
1. Place the Washer on the Spindle shaft with the curve of the Washer facing up so that the outside diameter of the Washer will
contact the outer diameter of the Bearing. Place the Dust Shield onto the Spindle shaft. Place the Spacer onto the shoulder of
the Spindle. Note: Be sure that the Dust Shield is past the shoulder where Spacer rests. Place the Bearing on the Spindle with
the seal side toward the Washer. Press onto Spindle using the XPA0195 Spindle Bearing Press Tool (see figure) until seated at
bottom.
2. Insert Shim with tangs into the bottom of Spindle Bore of the Shaft Balancer. (Do not use this shim if Shaft Balancer text shows a
+ symbol.)
3. When the Spindle Assembly is done correctly, the Bearing will rotate freely but not loosely.
4. Take the new Filter and center it on the small bore that the original Filter was in before removal. With a small diameter
screwdriver or flat-ended rod, press the Filter into the bore until it is flat in the bottom of the bore. Place the Valve into the bore so
it is oriented correctly, then press the Retainer into the bore until it is flush with the bottom of the Bearing bore.

7
5. Apply a pin head size drop of #271 Loctite® or equivalent to the outside diameter of each of the bearings on the spindle
assembly. Spread the drop of bearing locker around the bearing until distributed evenly.
CAUTION: Only a very small amount of bearing locker is needed to prevent rotation of the bearing OD. Any excess will make
future removal difficult. Place the Spindle Assembly into the bore of the Shaft Balancer and secure with the Retaining Ring.
CAUTION: Make sure that the Retaining Ring is completely snapped into the groove in the Balancer Shaft. Allow the
adhesive to cure.
Motor Assembly:
1. Place the Dust Shield onto the shaft of the Shaft Balancer.
2. Use the larger end of the XPA0494 Bearing Press Sleeve to press the front Bearing (with 2 Shields) onto the shaft of the Shaft
Balancer.
3. Slide the Front Endplate with the bearing pocket facing down onto the Motor Shaft. Gently press the Front End Plate onto the
Bearing using the larger end of the XPA0494 Bearing Press Sleeve until the Front Bearing is seated in the bearing pocket of the
Endplate.
CAUTION: Only press just enough to seat the bearing into the pocket. Over-pressing can damage the bearing.
4. Place the Key into the groove on the Shaft Balancer. Place the Rotor on the Shaft Balancer, making sure that it is a tight slip fit.
5. Oil the five Vanes with a quality pneumatic tool oil and place them in the slots of the Rotor. Place the Cylinder Assembly over the
Rotor with the short end of the Spring Pin engaging the blind hole in the Front Endplate.
NOTE: The Spring Pin must project 0.6”(1.5mm) above the flanged side of the Cylinder.
6. Press fit the rear Bearing (2 shields) into the Rear Endplate with the XPA0195 Bearing Press Tool. Make sure the XPA0195
Press Tool is centered on the O.D. of the outer race. Lightly press fit the Rear Endplate and Bearing Assembly over the Shaft
Balancer using the small end of the XPA0494 Bearing Press Sleeve. The sleeve should press only the inner race of the bearing.
IMPORTANT: The Rear Endplate and Bearing Assembly is pressed correctly when the Cylinder is squeezed just enough
between the Endplates to stop it from moving freely under its own weight when the shaft is held horizontal, but be able to slide
between the Endplates with a very light force. If the assembly is pressed to tightly the motor will not run freely. If the pressed
assembly is to loose, the motor will not turn freely after assembly in the Housing. Secure the assembly by placing the
Retaining Ring in the groove of the Shaft Balancer.
CAUTION: The Retaining Ring must be placed so that the middle and two ends of the hoop touch the Bearing first. Both
raised center portions must be securely "snapped" into the groove in the Shaft Balancer by pushing on the curved portions
with a small screwdriver.
7. Lightly grease the O-Ring and place in the air inlet of the Cylinder Assembly.
8. Lightly grease or oil the inside diameter of the Housing, line up the Spring Pin with the marking on the Housing and slide the
Motor Assembly into the Housing. Make sure the Spring Pin engages the pocket in Housing.
9. Carefully screw the Lock Ring into the Housing with the XPA0025 Motor Lock Ring Wrench/Spindle Puller Tool. Torque to 60
in/lbs (6.77 Nm.)
NOTE:A simple technique to assure first thread engagement is to turn the lock ring counter clockwise with the XPA0025
Motor Lock Ring Wrench/ Spindle Puller while applying light pressure. You will hear and feel a click when the lead thread of
the lock ring drops into the lead thread of the housing.
10. Spin on a new Pad and hand tighten it using a 24 mm Pad Wrench.
Testing:
Place 3 drops of quality pneumatic air tool oil directly
into the motor inlet and connect it to a 90 PSI (6.3 bar)
air supply. A 12,000 r/min tool should run between
11,500 to 12,500 r/min when the air pressure is 90 PSI
(6.3 bar) at the inlet of the tool while the tool is running
at free speed. This free speed will be about 500 r/min to
1,000 r/min less when a Vacuum or Hook Face Pad is
used because of wind resistance. This will not affect
performance when sanding.
Loctite® is a registered trademark of the Loctite Corp.

8
Troubleshooting:
Symptom Possible Cause Solution
Insufficient Air Pressure
Check air line pressure at the Inlet of
the Sander while the tool is running at
free speed. It must be 90 PSI (6.3 Bar).
Clogged Muffler(s)
See the "Housing Disassembly" section
for Muffler removal. The Muffler can
be back flushed with a clean, suitable
cleaning solution until all contaminates
and obstructions have been removed. If
for Muffler can not be properly cleaned
then replace it. Replace Muffler insert
(See the "Housing Assembly" Section).
Plugged Inlet Screen
Clean the Inlet Screen with a clean,
suitable cleaning solution. If Screen
does not come clean replace it.
One or more Worn or Broken Vanes
Install a complete set of new Vanes
(all vanes must be replaced for proper
operation). Coat all vanes with quality
pneumatic tool oil. See "Motor Disassembly"
and "Motor Assembly".
Internal air leakage in the Motor Housing
indicated by higher than normal air
consumption and lower than normal
speed
Check for proper Motor alignment and
Lock Ring engagement. Check for
damaged 0-Ring in Lock Ring groove.
Remove Motor Assembly and Re-Install
the Motor Assembly. See " Motor
Disassembly" and "Motor Assembly"
Low Power and/or Low Free Speed
Motor Parts Worn Overhaul Motor. Contact authorized
Service Center.
Air leakage through the Speed
Control and/or Valve Stem. Worn or broken Spindle Bearings
Replace the worn or broken Bearings. See
"Shaft Balancer and Spindle
Disassembly" and "Spindle Bearings,
and Shaft Balancer Assembly".
Dirty, broken or bent Valve Spring, Valve
or Valve Seat.
Disassemble, inspect and replace worn
or damaged parts. See Steps 2 and 3
in "Housing Disassembly" and Steps 2
and 3 in "Housing Assembly".
Incorrect Pad Only use Pad Sizes and Weights
designed for the machine.
Addition of interface pad or other material
Only use abrasive and/or interface
designed for the machine. Do not attach
anything to the Sanders Pad face
that was not specifically designed to be
used with the Pad and Sander.
Improper lubrication or buildup of foreign
debris .
Disassemble the Sander and clean in
a suitable cleaning solution. Assemble
the Sander.
Worn or broken Rear or Front Motor
Bearing(s)
Replace the worn or broken Bearings.
See "Motor Disassembly" and "Motor
Assembly " .
Vibration/Rough Operation
For vacuum machines it is possible to
have too much vacuum while sanding on
a flat surface causing the pad to stick to
the sanding surface.
For LSG machines add extra washer(s)
to the pad spindle to increase the gap
between the pad and shroud. For LSC
machines reduce vacuum through
the vacuum system and/or add extra
washer(s) to the pad.

9
Read all these safety instructions before operating this product and save these instructions.
The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the
event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual.
Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd.
General safety rules:
1. Watch the tool at all times when in use.
2. People under the influence of alcohol or drugs are not allowed to use, repair or maintain the tool.
3. Keep unqualified persons, children, etc. away from the tool.
4. Keep work area clean and with sufficient daylight or artificial lighting. The work area on which the machine is used must be
cleaned up. Disorder is a potential cause of accidents.
5. Danger of explosion. Never use oxygen and combustible gas as an air supply for the tool which many be ignited by spark and
cause fire or explosion.
6. Never use gasoline or other flammable liquids to clean the tool.
7. Do not use air tools in potentially explosive atmospheres such as in the presence of flammable liquids, cleaning solvents, fluid
energy or stored gases.
8. Do not expose air tools to rain. Do not use air tools in damp or wet locations.
9. When a fault or failure is detected, the tool must immediately be disconnected from the air supply and returned for repair.
10. It is not permitted to modify the tool in any way.
11. When not in use, keep tools in a dry place, either locked up or in a high place, out of the reach of children.
12. Do not force small air tools to do the job of a heavy –duty task. Do not use air tool for purpose of which was not intended.
13. Wear suitable ear protection at environment noise level >80dB(A) and safety spectacles when using the tool. Always wear
approved safety goggles if work in dusty. This also applies to other persons in the nearby vicinity.
14. Do not wear loose clothing or jewelry. They can be caught in moving parts. Rubber gloves and non-skid foot wear are
recommended when working outdoors. Wear protective hair covering to contain long hair.
15. Keep proper footing and balance at all times.
16. Use clamps or a vice to hold work-piece. It is safer than using your hand and free both hands to operate the air tool.
17. When not use, before performing service or changing accessories, please disconnect tool from air compressor.
18. Do not carry plugged in air tool with your finger on the switch trigger. Be sure switch is in the “OFF” position when connecting to
air supply.
19. Watch what you are doing. Use common sense, even unsafe situation or unbalanced positions, particularly when you are tired.
20. Air powered tools can vibrate in use. Vibration, repetitive motions or uncomfortable positions may be harmful to your hands or
arms. Stop using any tool if discomfort, tingling feeling or pain occurs. Seek medical advice before resuming use.
21. For multiple hazards, read and understand the safety instructions before installing, operating, repairing, maintaining, changing
accessories on, or working near the sander. Failure to do so can result in serious bodily injury.
22. Only qualified and trained operators should install, adjust or use the sander.
23. Do not modify this sander. Modifications can reduce the effectiveness of safety measures and increase the risks to the operator.
24. Do not discard the safety instructions; give them to the operator.
25. Do not use a sander if the tool has been damaged.
26. Tools shall be inspected periodically to verify that the ratings and markings required by this part of EN ISO 11148 are legibly
marked on the tool. The employer/user shall contact the manufacturer to obtain replacement marking labels when necessary.
Safety precautions for projectile hazards
1. Be aware that failure of the workpiece or accessories, or even of the inserted tool itself can generate high-velocity projectiles.
2. Always wear impact-resistant eye protection during operation of the sander. The grade of protection required should be assessed
for each use.
3. For overhead work, wear a safety helmet.
4. The risks to others should also be assessed at this time.
5. Ensure that the workpiece is securely fixed.
Safety precautions for entanglement hazards
1. Choking, scalping and/or lacerations can occur if loose clothing, personal jewellery, neck wear, hair or gloves are not kept away
from the tool and accessories.
Safety precautions for operating hazards
1. Use of the tool can expose the operator's hands to hazards, including cuts and abrasions and heat. Wear suitable gloves to
protect hands.
2. Operators and maintenance personnel shall be physically able to handle the bulk, weight and power of the tool.
3. Hold the tool correctly; be ready to counteract normal or sudden movements and have both hands available.
4. Maintain a balanced body position and secure footing.
5. Release the start-and-stop device in the case of an interruption of the energy supply.
6. Use only lubricants recommended by the manufacturer.
7. Personal protective safety glasses shall be used; suitable gloves and protective clothing are recommended.
8. Inspect the backing pad before each use. Do not use if cracked or broken or if it has been dropped.

10
9. Avoid direct contact with the moving sanding pad in order to prevent pinching or cutting of hands or other body parts. Wear
suitable gloves to protect hands.
10. Never run the tool unless abrasive is applied to the workpiece.
11. There is a risk of electrostatic discharge if used on plastic and other non-conductive materials.
12. Potentially explosive atmospheres can be caused by dust and fumes resulting from sanding.
13. Always use dust extraction or suppression systems which are suitable for the material being processed.
Safety precautions for repetitive motions hazards
1. When using a sander to perform work-related activities, the operator can experience discomfort in the hands, arms, shoulders,
neck or other parts of the body.
2. While using a sander, the operator should adopt a comfortable posture whilst maintaining secure footing and avoiding awkward or
off-balance postures. The operator should change posture during extended tasks; this can help avoid discomfort and fatigue.
3. If the operator experiences symptoms such as persistent or recurring discomfort, pain, throbbing, aching, tingling, numbness,
burning sensations or stiffness, these warning signs should not be ignored. The operator should tell the employer and consult a
qualified health professional.
Safety precautions for accessory hazards
1. Disconnect the sander from the energy supply before fitting or changing the inserted tool or accessory.
2. Avoid direct contact with the inserted tool during and after use, as it can be hot or sharp.
3. Use only sizes and types of accessories and consumables that are recommended by the manufacturer of sanders; do not use
other types or sizes of accessories or consumables.
4. Grinding wheels and cutting-off tools shall not be used.
5. Check that the maximum operating speed of the inserted tool (flap wheels, abrasive belts, fibre discs, backing pads, etc.), is higher
than the rated speed of the sander.
6. Self-fixing sander discs shall be placed concentrically on the supporting pad.
Safety precautions for workplace hazards
1. Slips, trips and falls are major causes of workplace injury. Be aware of slippery surfaces caused by use of the tool and also of trip
hazards caused by the air line or hydraulic hose.
2. The sander is not intended for use in potentially explosive atmospheres and is not insulated against contact with electric power.
3. Ensure that there are no electrical cables, gas pipes, etc., which can cause a hazard if damaged by use of the tool.
Safety precautions for dust and fume hazards
1. Dust and fumes generated when using sanders can cause ill health (for example cancer, birth defects, asthma and/or dermatitis);
risk assessment and implementation of appropriate controls for these hazards are essential.
2. Risk assessment should include dust created by the use of the tool and the potential for disturbing existing dust.
3. Operate and maintain the sander as recommended in these instructions, to minimize dust or fume emissions.
4. Direct the exhaust so as to minimize disturbance of dust in a dust-filled environment.
5. Where dust or fumes are created, the priority shall be to control them at the point of emission.
6. All integral features or accessories for the collection, extraction or suppression of airborne dust or fumes should be correctly used
and maintained in accordance with the manufacturer's instructions.
7. Select, maintain and replace the consumable/inserted tool as recommended in the instruction handbook, to prevent an
unnecessary increase in dust or fumes.
8. Use respiratory protection in accordance with employer's instructions and as required by occupational health and safety
regulations.
Safety precautions for noise hazards
1. Exposure to high noise levels can cause permanent, disabling hearing loss and other problems, such as tinnitus (ringing, buzzing,
whistling or humming in the ears). Therefore, risk assessment and implementation of appropriate controls for these hazards are
essential.
2. Appropriate controls to reduce the risk can include actions such as damping materials to prevent workpieces from “ringing”.
3. Use hearing protection in accordance with employer's instructions and as required by occupational health and safety regulations.
4. Operate and maintain the sander as recommended in the instruction handbook, to prevent an unnecessary increase in the noise
level.
5. Select, maintain and replace the consumable/inserted tool as recommended in the instruction handbook, to prevent an
unnecessary increase in noise.
6. If the sander has a silencer, always ensure it is in place and in good working order when the tool is being operated.
Safety precautions for vibration hazards
1. Exposure to vibration can cause disabling damage to the nerves and blood supply of the hands and arms.
2. Wear warm clothing when working in cold conditions and keep your hands warm and dry.
3. If you experience numbness, tingling, pain or whitening of the skin in your fingers or hands, stop using the sander, tell your
employer and consult a physician.
4. Operate and maintain the sander as recommended in the instruction handbook, to prevent an unnecessary increase in vibration
levels.
5. Hold the tool with a light but safe grip, taking account of the required hand reaction forces, because the risk from vibration is

11
generally greater when the grip force is higher.
Additional safety instructions for pneumatic power tools
1. Air under pressure can cause severe injury.
2. Always shut off air supply, drain hose of air pressure and disconnect tool from air supply when not in use, before changing
accessories or when making repairs.
3. Never direct air at yourself or anyone else.
4. Whipping hoses can cause severe injury. Always check for damaged or loose hoses and fittings.
5. Whenever universal twist couplings (claw couplings) are used, lock pins shall be installed and whipcheck safety cables shall be
used to safeguard against possible hose-to-tool and hose-and-hose connection failure.
6. Do not exceed the maximum air pressure stated on the tool.
7. Never carry an air tool by the hose.
Specific safety instructions
Warnings shall be given about any specific or unusual hazards associated with the use of the sander. Such warnings shall indicate the
nature of the hazard, the risk of injury and the avoidance action to be taken.
Riskofinjury
1. Compressed air can inflict serious injuries. Therefore never point the air hose at another person or yourself.
2. Shut – off the air supply and disconnect the tool in case:
You want to change or replace accessories.
You want to clean, repair or maintain the tool.
The tool is not going to use for some times.
3. Check compressed air hose before use. If it is damaged, broken, torn, or deformed, the hose is not to be connected to the tool.
4. Always check the pneumatic couplings before using the tool. If they show signs of damage, fracture, cracking or excessive
corrosion, the respective tool or the air hose is not to be used.
5. Use only qualified adapters and connectors, In case of wear they are to be replaced immediately.
6. Only use air pipes that are fit for the use at maximum pressure.
Maintenance instruction:
1. Dry the filter (fig1) and the air inlet of the tool.
2. Lubricate the quick connect coupling to prevent blocking.
3. Air tool require lubrication throughout the life of the tool. The air motor and bearing uses compressed air to start the tool. The
moisture in compressed air will rust the air motor; you must lubricate the motor daily.
4. Avoid storing the tool in a location subject to high humidity. If the tool is left as it is used, the residual moisture inside the tool can
cause rust.
5. Before storage, lubricate tool and run it for a few seconds.
6. Regular inspection of spindles, threads, and clamping devices in respect of wear and tolerances for location of abrasive
products.
7. If the tool is too seriously damage to be used anymore, recycle raw material instead of disposing as waste. The machine,
accessories and packaging should be sorted for environmental-friendly recycling. Check with your local authority or retailer for
recycling advice.
www.SUMAKE.com
www.AIRCOMPRESSOR.com.tw
