SummaSign Pro T750 Pro User manual

USER’S MANUAL FOR THE
T-Series
IMPORTANT
Before you begin...
Please complete the attached Warranty Registration Card and
return it to Summa today or go through the online registration at
http://www.summa.be/registration.html.(Users outside Europe,
Africa and the Middle East should check the address on the back
of the Warranty Registration Card.)
Failure to return the duly completed Warranty Registration Card or
Online registration might delay response to your warranty and
service enquiries.
NOTE
When selecting software drivers: If the Summa name is not
mentioned in the list of available software drivers, use
Summagraphics drivers.

FCC NOTICE
The SummaSign Pro T-series cutters have been tested and found to comply
with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. These cutters generate, use, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications.
Operation of these cutters in a residential area is likely to cause harmful
interference in which case the user will be required to correct the
interference at his own expense.
Caution !
Changes or modifications, not expressly approved by Summa, who is
responsible for FCC compliance, could void the users authority to operate
this equipment.
DOC NOTICE
The SummaSign Pro T-series cutters do not exceed the Class A limits for radio
noise for digital apparatus set out in the Radio Interference Regulations of
the Canadian Department of Communications.

Notice
NOTICE
Summa reserves the right to modify the information contained in this User
Manual at any time without prior notice. Unauthorised copying, modification,
distribution or display is prohibited. All rights reserved. All queries, comments or
suggestions concerning this and other Summa manuals should be directed to:
Americas and Asia Pacific
Summa Inc.
10001 Lake City Way NE
SEATTLE, WA 98125
USA
Tel +(01) 206-527-1050
Fax +(01) 206-527-1046
E-mail [email protected]
Europe
Summa NV
Rochesterlaan 6
8470 GISTEL
Belgium
Tel +32 59 270011
Fax +32 59 270063
E-mail [email protected]
Copyright 1999, Summa N.V.

Trademark Acknowledgements
TRADEMARK ACKNOWLEDGEMENTS
3M and Scotchcal are trademarks of the 3M Corp.
Arlon is a trademark of Keene Corp.
DM/PL and Houston Instrument are trademarks of Summagraphics Corporation.
Fasson is a trademark of Avery.
Gerber is a trademark of Gerber Scientific Products, Inc.
Grafitack is a trademark of Grafityp.
HP-GL is a trademark of Hewlett-Packard Company.
IBM PC, IBM PC/XT, and IBM AT are trademarks of International Business
Machines Corp.
Kapco is a trademark of Kent Adhesive Products Co.
Macintosh, Macintosh Plus, Macintosh SE, and Macintosh II are trademarks of
Apple Computer.
MACTac is a trademark of MACTac Europe.
Multifix is a trademark of Multiplast Grafics.
Rubylith is a trademark of Ulano.
Tesa and Tesacal are trademarks of Tesa.

SummaSign Pro T-series Cutters User’ s Manual
Table of Contents TOC-i
TABLE OF CONTENTS .................................................................................Page
1. GENERAL INFORMATION
1.1. Introduction...................................................................................................1-1
1.1.1. Product features...........................................................................................1-1
1.1.2. SummaSign Pro T-series User Manual..........................................................1-3
1.2. Specifications ...............................................................................................1-4
1.2.1. Cutter ............................................................................................................1-4
1.2.2. Media ............................................................................................................1-4
1.2.3. Knives, balpoint pen and pouncing tool ..................................................1-6
1.2.4. Interface........................................................................................................1-6
1.2.5. Firmware........................................................................................................1-7
1.2.6. Performance.................................................................................................1-7
1.2.7. Certifications.................................................................................................1-7
1.2.8. Environmental...............................................................................................1-8
1.2.9. Electrical .......................................................................................................1-8
1.3. Cutter options, accessories and consumables..........................................1-9
1.4. Rear panel components ............................................................................1-10
1.5. Front panel controls....................................................................................1-12
1.6. Powering up the cutter...............................................................................1-14
1.6.1. Earthing .......................................................................................................1-14
1.6.2. Power-up procedure .................................................................................1-15
1.7. Installation of a knife, pen or pouncing tool ............................................1-16
1.7.1. Installing a standard tangential knife.......................................................1-16
1.7.2. Installing a knife for cutting masking stencil or heavy materials............1-20
1.7.3. Installing a drag knife.................................................................................1-21
1.7.4. Installing a ballpoint pen...........................................................................1-23
1.7.5. Installing a pouncing tool..........................................................................1-24
1.8. Loading media ..........................................................................................1-26
1.8.1 Positioning the pinch rollers .......................................................................1-26
1.8.2. Feeding and positioning media................................................................1-27
1.9. Media load procedure ..............................................................................1-31

SummaSign Pro T-series Cutters User’ s Manual
Table of Contents TOC-ii
2. OPERATION
2.1. The control panel..........................................................................................2-1
2.1.1 The liquid crystal display..............................................................................2-2
2.1.2 The Reset/Load key......................................................................................2-2
2.1.3 The Online key..............................................................................................2-3
2.1.4 The Menu key...............................................................................................2-3
2.1.5 The Enter key.................................................................................................2-5
2.1.6 The 1 and 2 keys...........................................................................................2-5
2.1.7 The jogging keys...........................................................................................2-5
2.1.8 The Tool Up/Down key.................................................................................2-5
2.1.9 The Tool Select key.......................................................................................2-6
2.2. Normal Operation........................................................................................2-7
2.2.1 On line and off line......................................................................................2-7
2.2.2 Local operation............................................................................................2-8
2.3. The USER CONFIG menu..............................................................................2-9
2.3.1 Knife pressure..............................................................................................2-11
2.3.2 Pen pressure................................................................................................2-11
2.3.3 Pouncing pressure......................................................................................2-11
2.3.4 Knife offset...................................................................................................2-11
2.3.5 Pouncing gap.............................................................................................2-12
2.3.6 Velocity.......................................................................................................2-12
2.3.7 Overcut.......................................................................................................2-12
2.3.8 System setup...............................................................................................2-12
2.4. System setup...............................................................................................2-13
2.4.1 Concatenation...........................................................................................2-13
2.4.2 Smoothing ..................................................................................................2-13
2.4.3 Emulate ......................................................................................................2-13
2.4.4 Tool..............................................................................................................2-14
2.4.5 Menu units...................................................................................................2-14
2.4.6 Addressing..................................................................................................2-14
2.4.7 Baud rate....................................................................................................2-14
2.4.8 Parity............................................................................................................2-15
2.4.9 RTS/DTR........................................................................................................2-15
2.4.10 DM/PL errors................................................................................................2-16
2.4.11 HP/GL errrors...............................................................................................2-16
2.4.12 HP/GL origin .........................................................................................2-16
2.4.13 Media sensors.............................................................................................2-17
2.4.14 Autoload.....................................................................................................2-17
2.4.15 Tool command...........................................................................................2-17
2.4.16 LOAD ON W CMD.......................................................................................2-17
2.4.17 FLEX-CUT......................................................................................................2-18

SummaSign Pro T-series Cutters User’ s Manual
Table of Contents TOC-iii
2.4.18 Recut offset.................................................................................................2-18
2.5. Internal test menu ......................................................................................2-19
2.5.1 Tangential knife calibration.......................................................................2-20
2.5.1.1 Adjust Origin test routine............................................................................2-22
2.5.1.2 Adjust Lat. test routine................................................................................2-23
2.5.1.3 Adjust Long test routine .............................................................................2-24
2.5.2 Cut border ..................................................................................................2-25
2.5.3 Menu plot....................................................................................................2-25
2.5.4 Confidence cut..........................................................................................2-26
2.5.5 DIN plot ......................................................................................................2-26
2.5.6 System tests ................................................................................................2-26
2.6 System tests.................................................................................................2-27
2.6.1 Language ..................................................................................................2-27
2.6.2 ROM revision ...............................................................................................2-27
2.6.3 Service plot .................................................................................................2-27
2.6.4 Sensor setup................................................................................................2-28
2.6.5 Calibration ..................................................................................................2-28
2.6.6 Tracking test ................................................................................................2-28
2.6.7 Friction plot .................................................................................................2-28
2.6.8 RS232 test ....................................................................................................2-28
2.6.9 RAM test ......................................................................................................2-29
2.6.10 Install menu ................................................................................................2-29
2.6.11 Setup coil ....................................................................................................2-29
2.6.12 LCD contrast ...............................................................................................2-29
3. MAINTENANCE AND CLEANING
3.1. Maintenance ................................................................................................3-1
3.1.1 Cleaning the drive system...........................................................................3-1
3.1.2 Cleaning the sensors....................................................................................3-2
3.1.3 Cleaning the nose piece.............................................................................3-3
3.2. Operating voltage conversion ....................................................................3-4
4. INTERFACE
4.1. Introduction...................................................................................................4-1
4.2. Interface notes..............................................................................................4-1
4.2.1 System setup.................................................................................................4-1
4.2.1.1 MS-DOS or PC-DOS generating system......................................................4-1
4.2.1.2 Windows 3.xx.................................................................................................4-2
4.2.1.3 Windows 95...................................................................................................4-2

SummaSign Pro T-series Cutters User’ s Manual
Table of Contents TOC-iv
4.2.2 Serial interface connector on cutter..........................................................4-3
4.2.3 Parallel interface connector on cutter ......................................................4-3
4.3. Available serial signals ................................................................................4-4
5 CONTOUR CUTTING
5.1 Introduction...................................................................................................5-1
5.2 General (see section 6 for the actual procedure details) ........................5-5
5.3 Creating the design .....................................................................................5-5
5.4 Placing the Cross-marks..............................................................................5-6
5.5 Printing the design........................................................................................5-7
5.6 Loading the cutter and setting the parameters .........................................5-8
5.7 Registrating the cross-marks .......................................................................5-9
5.8 Cutting the contour ....................................................................................5-11
APPENDIX A:
Media certification ...................................................................................... A-1
LIST OF ILLUSTRATIONS
1-1 SummaSign Pro T-series cutter, rear view.................................................1-10
1-2 SummaSign Pro T-series cutter, front view ................................................1-12
1-3 Earth connection........................................................................................1-15
1-4 Standard knife assembly ...........................................................................1-16
1-5 Nose piece installation ..............................................................................1-17
1-6 Knife holder insertion..................................................................................1-17
1-7 Knife depth adjustment .............................................................................1-18
1-8 Knife depth test pattern.............................................................................1-19
1-9 Sandblast knife assembly ......................................................................... 1-20
1-10 Nose piece and knife installtion for cutting masking stencils or
heavy materials..........................................................................................1-21
1-11 Drag knife assembly...................................................................................1-22
1-12 Drag knife holder insertion.........................................................................1-22
1-13 Ballpoint pen assembly .............................................................................1-23
1-14 Ballpoint holder insertion ...........................................................................1-24

SummaSign Pro T-series Cutters User’ s Manual
Table of Contents TOC-v
1-15 Media positioning.......................................................................................1-27
1-16 Feeding roll media using media flanges .................................................1-28
1-17 Feeding roll media without ......................................................................1-29
1-18 Pinch roller positioning ...............................................................................1-29
2-1 SummaSign Pro T-series cutter, control panel ...........................................2-1
2-2 Configuration submenus .............................................................................2-4
2-3 Flowchart showing factory preset menu settings....................................2-10
2-4 Internal tests submenus .............................................................................2-20
2-5 Possible knife calibration grounds ............................................................2-21
3-1 Cleaning of the media drive sleeves .........................................................3-2
3-2 Location of the sensors ................................................................................3-2
3-3 Power entry module ....................................................................................3-4
LIST OF TABLES
1-1 SummaSign Pro T-series cutter specifications ............................................1-4
1-2 SummaSign Pro T-series media specifications ...........................................1-4
1-2 SummaSign Pro T-series media specifications (cont'd).............................1-5
1-3 SummaSign Pro T-series knives, ballpoint pen and pouncing tool .........1-6
1-4 SummaSign Pro T-series interface specifications .......................................1-6
1-5 SummaSign Pro T-series firmware................................................................1-7
1-6 SummaSign Pro T-series performances.......................................................1-7
1-7 SummaSign Pro T-series environmental specifications..............................1-8
1-8 SummaSign Pro T-series electrical specifications ......................................1-8
1-9 SummaSign Pro T-series accessories and consumables...........................1-9
2-1 Contents of the SummaSign Pro T-series menus........................................2-5

General Information 1-1
SECTION 1
GENERAL INFORMATION
1.1. INTRODUCTION
The SummaSign range of cutters has been designed to produce computer-
generated graphic designs on cut sheet or roll vinyl media. By replacing the
knife with a ballpoint pen, these cutters can also be used to produce
inexpensive previews of new graphic designs on paper.
This manual is a reference guide for installing and operating the SummaSign
Pro T-series cutter models. These cutter models feature a tangential head
indicated by the ‘T’ prefix to the product designation.
This manual covers the following SummaSign Pro T-series cutter models :
•The SummaSign T750 Pro, which can handle media widths from 60 mm up to
762 mm (2.4” to 30”).
•The SummaSign T1010 Pro, which can handle media widths from 110 mm up
to 1020 mm (4” to 40”).
•The SummaSign T1400 Pro, which can handle media widths from 110 mm up
to 1370 mm (4” to 54”).
The term ‘Pro T-series cutters’ is used when information is provided which is
common to all members of this series. The specific model terms T750 Pro, T1010
Pro and T1400 Pro are used if information pertains only to that particular model.
1.1.1. PRODUCT FEATURES
The following are the main features of the SummaSign Pro T-series cutters.
•Variable media widths.
•User-selectable DM/PLTM, HP/GLTM and HP/GL/2 TM software languages.
•Interchangeable drag knife

SummaSign Pro T-series Cutters User’ s Manual
General Information 1-2
•Interchangeable ballpoint pen for producing preview plots of sign designs
on paper.
•Interchangeable pouncing tool.
•Adjustable knife pressure (and offset settings)controlled by microprocessor.
•Communication with host computer via standard serial RS-232-C or
Centronics parallel interface.
•12-key control panel.
•Metric or English units.
•User-addressable resolution : 0.1 mm, 0.025 mm, 0.001" or 0.005".
•Menu mode for selection of the cutter's power-up operating configuration.
•Convenient operator control via a 2-line 16-character liquid crystal display.
•Extensive internal test routines.
•Wide variety of cutting speeds (in metric or English units).
•Up to four separate user configurations stored in non-volatile memory.
•Media support system for automatic loading of media with optional
“shuffling” to guarantee tracking of longer signs.
•Automatic media pull from roll.
•Media sensing.
•Simple origin adjustment to any location.
•Concatenation and curve smoothing to obtain better cut quality.
•Multiple recut feature.
•Re-cut of last file.
•Knife depth and offset test.
•Overcut for easy weeding.

SummaSign Pro T-series Cutters User’ s Manual
General Information 1-3
1.1.2. SUMMASIGN PRO T-SERIES USER MANUAL
This user manual provides the following information :
•Full technical specifications for the SummaSign Pro T-series cutters and the
media to be cut.
•A complete description of the SummaSign Pro T-series main components.
•Step-by-step instructions for knife and ballpoint pen installation and media
loading.
•Instructions for online and local mode ( ) operations.
•Instructions for USER CONFIGURATION and INTERNAL TESTS operations.
•Maintenance and cleaning instructions.
•Information about the RS-232-C and Centronics interface cables used to
inter-connect the cutter and IBM, IBM-compatible, Apple and Apple-
compatible host computers.

SummaSign Pro T-series Cutters User’ s Manual
General Information 1-4
1.2. SPECIFICATIONS
1.2.1. CUTTER
T750 Pro
with optional
stand
T1010 Pro
with standard
stand
T1400 Pro
with standard
stand
mm inch mm inch mm inch
Height without stand 265 10.43 265 10.43 265 10.43
with stand 1100 43.31 1100 43.31 1100 43.31
Width without stand 1270 50.00 1670 65.75 2015 79.33
with stand 1270 50.00 1670 65.75 2015 79.33
Depth without stand 550 21.65 550 21.65 550 21.65
with stand 550 21.65 550 21.65 550 21.65
Weight without stand 31 kg 68 lbs 38 kg 84lbs 43 kg 93 lbs
with stand 46 kg 101 lbs 54 kg 119 lbs 61 kg 134 lbs
TABLE 1-1 :
SUMMASIGN PRO T-SERIES CUTTER SPECIFICATIONS
1.2.2. MEDIA
T750 Pro T1010 Pro T1400 Pro
mm inch mm inch mm inch
Width 70 to 762 2.4 to 30 110 to 1020 4 to 40 110 to 1370 4 to 54
Max width Sheets & rolls up to
762 mm (30”) wide
can be
accommodated
Sheets & rolls up to 1200
mm (47”) wide can be
accommodated
Sheets & rolls up to
1545 mm (61”) wide
can be
accommodated
Tracking
Performance - 12 m/39 feet max. within guaranteed specifications * for media less than
750 mm (30”) wide.
- 4 m/13 feet max. within guaranteed specifications ** for media larger than
750 mm (30”).
TABLE 1-2 :
SUMMASIGN PRO T-SERIES MEDIA SPECIFICATIONS

SummaSign Pro T-series Cutters User’ s Manual
General Information 1-5
T750 Pro T1010 Pro T1400 Pro
mm inch mm inch mm inch
Thickness 0.05 to
1.2 0.002 to
0.050 0.05 to 1.2 0.002 to
0.050 0.05 to 1.2 0.002 to
0.050
Max.cutting/
plotting area 720 27.7 995 39.2 1345 53
Min. Margin***
Unperforated
Perforated 25
55 1.0
2.2 25
55 1.0
2.2 25
55 1.0
2.2
Front Margin 25 1.0 25 1.0 25 1.0
Rear Margin
Sensor on
Sensor off 42
30 1.7
1.2 42
30 1.7
1.2 42
30 1.7
1.2
* Media lengths greater than 12 m (39 feet) can be handled, but compliance with
specifications is not guaranteed (will be dependent on media type, media size and other
parameters).
** Media lengths greater than 4 m (13 feet) can be handled, but compliance with
specifications is not guaranteed (will be dependent on media type, media size and other
parameters).
*** for positioning of the pinch rollers (see section 1.8.)
TABLE 1-2 :
SUMMASIGN PRO T-SERIES MEDIA SPECIFICATIONS (CONT’D)
Vinyl Types
A wide range of vinyl types has been evaluated and tested on the SummaSign
Pro T-series cutters. When using duly certified media, operation in accordance
with the functional specifications of the model is warranted. Other media
should be certified by CalComp before use to ensure performance in
compliance with specifications.
For a full list of all duly certified media suitable for friction drive operation, see
Appendix A.
Plotting Paper
Bond paper (120 g/m2recommended)

SummaSign Pro T-series Cutters User’ s Manual
General Information 1-6
1.2.3. KNIVES BALLPOINT PEN AND POUNCING TOOL
The SummaSign Pro cutters are supplied with two standard knives (for vinyl
media),one masking stencil knife, one drag knife and one black ballpoint pen.
Tangential Knife Medium Quantity
supplied
Standard knife
(requires a standard knife holder along
with a standard grey nose piece)
standard, reflective &
fluorescent vinyl types 2 off
2 off
Double tip knife for high-density
reflective materials
(requires a standard knife holder)
high-density reflective
vinyl types optional
Knife for masking stencils
(requires a standard knife holder along
with black nose piece)
masking stencils &
thick materials 1 off
1 off
1 off
Drag Knife
Standard drag knife
(requires a drag knife holder)standard, reflective &
fluorescent vinyl types 1 off
1 off
Pen Colour Quantity
Ballpoint pen
(requires a ballpoint pen holder) black 1 off
1 off
Pouncing Tool Paper optional
TABLE 1-3 :
SUMMASIGN PRO T-SERIES KNIVES, PENS AND POUNCING TOOLS
To order replacement knives, pens and/or pouncing tools, contact your local
dealer, quoting the part numbers listed in table 1-9. The SummaSign Pro cutters
will only perform according to specifications if a Summagraphics genuine knife,
pen is installed. Do not replace the standard knife, pen or pouncing tool with
products from other manufacturers.
1.2.4. INTERFACE
Communication standard asynchronous RS-232-C and
Centronics parallel interface
Serial : I/O Port connector DB-9P
Mating connector DB-9S
Byte format 8 data bits, 2 stop bits, no parity
Baud rate 38400, 19200, 9600, 4800, 2400 bps
Parallel : I/O Port connector Centronics female
Mating connector Centronics male
TABLE 1-4 :
SUMMASIGN PRO T-SERIES INTERFACE SPECIFICATIONS

SummaSign Pro T-series Cutters User’ s Manual
General Information 1-7
1.2.5. FIRMWARE
Language DM/PL, HP/GL (758x emulation),
HP/GL/2
Supported character sets Standard ASCII
Supported fonts Sans serif (single stroke & medium)
ROM-based plots Confidence plot, DIN plot
TABLE 1-5 :
SUMMASIGN PRO T-SERIES FIRMWARE
1.2.6. PERFORMANCE
Cutting specifications on 0.05 mm (0.002") wax-backed vinyl, total media
thickness not greater than 0.25 mm (0.010")
Axial speed 50 to 1000 mm/s 2 to 40 ips
Default speed 800 mm/s 32 ips
Acceleration 3 G 3 G
Addressable resolution 0.025 mm, 0.1 mm 0.001", 0.005"
Default resolution 0.025 mm 0.001"
Mechanical resolution 0.0127 mm 0.0005"
Accuracy 0.2% of move or 0.25
mm, whichever is
greater*
0.2% of move or 0.010",
whichever is greater*
Knife pressure 0 to 600 gr. 0 to 600 gr.
Pen pressure 0 to 600 gr. 0 to 600 gr.
Pouncing pressure 0 to 600 gr. 0 to 600 gr.
*Excludes differences due to media expansion, stretching, etc.
TABLE 1-6 :
SUMMASIGN PRO T-SERIES PERFORMANCES
1.2.7. CERTIFICATIONS
CE Certificate
FCC Class A
Comply with UL 1950, CSA 950

SummaSign Pro T-series Cutters User’ s Manual
General Information 1-8
1.2.8. ENVIRONMENTAL
(cutter without media)
Operating Temperature 15 to 35°C 59 to 95°F
Storage temperature -30 to 70°C -22 to 158°F
Relative humidity 35 - 85 %, non con-
densing 35 - 85 %, non con-
densing
TABLE 1-7 :
SUMMASIGN PRO T-SERIES ENVIRONMENTAL SPECIFICATIONS
IMPORTANT HINT
The use of dimensionally stable media is an essential pre-requisite to
obtaining high cut quality. Additionally, media expansion or
contraction may occur as a result of temperature variations.
To improve the dimensional stability of media, let it stabilize to the
current environmental conditions before usage, for a minimum period
of 24 hours.
1.2.9. ELECTRICAL
Mains Supply : 48-62 Hz, single phase.
Nominal line Min./Max. line Fuse
100 V AC 89 - 108 V AC 1.25 A, Slo-Blo
120 V AC 108 - 130 V AC 1.25 A, Slo-Blo
220 V AC 197 - 238 V AC 0.6 A, Slo-Blo
240 V AC 216 - 260 V AC 0.6 A, Slo-Blo
TABLE 1-8 :
SUMMASIGN PRO T-SERIES ELECTRICAL SPECIFICATIONS

SummaSign Pro T-series Cutters User’ s Manual
General Information 1-9
1.3. CUTTER ACCESSORIES AND CONSUMABLES
The following is an overview of the accessories and consumables available for
the various SummaSign Pro T-series models:
OPTIONS/
ACCESSORIES/
CONSUMMABLES T750 Pro T1010 Pro
T1400 Pro
Cutter Stand Optional 391-400 standard
User’s Manual MD9045
Power Supply Cables MC1184 (Europe)
MC3545(US)
Serial Interface Kit,
consisting of :
- 9 pin to 9 pin cable
- 9 pin to 8 pin DIN conv
423-155
TANGENTIAL knife holder 391-663
Standard TANGENTIAL
knife (1 off) 390-549
Double tip knife 390-551
Standard nose piece 391-664
TANGENTIAL knife for
masking stencil (1 off) 390-550
Nose piece for masking
stencil 391-666
Ballpoint holder 391-667
Ballpoint pen 391-669
Holder for drag knife 391-668
Drag knife (set of 5) 391-360
2 Flanges for media roll 391-510
Manual cut-off razor
blades (set of 10) 391-146
Razor blade & holder 391-142
Pouncing tool 391-981
TABLE 1-9 :
SUMMASIGN PRO T-SERIES ACCESSORIES AND CONSUMABLES

SummaSign Pro T-series Cutters User’ s Manual
General Information 1-10
1.4. REAR PANEL COMPONENTS
In order to get acquainted with your SummaSign Pro cutter, read the following
description of the rear panel components. Figure 1-1 shows the location of the
main components.
FIGURE 1-1 :
SUMMASIGN PRO T-SERIES CUTTERS, REAR VIEW*
FOR PRACTICAL REASONS, ILLUSTRATIONS RELATE TO THE T750 PRO MODEL. ALL MEMBERS OF THE
PRO T-SERIES CUTTERS ARE SIMILAR EXCEPTING IN WIDTH.
This manual suits for next models
2
Table of contents
Other SummaSign Pro Cutter manuals
