20-40GbyteSPARCstorage™
DLT™4000TapeDriveManual
Part No.: 805-0810-10
Revision A, February 1997
Sun Microsystems Computer Company

Please
Recycle
Copyright 1997 Sun Microsystems, Inc. 2550 Garcia Avenue, Mountain View, California 94043-1100 U.S.A. All rights reserved.
This product or document is protected by copyright and distributed under licenses restricting its use, copying, distribution, and decompilation.
No part of this product or document may be reproduced in any form by any means without prior written authorization of Sun and its licensors,
if any.
Portions of this product may be derived from the UNIX®system, licensed from Novell, Inc., and from the Berkeley 4.3 BSD system, licensed from
the University of California. UNIX is a registered trademark in the United States and in other countries and is exclusively licensed by X/Open
Company Ltd. Third-party software, including font technology in this product, is protected by copyright and licensed from Sun’s suppliers.
RESTRICTED RIGHTS: Use, duplication, or disclosure by the U.S. Government is subject to restrictions of FAR 52.227-
14(g)(2)(6/87) and FAR 52.227-19(6/87), or DFAR 252.227-7015(b)(6/95) and DFAR 227.7202-3(a).
Sun, Sun Microsystems, the Sun logo, SunOS, AnswerBook, SunVTS, SunDiag, and Solaris are trademarks or registered trademarks of Sun
Microsystems, Inc. in the United States and in other countries. All SPARC trademarks are used under license and are trademarks or registered
trademarks of SPARC International, Inc. in the United States and in other countries. Products bearing SPARC trademarks are based upon an
architecture developed by Sun Microsystems, Inc. DLT is claimed as a trademark by Quantum Corporation in the United States and other
countries.
The OPEN LOOK®and Sun™ Graphical User Interfaces were developed by Sun Microsystems, Inc. for its users and licensees. Sun
acknowledges the pioneering efforts of Xerox Corporation in researching and developing the concept of visual or graphical user interfaces for the
computer industry. Sun holds a nonexclusive license from Xerox to the Xerox Graphical User Interface, which license also covers Sun’s licensees
who implement OPEN LOOK GUIs and otherwise comply with Sun’s written license agreements.
THIS PUBLICATION IS PROVIDED “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR
NON-INFRINGEMENT.
Copyright 1997 Sun Microsystems, Inc., 2550 Garcia Avenue, Mountain View, Californie 94043-1100 U.S.A. Tous droits réservés.
Ce produit ou document est protégé par un copyright et distribué avec des licences qui en restreignent l’utilisation, la copie et la décompilation.
Aucune partie de ce produit ou de sa documentation associée ne peut être reproduite sous aucune forme, par quelque moyen que ce soit, sans
l’autorisation préalable et écrite de Sun et de ses bailleurs de licence, s’il y en a.
Des parties de ce produit pourront être derivées du système UNIX®licencié par Novell, Inc. et du système Berkeley 4.3 BSD licencié par
l’Université de Californie. UNIX est une marque enregistrée aux Etats-Unis et dans d’autres pays, et licenciée exclusivement par X/Open
Company Ltd. Le logiciel détenu par des tiers, et qui comprend la technologie relative aux polices de caractères, est protégé par un copyright et
licencié par des fournisseurs de Sun.
Sun, Sun Microsystems, le logo Sun, SunOS, AnswerBook, SunVTS, SunDiag, et Solaris sont des marques déposées ou enregistrées de Sun
Microsystems, Inc. aux Etats-Unis et dans d’autres pays. Toutes les marques SPARC, utilisées sous licence, sont des marques déposées ou
enregistrées de SPARC International, Inc. aux Etats-Unis et dans d’autres pays. Les produits portant les marques SPARC sont basés sur une
architecture développée par Sun Microsystems, Inc. La marque DLT a été déposée par Quantum Corporation aux Etats-Unis et dans d'autres
pays.
Les utilisateurs d’interfaces graphiques OPEN LOOK®et Sun™ ont été développés de Sun Microsystems, Inc. pour ses utilisateurs et licenciés.
Sun reconnaît les efforts de pionniers de Xerox Corporation pour la recherche et le développement du concept des interfaces d’utilisation visuelle
ou graphique pour l’industrie de l’informatique. Sun détient une licence non exclusive de Xerox sur l’interface d’utilisation graphique, cette
licencecouvrantaussileslicenciésdeSunquimettenten place les utilisateurs d’interfaces graphiques OPEN LOOK et qui en outreseconforment
aux licences écrites de Sun.
CETTE PUBLICATION EST FOURNIE "EN L’ETAT" SANS GARANTIE D’AUCUNE SORTE, NI EXPRESSE NI IMPLICITE, Y COMPRIS,
ET SANS QUE CETTE LISTE NE SOIT LIMITATIVE, DES GARANTIES CONCERNANT LA VALEUR MARCHANDE, L’APTITUDE DES
PRODUITS A REPONDRE A UNE UTILISATION PARTICULIERE OU LE FAIT QU’ILS NE SOIENT PAS CONTREFAISANTS DE PRODUITS
DE TIERS.

iii
Contents
Preface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
1. Installation in a Multi-Tape Backup Tray. . . . . . . . . . . . . . . . . 1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2. Installation in Other Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3. Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Front Panel Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . 13
Tape Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Write-Protect. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Handling and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Loading a Tape Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Selecting Density . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

iv 20-40 Gbyte SPARCstorage DLT4000 Tape Drive Manual—February 1997
Valid Densities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Selecting Density Using the Front Panel. . . . . . . . . . . . . . . . 20
Selecting Density Using Software Commands. . . . . . . . . . . 21
Unloading a Tape Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Using a Cleaning Tape Cartridge. . . . . . . . . . . . . . . . . . . . . . . . . 23
System Diagnostic Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
A. Modifying the st.conf File. . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Understanding the st.conf file . . . . . . . . . . . . . . . . . . . . . 26
Modifying the st.conf file. . . . . . . . . . . . . . . . . . . . . . . . . . 28
B. Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Physical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Interface and Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Tape Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Quality. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

v
Preface
The 20-40 Gbyte SPARCstorage™ DLT™4000 Tape Drive Manual provides
installation instructions and user information for the DLT 4000 Tape Drive.
These instructions are designed for a system administrator.
How This Book Is Organized
Chapter1, “Installation in a Multi-Tape Backup Tray,”provides instructions on
how to install the tape drive into a Multi-Tape Backup Tray. The steps in this
chapter should be performed in conjunction with installation instructions
specific to the system or enclosure the tape drive will be installed into.
Chapter 2, “Installation in Other Devices,” provides instructions on how to
install the tape drive into devices other than a Multi-Tape Backup Tray. The
steps in this chapter should be performed in conjunction with installation
instructions specific to the system or enclosure the tape drive will be installed
into.
Appendix A, “Modifying the st.conf File,” provides instructions on how to
modify the st.conf file for tape drives that are being connected to
workstations using SunOS™ 5.4, 5.5, and 5.5.1 operating systems.
Appendix B, “Specifications,” provides specifications for the tape drive and
tape cartridge.

vi 20-40 Gbyte SPARCstorage DLT4000 Tape Drive Manual—February 1997
Software Commands
Brief descriptions of some software commands commonly used with tape
drives are in the following table. Refer to the Solaris 2.x Handbook for SMCC
Peripherals, man pages or the AnswerBook™ online documentation for more
information.
For information on:
•Shutting down the system
•Booting the system
•Configuring devices
•Other basic software procedures
See one or more of the following:
•Solaris 2.x Handbook for SMCC Peripherals for Solaris™ 2.x software
commands.
•AnswerBook online documentation for the complete set of documentation
supporting the Solaris 2.x software environment.
•Other software documentation that you received with your system.
Table 1
Command Description
ufsdump Creates incremental or full backups
ufsrestore Retrieves data backed up using ufsdump
tar Creates tape archives and adds or extracts files
mt Sends commands to magnetic tape devices
st Acts as a device driver and interface to SCSI tape devices
tapetool OpenWindows™ tool that reads files from tape or archives files to
tape
cpio Copies file archives in and out

Preface vii
Shell Prompts
The following table shows the default system prompt and superuser prompt
for the C shell, Bourne shell, and Korn shell.
Typographic Conventions
The following table describes the typographic changes used in this book.
Shell Prompt
C shell machine_name%
C shell superuser machine_name#
Bourne shell and Korn shell $
Bourne shell and Korn shell superuser #
Typeface or
Symbol Meaning Example
AaBbCc123 The names of commands,
files, and directories;
on-screen computer output
Edit your .login file.
Use ls -a to list all files.
machine_name% You have mail.
AaBbCc123 What you type, contrasted
with on-screen computer
output
machine_name% su
Password:
AaBbCc123 Command-line placeholder:
replace with a real name or
value
To delete a file, type rm filename.
AaBbCc123 Book titles, new words or
terms, or words to be
emphasized
Read Chapter 6 in the User’s Guide.
These are called class options.
You must be root to do this.

viii 20-40 Gbyte SPARCstorage DLT4000 Tape Drive Manual—February 1997
Ordering Sun Documents
SunDocsSM is a distribution program for Sun Microsystems technical
documentation. Easy, convenient ordering and quick delivery is available from
SunExpress™. You can find a full listing of available documentation on the
World Wide Web: http://www.sun.com/sunexpress/
Sun Welcomes Your Comments
Please use the Reader Comment Card that accompanies this document. We are
interested in improving our documentation and welcome your comments and
suggestions.
If a card is not available, you can email or fax your comments to us. Please
include the part number of your document in the subject line of your email or
fax message.
•Email: [email protected]
•Fax: SMCC Document Feedback
1-415-786-6443
Country Telephone Fax
United States 1-800-873-7869 1-800-944-0661
United Kingdom 0-800-89-88-88 0-800-89-88-87
France 0800-90-61-57 0800-90-61-58
Belgium 02-720-09-09 02-725-88-50
Luxembourg 32-2-720-09-09 32-2-725-88-50
Germany 01-30-81-61-91 01-30-81-61-92
The Netherlands 06-022-34-45 06-022-34-46
Sweden 020-79-57-26 020-79-57-27
Switzerland 0800-55-19-26 0800-55-19-27
Japan 0120-33-9096 0120-33-9097

1
InstallationinaMulti-Tape
BackupTray 1
Follow the instructions in this chapter to configure and install the DLT4000
tape drive in a Multi-Tape Backup Tray.
Installation
1. Determine your operating system using the uname -rs command.
Caution – For SunOS 5.4, 5.5, or 5.5.1 operating systems, you must perform the
procedures in Appendix A, "Modfiying the st.conf File," before proceeding.
2. Shut down the operating system.
Use either the init or shutdown command. See the man pages for these
commands or the Solaris AnswerBook online documentation.
3. Determine the SCSI device identifier (SCSI ID) for the tape drive.
To check for an available SCSI ID, enter probe-scsi-all at the ok
prompt. Use a SCSI ID that is not returned by this command. Tape drives
are usually set to a SCSI ID of 4 or 5. Write down the SCSI ID (and SCSI host
adapter identifier) for future use.
Note – Do not use SCSI ID 7; it is reserved for the host adapter.
4. Turn off the power to your system and then to your peripherals.
!

220-40 Gbyte SPARCstorage DLT4000 Tape Drive Manual—February 1997
1
5. Prepare your system or enclosure for servicing.
Follow the procedures in the service manual for your system or enclosure.
6. Install the tape drive.
Refer to the procedures in your system or enclosure service manual. Install
this drive as you would any full-height device.
Connect the cables as shown in Figure 1-1
Figure 1-1 Back of DLT4000 Tape Drive
Note – Although there are other switches and connectors on the tape drive,
they are inactive in Sun™ configurations.
SCSI ID
connector
SCSI
connector Power connector
SCSI ID
adapter cable

Installation in a Multi-Tape Backup Tray 3
1
7. Install new locking brackets and spacers if you are installing the tape
drive in a Multi-Tape Backup Tray that is in a Data Center Expansion
Cabinet.
a. Install new locking brackets on the Multi-Tape Backup Tray.
Figure 1-2 Installing New Locking Brackets on a Multi-Tape Backup Tray
b. Install spacers and screws on the other tape devices and filler panels to
make them flush with the DLT4000 tape drive.
Figure 1-3 Installing spacers and screws behind other devices and filler panels
Use these holes
for DLT tape drives

420-40 Gbyte SPARCstorage DLT4000 Tape Drive Manual—February 1997
1
8. Power on your peripherals and then your system.
Note – If your system starts to reboot, interrupt the reboot proces by pressing
the ‘Stop’ and ‘A’ keys together.
9. Reboot your system using the boot -r command.
10. Load a tape cartridge into the tape drive (see "Loading a Tape Cartridge"
on page 19).
Wait for the tape drive to fully load the tape cartridge.
Note – If all the LEDs on the right or left side of the tape drive front panel are
blinking, then the tape drive has failed its power-on self-test (POST). Go to
“Troubleshooting” on page 6.
11. Determine which remote number the tape drive has been mapped to.
a. Process the remote numbers in the /dev/rmt directory.
For example, a system with two tape drives (one connected to an internal
SCSI host adapter and one to an external host adapter) might look like:
b. Find the remote number that contains the controller and SCSI ID (st)
number for the tape drive you installed.
In the previous example, the remote number 0would be used for a tape
drive connected to SCSI ID 4 on SCSI host adapter at
dma@f,81000/esp@f,80000.
#ls -l /dev/rmt/? | sed 's/.*rmt\///'
#ls -l /dev/rmt/? | sed 's/.*rmt\///'
0 -> ../../devices/iommu@f,e0000000/sbus@f,e0001000/dma@f,81000/esp@f,80000/st@4,0:
1 -> ../../devices/iommu@f,e0000000/sbus@f,e0001000/QLGC,isp@2,10000/st@5,0:
Remote number SCSI host adapter SCSI ID

Installation in a Multi-Tape Backup Tray 5
1
12. Verify that the system recognizes the tape drive.
•A correct response would resemble:
Other tape drive on the first line of the output indicates that the tape
drive is correctly recognized. The rest of the output does not matter.
•Incorrect responses include:
•No tape loaded or drive offline indicates there is no cartridge
in the drive or that the cartridge is not yet loaded. Install a cartridge or
wait for the cartridge load to complete and retry the mt status
command.
•No such file or directory indicates there is no tape drive
attached to that rmt (remote) number. Try another remote number.
•SCSI tape drive indicates the st.conf entry is incorrect. You must
edit the st.conf file and reboot until you no longer see SCSI tape
drive.
The Tape In Use LED should be lit, signifying that the drive is ready for use.
Go to Chapter 3, "Operation."
Note – If the tape drive does not complete POST, or if all the right- or left-side
LEDs blink repeatedly, go to “Troubleshooting” on page 6.
#mt -f /dev/rmt/ remote_number status
#mt -f /dev/rmt/3 status
Other tape drive:
sense key(0x0)= No Additional Sense residual= 0 retries= 0
file no= 0 block no= 0
#

620-40 Gbyte SPARCstorage DLT4000 Tape Drive Manual—February 1997
1
Troubleshooting
If the DLT4000 tape drive fails during POST or operation, use Table 1-1 to
determine the problem and the action to take.
Table 1-1 Troubleshooting
Symptom: Your system does not recognize the DLT4000 tape drive.
Action: Make sure that:
•The SCSI ID is unique.
•The SCSI data cable is not loose.
•The SCSI bus is correctly terminated.
•You have rebooted the system using the boot -r command.
Symptom: All LEDs on the right- or left-side of the tape drive front panel
blink.
Action: Try to unload the tape and reinitialize the drive by pressing the
Unload button, or turn the drive power off and then on again.
The right- or left-side LEDs stop blinking and the drive tries to
reinitialize. The LEDs should turn on steady again and go off if
the test succeeds.
If all right- or left-side LEDs still blink, the drive has a hardware
failure.

7
InstallationinOtherDevices 2
Follow the instructions in this chapter to configure and install a DLT4000 tape
drive in systems or enclosures other than a Multi-Tape Backup Tray.
Caution – Do not install a SPARCstorage DLT4000 tape drive in a
SPARCserver™2000 system rack.
Installation
1. Determine your operating system using the uname -rs command.
Caution – For SunOS 5.4, 5.5, or 5.5.1 operating systems, you must perform the
procedures in Appendix A, "Modifying the st.conf File," before proceeding.
2. Shut down the operating system.
Use either the init or shutdown command. See the man pages for these
commands or the Solaris AnswerBook online documentation.
3. Determine the SCSI device identifier (SCSI ID) for the tape drive.
To check for an available SCSI ID, enter probe-scsi-all at the ok
prompt. Use a SCSI ID that is not returned by this command. Tape drives
are usually set to a SCSI ID of 4 or 5. Write down the SCSI ID (and SCSI host
adapter identifier) for future use.
!
!

820-40 Gbyte SPARCstorage DLT4000 Tape Drive Manual—February 1997
2
Note – Do not use SCSI address 7; it is reserved for the host adapter.
4. Turn off the power to your system and then to your peripherals.
5. Prepare your system or enclosure for servicing.
Follow the procedures in the service manual for your system or enclosure.
6. Install the tape drive.
Refer to the procedures in your system or enclosure service manual. Install
this drive as you would any full-height device.
a. Connect the SCSI and power cables to the connectors on the back of
the tape drive (Figure 2-1).
Figure 2-1 Back of DLT4000 tape drive
SCSI
connector Power connector

Installation in Other Devices 9
2
a. Set the SCSI ID.
For systems or enclosures with a SCSI ID cable, install the SCSI ID cable
as shown in Figure 2-2 and set the SCSI ID for the tape drive using the
SCSI ID switch on the system or enclosure.
Figure 2-2 SCSI ID connectors
For systems or enclosures that do not have a SCSI ID cable, connect the
jumpers as shown in Figure 2-3.
Figure 2-3 Setting SCSI ID Jumpers
Note – Although there are other switches and connectors on the tape drive,
they are inactive in Sun configurations.
SCSI ID
connectors
SCSI ID 0 SCSI ID 1 SCSI ID 2 SCSI ID 3
SCSI ID 4 SCSI ID 5 SCSI ID 6 SCSI ID 7

10 20-40 Gbyte SPARCstorage DLT4000 Tape Drive Manual—February 1997
2
7. Power on your peripherals and then your system.
Note – If your system starts to reboot, interrupt the reboot process by
pressing the ‘Stop’ and ‘A’ keys together.
8. Reboot your system using the boot -r command.
9. Load a tape cartridge into the tape drive (see"Loading a Tape Cartridge"
on page 19).
Wait for the tape drive to fully load the tape cartridge.
Note – If all of the LEDs on the right or left side of the tape drive front panel
are blinking, then the tape drive has failed its power-on self-test (POST). Go to
“Troubleshooting” on page 12.
10. Determine which remote number the tape drive has been mapped to.
a. Process the remote numbers in the /dev/rmt directory.
For example, a system with two tape drives (one connected to an internal
SCSI host adapter and one to an external host adapter) might return:
b. Find the remote number that contains the controller and SCSI ID (st)
number for the tape drive you installed.
In the previous example, the remote number 0would be used for a tape
drive connected to SCSI ID 4 on SCSI host adapter at
dma@f,81000/esp@f,80000.
#ls -l /dev/rmt/? | sed 's/.*rmt\///'
#ls -l /dev/rmt/? | sed 's/.*rmt\///'
0 -> ../../devices/iommu@f,e0000000/sbus@f,e0001000/dma@f,81000/esp@f,80000/st@4,0:
1 -> ../../devices/iommu@f,e0000000/sbus@f,e0001000/QLGC,isp@2,10000/st@5,0:
Remote number SCSI host adapter SCSI ID

Installation in Other Devices 11
2
11. Verify that the system recognizes the tape drive.
•A correct response would resemble:
Other tape drive on the first line of the output indicates that the tape
drive is correctly recognized. The rest of the output does not matter.
•Incorrect responses include:
•No tape loaded or drive offline indicates there is no cartridge
in the drive or that the cartridge is not yet loaded. Install a cartridge or
wait for the cartridge load to complete and retry the mt status
command.
•No such file or directory indicates there is no tape drive
attached to that rmt (remote) number. Try another remote number.
•SCSI tape drive indicates the st.conf entry is incorrect. You must
edit the st.conf file and reboot until you no longer see SCSI tape
drive.
The Tape In Use LED should be lit, signifying that the drive is ready for use.
Go to Chapter 3, "Operation."
Note – If the tape drive does not complete POST, or if all the right- or left-side
LEDs blink repeatedly, go to “Troubleshooting” on page 12.
#mt -f /dev/rmt/ remote_number status
#mt -f /dev/rmt/3 status
Other tape drive:
sense key(0x0)= No Additional Sense residual= 0 retries= 0
file no= 0 block no= 0
#

12 20-40 Gbyte SPARCstorage DLT4000 Tape Drive Manual—February 1997
2
Troubleshooting
If the DLT4000 tape drive fails during POST or operation, use Table 2-1 to
determine the problem and the action to take.
Table 2-1 Troubleshooting
Symptom: Your system does not recognize the DLT4000 tape drive.
Action: Make sure that:
•The SCSI ID is unique.
•The SCSI data cable is not loose.
•The SCSI bus is correctly terminated.
•You have rebooted the system using the boot -r command.
Symptom: All LEDs on the right- or left-side of the tape drive front panel
blink.
Action: Try to unload the tape and reinitialize the drive by pressing the
Unload button, or turn the drive power off and then on again.
The right or left side LEDs stop blinking and the drive tries to
reinitialize. The LEDs should turn on steady again and go off if
the test succeeds.
If all right or left side LEDs still blink, the drive has a hardware
failure.
