Preface
This guide describes how to install the SunTM PGX64 PCI graphics card hardware
and software in a Sun system.
How This Book Is Organized
Chapter 1 provides an overview of the Sun PGX64 graphics card.
Chapter 2 provides hardware and software installation instructions.
Using UNIX Commands
This document may not contain information on basic UNIX®commands and
procedures such as shutting down the system, booting the system, and configuring
devices.
See one or more of the following for this information:
■Solaris Handbook for Sun Peripherals
■AnswerBook2™ online documentation for the Solaris™ operating environment
■Other software documentation that you received with your system

xiv Sun PGX64 Graphics Card Installation Guide • March 2001
Typographic Conventions
Shell Prompts
Typeface Meaning Examples
AaBbCc123 The names of commands, files,
and directories; on-screen
computer output
Edit your.login file.
Use ls -a to list all files.
% You have mail.
AaBbCc123 What you type, when
contrasted with on-screen
computer output
%su
Password:
AaBbCc123 Book titles, new words or terms,
words to be emphasized
Read Chapter 6 in the User’s Guide.
These are called class options.
You must be superuser to do this.
Command-line variable; replace
with a real name or value
To delete a file, type rm filename.
Shell Prompt
C shell machine_name%
C shell superuser machine_name#
Bourne shell and Korn shell $
Bourne shell and Korn shell superuser #

Preface xv
Accessing Sun Documentation Online
The docs.sun.comSM web site enables you to access a select group of Sun technical
documentation on the Web. You can browse the docs.sun.com archive or search
for a specific book title or subject at:
http://docs.sun.com
Ordering Sun Documentation
Fatbrain.com, an Internet professional bookstore, stocks select product
documentation from Sun Microsystems, Inc.
For a list of documents and how to order them, visit the Sun Documentation Center
on Fatbrain.com at:
http://www.fatbrain.com/documentation/sun
Sun Welcomes Your Comments
Sun is interested in improving its documentation and welcomes your comments and
suggestions. You can email your comments to Sun at:
Please include the part number (806-6548-10) of your document in the subject line of
your email.

xvi Sun PGX64 Graphics Card Installation Guide • March 2001

1
CHAPTER 1
Sun PGX64 Graphics Card
Overview
The Sun PGX64 graphics card (FIGURE 1-1) is a 24-bit high-resolution
PCI-based graphics frame buffer. The Sun PGX64 graphics card runs on all Sun
PCI-based system platforms.
Installation Kit
The PGX64 graphics card installation kit includes:
■Sun PGX64 graphics card
■Antistatic wrist strap
■Sun PGX64 software on CD-ROM
■HD15 to 13W3 adapter cable
■Sun PGX64 Graphics Card Installation Guide, this document

2Sun PGX64 Graphics Card Installation Guide • March 2001
Features
The PGX64 graphics card (FIGURE 1-1) offers the following features:
■2D 24-bit graphics
■Flexible 8- and 24-bit color application support
■24-bit color, high resolution for multihead displays in supported systems
■HD15 monitor connector for a wide range of Sun and third party monitors
■3D support through the software
FIGURE 1-1 Sun PGX64 Graphics Card
FIGURE 1-2 shows the Sun PGX64 graphics card backplate and HD15 monitor
connector.
FIGURE 1-2 Sun PGX64 Backplate
PGX64 graphics card
PGX64 backplate
Video port

Chapter 1 Sun PGX64 Graphics Card Overview 3
Sun PGX64 Screen Resolutions and
Video Formats
TABLE 1-1 lists the monitor screen resolutions and video formats supported by the
Sun PGX64 graphics card:
Note – For assistance and information not found in this document concerning the
Sun PGX64 card, see SunServiceSM at http://www.sun.com/service/online/.
TABLE 1-1 Sun PGX64 Monitor Screen Resolutions
Display
Resolution Vertical Refresh Rate Sync Standard
Aspect Ratio
Format Color Depth
1920 x 1200 70 Hz Sun 16:10 8-bit
1920 x 1080 72 Hz Sun 16:9 8-bit
1600 x 1280 76 Hz Sun 5:4 8-bit
1600 x 1200 75 Hz VESA 4:3 24-bit
1600 x 1000 66, 76 Hz Sun 16:10 24-bit
1440 x 900 76 Hz Sun 16:10 24-bit
1280 x 1024 60, 75, 85 Hz VESA 5:4 24-bit
1280 x 1024 67, 76 Hz Sun 5:4 24-bit
1280 x 800 76 Hz Sun 16:10 24-bit
1152 x 900 66, 76 Hz Sun 5:4 24-bit
1152 x 864 75 Hz VESA 4:3 24-bit
1024 x 768 60, 70, 75, 85 Hz VESA 4:3 24-bit
800 x 600 56, 60, 72, 75, 85 Hz VESA 4:3 24-bit
720 x 400 85 Hz VESA 9:5 24-bit
640 x 480 60, 72, 75, 85 Hz VESA 4:3 24-bit

4Sun PGX64 Graphics Card Installation Guide • March 2001
Table of contents
Other Sun Microsystems Video Card manuals

Sun Microsystems
Sun Microsystems Sun Expert3D User manual

Sun Microsystems
Sun Microsystems Sun Crypto Accelerator 4000 User manual

Sun Microsystems
Sun Microsystems XVR-300 x8 User manual

Sun Microsystems
Sun Microsystems XVR-600 User manual

Sun Microsystems
Sun Microsystems XVR-300 User manual

Sun Microsystems
Sun Microsystems Sun XVR-100 User manual

Sun Microsystems
Sun Microsystems XVR-2500 User manual

Sun Microsystems
Sun Microsystems XVR-1000 User manual

Sun Microsystems
Sun Microsystems Sun 1024 User manual

Sun Microsystems
Sun Microsystems Elite3D User manual
