Sunbeam HE2800 User manual

Oscillating Digital Ceramic
Heater
Instruction Booklet
HE2800
Please read these instructions carefully
and retain for future reference.

Sunbeam’s Safety Precautions 1
Safety Precautions for your heater 2
Sunbeam’s Total Safety System 3
Features of your Oscillating Digital
Ceramic Heater 4
Using your Oscillating Digital
Ceramic Heater 6
Resetting the safety auto shut off 8
Care and cleaning 8
Contents

1
Sunbeam are very safety conscious when
designing and manufacturing consumer products,
but it is essential that the product user also
exercise care when using an electrical appliance.
Listed below are precautions which are essential
for the safe use of an electrical appliance:
• Read carefully and save all the instructions
provided with an appliance.
• Always turn the power off at the power outlet
before you insert or remove a plug. Remove
by grasping the plug - do not pull on the cord.
• Turn the power off and remove the plug
when the appliance is not in use and
before cleaning.
• Do not use your appliance with an extension
cord unless this cord has been checked
and tested by a qualified technician or
service person.
• Always use your appliance from a power
outlet of the voltage (A.C. only) marked
on the appliance.
• Close supervision is necessary when your
appliance is being used near children or
infirm persons.
• Never leave an appliance unattended while
in use.
• Young children should be supervised to ensure
that they do not play with the appliance.
• Do not use an appliance for any purpose
other than its intended use.
• Do not place an appliance on or near a hot gas
flame, electric element or on a heated oven.
Do not place on top of any other appliance.
• Do not let the power cord of an appliance hang
over the edge of a table or bench top or touch
any hot surface.
• For safety reasons and to avoid maintenance
by unskilled persons, some appliances are
‘sealed’ using tamperproof screws. Such
appliances should always be returned to the
nearest Sunbeam Appointed Service Centre
for adjustment or repair if required.
• Do not operate any electrical appliance with a
damaged cord or after the appliance has been
dropped or damaged in any manner. If damage
is suspected, return the appliance to the
nearest Sunbeam Appointed Service Centre
for examination, repair or adjustment.
• For additional protection, Sunbeam
recommend the use of a residual current
device (RCD) with a tripping current not
exceeding 30mA in the electrical circuit
supplying power to your appliances.
• Do not immerse the appliance in water
or any other liquid unless recommended.
If you have any concerns regarding the performance and use of your appliance,
please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.
Ensure the above safety precautions are understood.
Sunbeam’s Safety Precautions

2
If you have any concerns regarding the performance and use of your appliance,
please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.
Ensure the above safety precautions are understood.
Sunbeam’s Safety Precautions
• This heater becomes hot during use. To avoid
burns, do not let bare skin touch hot surfaces.
If provided, use handles when moving this
heater. Keep combustible materials such as
furniture, pillows, bedding, papers, clothes and
curtains at least 3 feet (90cm) away from the
front of the heater and keep them away from
the sides and rear.
• Extreme caution is necessary when any heater
is used by or near children or invalids and
whenever the heater is left unattended.
• Always unplug the heater when not in use.
• Do not use outdoors.
• Do not run the cord of the heater under
carpeting. Do not cover the cord with throw
rugs, runners or other floor coverings. Arrange
the cord away from traffic areas where it will
not be tripped over.
• Do not locate the heater immediately below a
socket outlet.
• Do not use this heater in the immediate
surrounds of a bath, shower, laundry area or
swimming pool.
• Do not insert or allow foreign objects to enter
any ventilation or exhaust openings as this may
cause electric shock or fire, or damage to the
heater.
• To prevent a possible fire, do not block air
intakes or exhaust in any manner. Do not use
on soft surfaces, such as beds, where opening
may become blocked.
• A heater has hot and arcing or sparing parts
inside. Do not use it in areas where petrol,
paint or flammable liquids are used or stored.
Important instructions – retain for
future use.

3
Safety auto shut off
Your Sunbeam Oscillating Digital Ceramic
Heater is equipped with a safety system
that detects any abnormally high
temperatures within the heater and
automatically shuts it off to prevent
overheating. This first stage of the safety
system requires the user to manually reset
the heater for it to resume operation.
For instructions on how to reset your
heater, see page 8.
Thermal back-up fuse
In addition to this automatic cut off, your
heater contains a thermal back-up fuse to
provide additional back-up protection. If
the heater is in an overheat situation, the
back-up fuse will open, stopping the power
flow to the ceramic heating discs and fan.
This fuse cannot be reset, so in the event
that the back-up fuse is activated, the
heater will need to be replaced.
Sunbeam’s Total Safety System

Control panel
The compact control panel houses all of the buttons
required to operate the various functions of the
heater.
Mode button
Pres the mode button to select the desired operating
mode: Low Heat, High Heat or Auto mode.
Auto mode
Select the AUTO mode to operate the thermostat.
Use the Temp + and – buttons to select your desired
temperature. Once the set temperature is reached the
thermostat will cycle the heater on and off to
maintain it.
Timer function
The timer function allows you to set the heater to
switch itself off automatically after a specified period
of time, from 1 to 8 hours.
Oscillating function
The heater oscillates 120° on the base, providing
greater heat coverage to gradually warm the entire
room.
4
Features of your Oscillating Digital
Ceramic Heater

5
LCD screen
The LCD screen displays the current
settings, including the ambient room
temperature, the selected mode or heat
setting, and the timer icon if activated. It
features a blue backlight for easy
adjustment in the dark.
Remote control
The handy remote allows you to control the
heater from wherever you are in the room.
Switch the unit on or off, adjust the heat or
temperature setting, activate the oscillation,
or set the timer, all at the touch of a button.
Batteries are included.
Instant tip over cut out
The instant tip over cut out interrupts the
power to the heating element and fan if the
heater is accidentally tipped over. The
heater will not resume operation until it is
replaced in the upright position.
Safety auto shut off
The safety auto shut off system detects any
abnormally high temperatures within the
heater and automatically switches it off to
prevent overheating.

6
1. Place the heater on a flat level surface
and ensure that the air intake and air
outlet are clear of obstructions.
2. Insert the plug into a 230-240V power
outlet and turn the power on.
3. Move the on/off switch at the rear of the
unit to the on (I) position. A beep will
sound.
4. Press the power button on the control
panel to turn the heater on. The LCD will
display the current room temperature and
HIGH, indicating that it is operating in
HIGH heat mode.
5. Press the MODE button to cycle through
the various operating modes:
LOW – the heater will continuously run at
its low wattage.
AUTO - the digital thermostat will cycle
the heater on and off to maintain your
selected temperature. See instructions on
setting the digital thermostat below.
HIGH - the heater will continuously run at
its high wattage.
6. To turn the heater off, press the power
button on the control panel. The heater
will stop operating.
7. Move the on/off switch at the rear of the
unit to the off position (O). Turn the power
off and remove the plug from the power
outlet when not in use.
Setting the digital thermostat
1. Press the mode button to select AUTO
mode. AUTO will appear on the LCD
screen, and the current room temperature
will flash.
2. Use the Temp + and – buttons to select
the desired temperature setting. SET,
TEMP and the selected temperature will
flash several times to indicate that the
thermostat is set. The LCD will return to
displaying the room temperature.
3. Once the room temperature reaches 3°C
above the selected temperature, the heater
will operate for a further 20 seconds and
then cutout. When the room temperature
drops below the set temperature, the
heater will switch back on. The thermostat
will continue to cycle the heater on and off
to maintain your selected temperature.
4. To view the set temperature, press the
Temp button. The set temperature setting
will flash on the screen.
5. To turn the heater off, press the power
button on the control panel. The heater
will stop operating.
6. Move the on/off switch at the rear of the
unit to the off position (O). Turn the power
off and remove the plug from the power
outlet when not in use.
Using your Oscillating Digital
Ceramic Heater
Fig. 2

7
Activating the Oscillation function
Press the OSC button on the control panel or
remote to activate the oscillation. The heater
will continue to oscillate from side to side,
distributing warm air around the room, until
the OSC button is pressed again.
The body of the heater will stop oscillating in
its current position. To align the heater body
and base, press the OSC button to activate
the oscillation, and press it again when the
two parts are aligned.
Setting the timer
1. Set the heater to the desired heat or
temperature setting as per the instructions
above.
2. Press the timer button once to set the
heater to switch off after one hour, twice
for 2 hours and so on, up to 8 hours. The
timer icon will appear on the screen, as
shown in figure 3. The heater will continue
operating for the selected number of hours
and will then switch off automatically.
Using the remote control
The buttons on the remote control function
in the same way as the buttons on the
control panel. It is powered by 2 x AAA
batteries.
Note: when using the oscillating function in
AUTO mode the heater will stop oscillating
when the selected temperature is reached
and the unit cycles off. It will resume
oscillating when the heater cycles back on to
maintain the selected temperature level.
Using your Oscillating Digital Ceramic Heater (continued)
AUTO ROOM TEMP
Fig. 3

8
Your Oscillating Digital Ceramic heater is
equipped with a safety system that detects
any abnormally high temperatures within the
heater and automatically shuts it off to
prevent overheating. Should the safety auto
shut off activate and switch the heater off, it
will need to be reset.
To reset the heater:
1. Move the on/off switch at the rear of the
heater to the off position (O).
2. Unplug the heater and wait 5-10 minutes
for the unit to cool down.
3. After 5-10 minutes, plug the heater in
again and operate as usual.
Resetting the safety auto shut off
Ensure that the heater is switched off and
disconnected from the power outlet before
cleaning.
Carefully wipe the exterior of the heater with
a soft damp cloth and dry thoroughly with a
dry cloth.
Over timer dust may accumulate on the front
vent of the heater, this can be removed by
wiping with a damp cloth, or carefully going
across the vent with a vacuum cleaner with
brush attachment.
Do not use harsh or abrasive cleaners to
clean your heater, as these will damage the
surface.
Care and cleaning

is a registered trademark of Sunbeam
Corporation Limited.
Made in China. Due to minor changes in design or
otherwise, the product you buy may differ from the one
shown in this leaflet.
Backed by Sunbeam‘s 2 Year Replacement Guarantee and
National Service Network.
© Copyright. SUNBEAM CORPORATION LIMITED 2004.
(INCORPORATED IN N.S.W.) A.C.N. 000 006 771
Sunbeam Corporation is a division of GUD Holdings Ltd.
For more information or advice on this or any other
Sunbeam appliance, visit www.sunbeam.com.au or
contact the Sunbeam Consumer Service Line.
Australia 1800 025 059
New Zealand [phone].

Consumer Hotline
Australia
1800 025 059
New Zealand
[phone]
www.sunbeam.com.au
