SERVICE MANUAL 2000
HOUSEHOLD PRODUCTS
SLICE TOASTER
11/30/2000
2000
XPART NO.
6225 X
BASIC PARTS
X
120 V., 950 W., 50-60 HZ. 12345
KEY # DESCRIPTION PART # QUANTITY REQ'D
1CHASSIS ASSEMBLY,SBM,2SL 103012-000-000 1
2BASE,2SL,SBM 103017-000-000 1
4TOP CAP,2SL,SBM T2000 103021-000-000 1
7KNOB,COLOR,SBM T2000 103029-000-000 1
9LIFTER,CAP,SBM 103037-000-000 1
10 CANCEL BUTTON,SBM T2000 103042-000-000 1
11 BEZEL,KNOB,SBM 103043-000-000 1
12 PCB,SBM,CANCEL 103608-000-000 1
13 LIFTER HANDLE,SBM 103609-000-000 1
14 LED PIPE , 2 SL , SBM 1036614-000-000 5
15 RUBBER FEET 103744-000-000 4
16 HOUSING,2SL,SBM 2X3 T2000 103015-002-000 1
17
PCB ASSY,SBM,SIMPLY TOAST T2000 103032-001-000 1
18 PUSH BUTTON , LEFT , DOUBLE, SBM 103046-001-000 1
19
PUSH BUTTON , RIGHT , TRIPLE , SBM
103046-003-000 1
20 SPRING,BREAD GUIDE 082319-000-000 2
21 LIFT LEVER ARM,METAL 103052-000-000 1
22 SPRING,BREAD RACK 082318-000-000 1
23
CRUMB TRAY ASSY,SBM
103611-000-000 1
24
STANDOFF, PCB
103737-000-000 2
** INSTRUCTION, SB1 103067-000-000 1
** NOT SHOWN ON DRAWING
