Sundrax Splitter PRO User manual

User
Manual
Version 2.01
April 5, 2022
Splitter Pro

Contents
Safe operation
General information
Installation
LED indication
Connection scheme
Technical maintenance
Notes
3
3
3
3
4
6
6
2
Splitter Pro

Safe operation
To ensure safe and reliable operation of the devices, please
observe the following requirements:
Use the device only for its intended purpose
Do not use devices that show signs of malfunctioning
Avoid strong physical impacts on the device
Protect devices and cables from contact with moisture or other corrosive liquids
Whenever a fault is detected in the device, please contact the manufacturer.
General information
Splitter Pro is a single-channel DMX512 splitter and is an effective solution for controlling dynamic
lighting equipment. A feature of the splitter is the ability to transfer DMX512, RDM (ANSI E1.20)
protocols from one input to 5 or 10 outputs. Splitter Pro (double input modifications) is a double-channel
DMX512 splitter with 2 inputs and 8 outputs. Splitter Pro (double input modifications) can work as two
separate splitters 1-to-4, or as a single splitter with 1 input and 10 outputs (similar to Splitter Pro).
Splitter Pro and Splitter Pro (double input modifications) can be supplied with XLR 5-pin, XLR 3-pin,
or EtherCON connectors. RDM support can be enabled and disabled by a stick switch on the front panel.
Each input connector has a through-output connector to pass DMX512 signal to other devices in a chain.
The device is designed in a housing for installation in a 19-inch rack and can be used at positive
temperatures indoors.
Installation
Before mounting and power up, it is necessary to verify protective earthing and cable connections.
1. Ensure the device has no damage due to transportation.
2. Install the unit into the rack and secure it with screws. Connect the power cable plug
to a power outlet.
3. Connect cable to input port “IN” if you use Splitter Pro device or to necessary input port
(“IN COM”, “IN A” or “IN B”) if you use Splitter Duo Pro device. If the input signal is present,
the appropriate port indicator lights green. If there is no signal, the indicator is red.
4. Connect the desired number of output lines to the “OUT” connectors.
5. The device is ready for use.
LED indication
3Splitter Pro
LED
Red
Green
Blinks green
Blinks orange
Status
No valid DMX signal on input
Valid signal is detected, no changes in DMX data
Valid signal is detected, DMX data is being changed
RDM activity is detected
Warning!
The device uses hazardous
voltage AC 100-230V

Connection scheme
Splitter Pro, Splitter Pro (double input modifications)
4
Splitter Pro
DMX
DMX
DMX
DMX

5Splitter Pro
Connection scheme
Splitter Pro (double input modifications)
PUSH PUSH PUSH PUSH PUSH
Splitter DUO
PRO
PUSH PUSH PUSH PUSH PUSH PUSH
DMX A
DMX B
DMX COM
DMX RDM
DMX ONLY
SECTION A SECTION B
DMX A DMX B
DMX A
DMX A
DMX B
DMX B

Technical maintenance
Maintenance the device, search and troubleshooting should be performed
by service personnel. The device should be free from dirt, dents, connecting
cables and wires must be intact and securely fastened.
Notes
Please send all your warranty-related questions to [email protected]
All Sundrax products are covered by a 36 months warranty.
6
Splitter Pro

Notes
7Splitter Pro

Sundrax Electronics
6008, First Central 200
2 Lakeside Drive, Park Royal, London
NW10 7FQ United Kingdom
+ 44 (0) 208 991 33 19
[email protected]
www.sundrax.com
