Bosch HPC 410 User manual

6721832682 (2021/02)
Installation instructions for contractors
User interface
HPC 410
EMS 2
0010031776-002

Table of contents
HPC 410 – 6721832682 (2021/02)
2
Table of contents
1 Explanation of symbols and safety instructions . . . . . . . . . . . 3
1.1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 General safety instructions . . . . . . . . . . . . . . . . . . . . . . . 3
2 Product information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.1 Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . 4
2.2 Product Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2.3 Additional accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.1 General commissioning of the user interface. . . . . . . . . 4
3.2 System commissioning with the configuration
wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3.3 Additional settings at commissioning . . . . . . . . . . . . . . . 6
3.3.1 Important heating settings . . . . . . . . . . . . . . . . . . . . . . . 6
3.3.2 Important settings for the DHW system . . . . . . . . . . . . . 6
3.3.3 Important setting for additional systems or
devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.4 Performing function tests . . . . . . . . . . . . . . . . . . . . . . . . 6
3.5 Check monitored values . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.6 System handover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3.7 Shutdown / switching off. . . . . . . . . . . . . . . . . . . . . . . . . 6
3.8 Quick start of heat pump . . . . . . . . . . . . . . . . . . . . . . . . . 6
4 Service menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.1 Settings for the heat pump . . . . . . . . . . . . . . . . . . . . . . . 6
4.1.1 Menu: Heat pump. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
4.1.2 Menu: Pumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4.1.3 Menu: External connections . . . . . . . . . . . . . . . . . . . . . . 7
4.1.4 Menu: Smart grid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.1.5 Menu: PV system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4.2 Additional heater settings . . . . . . . . . . . . . . . . . . . . . . . . 8
4.2.1 Menu: Set additional heater . . . . . . . . . . . . . . . . . . . . . . 8
4.2.2 Menu: Electric auxiliary heater . . . . . . . . . . . . . . . . . . . . 8
4.2.3 Menu: Auxiliary heater with mixer. . . . . . . . . . . . . . . . . . 9
4.3 Heating settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.3.1 System data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.3.2 Menu Priority heating circuit 1 . . . . . . . . . . . . . . . . . . . 10
4.3.3 Menu heating circuit 1 ... 4 . . . . . . . . . . . . . . . . . . . . . . 10
4.3.4 Screed drying menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.4 DHW settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.5 Menu: Pool settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.6 Solar thermal system settings . . . . . . . . . . . . . . . . . . . . 15
4.7 Settings for the hybrid system. . . . . . . . . . . . . . . . . . . . 16
4.8 Save all settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.9 Diagnosis menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.9.1 Function test menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.9.2 Monitored values menu . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.9.3 Fault display menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.9.4 SnapShot menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.9.5 System information menu . . . . . . . . . . . . . . . . . . . . . . . 16
4.9.6 Maintenance menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.9.7 Reset menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.9.8 Calibration menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6 Environmental protection and disposal . . . . . . . . . . . . . . . . . 17
7 Data Protection Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
8 Unit troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
9 Overview of the service menu . . . . . . . . . . . . . . . . . . . . . . . . . 20

Explanation of symbols and safety instructions
3
HPC 410 – 6721832682 (2021/02)
1 Explanation of symbols and safety instructions
1.1 Explanation of symbols
Warnings
In warnings, signal words at the beginning of a warning are used to
indicate the type and seriousness of the ensuing risk if measures for
minimizing danger are not taken.
The following signal words aredefined and can be used in this document:
DANGER
DANGER indicates that severe or life-threatening personal injury will
occur.
WARNING
WARNING indicates that severe to life-threatening personal injury may
occur.
CAUTION
CAUTION indicates that minor to medium personal injury may occur.
NOTICE
NOTICE indicates that material damage may occur.
Important information
The info symbol indicates important information where there is no risk to
people or property.
1.2 General safety instructions
HNotice for the target group
These installation instructions are intended for
plumbers, heating engineers and electricians. All
instructions must be observed. Failure to comply with
instructions may result in material damage and
personal injury, including possible loss of life.
▶ Read the installation instructions (heat source,
heating controller, etc.) before installation.
▶ Observe the safety instructions and warnings.
▶ Observe national and regional regulations,
technical rules and guidelines.
HDetermined use
▶ Use the product only to control heating systems.
Any other use is considered inappropriate. We take no
responsibility for damage caused through incorrect
use.

Product information
HPC 410 – 6721832682 (2021/02)
4
2 Product information
This is an original manual. This manual may not be translated without the
approval of the manufacturer.
2.1 Declaration of conformity
The design and operating characteristics of this product comply with the
European and national requirements.
The CE marking declares that the product complies with all the
applicable EU legislation, which is stipulated by attaching this
marking.
The complete text of the Declaration of Conformity is available on the
Internet: worcester-bosch.co.uk
2.2 Product Description
The user interface HPC 410 controls max. 4 heating/cooling1) circuits
individually and a cylinder primary circuit for DHW heating, solar DHW
heating and solar central heating backup.
• The user interface incorporates a time program:
– Heating systems: For each heating circuit, 2 time programs with 2
switching times per day.
– Domestic hot water: One time program for DHW heating and one
time program for the DHW circulation pump, each with 6
switching times per day.
• Certain menu items are specific to certain countries and are only
displayed if the country in which the heat pump is installed has been
set accordingly.
The functional scope and thus the menu structure of the user interface
are determined by the structure of the system. The adjustment ranges,
default settings and functional scope may differ from the information in
these instructions, depending on the system installed at the site.
Depending on the software version of the control unit, the texts shown in
the display may differ from the texts in this manual.
• If 2 or more heating/cooling1) circuits are installed, settings for each
heating/cooling1) circuit is available and are necessary.
• If special system components and modules are installed (e.g.
MS 200solar module,poolmodule MP 100), correspondingsettings
are available and necessary.
Control modes
The following main control modes are available for the heating system:
•Outdoor-temp.-compensated
– the flow temperature is adjusted based on the outside
temperature according to an optimised heating curve.
•Outdoor-temp.-compensated with low end
– the flow temperature is adjusted based on the outside
temperature according to a simplified heating curve.
For both of the control modes a room controller may be installed in the
reference room to allow the influence of the measured and required
room temperature. The heating curve is then adjusted accordingly.
If cooling is active, a set constant temperature is maintained.
2.3 Additional accessories
Function modules and user interfaces of the EMS 2 control system:
•User interface CR102) as a simple remote room controller.
•User interface CR10H as a simple remote room controller with
option to measure relative humidity (heating/cooling circuits).
•MM 100: module for one heating/cooling circuit with mixing valve.
•MP 1002): module for a swimming pool.
•MS 1002): module for solar DHW heating.
•MS 2002): module for advanced solar systems.
Combination is not possible with the following products:
• FR..., FW..., TF..., TR..., TA...
3 Commissioning
WARNING
Risk of scalding!
As DHW temperatures above 60 °C can be reached when the customer
activates the extra DHW function, a temperature mixing device must be
installed.
NOTICE
Floor damage!
The floor may be damaged due to excessive heat.
▶ For underfloor heating systems, make sure that the maximum
temperature for the floor type in question is not exceeded.
▶ If necessary, connect an additional temperature switch at the voltage
input of the respective circulation pump and to one of the external
inputs.
3.1 General commissioning of the user interface
1. Do proper coding of the modules (observe instructions of the
modules).
2. Switch on the system.
3. Commission the remote room control (observe the operating
instructions of the remote room control).
4. Once the user interface HPC 410 is connected to the power supply,
the Language menu appears on the display. Make adjustments by
turning and pressing the selector.
5. Set the language.
The display changes to the Date menu.
6. Set the date and confirm with Next.
The display changes to the Time menu.
7. Set the time and confirm with Next.
The display changes to the Country information menu.
8. Set the country and confirm.
The display changes to the Buffer cyl. menu.
9. Select Yes if a buffer cylinder is installed and confirm. Otherwise
select No and confirm3).
The display changes to the Configuration wizard menu.
10.Start the configuration wizard with Yes (or skip with No).
11.Check and, if necessary, adjust the settings in the service menu and
perform configuration of specific modules (e.g. solar).
12.Remedy warning and fault displays, if necessary, and reset fault
history.
13.Name heating circuits (operating instructions).
14.System handover (Chapter 3.6).
3.2 System commissioning with the configuration wizard
The configuration wizard automatically recognises which BUS nodes are
installed in the system. The configuration wizard adjusts the menu and
the factory defaults.
The system analysis may take up to one minute.
After the configuration wizard has performed the system analysis, the
Commissioning menu is opened. The sub-menus and settings must
1) Cooling mode is not available in BE and DK.
2) This accessory is not available in IE and UK.
3) The buffer cylider option is not available for Air/Water indoor units with
integrated buffer cylinder (AWMB).

Commissioning
5
HPC 410 – 6721832682 (2021/02)
always be checked here and, if necessary, adjusted and finally
confirmed.
If the system analysis is skipped, the Commissioning menu is opened
directly. The sub-menus and settings listed here must be carefully
adjusted according to the installed system. Finally, the settings must be
confirmed.
Table 1 Commissioning with the configuration wizard
Menu item Control range: Function description
Country information
Set the country and confirm.
Buffer cyl.
Select [Yes] if a buffer cylinder is installed.
Otherwise select [No] and confirm.
Start configuration wizard
[Yes] | [No]: Please ensure before starting the
configuration wizard:
• that all connected modules are installed and
addressed.
• that an outdoor temperature sensor is installed.
Min. outside
temp.
Set the design temperature for the system, DUT
(Dimensioning outdoor temperature). This is the
lowest average outdoor temperature for the region.
The setting affects the slope of the heating curve as it
is the point where the heat source reaches the
highest flow temperature.
VC0 valve
connected
Set this if a 3-way valve is installed between the
buffer cylinder and the heat pump/indoor unit.
Select add. heat
appliance
[Not installed]
[Electric booster heater in series]: this selection
applies to the integrated electrical heater.
[Additional heater with mixer only]: this selection
applies to a mixed additional heater that only runs
when the heat pump is off.
[Add. heater with mixer in parallel]: this selection
appliestoa mixed additional heater thatisallowedto
run in parallel with the heat pump.
[Hybrid]: this selection applies to an additional
heater thatisallowed torun instead of the heat pump
based on the energy price settings.
Mixed aux. heat.
conn
[230V] The mixed additional heater is controlled by
on/off signal.
[0-10V] The mixed additional heater is controlled
based on power demand.
Heating circuit 1
installed
[On the heat appliance]: heating circuit 1 is
connected directly to the heat pump/indoor unit.
[On module]: heating circuit 1 is electrically
connected to a mixing module. Buffer cylinder is
required.
Config. HC1 at
HP
[No HC1 on heat appliance]: no heating circuit
connected to the heat source.
[No own heating circuit pump]: heating circuit 1 is
directly connected to the heat pump/indoor unit
without heating circuit pump.
[Via pump PC1]: heating circuit 1 is directly
connected to the heat pump/indoor unit and
equipped with a heating circuit pump.
Priority heating
circuit 1
Select [Yes] if heating circuit 1 limits the heating
supply to additional heating circuits. Otherwise
select [No] and confirm.
Mixer heating
circuit 1
[Yes] | [No]: setting that defines whether heating
circuit 1 is a heating circuit with mixer.
Mixer runtime
heat circ. 1
0 ... 600 s: setting that specifies the time required
by the mixing valve in heating circuit 1 to turn from
one stop to the other.
Heating system
heat circ. 1
[Radiators] | [Convector] | [Floor]: setting for the
type of heating distribution in the selected heating
circuit.
Ctrl type h. circ.
1
[Outside temp.-compensated]: Weather-
compensated flow temperature controlled by the
outside temperature sensor.
[Outside temp. with base point]: weather-
compensated control, taking a base point into
account.
Rem. ctr. heat.
circuit 1
[None] | [CR10] | [CR10H]: selection of the
corresponding remote room controller for the
heating circuit.
[Heating circuit 2 ... 4]: see [Heating circuit 1 installed], but only the
first heating circuit can be directly connected to the heat source. All
additional heating circuits must be mixed.
DHW install. [No]: no DHW system installed.
[Heat p.]: a DHW system is activated and connected
directly to the heat pump, either by the integrated
cylinder or externally by a 3-way valve.
[Freshwa.]: a freshwater station is connected.
DHW circ.pump
installed
[No] | [Yes]: setting that specifies whether a DHW
circulation pump is installed in the DHW system and
controlled by the user interface. This menu is not
shown if a freshwater station is installed.
Size of
freshwater
station
[15/20 l/min] | [27 l/min] | [40 l/min]: setting that
specifies the size of the freshwater station.
Freshwater
station
2...Freshwater
station 4
[No]: no further freshwater station is connected.
[MS100]: a freshwater extension station is
connected.
Change
freshwater
configuration
Setting that specifies the configuration of the
freshwater installation. Check and confirm that it
corresponds with the system installed.
Ventilation
installed
[No] | [Yes]: setting that specifies whether or not a
ventilation system is installed and controlled by the
user interface.
Sol.therm.sys.
instlld
[No] | [Yes]: setting that specifies whether or not a
solar thermal system is installed and controlled by
the user interface.
Solar extension
module
[No] |[SM100]:settingthatspecifieswhether or not
a solar extension module is installed and controlled
by the user interface.
Pool mixing
valve
0 ... 600 s: if a mixing valve for a pool is installed and
controlled by the user interface, set the time
required by the valve to turn from one stop to the
other.
Electr. anode in
cylinder
[No] | [Yes]: setting that specifies whether or not an
electric anode is installed in the DHW cylinder.
Fuse size [16A] | [20A] | [25A] | [32A]: set the main fuse of
the house dedicated to the heating appliance.
Confirming configuration
[Confirm: if all settings correspond to the installed
system.
[Back]: if changes are needed.
Menu item Control range: Function description

Service menu
HPC 410 – 6721832682 (2021/02)
6
3.3 Additional settings at commissioning
If corresponding functions are deactivated and modules, assemblies or
components are not installed, menu items that are not required are
disabled when continuing with additional settings.
Alwaysremembertosaveallsettingswhenthe commissioningis doneby
confirming Save all settings in the service menu.
3.3.1 Important heating settings
In all cases, the settings in the heating menu must be checked and
adjusted if necessary during commissioning. This is important to ensure
the function of the heating system. It is useful to check all displayed
settings.
▶ Check settings in the system data menu.
▶ Check settings in the menu for heating circuit 1 ... 4.
– Set heating curve according to the requirements of the system.
3.3.2 Important settings for the DHW system
The settings in the DHW menu must be checked and, if necessary,
adjusted during commissioning. This is important to make sure the DHW
heating is working properly. Not applicable for hybrid systems with a
central heating combi boiler.
3.3.3 Important setting for additional systems or devices
Ifotherspecificsystemsordevicesareinstalledin thesystem,additional
menu items will be available. This means that systems and devices are
available, for example:
• Solar thermal system
•Hybridsystem
•Externalboosterheater
• Pool
• Ventilation
Observe the relevant technical documentation of the module, system or
device to ensure proper function.
3.4 Performing function tests
The function tests can be accessed via the Diagnosis menu. The
available menu items are strongly dependent on the system installed.
Under this menu the following can be tested, for example: DHW circ.
pump: On/Off.
3.5 Check monitored values
The monitored values can be accessed via the Diagnosis menu.
3.6 System handover
▶ Enter the contact details of the responsible contractor in the
Diagnosis > Maintenance > Contact addr. menu, e.g. company
name, phone number and address or e-mail address.
▶ Explain to the customer how the user interface and the accessories
work and how to operate them.
▶ Inform the customer about the selected settings.
3.7 Shutdown / switching off
The user interface is powered via the BUS interface and is normally
switched on. The system should only be shutdown for maintenance
work, for example. The complete system is deactivated and there is no
frost protection during a shutdown.
▶ To temporarily switch off the system:
– Press and hold the selector until a pop-up menu is displayed.
– Select Yes in the menu Switch to standby mode?
▶ To switch on the system:
– Press and hold the selector until a pop-up menu is displayed.
– Select Yes in the menu Switch from standby mode to normal
operation?
▶ To permanently shutdown: Disconnect power from the entire system
and all BUS nodes.
After a prolonged power failure or extended period of idleness, the date
and time may need to be reset. All other settings are retained
permanently.
3.8 Quick start of heat pump
▶ Open the service menu.
▶ Press and hold both the menu and info keys until a pop-up window
appears on the display.
The quick start function raises the heating demand so that the heat
pump starts as soon as possible.
4Servicemenu
Service menu overview Page 20.
▶ If the standard display is active, press and hold both the selector and
the menu button for about three seconds until the menu Service
menu is displayed.
▶ Turn the selector in order to select the desired menu item.
▶ Press the selector to open the selected menu item, activate the input
field for a setting or confirm a setting.
▶ Press the dbutton to cancel the current setting or exit the current
menu item.
The default settings are highlighted.
4.1 Settings for the heat pump
4.1.1 Menu: Heat pump
Make the heat pump specific settings in this menu. These settings are
only available if the system is designed and configured accordingly and
the type of appliance used supports this setting.
Menu item Control range: Function description
On/off hysteresis
Only available for
AW Split heat
pumps.
The heat pump switches between [On] or [Off] according
to the set hysteresis. The hysteresis specifies by how many
degrees and for how long time the actual value has to
exceed or fall below the limit value before the switch is
done. The range and default values varies depending on
model of heat pump.
[Set on/off hysteresis of split outdoor unit in heating
mode.]:
50...1500 K x min
The heat pump starts when the flow temperature has been
below the set flow temperature for the set value. The heat
pumpstopswhentheflow temperaturehas beenabove the
set flow temperature for the set value.
[Set on/off hysteresis in cooling mode.]: 50...1500 K x
min
The heat pump stops when the flow temperature has been
below the set flow temperature for the set value. The heat
pump starts when the flow temperature has been above
the set flow temperature for the set value.
[Set on/off hysteresis in pool mode.]: 50...1500 K x min
The heat pump stops when the flow temperature has been
below the set flow temperature for the set value. The heat
pump starts when the flow temperature has been above
the set flow temperature for the set value.
Stand-alone mode [Yes]: Noheat pumpinstalled.Heating andDHWproduced
solely by the additional heater/indoor unit.
[No]: Normal operation. Heating and DHW produced by
the heat pump and the additional heater/indoor unit.

Service menu
7
HPC 410 – 6721832682 (2021/02)
Table 2 Settings for the heat pump
4.1.2 Menu: Pumps
Make the circulation pump specific settings in this menu. These settings
are only available if the system is designed and configured accordingly
and the type of appliance used supports this setting.
Table 3 Settings in the heat pump data menu
4.1.3 Menu: External connections
Make the specific settings for each external connection in this menu.
Multiple settings is possible in each menu.
The ESC blocking time1 on menu items are only available in the
External connection 1 menu. If any of these items are set to “On” the
smart grid function is automatically activated for External connection 4
and no other settings can then be done in that menu.
Table 4 Settings in the heat pump data menu
Pumps Make the circulation pump settings in this menu (
Chapter 4.1.2).
External
connections
If used, do the settings for external connections in this
menu (Chapter 4.1.3).
Fuse size If change needed after commissioning, set the main fuse
size for the house.
Manual defrosting [Yes]: The heat pump is forced to defrost the evaporator.
Smart grid If used, do the settings for the smart grid in this menu (
Chapter 4.1.4).
PV system If used, do the settings for the PV system in this menu (
Chapter 4.1.5).
Fixed temperature Use this setting if a buffer cylinder with integrated DHW
heating is installed. The heat pump will heat the cylinder to
asettemperature independentof outdoortemperature.All
heating circuits must be controlled by mixing valves.
Central fault [All faults and messages]: All faults and messages
indicated will be displayed.
[Only faults]: Only faults indicated will be displayed.
Low-noise
operation
[Silent mode on]
• [No]: The heat pump will always run in normal
operation.
• [Auto]: The heat pump will run in low noise mode
during the set time period.
• [On]: The heat pump will always run in low noise mode.
If [Auto] is activated the heat pump will run in reduced
sound operation during the set time period.
• [Low-noise operation of]: set the start time for the low
noise operation.
• [Low-noise operation until]: set the stop time for the
low noise operation.
• [Min. outside temp.]: Below this outdoor temperature
the heat pump switches over to normal operation.
Menu item Control range: Function description
Prim. heating
pump mode
[Automatic]: The primary circulation pump is in operation
when any heat source is active. When all heat sources are
off, the circulation pump is also off.
[On]: The primary circulation pump is in operation
continuously.
Minimum flow rate The heat pump only starts once the minimum flow rate has
been reached.
Flow rate detect. [On]: activates the flow control.
[Off]: deactivates the flow control.
Temp.diff. TC3/
TC0 Heat.
3...7...10 K: Set the permissible temperature differential
between the heat pump flow and return in heating mode.
Temp.diff. TC3/
TC0 Cool.
2...3...10 K: Set the permissible temperature differential
between the heat pump flow and return in cooling mode.
Menu item Control range: Function description
Menu item Control range: Function description
Logic ext.
connection 1...4
[Closed (NO)]: Open contact is interpreted as On.
[Open (NC)]: Closed contact is interpreted as On.
[Block compr. operation]:
An active signal on the external input blocks the
compressor operation.
[Block HW operation]:
An active signal on the external input blocks the DHW
operation.
[Block heating mode]:
An active signal on the external input blocks the heating
operation.
[Block cooling mode]:
An active signal on the external input blocks the cooling
operation.
[Overheat. protection HC1]:
An active signal on the external input blocks the heating
operation and indicates a fault.
[ESC blocking time1 on]:
An active signal on the external input blocks compressor
and additional heater operation.
[ESC blocking time2 on]:
An active signal on the external input blocks compressor
operation.
[ESC blocking time3 on]:
An active signal on the external input blocks additional
heater operation.
[Block additional heater]:
An active signal on the external input blocks additional
heater operation.
[PV system]:
An active signal on the external input indicates that there
are photovoltaic energy available. Heating and DHW
temperatures will be adjusted according to the settings
made in the [PV system] menu.

Service menu
HPC 410 – 6721832682 (2021/02)
8
4.1.4 Menu: Smart grid
Make theSmart Grid specific settings in this menu. Select if the available
energy should be used for Heating or DHW. These settings are only
available if the system is designed and configured accordingly and the
type of appliance used supports this setting.
If smart grid energy is available and a buffer cylinder is installed with all
heating circuits mixed, the buffer cylinder will be heated to the heat
pump maximum temperature.
Table 5 Settings in the smart grid data menu
4.1.5 Menu: PV system
Make the photovoltaic (PV) specific settings in this menu. Select if the
available energy should be used for Heating or DHW. These settings are
only available if the system is designed and configured accordingly and
the type of appliance used supports this setting.
Ifphotovoltaic energyisavailableandabuffercylinderisinstalledwith all
heating circuits mixed, the buffer cylinder will be heated to the heat
pump maximum temperature.
Table 6 Settings in the PV system data menu
4.2 Additional heater settings
4.2.1 Menu: Set additional heater
Make the additional heater general settings in this menu. These settings
are only available if the system is designed and configured accordingly
and the type of appliance used supports this setting.
Table 7 Settings in the additional heater data menu
4.2.2 Menu: Electric auxiliary heater
Make the electric additional heater specific settings in this menu. These
settings are only available if the system is designed and configured
accordingly and the type of appliance used supports this setting.
Table 8 Settings in the electric additional heater data menu
Menu item Control range: Function description
Heating The energy available in the smartgrid is used for heating, if
the system is in heating mode.
[Selectable peak]: 0...5 K
Set how much the room temperature may be increased.
[Forced peak]: 2...5 K
Set how much the room temperature is forced to increase.
DHW The energy available in the smart grid is used for DHW.
[Selectable peak]: [Yes] | [No]
If enabled the DHW is heated to the temperature set for
DHWoperatingmode [DHWcomfort].No heatingis doneif
the holiday program is active.
Menu item Control range: Function description
Heating peak The energy availablein the PV system is used for heating, if
the system is in heating mode.
0...5 K
Set how much the room temperature may be increased.
DHW peak The energy available in the PV system is used for DHW.
[Yes] | [No]
If enabled the DHW is heated to the temperature set for
DHWoperatingmode [DHWcomfort].No heatingis doneif
the holiday program is active.
Cooling setback
mode
If [Only cool with PV] is set to [Yes]: set how many degrees
the heat pump is allowed to lower the indoor temperature.
Only cool with PV Cooling mode is activated only if energy is available in the
PV system.
[Yes] | [No]
No cooling is done if the holiday program is active.
Menu item Control range: Function description
Gen. additional
heater settings
These settings are valid for all types of additional heaters.
[Additional heater on delay]:
10...300...1000 K x min
The additional heater is switched on after a set delay. The
delay is dependingon time and deviation from desired flow
temperature.
[Mode after EVU block]:
[Comfort]: The heat pump is allowed to start immediately
after the blocking period.
[ECO]: The heat pump is allowed start with a delay after
the blocking period.
[Auxiliary heater only]: [Yes] | [No]:
This setting specifies whether the additional heater should
be the only heat source or not.
[Switch off add. heater]: [Yes]|[No]:
This setting specifies whether the heat pump should be the
only heat source or not. If blocking is selected the
additional heater will still be available during extra DHW,
thermal disinfection or alarm operation.
[Max. add. heater temp.]: This setting specifies whether
theadditional heatershould beblockedor limited whilethe
heat pump is running close to its maximum flow
temperature. The setting is activated by selecting and
setting the offset.
[Maximum limit]: Below this offset from the flow
temperature the additional heater is blocked.
[Limit start]: Below this offset from the flow temperature
the additional heater is limited.
Menu item Control range: Function description
Lim. with
compressor
[0...Maximum output of installed electric heater].
Duringcompressoroperation the electricadditionalheater
output is limited to the set value.
Limit add. heater
output
[0...Maximum output of installed electric heater].
During electric additional heater operation without
compressor, the output is limited to the set value.
Limit DHW mode
output
[0...Maximum output of installed electric heater].
During DHWheatingthe electricadditional heateroutput is
limited to the set value. The setting cannot be greater than
the value set in [Limit add. heater output].
Outdoor temp.
limit1)
1) Not available if Germany is set as country.
[-20...20] °C: The electric additional heater is allowed to
start below the set outdoor temperature.
Bivalence point2)
2) Only available if Germany is set as country.

Service menu
9
HPC 410 – 6721832682 (2021/02)
4.2.3 Menu: Auxiliary heater with mixer
Make the mixed auxiliary heater specific settings in this menu. These
settings are only available if the system is designed and configured
accordingly and the type of appliance used supports this setting.
Table 9 Settings in the auxiliary heater data menu
4.3 Heating settings
4.3.1 System data
Settings for the entire heating system can be made in this menu.
Table 10 Settings in the system data menu
Building type
If damping is activated, the outside temperature fluctuations are
damped with the building type. By damping the outside temperature,
the thermal inertia of the building mass is taken into account in the
weather-compensated control.
Table 11 Settings for the menu item Building type
Fig. 1 Example for adjusted outside temperature:
[1] Actual outside temperature
[2] Adjusted outside temperature
In the default setting any changes in the outside temperature have an
effect after a delay of three hours at the latest on the calculation of the
weather-compensated control.
▶ To view the course of the outside temperature of the last 2 days: open
the menu Info > Outdoor temp.
Menu item Control range: Function description
Mixed aux. heat.
conn
[230V] The mixed additional heater is controlled by on/off
signal.
[0-10V] The mixed additional heater is controlled based
on power demand.
Delay time for
mixer
[0...120]min:Set thedelayfor openingofthemixing valve
to allow the auxiliary heater to preheat.
Mixer run time [1...120...6000] s: Set the runtime for the mixing valve to
go from one end point to the other.
Alarm input logic [Open contact] | [Closed contact]: Set if the auxiliary
heater has a “NO” or “NC” output for the alarm.
Outs. temp par.
mode1)
1) Not available if Germany is set as country.
[-20...20] °C: The auxiliary heater is allowed to start in
parallel operation below the set outdoor temperature.
Bival. pt. parallel
mode2)
2) Only available if Germany is set as country.
Outdr temp switch
mod1)
[-20...20] °C: The auxiliary heater is allowed to start and
the heat pump is blocked below the set outdoor
temperature (Alternating operation).
Bival. pt. switch
mode2)
Add. heater DHW
cylinder
[Yes] | [No]: Choose if the DHW cylinder has an electric
additional heater installed.
Menu item Control range: Function description
Is a buffer cylinder
installed?
[Yes] | [No]: Set if a buffer cylinder is installed in the
heating system.
Config. HC1 at HP [No HC1 on heat appliance]: no heating circuit connected
to the heat source.
[No own heating circuit pump]: heating circuit 1 is directly
connected to the heat pump/indoor unit without heating
circuit pump.
[Via pump PC1]: heating circuit 1 is directly connected to
the heat pump/indoor unit and equipped with a heating
circuit pump.
Internal heating
pump
[Heating pump]: the internal heat source pump also serves
as heating pump in heating circuit 1.
Min. outside temp. Set the design temperature for the system, DUT
(Dimensioning outdoor temperature). This is the lowest
average outdoor temperature for the region. The setting
affects the slope of the heating curve as it is the point
where the heat source reaches the highest flow
temperature.
Damping1)
1) To get a more responsive regulation it is recommended to choose “No”.
[Yes]:the setbuilding typeaffects themeasurement ofthe
outside temperature. The outside temperature is delayed
(adjusted).
[No]: the measured outside temperature is included
unadjusted in the weather-compensated control.
Building type Measure of the thermal storage capacity of the heated
building.
Adjustment Function definition
Heavy (high
storage capacity)
Type
E.g. brick house
Effect
• Intense damping of the outside temperature
• Longexcessiveincreaseinflow temperaturewith quick
heat-up
Medium (medium
storage capacity)
Type
e.g. house made of hollow blocks (default setting)
Effect
• Medium damping of the outside temperature
• Excessive increase in flow temperature with quick
heat-up of medium duration
Light (low storage
capacity)
Type
e.g. prefabricated building, beam and column
construction, timber frame construction
Effect
• Slight damping of the outside temperature
• Short excessive increase in flow temperature with
quick heat-up
2
1
0°C
20°C
0 h 12 h 24 h
0 010 008 067-001

Service menu
HPC 410 – 6721832682 (2021/02)
10
4.3.2 Menu Priority heating circuit 1
Make the heating priority settings in this menu. The settings are only
available if more then one heating circuit is installed.
Table 12 Settings in the Priority heating 1 menu
4.3.3 Menu heating circuit 1 ... 4
Make the settings for the selected heating circuit in this menu.
NOTICE
Risk of damaging or destroying the screed!
▶ If an underfloor heating system is installed, observe the maximum
flow temperature recommended by the manufacturer.
Menu item Control range: Function description
Priority heating
circuit 1
[Yes]: Heating circuit 1 has priority and all additional
heating circuits are restricted by the requirements of
heating circuit 1. Any additional heating circuit will only be
heated if heating circuit 1 is heated. The maximum flow
temperature of all heating circuits is limited to the flow
temperature of heating circuit 1.
[No]: If any additional heating circuit is heated, the
unmixed heating circuit 1 is also heated. Heating circuit 1
will get the same flow temperature as the highest flow
temperature of the additional heating circuits.
Menu item Adjustment range
Heating circuit
installed
[No]: heating circuit is not installed. If no heating circuit is
installed, the heat source is only used for DHW heating.
[On the heat appliance]: electrical assemblies and
components of the selected heating circuit are directly
connected to the heat source (only available with heating
circuit 1).
[On module]: electrical assemblies and components of the
selected heating circuit are connected to a MM 100/
module.
Remote ctrl [HPC 410]: HPC 410 controls the selected heating circuit
without remote control.
[CR10]: CR10 is installed as remote control for the
selected heating circuit.
[CR10H]: CR10H is installed as remote control for the
selected heating circuit.
Heating system [Radiators] | [Convector] | [Floor]: factory default of the
heatingcurve accordingto heatingtype,e.g. curvatureand
design temperature.
Heating circuit
function
[Heating and cooling]: The selected circuit is used for both
heating and cooling.
[Cooling only]: The selected circuit is only used for cooling.
Control type [Outside temp.-compensated]: The flow temperature is
adjustedbasedonthe outside temperature accordingtoan
optimised heating curve.
[Outside temp. with base point]: The flow temperature is
adjusted based on the outside temperature according to a
simplified heating curve.
Set heating curve Fine adjustment of the heating curve that is present in the
heating system ("Menu for setting of the heating
curve").
Constant heat
below
[Off]: the heating system operates independently of the
adjustedoutside temperatureinthe active operatingmode
("Heat constantly below a certain outside
temperature").
[ – 30 ... 10] °C: if the adjusted outside temperature falls
below the value set here,the heating system automatically
changes from the setback mode to the heating mode (
"Heat constantly below a certain outside temperature").
Frost prot. Notice: to ensure frost protection for the entire heating
system, set outside temperature-dependent frost
protection. This setting is independent of the set control
type.
[Outdoor temp] | [Room] | [Room and outside temp.]:
frost protection is deactivated/activated on the basis of
the temperature selected here ("Frost protection limit
temperature (outside temperature threshold)").
[Off]: frost protection off.
Frost prot. limit
temp.
[ – 20 ... 5... 10] °C: "Frost protection limit
temperature (outside temperature threshold)".
Sum./winter
changeover
[Permanently summer]: The heat pump and the additional
heater isonly active in DHW mode.The heatingcircuitsis in
summer mode (no heating).
[Automatic mode]: The system automatically switches
between heating or cooling mode depending on the
outdoor temperature.
[Permanent heating]: The heat pump and the additional
heater is active in heating and DHW mode, cooling mode is
not allowed. The heating circuits is in heating mode.
[Permanent cooling]: The heat pump is active in cooling
and DHW mode. The heating circuits is in cooling mode.
Summer mode
from
[10... 17... 30] °C: Set the outside temperature threshold
to activate the heating mode.
Heating direct start
limit
[0... 1... 10] K: Set limit for direct start of heating mode. If
the outside temperature falls below the [Summer mode
from] temperature with this offset, heating is immediately
activated.
Cooling switch-off
delay
[1...4...48] h: Set the cooling mode switch-off delay. The
timer activates when the outdoor temperature falls below
the threshold temperature.
Cooling switch-on
delay
[1...8...48] h: Set the cooling mode switch-on delay. The
timer activates when the outdoor temperature raises over
the threshold temperature.
Heating switch-off
delay
[1...1...48] h: Set the heating mode switch-off delay. The
timer activates when the outdoor temperature raises over
the threshold temperature.
Heating switch-on
delay
[1...4...48] h: Set the heating mode switch-on is delay.
The timer activates when the outdoor temperature falls
below the threshold temperature.
Room temp.
switch. diff.
[-5...2...5] K: Cooling mode is activated if the set room
temperature is exceeded with the amount set here (e.g for
2 K: set room temperature = 23 °C; actual room
temperature = 25 °C – cooling is activated).
Dew point temp.
diff.
[2...5...10] K: Set the safety margin to the calculated dew
point. The controller will keep the set flow temperature
above the calculated dew point with this value.
Min. set flow
temperature
[7...10...35] °C: Minimum set flow temperature for the
heating/cooling circuit if the system and the appliance is
designed for condensing cooling.
[7...17...35] °C: Minimum set flow temperature for the
heating/cooling circuit when it is used for non-condensing
cooling.
Mixer [Yes]: the selected heating circuit is with mixing valve.
[No]: the selected heating circuit is without mixing valve.
Mixer run time [10 ...120 ... 600] s: elapsed time of mixing valve in the
selected heating circuit.
Menu item Adjustment range

Service menu
11
HPC 410 – 6721832682 (2021/02)
Table 13 Check settings in the menu for heating circuit 1 ... 4
Set the heating system and heating curves for weather-
compensated control
▶ Set the heating type (radiator, convector or underfloor heating
system) in the menu Set heating/cooling > Heating circuit 1 ... 4 >
Heating system heat circ. 1.
▶ Set the control type (weather-compensated or weather-
compensated with base point) in the menu Ctrl type h. circ. 1.
Menu items that are not required for the selected heating system and
controltypeareswitchedoffin thedisplay.Thesettingsonlyapplyfor
the selected heating circuit, if available.
Menu for setting of the heating curve
Table 14 Set heating curve menu
Default heating curve
The default heating curve is curved upward and is based on the precise
correspondence of the flow temperature to the relevant outside
temperature.
Fig. 2 Setting of the heating curve for underfloor heating system
Gradient via design temperature T0and minimum outside
temperature T1,min
Fig. 3 Setting the heating curve for underfloor heating system
Parallel shift above with Room temperature offset or required
room temperature
T1Outdoor Temperature
T0Flow temperature
[1] Setting: T0= 45 °C, T1,min = –10 °C (base curve), limit at T0,max =
48 °C
[2] Setting: T0= 40 °C, T1,min = –10 °C
[3] Setting: T0= 35 °C, T1,min = –20 °C
[4] Parallel displacement of the base curve [1] bychanging the offset
by +3 or by increasing the desired room temperature, limit at
T0,max = 48 °C
[5] Parallel displacement of the base curve [1] by changing offset by
-3 or by reducing the desired room temperature
Shown in standard
display
[Yes]: the selected heating circuit is visible in the standard
display.
[No]: the selected heating circuit is not visible in the
standard display.
Detection low flow
rate
[On]: the low flow detection is activated for the selected
heating circuit.
[Off]:the low flow detectionis deactivated fortheselected
heating circuit.
Menu item Adjustment range
Design
temperature
or
End point
30 ... 75 ... 85 °C
(radiator/convector)/
30 ... 45 ... 85 °C
(underfloor heating system):
The design temperature is only available with weather-
compensated control without base point. The design
temperature is the flow temperature that is reached at the
minimum outside temperature and therefore affects the
steepness/inclination of the heating curve.
The end point is only available with weather-compensated
control with base point. The end point is the flow
temperature reached when the outside temperature is at
the minimum and, thus, affects the steepness/inclination
of the heating curve. When the basepoint is set higher than
30°C, the base point is the minimum value.
Base line e.g. 20 ... 25 °C ... End point: the base point of the heating
curve is only available with weather-compensated control
with a simple heating curve.
Max. flow
temperature
30 ... 75 ... 85 °C
(radiator/convector)/
30 ... 48 ... 60 °C
(underfloor heating system):
Setting for maximum flow temperature.
Solar effect – 5 ... – 1 K: within certain limits, the solar irradiation
influences the weather-compensated control (the
additional heat from the sun lowers the required heat
output).
Off: the solar irradiation is not considered by the control.
Room influence Off: the weather-compensated control operates
independently of the room temperature.
1...10 K: Deviationsinthe roomtemperatureto theextent
set are set off by parallel displacement of the heating curve
(only available if a remote control is installed in a suitable
reference room). The higher the setting value, the greater
the weighting of the room temperature deviation and the
maximum possible influence of the room temperature on
the heating curve.
Room temperature
offset
– 10 ... 0... 10 K: parallel displacement of the heating
curve (e.g. when the room temperature measured with a
thermometer deviates from the set value)
Menu item Adjustment range
0
+10
+20 -10 -20
T
1
20
30
40
50
60
T
0
C
C
0010021106-001
1
2
3
T
1
T0
0
+10
+20 -10 -20
20
30
40
50
60
C
0010021108-001
C
1
4
5

Service menu
HPC 410 – 6721832682 (2021/02)
12
Fig. 4 Setting of the heating curve for radiators
Gradient via design temperature T0and minimum outside
temperature T1min
Fig. 5 Setting the heating curve for radiators
Parallel shift above Room temperature offset or required room
temperature
T1Outdoor Temperature
T0Flow temperature
[1] Setting: T0= 75 °C, T1,min = –10 °C (base curve), limit at T0,max =
75 °C
[2] Setting: T0= 80 °C, T1,min = –10 °C, limit at T0,max = 80 °C
[3] Setting: T0= 70 °C, T1,min = –20 °C
[4] Parallel displacement of the base curve [1] by changing the offset
by +3 or by increasing the desired room temperature, limit at
T0,max = 80 °C
[5] Parallel displacement of the base curve [1] by changing the
offset -3 or by reducing the desired room temperature, limit at
T0,max = 75 °C
Simple heating curve
The simple heating curve (Ctrl type h. circ. 1: Outside temp. with base
point) is represented by a straight line. This straight line is described by
two points: the base point (starting point of the heating curve) and the
end point.
Table 15 Basic settings of the simple heating curve
Heat constantly below a certain outside temperature
To prevent the system from cooling down, DIN-EN 12831 requires that,
for the maintaining of a comfortable heat, all heating surfaces and heat
sources are designed to a defined output. If the adjusted outside
temperature set under Constant heat below is undercut, the active
setback mode is interrupted by normal heating mode.
For example, if the settings Setback: Heating off : 5 °C and Constant
heat below: -15 °C are active, the setback mode is activated when the
adjusted outside temperature is between 5 °C and -15 °Cand the heating
mode is activated below -15 °C. This allows smaller heat emitters to be
utilised.
Frost protection limit temperature (outside temperature threshold)
Under this menu item the limit temperature for the frost protection
(outside temperature threshold) is set. It is only effective if Frost prot.,
Outdoor temp or Room and outside temp. is set in the menu.
NOTICE
Domestic hot water carrying parts may be damaged beyond repair if
the frost protection limit temperature is set too low and in prolonged
periods with outside temperature below 0 °C.
▶ Only contractors are permitted to adjust the factory setting of the
frost protection limit temperature (5 °C).
▶ Do not set the frost protection limit temperature too low. Damage
caused by a low frost protection limit temperature is not covered by
the warranty.
▶ Set frost protection limit temperature and frost protection for all
heating circuits.
▶ To ensure frost protection for the entire heating system, set either
Outdoor temp or Room and outside temp. in the Frost prot. menu.
The setting Room temperature does not offer absolute frost protection,
because pipework installed in façades, for instance, can freeze. If an
outside temperature sensor is installed on the other hand, frost
protection can be assured for the entire heating system regardless of the
control type set.
4.3.4 Screed drying menu
This menu is only available if at least one under floor heating circuit is
installed in the system and adjusted.
A screed drying program is set for the selected heating circuit or the
entire heating system in this menu. To dry a new screed the heating
system automatically runs the screed drying program once.
In case of a voltage failure the user interface automatically continues
with the screed drying program. The voltage failure, however, must not
last longer than the power reserve of the user interface or the maximum
interruption duration.
Underfloor heating
system
Radiator
Minimumoutsidetemperature
T1,min
– 10 °C – 10 °C
Basepoint 25°C 25°C
0
+10
+20 -10 -20
20
30
40
50
60
70
80
90
C
C
0010021109-001
T1
T
0
1
2
3
0
+10
+20 -10 -20
20
30
40
50
60
70
80
90
C
0010021110-001
C
T
1
T0
1
4
5
End point 45 °C 60 °C
Maximum flow temperature
T0,max
48 °C 75 °C
Room temperature offset 0.0 K 0.0 K
Underfloor heating
system
Radiator

Service menu
13
HPC 410 – 6721832682 (2021/02)
NOTICE
Risk of damaging or destroying the screed!
▶ With multi-circuit systems, this function can only be used in
combination with a heating circuit with mixer.
▶ Set the screed drying according to the instructions of the screed
manufacturer.
▶ In spite of the screed drying function, visit the systems daily and keep
the prescribed record.
Fig. 6 Screed drying process with default settings in the heat-up
phase
Fig. 7 Screed drying process with default settings in the cooling phase
Key to Fig. 6 and Fig. 7:
T0Supply temperature
t Time (in days)
Table 16 Settings in the Screed drying menu (Figs. 6 and 7 show the
default setting of the screed drying program)
Menu item Control range: Function description
Activated [Yes]: the required settings for the screed drying are
displayed.
[No]: the screed drying is not active and the settings are
not displayed (default setting).
Wait time before
start
[No wait time]: the screed drying program starts
immediately for the selected heating circuits.
[1 ... 50] days: the screed drying program starts after the
setwaiting time.The selectedheatingcircuits areswitched
off during the waiting time, the frost protection is active
(Fig. 6, time before day 0)
Start phase period [No start phase]: no start phase.
[1 ... 3... 30] days: setting for the time delay between the
beginning of the start phase and the next phase (Fig. 6,
[1]).
Start phase temp. [20 ... 25 ... 55] °C: flow temperature during the start
phase (Fig. 6, [1])
20
30
40
50
60
0 2 4 6 8 10 12 14
t/d
T
0
/°C
2
3
1
4
0010021148-001
20
30
40
50
60
16 18 20 228 101214
t/d
T
0
/°C
6
5
4
7
0010021149-001
Heat-up phase
increment
[No heat-up phase]: no heat-up phase takes place.
[1... 10] days: setting for the time delay between the
steps (increment) in the heat-up phase (Fig. 6, [3])
Ht-up phase temp.
diff.
[1 ... 5... 35] K: temperature differential between the
steps in the heat-up phase (Fig. 6, [2])
Holding phase
period
[1 ... 7... 99] days: time delay between the beginning of
the holding phase (duration of the maximum temperature
for screed drying) and the next phase (Fig. 6, [4])
Holding phase
temp.
[20 ... 55] °C: flow temperature during the holding phase
(maximum temperature, Fig. 6, [4])
Cool-down phase
incr.
[No cool-down phase]: no cooling phase takes place.
[1... 10] days: setting for the time delay between the
steps (increment) in the cooling phase (Fig. 7, [5]).
Cool-down ph.
temp.diff.
[1 ... 5... 35] K: temperature differential between the
steps in the cooling phase (Fig. 7, [6]).
End phase period [No end phase]: no end phase takes place.
[Perm.]: an end time is not defined for the end phase.
[1... 30] days: setting for the time delay between the
beginningof theendphase (lasttemperaturestep) andthe
end of the screed drying program (Fig. 7, [7]).
End phase temp. [20 ... 25 ... 55] °C: flow temperature during end phase
(Fig. 7, [7]).
Max. interruption
time
[2 ... 12 ... 24] h: maximum duration of a screed drying
interruption (e.g. by stopping the screed drying or power
failure) until a fault display is output.
Screed dry.
System
[Yes]: screed drying is active for all heating circuits of the
system.
Notice: single heating circuits cannot be selected. DHW
heating is not possible. The display of menus and menu
items with settings for DHW is switched off.
[No]: screed drying is not active for all heating circuits.
Notice: single heating circuits can be selected. DHW
heating is possible. The menus and menu items with
settings for DHW are enabled.
Screeddry.HC1 ...
Screed dry. HC 4
[Yes] | [No]: setting that specifies whether screed drying
in the selected heating circuit is active/not active.
Start [Yes]: start screed drying now.
[No]: screed drying not yet started or terminated.
Interrupt [Yes] | [No]: setting that specifies whether or not the
screed drying is to be provisionally halted. If the maximum
interruption duration has been exceeded, a fault display is
output.
Continue [Yes] | [No]: setting that specifies whether or not screed
drying is to be resumed once it has been halted.
Menu item Control range: Function description

Service menu
HPC 410 – 6721832682 (2021/02)
14
4.4 DHW settings
General DHW settings
The settings of the DHW systems can be adapted in this menu. These
settings are only available if the system is designed and configured
accordingly. Default temperature settings depend on the installed heat
source.
CAUTION
Risk of scalding!
The maximum DHW temperature can be set above 60 °C and during
thermal disinfection the DHW is heated to above 60 °C.
▶ Inform all people concerned and make sure that a mixing device is
installed.
The DHW system is activated by default at delivery.
▶ If no DHW system is installed, deactivate DHW system in the
commissioning or in the DHW menu.
Perform thermal disinfection to kill off pathogens (e.g. legionella) on a
regular basis. In the case of larger DHW systems, there may be statutory
requirements for thermal disinfection.
DHW settings menu
Table 17 Settings in the DHW menu
Menu item Control range: Function description
DHW operation
energy manager
[Switch-on temp. EM]: Set the switch on DHW-
temperature from the energy management system.
[Switch-off temperature EM]: Set the switch-off DHW-
temperature from the energy management system.
DHW comfort [Switch-on temperature]
[15... 65] °C: start (minimum) temperature for the DHW in
comfort mode (depending on the installed heat source).
[Switch-off temperature]
[15...65] °C: stop(maximum)temperature fortheDHW in
comfort mode (depending on the installed heat source).
[Ramp-up delay]
[4... 10...36] h: Start delay for the DHW mode.
DHW Eco [Switch-on temperature]
[15... 65] °C: start (minimum) temperature for the DHW in
Eco mode (depending on the installed heat source).
[Switch-off temperature]
[15...65] °C: stop(maximum)temperature fortheDHW in
Eco mode (depending on the installed heat source).
[Ramp-up delay]
[4... 30...36] h: Start delay for the DHW mode.
DHW Eco+ [Switch-on temperature]
[15... 65] °C: start (minimum) temperature for the DHW in
Eco+ mode (depending on the installed heat source).
[Switch-off temperature]
[15...65] °C: stop(maximum)temperature fortheDHW in
Eco+ mode (depending on the installed heat source).
[Ramp-up delay]
[4... 48...50] h: Start delay for the DHW mode.
DHW circ. pump [DHW circ.pump installed]: if a DHW circulation pump is
installed and to be controlled by the heat source, the DHW
circulation pump must be activated here as well.
[Off]: the DHW circulation pump cannot be controlled by
the heat source.
Circulation oper.
mode
[Off]: circulation off.
[On]: circulation permanently on (by taking the start
frequency into account).
[As DHW system]: Activate the same time program for
circulation as for DHW heating. Further information and
settings ofthe customisedtime program(user interface
operating instructions).
[Own time program]: activate customised time program
for circulation. Further information and settings of the
customised time program (user interface operating
instructions).
DHW circ. start
freq.
If the DHW circulation pump is active via the time program
for the DHW circulation pump or if it is permanently
switched on (DHW circulation pump operating mode:
[On]), this setting affects the DHW circulation pump
operation.
[1 x 3 minutes/h] ...[3 x 3 minutes/h]...
[6 x 3 minutes/h]: the DHW circulation pump goes into
operation once ... 6 times per hour for 3 minutes.
[Permanent]: the DHW circulation pumpis permanently in
operation.
Autom. therm.
disinfect.
[Yes]: the thermal disinfection is started automatically at
the set time. If a solar system is installed, the thermal
disinfection must also be activated for this (Technical
documentation [MS 100] or [MS 200]).
[No]: the thermal disinfection is not started automatically.
Therm.
disinfection day
[Monday] ... [Tuesday] ... [Sunday]: weekday on which
thermal disinfection is performed.
[Daily heat-up]: thermal disinfection is performed daily.
Therm.
disinfection time
[00:00 ... 02:00 ... 23:45]: time of day for the start of
thermal disinfection at the set day.
Therm.
disinfection temp.
[60 ...65...80] °C: temperature to which the DHW volume
is heated during thermal disinfection.
Maximum duration [60 min...180...240] min: Maximum duration of the
thermal disinfection.
Heat maint. time [0 h...1...6] h: Time during which the temperature is held
at thermal disinfection.
Daily heat-up [Yes]: The DHW volume is automatically heated up daily at
the same time to 60 °C.
[No]: No daily heat-up.
Daily heat-up time [00:00 ... 02:00 ... 23:45]: time for the start of the daily
heat-up.
DHW alternating
operation
[Yes]: If a simultaneous heat requirement from the heating
system and the DHW system are present, the heat source
willalternating supply theheatingsystem or DHWbasedon
set times.
[No]: DHW heating has the higher priority and interrupts
heating mode, if necessary.
[Prioritise DHW for]:
[0...30...120] min: Duration of DHW heating.
[Heating priority for]:
[5...20...120] min: Duration of heating mode.
Heat. circ. p. on,
DHW op.
[Yes] | [No]: Set if all heating circulation pumps should run
when DHW heating is active.
Menu item Control range: Function description

Service menu
15
HPC 410 – 6721832682 (2021/02)
DHW settings menu for fresh water station
If a fresh water station is installed and configured for the system, this
menu replaces the standard DHW menu.
Setting the DHW temperature ≥ 52 °C can lead to higher electricity cost
as the electric booster heater may be activated.
Table 18 Settings in the DHW fresh water station menu
4.5 Menu: Pool settings
Make the pool heating specific settings in this menu. These settings are
only available if the system is designed and configured accordingly and
the type of appliance used supports this setting.
Table 19 Settings in the pool data menu
4.6 Solar thermal system settings
If a solar thermal system is integrated into the heating system via a
module, corresponding menus and menu items are available. Extension
of the menus by the solar thermal system is described in the operating
instructions of the used module.
In the Solar settings menu the sub-menus listed in Tab. 20 are available
with all solar thermal systems.
NOTICE
Risk of system damage!
▶ Charge and vent solar system before commissioning.
Menu item Control range: Function description
Max. DHW temp. Set the maximum DHW-temperature for the system.
DHW temp. comf. [15... 65] °C: set the DHW-temperature for the comfort
mode (depending on the installed heat source).
DHW temp. Eco [15... 65] °C: set the DHW-temperature for the Eco mode
(depending on the installed heat source).
Circulation time [Yes] | [No]: activate or deactivate the DHW circulation
pump.
Circulation oper.
mode
[Off]: circulation off.
[On]: circulation permanently on (by taking the start
frequency into account).
[As DHW system]: Activate the same time program for
circulation as for DHW heating. Further information and
settings of the customised time program (userinterface
operating instructions).
[Own time program]: activate customised time program
for circulation. Further information and settings of the
customised time program (user interface operating
instructions).
DHW circ. start
freq.
If the DHW circulation pump is active via the time program
for the DHW circulation pump or if it is permanently
switched on (DHW circulation pump operating mode:
[On]), this setting affects the DHW circulation pump
operation.
[1 x 3 minutes/h] ...[3 x 3 minutes/h]...
[6 x 3 minutes/h]: the DHW circulation pump goes into
operation once ... 6 times per hour for 3 minutes.
[Permanent]: the DHW circulation pump is permanently in
operation.
Circulation pulse [Yes] | [No]: The circulation pump runs for 3 minutes as
soon as there is a short tap (2-10 seconds). The pump is
then blocked for 10 minutes.
Automat. therm.
disinfect.
[Yes]: the thermal disinfection is started automatically at
the set time.
[No]: the thermal disinfection is not started automatically.
Therm.
disinfection day
[Monday] ... [Tuesday] ... [Sunday]: weekday on which
thermal disinfection is performed.
[Daily heat-up]: thermal disinfection is performed daily.
Therm.
disinfection time
[00:00 ... 02:00 ... 23:45]: time of day for the start of
thermal disinfection at the set day.
Therm.
disinfection temp.
e.g. [60 ...65...80] °C: temperature to which the DHW
volume is heated during thermal disinfection.
Daily heat-up [Yes]: The DHW volume is automatically heated up daily at
the same time to 60 °C.
[No]: No daily heat-up.
Daily heat-up time [00:00 ... 02:00 ... 23:45]: time for the start of the daily
heat-up.
Fault display [Yes]:If afaultoccurs inthefresh watersystem, theoutput
for a fault message is switched on.
[No]: If a fault occurs in the fresh water system, the output
for a fault message is not switched on (always without
power).
[Inverted]:
The fault message output is energized in normal operation,
but If a fault occurs in the fresh water system the output is
deenergized.
Keep hot [Yes] | [No]: Activate the warm keeping function. If the
freshwater system isfar from thebuffer tank, itcanbe kept
warm by circulation. The primary circuit pump starts every
15 minutes until the hot water target temperature is
reached on the flow sensor.
Ht main. sw.-on
temp. diff
Set the temperature difference between set temperature
and actual temperature that is required to start the warm
keeping function.
Sw.diff. ret.
stratification
Set the temperature difference between the buffer tank
temperature (at the level of the return valve) and the
secondary-side cold water inlet temperature for switching
the return valve.
Menu item Control range: Function description
Pool module
available?
[Yes] | [No]: Set if a pool module is installed.
Pool mixing valve [10...6000] s: Set the runtime for the pool mixing valve.
Control rate pool
op.
Setthe controlvalue thatregulates thecompressorcontrol
speed. A higher value results in higher speed.
Del. aux. heater
pool oper.
[60...1200] K x min: Set the additional heater switch-on
delay for pool heating. The delay is depending on time and
deviation from desired flow temperature.
Logic external
connection
[Open contact]: Open contact is interpreted as “On”.
[Closed contact]: Closed contact is interpreted as “On.
Menu item Purpose of the menu
Change solar
configuration
Graphic configuration of the solar thermal system.
Current solar
configuration
Graphic representation of the configured solar thermal
system.
Menu item Control range: Function description

Service menu
HPC 410 – 6721832682 (2021/02)
16
Table 20 General settings for the solar thermal system
4.7 Settings for the hybrid system
Set the energy/price ratio in the Hybrid system menu. Further
information is available in the instructions supplied with the hybrid
system components.
4.8 Save all settings
Select Commissioning complete to confirm and save all settings done
in the service menu, when the commissioning is complete. After first
commissioning, the settings should be saved whenever a change is
done.
4.9 Diagnosis menu
The Diagnosis service menu contains a number of tools for diagnosis.
Note that the menu items shown will vary depending on the heating
system.
4.9.1 Function test menu
This menu can be used to test active heating system components
individually. If the option Activating function checks is set to Yes in this
menu, the normal heating mode is interrupted in the entire system. All
settings are saved. The settings in this menu are only temporary and
revert to the respective default settings as soon as Activating function
checks is set to No or the Function check menu is closed. The available
functions and the possible settings vary depending on the system
installed.
A function test is performed by setting the parameters of the listed
component accordingly. You can check whether the compressor, mixing
valve, circulation pump or 3-way-valve responds appropriately by
inspecting the behaviour of the corresponding component.
E.g. can the Air purge mode be activated:
•On: the air purging mode starts.
•Off: The air purging mode is deactivated.
4.9.2 Monitored values menu
Heating system settings and measurements are displayed in this menu.
For instance the flow temperature or the current DHW temperature can
be displayed here.
You can also call up detailed information on system parts, e.g. the heat
source temperature. The information and values that are provided
depend on the system that has been installed. Observe the technical
documents for the heat source, modules and other system components.
4.9.3 Fault display menu
Current faults and the fault history are displayed in this menu.
Table 21 Information in the fault display menu
4.9.4 SnapShot menu
Additional information about the system status in the occurrence of a
fault can be found with this function.
▶ Open the menu: Service menu > Diagnosis > Fault displays > Heat
pump fault history
▶ Turn the selector until the fault you are searching for appears.
▶ Press and hold the info key until a list of data is displayed.
▶ Turn the selector to view additional data in the list.
4.9.5 System information menu
The software versions of the BUS nodes installed in the system can be
called up in this menu.
4.9.6 Maintenance menu
The contact address for a service company can be set in this menu.
The contact address is automatically displayed to the end user in case of
a fault.
Entering company name and telephone number
The current cursor position will flash (marked by | ).
▶ Turn the selector to move the cursor.
▶ Press the selector to activate the input field.
▶ Turn and press the selector to enter characters.
▶ Press dwhen you have finished making entries.
▶ Press the dkey again to switch to the next higher menu. Further
Information on the text input can be found in the operating
instructions of the user interface (Renaming heating circuit).
4.9.7 Reset menu
You can delete different settings or lists or reset them to the default
setting in this menu.
Table 22 Resetting the settings
Solar parameters Settings for the installed solar thermal system.
Start solar thermal
system
Once all required parameters have been set, the solar
thermal system can be started up.
Menu item Description
Current faults All current faults that are present in the system are
displayed here according to their severity.
System fault
history
The last 20 faults for the entire system are chronologically
displayed here. The fault history can be deleted in the
Reset menu (Chapter, 4.9.7).
Heat pump fault
history
The last 20 faults for the heat pump are chronologically
displayed here. For each fault that is stored, a snapshot is
available of the data recorded in the system at the time the
fault occurred. The fault history can be deleted in the Reset
menu (Chapter, 4.9.7).
Menu item Purpose of the menu
Menu item Description
System fault
history
The system fault history is deleted. If currently a fault is
present, it is immediately entered again.
Heat pump fault
history
The heat pump fault history is deleted. If currently a fault is
present, it is immediately entered again.
Heating circ. time
prog.
The time programs of all heating circuits are reset to the
default setting.
Time prog. DHW All time programs of all DHW systems (including the time
programs for the DHW circulation pump) are reset to the
default setting.
Time prog.
Ventilation
All venting system settings are reset to the default setting.
Theventingsystemneedstobe re-commissionedfollowing
this reset.
Ventil. elapsed
times
The operating hours for the venting system are reset to
zero.
Solar therm.syst.
el. times
The operating hours for the solar system are reset to zero.
Sol. therm. system All solar system settings are reset to the default setting.
The solar system needs to be re-commissioned following
this reset.
Hours run The operating hours are reset to zero.
Restore
commissioning
sett.
All commissioning settings saved by the installer are
restored.
Restore default
settings
All default settings are restored. The system needs to be re-
commissioned following this reset.

Technical data
17
HPC 410 – 6721832682 (2021/02)
4.9.8 Calibration menu
Table 23 Settings in the Calibration menu
5Technicaldata
Table 24 Technical data
6 Environmental protection and disposal
Old electrical and electronic appliances
This symbol means that the product must not be disposed
of with other waste, and instead must be taken to the waste
collection points for treatment, collection, recycling and
disposal.
The symbol is valid in countries where waste electrical and
electronic equipment regulations apply, e.g. "European Directive 2012/
19/EC on old electronic and electrical appliances". These regulations
define the framework for the return and recycling of old electronic
appliances that apply in each country.
As electronic devices may contain hazardous substances, it needs to be
recycled responsibly in order to minimize any potential harm to the
environment and human health. Furthermore, recycling of electronic
scrap helps preserve natural resources.
For additional information on the environmentally compatible disposal
of old electrical and electronic appliances, please contact the relevant
local authorities, your household waste disposal service or the retailer
where you purchased the product.
You can find more information here:
www.weee.bosch-thermotechnology.com/
7 Data Protection Notice
We, Bosch Thermotechnology Ltd., Cotswold Way,
Warndon, Worcester WR4 9SW, United Kingdom
process product and installation information,
technical and connection data, communication data,
product registration and client history data to provide
product functionality (art. 6 (1) sentence 1 (b)
GDPR), to fulfil our duty of product surveillance and for product safety
and security reasons (art. 6 (1) sentence 1 (f) GDPR), to safeguard our
rights in connection with warranty and product registration questions
(art. 6 (1) sentence 1 (f) GDPR) and to analyze the distribution of our
products and to provide individualized information and offers related to
the product (art. 6 (1) sentence 1 (f) GDPR). To provide services such as
sales and marketing services, contract management, payment handling,
programming, data hosting and hotline services we can commission and
transfer data to external service providers and/or Bosch affiliated
enterprises. In some cases, but only if appropriate data protection is
ensured, personal data might be transferred to recipients located
outside of the European Economic Area. Further information are
provided on request. You can contact our Data Protection Officer under:
Data Protection Officer, Information Security and Privacy (C/ISP),
Robert Bosch GmbH, Postfach 30 02 20, 70442 Stuttgart, GERMANY.
You have the right to object, on grounds relating to your particular
situation or where personal data are processed for direct marketing
purposes, at any time to processing of your personal data which is based
on art. 6 (1) sentence 1 (f) GDPR.To exercise your rights,please contact
us via privacy[email protected] To find further information, please
follow the QR-Code.
8 Unit troubleshooting
A fault appears on the display of the user interface. The cause can be a
fault on the user interface, in a component, in an assembly or on the heat
source. Where the fault code is not shown within this manual please
consult the relevant heat source or component manual.
Structure of table headers:
Fault code - sub-code - [cause or fault description].
Menu item Description
Time correction This correction ( – 20 ... 0...+20s)isautomatically
carried out once a week.
Example: deviation of the time by approximately
– 6 minutes per year
• – 6 minutes a year is equal to
– 360 seconds a year
• 1 year = 52 weeks
• – 360 seconds: 52 weeks
• – 6.92 seconds per week
• Correction factor = + 7 s/week.
Ball pressure test temperature 75 °C
Degree of pollution 2
A01 - 811 - and A41 - 4051...4052 -
[DHW provision: thermal disinfection unsuccessful]
Test procedure/Cause Action
Check if water is possibly being
drawn from the DHW cylinder
constantly due to a leak or taps
being open
If water is being drawn constantly,
take action to stop this
Checktheposition of the hotwater
temperature sensor; it may be
attached incorrectly or suspended
in the air
Position the hot water
temperature sensor correctly
If the DHW priority was deselected
and heating and DHW are running
in parallel, the boiler output may
not be sufficient
Set DHW heating to "priority"
Check whether the heating coil in
the cylinder has been vented
completely
Vent if necessary
Check the connection pipes
between the boiler and cylinder,
and with the aid of the installation
instructions, ensure that they are
connected properly
Rectify any faults in the pipework.

Unit troubleshooting
HPC 410 – 6721832682 (2021/02)
18
Table 25
Table 26
Table 27
Table 28
Table 29
Table 30
Table 31
Table 32
Using the technical
documentation, check whether
the installed cylinder primary
pump can deliver the required
output
Replace the pump if there are
deviations
Excessive losses in the DHW
circulation line
Check DHW circulation line
Check the hot water temperature
sensor according to table
Replace the sensor if there are
deviations from the table values
Check the system configuration.
The output of the electric booster
heater is possibly too small in
relation to the required water
volume
Check/increase the DHW settings
in the service menu >>DHW >>
Maximum duration (60 min
....240 min)
A11 - 1000 - [System configuration not confirmed]
Test procedure/Cause Action
System configuration not
completed
Configure system completely and
confirm
A11 - 1010 - [No communication via BUS interface EMS 2]
Test procedure/Cause Action
Check whether BUS cable was
connected incorrectly
Rectify wiring faults and switch
controller off and on again
Check whether BUS cable is
defective. Remove expansion
module from BUS and switch
controller off and back on. Check
whether the cause of the fault is a
module or module wiring
• Repair or replace the bus cable
• Replace faulty BUS node
A11 – 1037 – and A61…A64 – 1037 – [outside temperature sensor
– heating standby mode active] (A61 = heating circuit 1…A64 =
heating circuit 4)
Test procedure/Cause Action
Check configuration. The selected
setting requires an outside
temperature sensor.
If an outside temperature sensor is
not required, select the room
temperature-dependent
configuration in the controller.
Check the connecting lead
between the control unit and
outside temperature sensor for
continuity
If there is no continuity, rectify the
fault
Check the electrical connection of
the connecting lead in the outside
temperature sensor or on the plug
in the control unit
Clean corroded terminals in the
outside sensor housing.
Check outside temperature sensor
according to table
If values do not match, replace the
sensor
Check the voltage at the
connecting terminals of the
outdoor temperature sensor in the
controller in accordance with table
If the sensor values matched, but
the voltage values do not match,
replace the control unit
A01 - 811 - and A41 - 4051...4052 -
[DHW provision: thermal disinfection unsuccessful]
Test procedure/Cause Action
A11 - 1038 - [Invalid time/date]
Test procedure/Cause Action
Date/time not yet set Set date/time
Prolonged loss of power supply Avoid voltage failures
A11 - 3061...3064 - [No communication with mixer module (3061
= heating circuit 1...3064 = heating circuit 4)
Test procedure/Cause Action
Check configuration (set address
at the module). The selected
setting requires a heating circuit
module
Change configuration
Check the BUS connecting lead to
the heating circuit module for
damage. BUS voltage at the
heating circuit module must be
between 12-15 V DC
Replace damaged cables
Heating circuit module defective Replace heating circuit module
A11 - 3091...3094 - [Room temperature sensor defective] (3091 =
heating circuit 1...3094 = heating circuit 4)
Test procedure/Cause Action
• Change the control type of the
heating circuit from room
temperature-dependent to
weather-compensated
• Change frost protection from
room temperature-dependent
to outside temperature-
dependent, if necessary
Replace the system controller or
the remote control.
A11 - 6004 - [No communication with solar module]
Test procedure/Cause Action
Check configuration (set address
at the module). The selected
setting requires a solar module
Change configuration
Check the BUS connecting lead to
the solar module for damage. BUS
voltage at the solar module must
be between 12-15 V DC.
Replace damaged cables
Solar module defective Replace the module
A31...A34 – 3021…3024 – [heating circuit 1… 4 flow temperature
sensor faulty – standby mode active] (A31/3021 = heating circuit
1…A34/3024 = heating circuit 4)
Test procedure/Cause Action
Check configuration. The selected
setting requires a flow
temperature sensor
Change configuration
Check the connecting lead
between heating circuit module
and flow temperature sensor
Establish a connection properly
Check flow temperature sensor
according to table
If values do not match, replace the
sensor
Check the voltage at the terminals
of the flow temperature sensor at
the heating circuit module
according to table
If the sensor values matched, but
the voltage values do not, replace
the heating circuit module

Unit troubleshooting
19
HPC 410 – 6721832682 (2021/02)
Table 33
Table 34
Table 35
Table 36
Table 37
Table 38
Table 39
Table 40
Table 41
A51 - 6021 - [Solar collector temperature sensor defective]
Test procedure/Cause Action
Check configuration. The selected
setting requires a solar collector
temperature sensor
Change configuration.
Check connecting lead between
solar module and collector
temperature sensor
Establish a connection properly
Check collector temperature
sensor according to the table
If values do not match, replace the
sensor
Check the voltage at the terminals
of the collector temperature
sensor on the solar module
according to the table
If the sensor values matched, but
the voltage values do not, replace
the solar module
A51 - 6022 - [Cylinder 1 Bottom temp. sensor faulty - heating
standby mode active]
Test procedure/Cause Action
Check configuration. The selected
setting requires a bottom cylinder
temperature sensor.
Change configuration
Check connecting lead between
solar module and bottom cylinder
temperature sensor
Establish a connection properly
Check the electrical connection of
the connecting lead at the solar
module
If a screw or plug is loose, rectify
the contact problem
Check the bottom cylinder
temperature sensor according to
the table
If values do not match, replace the
sensor
Check the voltage at the terminals
of the bottom cylinder
temperature sensor on the solar
module according to the table
If the sensor values matched, but
the voltage values do not match,
replace the module
A61...A64 – 1081…1084 – [two master control units in the
system] (A61/1081 = heating circuit 1…A64/1084 = heating
circuit 4)
Test procedure/Cause Action
Check parameter settings at the
installation level
Register room temperature-
dependent controller for heating
circuit 1… 4 as remote control
Hxx - ... - [...]
Test procedure/Cause Action
For instance, service interval of
heat source elapsed.
Service required; see documents
for the heat source.
A01 - 5378 - [Outdoor unit defrost failure]
Test procedure/Cause Action
Too low temperature of heating
system.
Open more thermostats on the
heating system.
Defective sensor TL2. Check sensor TL2 against sensor
tables. Replace sensor TL2 If there
is a deviation.
A01 - 5522 - [Wrong combination of indoor and outdoor units]
Test procedure/Cause Action
Not matching combination of heat
pump and indoor unit.
Check if the combination is
allowed against combination
tables.
I/O module in the heat pump has
been replaced, but the rotary
encoder is not correctly set.
Check rotary encoder setting on
the old I/O module or in the
electrical wiring diagram.
Installer module in the indoor unit
has been replaced, but the rotary
encoder is not correctly set.
Check rotary encoder setting on
the old installer module or in the
electrical wiring diagram.
H01 - 5594 - [Air in the system]
Test procedure/Cause Action
Heat carrier flow blocked by a
valve.
Open all valves blocking the flow.
No heat carrier flow due to faulty
primary circulation pump.
ChecktheprimaryDHWcirculation
pump and replace it if faulty.
Air in the appliance. Perform purging procedure
according to the installation
instructions of the appliance.
H01 - 5239 - [DHW temp sensor TW1 fault]
Test procedure/Cause Action
Sensor TW1 / signal cable shorted
or broken.
Withthe sensordisconnected from
the installer board, measure and
compare the resistance to the
sensor table. Repair cable or
replace sensor if is deviation
found.
Defective installer board. If the sensor is working correctly
and the warning still triggered,
replace the installer board.

Overview of the service menu
HPC 410 – 6721832682 (2021/02)
20
9 Overview of the service menu
The menu items are displayed in the sequence below.
Service menu
Commissioning
– Country information
–Buffercyl.
– Start configuration wizard
– Enter regional minimum outside temperature.
– VC0 valve connected
– Select add. heat appliance
– Mixed aux. heat. conn
– Add. el. heater op. mode
– Fan speed
– Supply air heat. by heat p.
– Heating circuit 1 installed
– Config. HC1 at HP
– Priority heating circuit 1
– Mixer heating circuit 1
– Mixer runtime heat circ. 1
– Heating system heat circ. 1
– Ctrl type h. circ. 1
– Rem. ctr. heat. circuit 1
– Heating circuit 2 installed... Heating circuit 4 installed
–DHWinstall.
– DHW circ.pump installed
– Size of freshwater station
– Freshwater station 2... 4
– Change freshwater configuration
– Ventilation installed
– Sol.therm.sys. instlld
– Solar extension module
– Pool mixing valve
– Electr. anode in cylinder
–Fusesize
– Confirming configuration
Heat pump
– On/off hysteresis
–Heating
– Set on/off hysteresis in cooling mode.
– Pool
– Stand-alone mode
–Pumps
–Prim.heatingpumpmode
– Minimum flow rate
–Externalconnections
–Externalconnection1
– Logic ext. connection 1
– Block compr. operation
– Block HW operation
– Block heating mode
– Block cooling mode
– Overheat. protection HC1
– ESC blocking time1 on
– ESC blocking time2 on
– ESC blocking time3 on
– Block additional heater
–PVsystem
– External connection 2
– External connection 3
– External connection 4
–Fusesize
– Manual defrosting
– Smart grid
–Heating
– Selectable peak
– Forced peak
–DHW
– Selectable peak
– PV system
–Heatingpeak
– DHW peak
– Cooling setback mode
– Only cool with PV
– Fixed temperature
–Centralfault
–Low-noiseoperation
–Low-noiseoperation
– Low-noise operation of
– Low-noise operation until
– Min. outside temp.
Set additional heater
– Gen. additional heater settings
– Select add. heat appliance
– Additional heater on delay
– Mode after EVU block
–Auxiliaryheateronly
– Switch off add. heater
– Max. add. heater temp.
–Maximumlimit
– Limit start
– Electric auxiliary heater
– Add. el. heater op. mode
– Lim. with compressor
– Limit add. heater output
– Limit DHW mode output
–Outdoortemp.limit
– Bivalence point
– Auxiliary heater with mixer
– Mixed aux. heat. conn
– Delay time for mixer
– Mixer run time
– Alarm input logic
– Outs. temp par. mode
–Bival.pt.parallelmode
– Outdr temp switch mod
– Bival. pt. switch mode
– Add. heater DHW cylinder
Set heating/cooling
–Systemdata
–Buffercyl.
– Config. HC1 at HP
– Internal heating pump
– Min. outside temp.
–Damping
–Buildingtype
