Sunlux XL-9620D Installation instructions

1
Wireless 2D Barcode Scanner
Full Manual
V4.5

2
Content
Version No. ............................................................................................................................................................. 4
Factory Default Setting ...........................................................................................................................................4
Output Mode ...........................................................................................................................................................4
Data Transfer Mode ............................................................................................................................................... 4
Communication Mode ............................................................................................................................................ 5
USB interface type ................................................................................................................................................. 6
USB-HID Data type ................................................................................................................................................ 6
Inventory Mode .......................................................................................................................................................7
Scanner Sound Set ................................................................................................................................................ 7
Base Sound Set ..................................................................................................................................................... 8
Sleep Time Set ....................................................................................................................................................... 8
GS (group separator) characters conversion ...................................................................................................... 10
Letter case conversion .........................................................................................................................................10
Language Set ....................................................................................................................................................... 11
Code ID ......................................................................................................................................................... 15
AIM ID ........................................................................................................................................................... 16
Prefix And Suffix Order Setting .....................................................................................................................16
Data Edition ..........................................................................................................................................................17
Field Length Configuration ........................................................................................................................... 17
Transfer Configuration .................................................................................................................................. 17
Inverse Color Barcode Setting .............................................................................................................................18
Non-standard Barcode Option ............................................................................................................................. 18
Barcode Type Selection ....................................................................................................................................... 19
Enable/Disable All Barcodes ........................................................................................................................ 19
Enable/Disable All 1D Barcodes ...................................................................................................................19
Enable/Disable All 2D Barcodes ...................................................................................................................19
Codabar ........................................................................................................................................................ 20
Code 39 .........................................................................................................................................................21
Code 32(Enable Code39 First) .....................................................................................................................23
Interleaved 2 of 5 (ITF25) ............................................................................................................................. 23
Industrial 2 of 5 ............................................................................................................................................. 26
Matrix 2 of 5 (4-24bits) ..................................................................................................................................27
Code 93 .........................................................................................................................................................27
Code 11 ......................................................................................................................................................... 28
Code 128 .......................................................................................................................................................29
UPC-A ........................................................................................................................................................... 31
UPC-E ........................................................................................................................................................... 32
EAN/JAN-8 ....................................................................................................................................................34
EAN/JAN-13 ..................................................................................................................................................35
EAN 13 Check Bit Output ............................................................................................................................. 35
UPC/EAN/JAN Additional Code ................................................................................................................... 35
EAN13 Convert to ISBN ............................................................................................................................... 36
EAN13 Convert to ISSN ............................................................................................................................... 36
GS1 DataBar (RSS14) ..................................................................................................................................36

3
GS1 DataBar Limited ....................................................................................................................................37
GS1 DataBar Expanded ............................................................................................................................... 37
PDF417 ......................................................................................................................................................... 37
Micro PDF417 ............................................................................................................................................... 38
QR Code ....................................................................................................................................................... 38
Micro QR ....................................................................................................................................................... 39
Data Matrix ....................................................................................................................................................39
Aztec Code ....................................................................................................................................................39
Hanxin Code ................................................................................................................................................. 40
Scan Mode ........................................................................................................................................................... 40
Auto Sense Mode off .................................................................................................................................... 40
Auto Sense Mode on .................................................................................................................................... 40
Repeat Barcode Detection ........................................................................................................................... 40
Center Mode ................................................................................................................................................. 41
LED Indicator Light ...............................................................................................................................................42
2.4G Pairing ..........................................................................................................................................................42
Bluetooth HID Pairing ...........................................................................................................................................42
Show or Hide the Keyboard in IOS ......................................................................................................................42
Bluetooth HID Transfer Rate ................................................................................................................................43
Data Editor ............................................................................................................................................................43
Suffix Terminator character Setting .............................................................................................................. 43
Hidden character Settings ............................................................................................................................ 44
Add prefix and suffix Settings ....................................................................................................................... 46
Hiding front character shortcut setting ......................................................................................................... 47
Hiding back character shortcut setting ......................................................................................................... 48
Data Code Table ...................................................................................................................................................49
ASCII Code Table .................................................................................................................................................51
Add Ctrl、Shift、Alt、GUI function key ...............................................................................................................57

4
Version No.
Version Number
Factory Default Setting
Restore Factory Default
Note: the asterisk(*) is the factory default.
Output Mode
USB priority output(*)
Note: When inserting USB cable, data only output by USB.
Output at the same time
Note: USB, 2.4G or Bluetooth output at the same time(depending on the communication mode),
Scanner will make an error sound if transfer is failed in whichever mode.
Data Transfer Mode
Immediate Mode
Note: The scanned data will be uploaded immediately, and the data will not be saved if the
transfer failed.

5
Inventory Mode
Note: The scanned barcodes will be saved automatically, please scan setting codes if you need
to view statistical data or upload data.
Automatic storage mode
Note: If the scanner is out of connection distance, the data will be saved automatically. please
scan setting code ‘upload all data’ when you need to upload the saved data.
Communication Mode
2.4G Mode(*)
2.4G Pairing
Bluetooth HID Mode
Note: Please scan ‘Bluetooth HID pairing’ setting code if you need to pair the scanner
with a new device.
Bluetooth HID pairing

6
Bluetooth BLE Mode
Please download or develop low-power Bluetooth BLE transfer software if you need to use this
function.
Bluetooth SPP Mode
Please download or develop low-power Bluetooth SPP transfer software if you need to use this
function.
USB interface type
USB-HID(*)
USB-VCOM
USB-HID Data type
Transfer keyboard function keys
Send ASCII

7
Keyboard+ASCII Mode 1
> 0x1F Send ASCII Mode 2
Inventory Mode
Clear All Saved Data
Statistical Information
Upload All Data
Scanner Sound Set
Mute
High(*)

8
Medium
Low
Base Sound Set
Mute Base
Enable Base Voice
Sleep Time Set
No Sleep
Sleep Now

9
10S
30S
1Min(*)
2Min
5Min
10Min
30Min
Note: Keep pressing the button until you hear the first beep for about 8 seconds, release the
button and the scanner will enter sleep.

10
GS (group separator) characters conversion
None(*)
GS converts to <GS>
GS converts to |
GS converts to ]
GS converts to ^]
GS converts to F8
Letter case conversion
Normal Letter Case(*)

11
All Uppercase
All Lowercase
Case Inversion
Language Set
USA(*)
German
France
Italy

12
Canadian
Spain
Brazil
Sweden
Portugal
Belgium
TurkeyF

13
TurkeyQ
Italian14
Netherlands
Poland
Finland
Latin America
Serbia

14
Hungary
Denmark
Norway
Japan
KORI-8 Convert to Russian
UTF-8 Convert to Turkey
UTF-8 Convert to Czech

15
Czech
Code ID
Output Options
Disable(Default)
Enable Code ID In Front Of Barcode
Enable Code ID Behind Of Barcode
Edit
Set Custom Code ID
(Please refer to appendix ID type table, data and edit barcode)
Clear All Custom Code ID

16
AIM ID
Disable(Default)
Enable AIM ID In Front Of Barcode
Enable AIM ID Behind Of Barcode
Prefix And Suffix Order Setting
Prefix
Start Character+CODE ID+AIM ID+Custom Prefix (Default)
Start Character+Custom Prefix+CODE ID+AIM ID
Suffix
Custom Suffix+CODE ID+AIM ID+Terminal Character (Default)

17
CODE ID+AIM ID+Custom Suffix+Terminal Character
Data Edition
The data edition function can customize the barcode data to three fields(Start/Center/End) by configuring the
Start/End field length.
Note: Custom prefix/suffix, start characters, end characters, CODE ID, AIM ID and other non-barcode contents
will not be affected by the data edition function.
Field Length Configuration
Set Start Field Length
Set End Field Length
Transfer Configuration
Transfer The Full Data Field
Only Transfer The Start Field

18
Only Transfer The Center Field
Only Transfer The End Field
Inverse Color Barcode Setting
(Only 1D/DataMatrix/Aztec)
Normal Color
Inverse Color
Both (Normal/Inverse)
Non-standard Barcode Option
When non-standard barcode decoding enabled, scanner can be better compatible with some non-standard
barcodes, but the probability of reading errors will increase.
Disable(Default)

19
Enable
Barcode Type Selection
Enable/Disable All Barcodes
Enable All
Disable All
Enable/Disable All 1D Barcodes
Enable All
Disable All
Enable/Disable All 2D Barcodes
Enable All

20
Disable All
Codabar
Enable
Disable
Codabar Start/End Character Transfer
Disable(Default)
Enable
Set Length Range For Codabar
Minimum Length(0~50bits)
