2.7 Mintemp Prio tank ---------------------------------- Page 25
2.8 Min rev pump
2.9 dTMax return ---------------------------------- Page 26
2.10 dTMin return
2.11 dT FS: Full Speed
2.12 Mintemp Collector
2.13 Delay P2
Extra Functions
2.14 Thermostat function ---------------------------------- Page 27
2.14.1 Start
2.14.2 Hysteresis
2.15 Cooling function ---------------------------------- Page 28
2.15.1 Cooling Start
2.15.2 Cooling Hysteresis
2.16 Anti-stagnation ---------------------------------- Page 29
2.16.1 Start
2.16.2 Stop
2.16.3 Output option
2.17 Diffcontrol function ---------------------------------- Page 30
2.17.1 Max cold tank (no auxiliary heat source)
2.17.2 Min warm tank (no auxiliary heat source)
2.17.3 Max cold tank (w/auxiliary heat source)
2.17.4 Min warm tank (w/auxiliary heat source)
2.17.5 dTMax
2.17.6 dTMin
3 Operation Menu ---------------------------------- Page 31
3.1 Automatic and Off operation
3.2 Manual testing operation
4 Operation Hours Menu ---------------------------------- Page 32
4.1 SD Card option ------------------------------------ Page 33
4.1.1 Configuring/Changing your system settings
4.1.2 Using the DataViewer software
4.1.3 Transferring data from the PC to the Control ------- Page 34
4.1.4 Viewing graphs of system data ------------------------ Page 35
4.1.5 Backup
4.1.6 Exporting to Excel ---------------------------------- Page 36
4.1.7 Send by Outlook Express & Export all Zip
4.1.8 Savings File: Save & Savings File: Load
5 Temperatures Menu ---------------------------------- Page 37
6 Special Functions ---------------------------------- Page 38
6.1 Pump exercise function
6.2 Dimmer function
6.3 Security function
Appendix A Ohm to °F Conversion Chart for PT1000 Sensors Page 39
Appendix B Pump Functions by System ----------------------- Page 40
Appendix C Controller Schematic ----------------------- Page 41
Appendix D Controller Dimensions ----------------------- Page 42
Warranty ------------------------------------------------------- Page 43
