TORNADO AIR BIKE
SF-B2706
USER MANUAL
IMPORTANT! Read all instructions carefully before using this product. Retain owner’s manual
for future reference. For customer service, please contact: [e-mail]

IMPORTANT SAFETY NOTICE
We thank you for choosing our product. To ensure your safety and health, please use this equipment
correctly. It is important to read this entire manual before assembling and using the equipment. Safe and
effective use can only be assured if the equipment is assembled, maintained, and used properly. It is your
responsibility to ensure that all users of the equipment are informed of all warnings and precautions.
1. Before starting any exercise program you should consult your physician to determine if you
have any medical or physical conditions that could put your health and safety at risk or prevent
you from using the equipment properly. Your physician’s advice is essential if you are taking any
medication that may affect your heart rate, blood pressure, or cholesterol level.
2. Be aware of your body’s signals. Incorrect or excessive exercise can damage your health. Stop
exercising if you experience any of the following symptoms: pain, tightness in your chest,
irregular heartbeat, shortness of breath, lightheadedness, dizziness, or feelings of nausea. If
you do experience any of these conditions, you should consult your physician before continuing
with your exercise program.
3. Keep children and pets away from the equipment. The equipment is designed for adult use only.
4. Use the equipment on a solid, flat level surface with a protective cover for your floor or carpet.
To ensure safety, the equipment should have at least 2 feet of free space all around it.
5. Ensure that all nuts and bolts are securely tightened before using the equipment. The safety of
the equipment can only be maintained if it is regularly examined for damage and/or wear and
tear.
6. It is recommended that you lubricate all moving parts on a monthly basis.
7. Always use the equipment as indicated. If you find any defective components while assembling
or checking the equipment, or if you hear any unusual noises coming from the equipment during
exercise, stop using the equipment immediately and don’t use the equipment until the problem
has been rectified.
8. Wear suitable clothing while using the equipment. Avoid wearing loose clothing that may
become entangled in the equipment.
9. Do not place fingers or objects into the moving parts of the equipment.
10.The maximum weight capacity of this unit is 300 pounds.
11.This equipment is not suitable for therapeutic use.
12.Move with caution when lifting and moving the equipment. Always use proper lifting technique
and seek assistance if necessary.
13.Your product is intended for use in cool, dry conditions. You should avoid storage in extreme
cold, hot, or damp areas as this may lead to corrosion and other related problems.
14.This equipment is designed for indoor household use only! It is not intended for commercial
use!
WARNING: This product can expose you to one or more chemicals known to the State of
California to cause cancer and birth defects or reproductive harm. For more information go
to www.P65Warnings.ca.gov.
1

EXPLODED DIAGRAM
2

PARTS LIST
NO.
DESCRIPTION
QTY
NO.
DESCRIPTION
QTY
1
Main frame
1
20L/R
Rear end cap
1.pr
2
Handlebar
1
21
Cross pan head screw
ST4.2*18
4
3
Seat tube
1
22
Central axle Screw
2
4
Slide rail
1
23
Bearing
2
5L/R
Swing Tube
1.pr
24
Bolt
2
6
Foot tube
2
25
Hex thin nut M8*H5
2
7
Connecting tube
1
26
Bearing
2
8L/R
Small crank
1.pr
27
Nylon nut M8
2
9
Front stabilizer
1
28
Flange nut M14*1.5
2
10
Rear stabilizer
1
29
Flat washer Φ17*Φ22*1
2
11L/R
Pedal
1.pr
30
Bearing 6003Z
4
12
Computer
1
31
Pedal tube axle
2
13L/R
Crank
1.pr
32
Wave washer Φ17*Φ25*0.3
4
14
Saddle
1
33
Stop ring Φ22
2
15
Bushing
2
34
Foam grip
2
16
Hex pan head screw M8*20
10
35
Spring knob
2
17
Spring washer D8
10
36
End cap
1
18
Flat washer Φ8*Φ16*1.5
10
37
Cross pan head screw
4
19L/R
Front end cap
1.pr
38
Sensor wire
1
3

ASSEMBLY INSTRUCTION
STEP 1
1. Disassemble the Hex Pan Head Screws (16), Spring Washers (17) and Flat washers (18)
from the Front Stabilizer (9) and Rear Stabilizer (10).
2. Attach the Front Stabilizer (9) and the Rear Stabilizer (10)to the Main Frame (1) with the Hex
Pan Head Screws (16), Spring Washers (17) and Flat washers (18) again.
4

STEP 2
1. Disassemble the Bolts (24), Hex Thin Nuts (25) and Nylon Nuts (27) from the Swing Tube
(5L/R).
2. Attach the Pedal Tube Axle (31) of the Swing Tube (5L/R) to the two sides of the Main Frame
(1). (Do not tighten yet.)
3. Lock the Swing Tube (5L/R) with the Pedal Tube (7) tightly with Bolts (24), Hex Thin Nuts (25)
and Nylon Nuts (27). Now tighten the Pedal Tube Axle (31).
4. Put the Saddle (14) onto the Slide Rail (4), and lock them tightly with cross wrench.
5

STEP 3
Attach the Pedal (11L/R) to the Crank (13L/R) with the cross wrench.
NOTE: Make sure to attach Right Pedal, marked (R), to the Right Crank (R). It should be
tightened clockwise. Attach the Left Pedal, marked (L), to the Left Crank (L). It should be
tightened counterclockwise. Attaching the Pedal to the wrong Crank or turning it the wrong
direction will damage the Crank.
6

STEP 4
1. First, disassemble the Hex Pan Head Screws (16), Spring Washers (17) and Flat Washers
(18) from the Main Frame (1). Thread the Sensor Wire (38) from the bottom of the Handlebar
Post (2) and bring out from the top. Then attach the Handlebar Post (2) to the Main Frame (1)
with Hex Pan Head Screws (16), Spring Washers (17) and Flat Washers (18).
2. Disassemble the Hex Pan Head Screws (37) from the Computer (12). Connect the Sensor
Wire (38) with the wire of the Computer (12), then lock the Computer (12) on the bracket of the
Handlebar Post (2) with Hex Pan Head Screws (37).
Assembly is now complete!
7

Moving the Bike
Lift the bike by the Rear Stabilizer (10)until the wheels on the Front Stabilizer (9) touch the floor.
Now you can move the bike.
8

EXERCISE COMPUTER INSTRUCTIONS
DISPLAY FUNCTIONS
BUTTON FUNCTION
ITEM
DESCRIPTION
RPM
-Display the rotations per minute with range from 0~ 199.
SPEED
-Display current training speed. Maximum speed is 99.9 KM/H or ML/H.
TIME
-Count up - Time will count up from 00:00 to maximum
1:59:59 in 1 minute increments.
-Count down - The console will countdown from preset time to 00:00:00 in 1 minute
increments..
DISTANCE
-Accumulates total distance from 0.0 up to 999.9 ML or count down from preset
value. User may preset target distance value with UP/DOWN key. Each
increment is 1.0KM or ML.
CALORIES
-Accumulates calories consumption or count down during training from 0 to
maximum
999 calories.User may preset target Calories with UP/DOWN key.
WATT
-Display the power consumption during training.
-Display Range: 0~1999.
PULSE
-User may set up target pulse value from 0~30 to 230 and the console buzzer will
beep when the actual heart rate is over the target value during workout.
ITEM
DESCRIPTION
START
-To start workout quickly or resume workout in Stop mode.
STOP
-To stop/pause workout.
-To clear up all settings.
-Hold on this key for 2 seconds to reboot the console.
DOWN
-To adjust Distance, Calories, Heart-rate, Time, Age value down.
UP
-To adjust Distance, Calories, Heart-rate, Time, Age value up.
Target Distance
-Fast access to Target Distance training mode.
Target Calories
-Fast access to Target Calories training mode.
Target Heart-rate
-Fast access to Target Heart Rate training mode.
Target Time
-Fast access to Target Time training mode.
Interval
-There are 3 programs: INTERVAL 10/20,INTERVAL 20/10, Custom.
ENTER
-To confirm settings or enter program.
9

OPERATING INSTRUCTIONS
Age –The first time you turn on the meter, AGE will flash. Use arrow keys to set age. Press ENTER
to confirm. Meter will be in standby mode.
To set Kilometer or Mile, press and hold STOP and ENTER key at the same time for 2 seconds.
Press arrow key to select KM or M. Press ENTER to confirm.
Press START to start meter. Meter will be in standby mode.
Press START again to use Manual mode or press one of the preset function buttons:
TARGET DISTANCE, TARGET CALORIES, TARGET HEART RATE, TARGET TIME, INTERVAL
10/20, INTERVAL 20/10, CUSTOM INTERVAL
Press STOP to pause workout. While the meter is paused, it will beep every 30 seconds. After 5
minutes of inactivity, meter will go into standby mode.
Press START to resume workout or STOP to clear data.
Reset –press and hold STOP for 2 seconds to reset meter.
Auto Reset –After 30 seconds of inactivity, meter will auto reset, clear all values and go into
standby mode.
Pulse
Hold the pulse sensors to measure your heart rate. Meter will alternately display actual pulse, 65%,
85% MAX. This value cannot be used as the basis for medical treatment.
MANUAL MODE
Start pedaling. All functions will count up. Time continues to count up even if you are not pedaling.
COUNTDOWN MODES
Press TARGET TIME, TARGET DISTANCE, TARGET CALORIES.
Use the arrow keys to set a value. Press ENTER.
Meter will start countdown. The display will alternate between the preset value and the actual
workout value for 5 seconds each. When countdown reaches 0, meter will start counting from 0
again.
TARGET HEART RATE MODE
Press Target Heart Rate. Use arrow keys to set your age. Press ENTER to confirm.
During workout, display will switch between 65% and 85% heart rate. If heart rate goes below 65%
or above 85%, meter will continue to beep until heart rate is between 65% and 85%.
Preset Interval Modes
Press 10/20 INTERVAL or 20/10 INTERVAL
Meter will countdown for 3 seconds. WORK will flash and cycle time will countdown. Then REST
will flash and beep. Meter displays number of cycles (starts with 01/08). WORK and REST will
alternate. After 8 cycles, workout ends.
CUSTOM INTERVAL MODE
Press CUSTOM INTERVAL. Use arrow keys to set number of cycles. Press ENTER.
Use arrow keys to set number of seconds in WORK. Press ENTER.
Use arrow keys to set number of seconds in REST. Press ENTER.
At the end of interval workout or if you press STOP, meter will display Total Time, Distance, Calories.
Watt, Speed and RMP will switch to display Avg and Max values, each for 5 seconds.
10

BATTERIES
This meter use 2 AA batteries. If there is a problem with the display, try changing the batteries.
When changing the batteries, change both of them. Do not mix battery types or old and new
batteries. Dispose of batteries according to your regional guidelines.
11
Version 1.1
