Xterra FB160 User manual

FB160 Folding Bike
OWNER’S MANUAL
PLEASE CAREFULLY READ THIS ENTIRE MANUAL BEFORE OPERATING YOUR NEW FOLDING BIKE
FITNESS

Table Of Contents
1
2
5
9
12
14
15
Product Registration
Important Safety Instructions
FB160 Assembly Instructions
Operation of Your Console
Parts List
Exploded View
Manufacturer’s Limited Warranty
Thank you for your purchase of this quality Folding Bike from XTERRA Fitness. Your new
Folding Bike has been manufactured by one of the leading tness manufacturers in the world.
XTERRA Fitness will do all we can to make your ownership experience as pleasant as
possible for many years to come. If you have questions, or if parts are missing or damaged,
or you require customer service, call [phone]. Please have your model number and
serial number handy when you call.
Please take a moment to record where you purchased your machine, as well as the date of
purchase for future reference. We appreciate your condence in XTERRA Fitness and we
will always remember that you are the reason that we are in business. Please complete and
mail your registration card today and enjoy your new Folding Bike.
Yours in Health,
XTERRA Fitness
Congratulations On Your New Folding Bike and Welcome to the XTERRA Fitness Family!
FB160_VER2_20191007

FB160 Folding Bike
1
Manufacturer’s 90 Day Limited Warranty
ATTENTION
THIS FOLDING BIKE IS INTENDED FOR RESIDENTIAL USE ONLY AND IS WARRANTED FOR
THE APPLICATION. ANY OTHER APPLICATION VOIDS THIS WARRANTY IN ITS ENTIRETY.
Record Your Serial Number
Please record the Serial Number of this tness product
in the space provided below.
Serial Number
Register Your Purchase
The self-addressed product registration card must be completed in full and returned to
XTERRA Fitness. You can also go to www.xterratness.com/warrantyreg.html
to register online.
Product Registration
Purchase Location
Purchase Date
Your XTERRA Folding Bike is warranted for 90 days from the date of purchase against
defects in material when used for the purpose intended, under normal conditions and
provided it receives proper care. Any part found defective or missing will be sent at no cost
when returned in accordance with the terms of this warranty.
This warranty is not transferable and is extended only to the original owner.
The warranty shall not apply to exercise units which are (1) used for commercial or other
income producing purposes, or (2) subject to misuse, neglect, accident or unauthorized
repair and alterations.
This warranty provided herein is lieu of all other express warranties, any implied warran-
ties, including any implied warranties of merchantability of tness for particular purpose,
are limited in duration to the rst 90 days from date of purchase. All other obligations or
liabilities, including liability for consequential damages are hereby excluded.

2
FB160 Folding Bike
• Do not operate equipment on deeply padded, plush or shag carpet. Damage to both carpet and
equipment may result.
• Before beginning this or any exercise program, consult a physician. This is especially important for
persons over the age of 35 or persons with pre-existing health conditions.
• Keep hands away from all moving parts.
• The pulse sensors are not medical devices. Various factors, including the user’s movement, may affect the
accuracy of heart rate readings. The pulse sensors are intended only as exercise aids in determining heart
rate trends in general.
• Do not attempt to use your equipment for any purpose other than for the purpose it is intended.
• Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on your
equipment. Quality athletic shoes are recommended to avoid leg fatigue.
• Weight Limit: 250 LBS.
Important Safety Instructions
When using an electrical appliance, basic precautions should always be followed, including the following:
Read all instructions before using this appliance.
WARNING - To reduce the risk of burns, re electric shock, or injury to persons:
1. Do not operate under blanket or pillow. Excessive heating can occur and cause re, electric shock, or injury
to persons.
2. This exercise equipment is not intended for use by persons with reduced physical, sensory or mental capa-
bilities, or lack of experience and knowledge.
3. Use this appliance only for its intended use as described in this manual. Do not use attachments not
recommended by the manufacturer.
4. Never operate the appliance with the air openings blocked. Keep the air openings free of lint, hair, and the
like.
5. Never drop or insert any object into any opening.
6. Do not use outdoors.
7. Do not operate where aerosol (spray) products are being use or where oxygen is being administered.
8. The appliance is intended for household use.
SAVE THESE INSTRUCTIONS - THINK SAFETY!
Fitness Equipment Safety Instructions
CAUTION!! Please be careful when unpacking the carton.
Failure to follow all guidelines may compromise the effectiveness of the exercise experience, expose
yourself (and possibly others) to injury, and reduce the longevity of the equipment.
WARNING: This product can expose you to chemicals including Toluene and Acrylamide which are
known to the State of California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65Warnings.ca.gov

FB160 Folding Bike
3
Before you begin
Thank you for selecting our revolutionary XTERRA Fitness FB160 Folding Bike. A folding bike is an effective
exercise for improving cardiovascular tness, building endurance, and toning the body. Our folding bike provides
an impressive selection of features designed to make your workouts at home more effective and enjoyable.
For your benet, read this manual carefully before you use the XTERRA Fitness FB160 Folding Bike. To help
us assist you, note the product model number and serial number before contacting us. Before reading further,
please familiarize yourself with the parts that are labeled in the drawing below.
Console
Hand Pulse Sensor
Rear Support Tube
Pedals
Shroud
Seat
Rear Stabilizer
Front Stabilizer

4
FB160 Folding Bike
FB160 Assembly Part Checklist
No. 01/02
Main Frame
(1pc)
No. 03
Seat Support Tube
(1pc)
No. 04/08
Handlebar Tube/Console
(1pc / 1pc)
No. 05
Front Stabilizer
(1pc)
No. 09L/R
Pedal (L/R)
(1pc/1pc)
No. 06
Rear Stabilizer
(1pc)
No. 07
Seat
(1pc)
No. 10
Club Knob
(1pc)
No. 73
Hex Head Wrench
(1pc/1pc)
No. 72
Allen Key
(1pc)
Note: Above parts are all needed to assemble this machine. Before you start to assemble, please check the hardware
packing to make sure they are included.
Some of the parts for this machine are preassembled on the unit. Please read your manual to ensure everything is
there.

FB160 Folding Bike
5
1. Pull out the Lock Pin (No. 11) from the Front Support Tube (No. 01) and
adjust the Front Support Tube (No. 01) to the open position then re-insert the
Lock Pin (No. 11) to secure the frame position.
2. Attach the Front Stabilizer (has wheels) (No. 05) to the Front Support Tube
(No. 01), tighten with the pre-installed 2 Curved Washers (No.13) and 2
Domed Nuts (No. 14).
3. Repeat the procedure for the Rear Stabilizer (No. 06).
FB160 Assembly Instructions
02
11 14
13
05
14
13
06
01
11
11
73 Wrench
Front Stabilizer and Rear Stabilizer
1

6
FB160 Folding Bike
Pedals
2
1. Connect the Left Pedal Strap (L) to the Left Pedal (No. 09L). Adjust the pedal
strap to the length you need. Assemble the Right Pedal Strap (R) to the Right
Pedal (No. 09R) in the same way.
2. Connect the Left and Right Pedal (No. 09L & 09R) to their appropriate Crank
(No. 15L & 15R). The right pedal is on the right hand side of the bike as you sit on
it. The Right Pedal (No. 09R) should be tightened clockwise and the Left Pedal
(No. 09L) counter-clockwise.
73
15R
09R
01
15L
09L
Wrench
L R
09R
09R09L
09L

FB160 Folding Bike
7
1. Remove the pre-intalled 3 Flat Washers (No. 16) and 3 Nylon Nuts (No.
17) from the back of Seat (No. 07) (see g. 3.1). Attach the Seat (No. 07)
to the Seat Support Tube (No. 03), using the pre-installed 3 Flat Washers
(No.16) and 3 Nylon Nuts (No. 17).
2. Insert the Seat Support Tube (No. 03) to the Front Support Tube (No.
01); fasten with the Club Knob (No. 10).
10 Club knob
73 Wrench Fig. 3.1
07
03
16
17
01
10
07
17
16 03
Seat
3

8
FB160 Folding Bike
Handlebar
4
1. Remove 4 Screw Sets (No. 12) from the Handlebar Tube (No. 04).
2. Connect the Middle Sensor Wire (No. 19) with the Console (No. 08).
3. Attach the Handlebar Tube (No. 04) to the Rear Support Tube (No.
02), and tighten with 4 Screw Sets (No. 12).
72
04
08
19
12
02
08
19
Allen Key

FB160 Folding Bike
9
Operation of Your Console
FB160 Console
Functions AUTO SCAN Every 6 seconds
TIME 0:00 ~ 99:59
SPEED 0.0 ~ 999.9 KM/H (MILE/H)
DISTANCE 0.00 ~ 999.9 KM (MILE)
CALORIES 0.0 ~ 999.9 CAL
ODOMETER 0.0 ~ 9999 KM (MILE)
PULSE 40 ~ 240 BPM
BATTERY TYPE 2 AAA or UM 4
OPERATING TEMPERATURE 0°C ~ +40°C, 32˚F ~ 104˚F
STORAGE TEMPERATURE -10°C ~ +60°C, 14˚F ~ 140˚F

10
FB160 Folding Bike
KEY FUNCTIONS
BUTTONS
MODE - Push down for selecting functions.
SET - To Set the consumer movement of time, distance, calories and hand pulse.
RESET -For resetting consumer movement of time, distance, calories and hand pulse.
FUNCTIONS AND OPERATIONS
SCAN: Press the MODE button until SCAN appears, the monitor will rotate through the 6
functions: time, speed, distance, calorie, odometer, and pulse. Each display will be held 6
seconds.
TIME: Shows your elapsed workout time. Press the MODE button until “TIME” appears, press
SET button to set target time.
SPEED: Display current speed.
DISTANCE: Count the distance from exercise start to end. The maximum value is 999.99
miles. Press the MODE button until “DISTANCE” appears, press SET button to set target
distance.
CALORIE: Count the total calories from exercise start to end. Press the MODE button until
“CALORIE” appears, press SET button to set target calories.
ODOMETER: Monitor will display the total accumulated distance.
PULSE RATE: Press the MODE button until “PULSE” appears. Press SET button to set
target heart rate. The heart rate range can be set anywhere from 40 - 240 BPM.
Before measuring your pulse rate, please place your palms of the hands on both of the
contact pads. The monitor will show your current heart rate in beats per minute(BPM) on the
LCD after 6~7 seconds.
During the process of pulse measurement, the measurement value may be higher than
the actual pulse rate during the rst 2~3 seconds of reading, after which it will stabilize and
display a more accurate reading. The heart rate measurement value is not intended to be and
should not be used as the basis for medical treatment.
NOTE
• If the display is faint or shows no gures, please replace the batteries.
• The monitor will automatically shut off if there is no signal received after 4 minutes.

FB160 Folding Bike
11
STORAGE AND MAINTENANCE
HOW TO MOVE THE FOLDING BIKE
To move the folding bike, grasp the rear stabilizer and carefully lift it until the exercise folding
bike can be rolled on the front wheels. Carefully move the folding bike to the desired location
and then lower it.
Maintenance
Depending on your workout regimen, checks should be made weekly or before each workout.
This will help ensure your safety, as well as help maintain the integrity and performance of the
machine. Please see below for more detail:
• Check that the pedals are tightened securely as they can loosen over time.
• Check that seat nuts are secure.
• Check that stabilizer bolts are tight.
• Check that handlebar is secure.
• Tighten any parts that may have loosened over time before proceeding with your workout.
NOTE: Should any part become defective, contact XTERRA Customer Service immediately to
order replacement parts or seek advice on proper service. Discontinue use until the defective
part has been repaired.
Cleaning
A damp cloth is sufcient to clean most surfaces of this unit. Be careful not to drip water on
the monitor. A mild liquid soap may be added if needed.

12
FB160 Folding Bike
Part No. Serial No. Description Qty
01 FB160-665-PART01 Front support tube 1
02 FB160-665-PART02 Rear support tube 1
03 FB160-665-PART03 Seat support tube 1
04 FB160-665-PART04 Handlebar tube 1
05 FB160-665-PART05 Front stabilizer 1
06 FB160-665-PART06 Rear stabilizer 1
07 FB160-665-PART07 Seat DD-306 1
08 FB160-665-PART08 Console X3529 1
09L/09R FB160-665-PART09 Pedal ( L & R ) JG-16B 1*1
10 FB160-665-PART10 Club knob 1
11 FB160-665-PART11 Lock pin φ8x70L 1
12 FB160-665-PART12 Screw Set 4
13 FB160-665-PART13 Curved washer φ8.3 xφ22 4
14 FB160-665-PART14 Domed nut M8 4
15L/15R FB160-665-PART15 Crank ( L & R ) 1*1
16 FB160-665-PART16 Flat washer φ8.3xφ17.5 3
17 FB160-665-PART17 Nylon nut M8x8t 3
18 FB160-665-PART18 Hand pulse wire 1
19 FB160-665-PART19 Middle sensor wire 1
20 FB160-665-PART20 Flat washer φ4.3xφ12 2
21 FB160-665-PART21 Sensor bracket 1
22 FB160-665-PART22 Allen bolt M8x15L & at washer 25 2
23 FB160-665-PART23 End cap for handlebar 2
24 FB160-665-PART24 EVA pad 1
25 FB160-665-PART25 Hand pulse sensor 2
26 FB160-665-PART26 Foam grip for handlebar 2
27 FB160-665-PART27 Lower sensor wire 1
28 FB160-665-PART28 Screw M5x20L 1
29 FB160-665-PART29 Flat washer φ10.3xφ25 1
30 FB160-665-PART30 Self-tapping screw M4x10L 1
31 FB160-665-PART31 Self-tapping screw ST4.2x12L 2
32 FB160-665-PART32 Self-tapping screw ST4.2x20L 11
33 FB160-665-PART33 Magnet assembly 1
34 FB160-665-PART34 Axle for Main frame 1
35 FB160-665-PART35 Flat washer φ5.2xφ18 1
36 FB160-665-PART36 Pulley 1
PARTS LIST

FB160 Folding Bike
13
37 FB160-665-PART37 Plastic washer φ6.5 xφ13 1
38 FB160-665-PART38 Nylon nut M10 1
39 FB160-665-PART39 Flywheel 1
40 FB160-665-PART40 Axle for pulley 1
41 FB160-665-PART41 Idler wheel 1
42 FB160-665-PART42 Fixed plate 2
43 FB160-665-PART43 Hex head nut M10 2
44 FB160-665-PART44 Hex head nut M6 1
45 FB160-665-PART45 Nut M10 1
46 FB160-665-PART46 Screw M6x10L 6
47 FB160-665-PART47 Tension knob 1
48 FB160-665-PART48 Grommet 1
49 FB160-665-PART49 Flange nut M10 2
50 FB160-665-PART50 Hex head blot M6x30L 1
51 FB160-665-PART51 C-Clip 6
52 FB160-665-PART52 Wave washer 1
53 FB160-665-PART53 Flywheel adjustor 2
54 FB160-665-PART54 Spring 1
55 FB160-665-PART55 Self-tapping screw ST2.9x8L 4
56 FB160-665-PART56 Bearing 2
57 FB160-665-PART57 End cap for crank 2
58 FB160-665-PART58 Bushing for seat post 1
59 FB160-665-PART59 Screw M5x10L 1
60 FB160-665-PART60 Pulley 1
61 FB160-665-PART61 Bearing bracket 2
62 FB160-665-PART62 Cushion rubber 1
63 FB160-665-PART63 Bushing 6
64 FB160-665-PART64 Plastic washer φ14xφ10.3 1
65 FB160-665-PART65 Belt 2
66 FB160-665-PART66 Grommet 3
67 FB160-665-PART67 End cap for rear stabilizer 2
68 FB160-665-PART68 End cap for front stabilizer 2
69 FB160-665-PART69 Chain cover(L) 1
70 FB160-665-PART70 Chain cover(R) 1
71 FB160-665-PART71 Screw M5x8L 2
72 FB160-665-PART72 Allen key 1
73 FB160-665-PART73 Hex Head Wrench 1
PARTS LIST

14
FB160 Folding Bike
08
55
71
48
32
20
23
23 04
26
18
25
19
12
28
02 09L
57
49 15L
46
51
42
51 61
43
53 40
60
45
53
43
32
32
32 32
32
3232
70
38
29
41
59
37
33
65
13
67
06
32
69
32 62
34
63
23
10
58
73 72
14
24
11
22
68
31
05
64
50
30
21
27
01
44
54
51
52
51
39
51
36
39
51
61 56
42
46
15R
49 57
09R
35
4716
17
03 66
07
Exploded View

FB160 Folding Bike
15
Manufacturer’s Limited Warranty
Effective September 19, 2019 - Folding Bike LIMITED WARRANTY
Home Use Limited Warranty
Frame
1 Year
Parts
90 Days
XTERRA Fitness Inc. warrants all its home use Folding Bike parts for a period of time listed below, from the date of retail sale, as determined
by a sales receipt or in the absence of a sales receipt, eighteen (18) months from the original factory shipping date. XTERRA Fitness’
responsibilities include providing new or remanufactured parts, at XTERRA Fitness’ option, and technical support to our independent dealers
and servicing organizations. In the absence of a dealer or service organization, these warranties will be administered by XTERRA Fitness
directly to a consumer. The warranty period applies to the following components:
NORMAL RESPONSIBILITIES OF THE CONSUMER
This warranty applies only to products in ordinary household use. The consumer is responsible for the items listed below:
1. The warranty registration card must be completed and returned to the address listed on the card within 10 days of the original purchase
to validate the manufacturer’s limited warranty or register online at the XTERRA Fitness website.
2. Proper use of the Folding Bike in accordance with the instructions provided in this manual, including maintenance.
3. Proper connection to a power supply of sufcient voltage, replacement of blown fuses, repair of loose connections or defects in house/
facility wiring.
4. Expenses for making the Folding Bike accessible for servicing, including any item that was not part of the Folding Bike at the time it
was shipped from the factory.
5. Damages to the Folding Bike nish during shipping, installation or following installation.
EXCLUSIONS
This warranty does not cover the following:
1. CONSEQUENTIAL, COLLATERAL, OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL
EXPENSESRESULTING FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY. Note: Some states do not allow
the exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not apply to you.
2. Service call reimbursement to the consumer. Service call reimbursement to the dealer that does not involve malfunction or defects in
workmanship or material, for units that are beyond the warranty period, for units that are beyond the service call reimbursement period,
for Folding Bikes not requiring component replacement, or Folding Bikes not in ordinary household use.
3. Damages caused by services performed by persons other than authorized XTERRA Fitness service companies, use of parts other than
original XTERRA Fitness parts, or external causes such as alterations, modications, abuse, misuse, accident, improper maintenance,
inadequate power supply, or acts of God.
4. Products with original serial numbers that have been removed or altered.
5. Products that have been; sold, transferred, bartered, or given to a third party.
6. Products that are used as store display models.
7. Products that do not have a warranty registration on le at XTERRA Fitness Inc. XTERRA Fitness reserves the right to request proof of
purchase if no warranty record exists for the product.
8. Product use in any environment other than a residential setting.
9. THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES EXPRESSED OR IMPLIED, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR PURPOSE.
SERVICE
Keep your bill of sale. Warranty begins from the date on the bill of sale or three (3) months from the date of factory shipping as determined
by the serial number should service be required. If service is performed, it is in your best interest to obtain and keep all receipts. This written
warranty gives you specic legal rights. You may also have other rights that vary from state to state. Service under this warranty must be
obtained by following these steps, in order:
1. Contact your selling authorized XTERRA Fitness dealer. OR
2. Contact your local authorized XTERRA Fitness service organization.
3. If there is a question as to where to obtain service, contact our service department at [phone]
4. XTERRA Fitness’ obligation under this warranty is limited to repairing or replacing, at XTERRA Fitness’ option, the product through one
of our authorized service centers. All repairs must be preauthorized by XTERRA Fitness. If the product is shipped to a service center
freight charges to and from the service center will be the customer’s responsibility. For replacement parts shipped while the product is
under warranty, the customer will be responsible for shipping and handling charges. For in-home service, the customer will be respon-
sible for a trip charge. There will be an additional trip charge if the customer is located over 100 miles from the nearest service center.
5. The owner is responsible for adequate packaging upon return to XTERRA Fitness. XTERRA Fitness is not responsible for damages in
shipping. Make all freight damage claims with the appropriate freight carrier. DO NOT SHIP ANY UNIT TO OUR FACTORY WITHOUT
A RETURN AUTHORIZATION NUMBER. All units arriving without a return authorization number will be refused.
6. For any further information, or to contact our service department by mail, send your correspondence to:
Product features or specications as described or illustrated are subject to change without notice. All warranties are made by
XTERRA Fitness, Inc. This warranty applies only in the 48 contiguous United States. NOTE: This does not include Alaska or Hawaii.
XTERRA Fitness, Inc.
P.O. Box 2037
Jonesboro, AR 72402-2037
Labor
None

16
FB160 Folding Bike

FB160 Folding Bike
17
www.xterrafitness.com ©2019 All RIghts Reserved. FB160 Owner’s Manual
3000 Nestle Road Jonesboro, AR 72401 - Phone:[phone] - Fax:[phone]
