Sunnydaze Decor 10' OFFSET CANTILEVER UMBRELLA WITH SOLAR LED... User manual

RXB003 SOLAR
10' OFFSET CANTILEVER UMBRELLA
WITH SOLAR LED LIGHTS
01/2020
Thank you for choosing Sunnydaze Decor. We stand behind our brand and the quality of the items we sell.
Replacement parts or products will be sent at our discretion within the 1-year warranty period. Proof of purchase, with
the date of purchase as well as photos of the merchandise defect, must be provided. Photos are used to determine
the cause of defects and for future quality control. Register your warranty at https://tiny.cc/SunnydazeWarranty
If you have any questions, comments or concerns, feel free to contact us by phone at 888-881-4668, by email:
customerser[email protected], or via our contact us page at https://tiny.cc/SunnydazeContact
Purchase Date: / / Order/Customer Reference Number:
  
ATop Crossbar 1
BBottom Crossbar 1
CPole Support 1
DUmbrella 1
EThreaded Knob 2
FBolt 4
GWasher 4
HSolar Panel 1
HELPFUL HINT
Sunnydaze Decor advises reading this manual fully, and assembling the umbrella soon after purchase. Check
that all parts are accounted for and familiarize yourself with the assembly before beginning.
Save this manual for future reference.
Page 1 / 7
Ensure all parts are
accounted for before
disposing of packaging.
WARNING
CHOKING HAZARD — This
item contains small parts that
can be swallowed. Keep children
away during assembly.


Wrench

01/2020 Page 2 / 7RXB003 SOLAR
• This offset umbrella requires the use of 4 cantilever offset patio umbrella base weights or similar items, such as paving
slabs, for stability. Minimum total weight limit 120 lbs (54Kg).
• Read and understand this manual before assembling and using the product.
• Do not discard any of the packaging until all components and fittings have been accounted for. When discarding
packaging, take care and consideration for others and the environment.
• When assembling this umbrella, be aware of the safety of yourself and others.
• Because of the size of this offset umbrella, assembling it in the area intended for use is recommended.
• Some assembly may be easier with two people. Seek assistance when lifting large or heavy items.
• Assemble this umbrella on a clean, flat and level surface, e.g., the cardboard packaging.
• Assemble all parts loosely, by hand, before tightening any bolts or fixings.
• The Solar Panel collects energy from the sun to charge the battery inside the panel. Charging only occurs when the
solar panel is switched ON. Ensure the panel is in full sunlight all day to charge the battery.
IMPORTANT SAFETY INFORMATION
• Keep plastic bags away from children or animals.
• Keep fittings and small parts out of reach of children and animals.
• Do not place components directly onto patios or other abrasive surfaces where they may become damaged.
• Do not use power tools such as drills, as this may damage the frame or fittings.
• Do not use the umbrella if any parts are missing or broken.
• Do not use the umbrella until all the bolts are securely tightened. Do not over-tighten.
• Do not modify or alter the umbrella or frame in any way.
• Do not climb or stand on any part of the offset umbrella.
• Do not allow children to play on or around the offset umbrella.
• Please ensure that visitors are aware of the correct use and operation.
• Do not use your umbrella during inclement weather, including but not limited to, windy conditions, during thunderstorms,
heavy rains, or during freezing temperatures.
• Do not leave your offset umbrella unattended while it is in the raised position.
• The umbrella canopy does not provide complete protection from the sun or UV light.
BEFORE YOU BEGIN...
• Always use on a firm, flat and level surface.
• Always ensure that the umbrella is set up in its intended position and all locking mechanisms are engaged prior to use.
• This umbrella is designed for private and domestic use only.
• Do not use this product near heat sources such as barbecues, fire pits, candles, lanterns or heaters.
• Care must be taken when opening or closing the umbrella to prevent fingers and clothing from being pinched or trapped.
• Always ensure that the base is securely fixed or weighted before use.
HOW TO... use your oset umbrella

01/2020 Page 3 / 7RXB003 SOLAR
STEP 1 STEP 2
STEP 3
ASSEMBLY
Place the Top Crossbar onto the Bottom Crossbar.
Attach the Pole Support
to the crossbars using
the Washers and Bolts,
as shown.
1. Connect the umbrella pole, as shown.
2. Insert the plug into the socket under the solar panel.
3. Put the Solar Panel on the top of the umbrella, hiding the plug and
wire inside the groove at the top of the umbrella. Turn the solar panel
clockwise to lock it onto the umbrella. Do not over-tighten.
2
3
Remove the protective plastic lm from the solar panel.
The lm is to prevent the solar panel from becoming scratched or damaged during shipment.
1

01/2020 Page 4 / 7RXB003 SOLAR
STEP 4
Firmly insert the Umbrella into the assembled base.
Screw in and tighten the Threaded Knobs into the
pole support.
1. Flip the handle upwards.
2. Gently lift the curved bar upwards to extend the
canopy outward.
STEP 5
Weigh the unit down before proceeding.
4x Cantilever Offset Patio Umbrella Base Weights a recommended
to prevent the unit from tipping over (sold separately).
1
2

01/2020 Page 5 / 7RXB003 SOLAR
STEP 6
STEP 7
1. Push the curved pole upwards to extend
the canopy to the desired location.
2. Flip the handle down to lock into place.
3. Slide the sleeve down to secure the arm.
1
2
3
Turn the crank to open the umbrella until the canopy is fully expanded.
Do not use the umbrella if the canopy is not fully opened.

01/2020 Page 6 / 7RXB003 SOLAR
STEP 9 STEP 10
STEP 8
HOW TO... close the canopy
Turn the crank until the canopy is fully closed.
3
1
2
1. Slide the sleeve upward
on the arm, as shown.
2. Gently pull the curved
pole downward until the
umbrella is parallel with
the center pole.
3. Push the handle upwards
to unlock the umbrella.
Slide the collapsed
umbrella downward
and press the handle
downward to lock it
in place.

01/2020 Page 7 / 7

Cleaning & Maintenance
DO NOT USE BLEACH DO NOT USE A PRESSURE WASHER
RXB003 SOLAR
BASIC CARE
All fabrics will eventually fade from sun exposure. However, it is possible to maintain an umbrella's color for years to come by covering it
with an umbrella cover or storing it indoors when not in use.
Do not use bleach, acid, solvents or abrasive cleaners on this product.
Before putting into storage or covering, ensure the entire unit is clean and fully dry. Moisture may cause mold and mildew growth on the
canopy fabric and may cause the frame to rust.
During adverse weather conditions, or the winter, store your o󰀨set umbrella inside under a suitable cover.
METAL FRAME
Wipe the frame down using a soft cloth, warm water and mild soap; rinse thoroughly and dry.
If the painted nish should become chipped or scratched exposing bare metal, clean the surface thoroughly and treat with a touch-up paint.
Periodically use a suitable lubricant or water displacer on bolts and joints and check the frame for water build-up and empty if present.
Periodically check the tightness of any bolts or xings — re-tighten hardware as required.
CANOPY FABRIC
Brush or vacuum loose dust, dirt and debris from the canopy. To clean the fabric, use a weak solution of warm water and washing powder
or laundry detergent. Rinse fabric thoroughly and allow to air dry thoroughly. Always test cleaning solutions on a small area rst to ensure
suitability. Do not use bleach, acid, solvents or abrasive cleaners on the fabric.
SOLAR PANEL
Clean solar panels will absorb more sunlight. Wipe the panel down with a damp cloth and dry with a soft cloth.
Troubleshoong

Inspect the ribs beneath the canopy as they may be crossed. Carefully, and gently uncross the ribs and the canopy should open as intended
by turning the crank.

1. Check the solar panel to make sure the switch is turned to the 'ON' position, and the power switch under the canopy is turned to the
'ON' position.
2. Check the rechargeable battery and make sure that it is well contacted to the metal plate. The battery may need replacing; only use
compatible rechargeable batteries; alternatives may be incompatible, which may damage the system and will void the product warranty.
3. Be sure the solar panel is not receiving too much ambient light from sources such as exterior lights.
This product uses a rechargeable battery. When the battery can no longer be used, it should be removed from the unit and recycled.
The battery must not be incinerated or composted. Recycle the battery in accordance with local laws and regulations.

1. Check the location of the solar panel; make sure it is in a sunny area that does not become shaded during the day. The batteries will
only charge during the daytime.
2. Try a 'Boost Charge':
- Turn the power 'ON' and let it charge in full, direct sunlight for at least 8 hours.
- Turn the power 'OFF' at night to conserve the battery.
- Repeat this process for 2-3 days. If the unit still does not work, the battery may need replacing.
WARNING!



