Sunset Healthcare SUNNY NEB300BEAR User manual

Troubleshooting
If the device does not turn on:
1. Make sure the plug is rmly inserted into the electrical outlet.
2. Make sure the device has been operating within the limits indicated
in this instructional manual (30 minutes ON/30 minutes OFF).
If the device does not nebulize, or the nebulization
is weak:
1. Make sure the ends of the air tube are tted tightly onto the main
unit and onto the nebulizer (see connected kit and unit diagram
below)
2. Check whether the nebulizer mask or mouthpiece kit cup chamber is
empty or overlled with medication.
3. Check whether the nebulizer nozzle is obstructed (see
medicine cup diagram below)
4. Check whether the bafe is inserted properly. The bafe ts over the
medicine cup’s interior cone (see medicine cup diagram below).
Fit tube
ends tightly
Fit tube
ends tightly
Instruction Manual
SUNNY
Pediatric
Compressor
Nebulizer
NEB300BEAR
NEB300BEAR-R
NEB300BEAR-IFU V 1.00
2019-06-04
Deluxe Nasal Pillow CPAP Mask
Item# CM036
Intended Use
The nasal pillow mask is intended to provide an interface for Continuous Positive Airway Pressure (CPAP) or bilevel system.
The mask to be used by adult patients (>66lb/30kg) for whom positive airway pressure has been prescribed. The mask is for
single-patient re-use in the home environment and multi-patient re-use in the hospital/institutional environment.
Caution
US federal law restricts this device to sale by or on the order of a physician.
Excluding patient population
This mask may not be suitable for patients with the following conditions: impaired cardiac sphincter function, excessive
reflux, impaired cough reflex and hiatal hernia. It should not be used if the patient is unresponsive, obtunded, unable to
remove the mask, or uncooperative.
Warnings
This mask is designed for use with CPAP or bilevel systems recommended by your health care professional or respiratory
therapist. Do not wear this mask unless the CPAP or bilevel system is turned on and operating properly. Do not block or try
to seal the exhalation port.
CPAP systems are intended to be used with special masks with connectors which have vent holes to allow continuous ow of air out of the mask. When the
device is turned on and functioning properly, new air from the device ushes the exhaled air out through the attached mask exhalation port. However, when
the device is not operating, enough fresh air will not be provided through the mask, and exhaled air may be re-breathed. At low pressures, the airow through
the exhalation port may not be enough to clear all of the exhaled gas (CO2) from the mask. You may breathe in some of the air that you have exhaled.
If oxygen is used with the device, the oxygen flow must be turned off when the device is not operating.
• When the device is not in operation, and the oxygen ow is left on, oxygen delivered into the ventilator tubing may accumulate within the device enclosure.
Oxygen accumulated in the device enclosure will create a risk of re.
• Oxygen supports combustion. Oxygen should not be used while smoking or in the presence of an open ame.
• At a xed ow rate of supplemental oxygen ow, the inhaled oxygen concentration will vary, depending on the pressure settings, patient breathing pattern,
nasal interface selection, and the leak rate.
Some users may experience skin redness. If this happens, contact your health care professional.
Cleaning the Mask
The cushion, nasal interface, and tubing should be cleaned daily or as needed.
• Hand wash in warm water with a mild liquid dishwashing detergent. Do not use bleach, alcohol, or cleaning solutions
containing alcohol. Do not use cleaners containing conditioners or moisturizers.
• Rinse thoroughly. Pat with a towel and air dry completely before use
• Inspect all parts for damage or wear; replace if necessary.
Cleaning the Headgear
Hand wash the headgear weekly or as needed. Lay the headgear flat or line dry.
Disposal
The nasal pillow mask does not contain any hazardous substances and may be disposed of with your normal
household refuse.
latexfree
Manufactured for
Sunset Healthcare Solutions
180 N Michigan Ave Ste 2000
Chicago, IL 60601
SunsetHCS.com
DO NOT PRINT THIS LAYER.
100%
1 Color
1
PH 2.23.17
A4 (210mm x 297mm)
res036-ifu.pdf
When printing with default
Acrobat autoscale settings.
Cleaning
Cleaning of the compressor
Use a clean dry cloth and mild detergents to clean the outside of
the unit.
ATTENTION During cleaning, make sure the internal parts of the unit
are not in contact with liquids and the power cord is disconnected.
Cleaning and disinfection of the accessories
After each use, disassemble T-piece kit into 3 sections. Wash in warm
soapy water and rinse well. Wipe with a paper towel and allow to air dry.
Do not boil or autoclave angled mouthpieces, air tubes, or masks.
It is important that the cleaning instructions are carefully
followed to ensure optimal operation.
Replacement of Nebulizer Kit
RES2210 Pediatric Aerosol Mask
(Included in NEB300BEAR and NEB300BEAR -R)
The pediatric aerosol mask should be replaced after a long period of
inactivity, or if it is obstructed by dry medication, dust, etc. With normal
use, the pediatric aerosol mask should last 1 month.
RES091 Disposable Nebulizer Kit with Clear Tubing
(Included in NEB300BEAR and NEB300BEAR -R)
The disposable nebulizer T-Piece kit should be replaced after a long
period of inactivity, or if it is obstructed by dry medication, dust,etc. With
normal use, the disposable nebulizer T-piece kit should last 1 month.
RES093 Reusable Nebulizer Kit with Green Tubing
(Included in NEB300BEAR-R)
The reusable nebulizer T-Piece kit should be replaced after a long period
of inactivity, or if it is obstructed by dry medication, dust, etc. With
normal use, the reusable nebulizer T-piece kit should last 6 months.
Replacement of the filter
The lter is to be replaced after approximately 30 hours of use, or when
it appears dirty. Open the lter holder to replace the lter with a new
one. Use Sunset BF018 Nebulizer Filters.
Do not use the device without the lter.
Maintenance and Repair
Never open the device. There are no serviceable parts within the unit.
The compressor does not require lubrication or maintenance.
Exploded view
Medicine cup
Visual Guide
T-piece kit
Mask
Bafe
Nozzle
Closed view

Instructions for Use
The Sunset Compressor Nebulizer is an AC-powered air nebulizer
compressor system intended to provide a source of compressed air
for medical purposes for use in home healthcare. It is to be used with
a nebulizer kit to produce medicated aerosol particles for respiratory
therapy for both children and adults.
Important Read these instructions carefully before using this device.
Caution
Caution: Federal law restricts this device to sale by or on
the order of a physician
Use the device only for its intended purpose as described in
theseinstructions for use as a compressor nebulizer system for aerosol
therapy. Follow the instructions of your doctor. Any other form of use
constitutes improper use and may be dangerous. The manufacturer
cannot be held liable for any damage caused by improper, incorrect, or
unreasonable use, or if the unit is connected to electrical installations
not complying with safe regulations.
Keep this manual for future reference.
Do not operate the unit in the presence of any anesthetic, ammable
mixtures, or oxygen.
Correct device operation can be affected by electromagnetic
interference. If this device interferes with another electrical apparatus,
remove it and plug it into a different electrical outlet.
In case of failure and/or malfunction, do not open the compressor
housing, as this is not a serviceable product.
The proper function of the device can be compromised if original
replacement parts (e.g. lter) are not used.
When using any electrical appliance, certain important safety measures
must always be observed, including the following:
• Never submerge the unit in water, as the device is not protected
against water penetration
• Never touch the unit if hands are wet or moist
• Do not leave the unit outdoors
• Place on stable and horizontal surface when operating
• Make sure the air vent openings are unobstructed
• Do not allow unsupervised children or physically challenged
individuals to use the unit
• Turn the unit off with the power switch. Do not pull plug out from
electrical outlet while the power is on.
Make sure that the electrical rating shown on the rating plate on the
bottom of the unit corresponds to your main voltage and frequency
before plugging in the device.
Do not use electrical adapters including extension cords.
Instructions for Use
Examine the unit before the rst use in order to check
for possible shipping damage.
1. After unpacking the device, check the compressor and accessories
for visible damage or defects such as cracks in the plastic housing,
which could expose electrical components. Contact your retailer to
report any damaged product.
2. Before using the device, follow the cleaning instructions as detailed
in this user manual.
3. Attach the supply tube to the compressor and to the bottom of the
nebulizer cup.
4. Open the nebulizer cup by pushing down on the cap and
twisting counter-clockwise.
5. Add prescribed medication into nebulizer cup then turn top on
until secure.
6. Attach T-piece to the nebulizer bottle. If using mask option, attach
the mask in place of T-piece.
7. If using T-piece, attach mouthpiece and corrugated tube to T-piece.
8. Connect the 7ft tube to the nebulizer bottle and the
nebulizer machine.
9. Ensure connections are secure before turning on the
nebulizer machine.
10. Plug the compressor into the electrical outlet, making sure the
electrical rating shown on the rating plate on the bottom of the unit
corresponds to your main voltage.
11. To start treatment, switch the compressor on by pressing the
ON/OFF switch onto the “I” position. When taking a treatment sit
upright and relaxed.
ATTENTION: This device rated for intermittent use
30 minutes ON / 30 minutes OFF.
12. When mist is visible, begin inhaling with the mouthpiece or mask.
13. When the treatment has been completed, switch the unit OFF by
setting the switch position to “O” and disconnect the plug from the
electrical outlet.
14. Wash the nebulizer and accessories as described in the
cleaning section.
Do not leave the unit plugged in when not in use. Unplug the device
from the electrical outlet when not in operation.
Follow the manufacturer’s instructions for installing the device. The
manufacturer cannot be held responsible for any damage caused by
incorrect installation.
The power supply cord cannot be replaced by the user.
The power supply cord should always be fully unwound in order to
prevent dangerous overheating.
Before performing any cleaning operation or lter replacement,
disconnect the device from the main supply by unplugging it or by
turning the main supply switch OFF.
Some parts of the unit are small enough to be swallowed by children.
Do not let unattended children have access to the unit.
If you decide not to use the device, it is recommended to dispose of
it according to local regulations.
Remember to:
• Use this device only with medications prescribed by your doctor
• Use the accessories recommended by your doctor for therapy
Verify that the medications prescribed by your doctor can be used
with common compressor nebulizer systems for aerosol therapy.
Warranty
Sunset Healthcare Solutions offers a limited 3-year warranty on the
compressor unit to be free from defects in material and workmanship
under normal use and operation for a period of 3 years from date
of original retail purchase. This warranty does not extend to failures
resulting from accidental damage, misuse, negligence, abuse,
alteration, or improper operation. This warranty does not extend to
non-durable components which are subject to normal wear and need
periodic replacement nor does this warranty extend to hospital or clinic
use. All items returned must be properly packaged and shipped in a
manner to avoid shipping damage at the purchaser’s expense.
DO NOT return any product(s) or part(s) to Sunset Healthcare Solutions
without prior consent. For replacement under warranty, please call:
1-877-578-6738 (Monday to Friday, 9 am to 5 pm CST).
