Sunshine XGS101 User manual

- 1 -
Components List:
Installation Guide
Model
name XGS101/116 Anchor Bolt Angle Bolt & Nut
Model
name Rail Splice End Clamp Mid Clamp

- 2 -
Safe Installation Guide
POINTS TO CHECK
This manual contains critical information regarding electrical and mechanical installation and safety
information which you should know before starting installation.
● Stop work during stormy weather. Solar modules can be caught in the wind, causing you to fall.
● Never step or sit on the glass surface of a solar module. The glass may break, resulting in shock
or bodily injury. The module may also stop generating power.
●Always use the supplied parts to attach the solar modules and mounts. Use of weaker parts,
such as screws that are too short, is dangerous and may cause the solar modules or mounts to fall.
●Always use the specified tools. The solar modules or mounts may fall if the installation is not
strong enough, for example when parts are not tightened sufficiently.
●Do not modify or cut parts. Doing so is dangerous. Safety cannot be guaranteed.
●If you are unsure please seek the advice of a suitably qualified person.
●Determine the wind loads for the installation site.
●Check with your local building and safety department for the specific requirements.
●Make certain that the roof structure can support the weight of the mounts and PV array.
●Install solar modules facing south, if possible. Installations facing east and west are also
possible, although the amount of power generated will be lower.

- 3 -
Installation Steps
1. Attach two brackets to each frame with a nut and bolt.
2. If using anchor bolts, mark and drill the holes to correspond with the frames and place a
bolt in each hole holes. The frames should be level.
Use a horizontal reference line as a guide.

- 4 -

- 5 -
Horizontal reference line

- 6 -
3. Install the rails as shown below.
4. Place the first module of the bottom row. Slide the end clamp along the rail, tightly against the module and fasten
in place. Install the end clamps and mid clamps.
End clamps
Mid clamps

- 7 -
Slide the splice on the rear side of the pre-assembled rails. Fasten the first bolt firmly. Then slide
next rail into the splice. When together, fasten the other bolt. The connection is finished. An
expansion gap at the rail joints is suggested. Leave a gap about a finger width.
Installation of the splice to connect multiple rails together

- 8 -
Installation of nut
