Sunsky BT67 User manual

Bluetooth Car Charger User Manual- BT67
Operation Manual
PICTURE:
FEATURES:
1. Wireless transmit phone call from Bluetooth mobile phone to the car FM stereo system.
2. Built-in FM transmitter, full frequency: 87.5-108.0MHZ.
3. With built-in microphone and automatically calling-number system
4. Supports USB disk and SD card,A2DP function
5. With 3.5mm line-in jack, support external audio devices.
6. Switch to Hands-free mode automatically from music playing status when receiving calls
7. Supports 4 loop modes: Repeat all, Random, Repeat one, Folder,
8. 5 EQ for optional: Natural, Rock, Pop, Classic, Jazz
9. USB charging port for charging iPod/ iPhone, iPad and other mobile device. (output: DC 5V/2.1A).
10. Support 12-24V voltage from the car cigarette lighter.
11. Strong and elegant design with LCD screen display, just support number displaying.
12. Flexible metallic hose adapted for any type of autos.
13. With infrared remote control, easy operation

Bluetooth Car Charger User Manual- BT67
Using FM Transmitter function:
1. Plug the FM transmitter into your vehicle’s cigarette lighter or power port.
2. Tune your radio to an unused FM frequency, then match the same frequency of this unit.
3. Insert a USB flash drive or SD card which containing MP3 files into USB port or memory card slot of this unit
accordingly. It will play and transmit the MP3 files automatically.
4. Line-in function: Use the provided audio cable to connect an MP3/MP4 players or another external device to theAUX
input of this unit. When using this function, please stop playback of USB or memory card, and all functions will be
controlled by the external device.
Using Bluetooth function:
1. Using Bluetooth for the first time, you need to pair your mobile phone with this unit. Activate your mobile phone's
bluetooth function, then search new device. When the mobile phone detects this unit (named as "BT67"), please pair
and connect by using the original password "0000"
2. In the music playing mode, when there is an incoming call, this unit will automatically switch to telephone mode.
Note: The Bluetooth indicator light which on the top of the screen will be stop flashing after the Bluetooth connected
with your mobile phone.
Bluetooth calling:
1. Please press the red "Answer/Hang off" button in the middle of the keyboard to answer the incoming call.
2. Please press the red "Answer/Hang off" button in the middle of the keyboard to hang off a call.
3. When making a call, you can only dial the phone number by your mobile phone, but once the call connected, you can
use the hands-free function to enjoy it.
Note: The Bluetooth indicator light which on the top of the screen will be flash quickly when talking.
Using USB charger function:
When this unit powered from car lighter socket,
connect the USB Charger port to your mobile phone
with a special USB cable (not included).
This unit will serve as mobile phone charger.
Remote controller:
Most of the function can be fulfilled by the remote
controller provided.

Bluetooth Car Charger User Manual- BT67
Quick Guide:
Operation Guide
On FM transmitter
On Remote Controller
1. Answer / hang up
the call:
Press "answer/hang off " button: answer the
call
Press "answer/hang off" button: hang off the
call
Press” ”button
2. Play and Pause the
music:
Press “ ” Button: Play the music
Press “ ” Button again: Pause playing
Press Button
3. Adjust the Volume:
Press and hold “ ” button: Increase Volume
Press and hold “ ” Button: Decrease Volume
Press “vol+” to increase the Volume；
Press “vol-” to decrease the Volume；
4.Set frequency:
Press “CH” button first, then
press “ ”: increase the frequency
Press ” ”: decrease the frequency
Press “CH+” button: Increase 0.1MHz
Press “CH-” button: decrease 0.1MHz
Or press the numbers of the
frequency what you desired, press
“CH+” to confirm.
5. Choose music:
Press “ ” Button: Play the next song
Press “ ” Button: Play the previous song
Press button: Play the next song;
Press button: Play the previous
song;
Or press the number of the song then
press to confirm
6. Choose EQ:
Support by remote controller only
Press “EQ” button to choose your
favorite EQ
7. Switch folder:
Support by remote controller only
Press “folder”button to switch folder
8. Loop mode:
Long press “play/pause”button, four loop
modes optional: folder, single, random, all
Press “ ” button
SPECIFICATIONS:
BLUETOOTH IC: CSR BC8635 Stereo (CSR 4.0)
Frequency: 87.5-108.0 MHZ
Frequency Stability: ±10ppmI (0℃-+45℃)
Output Frequency: 20HZ-20KHZ
Supply Voltage : 12-24V
USB Charger output: 5V/2.1A
Music Format: MP3 Format
USB (Maximum support): 32GB
SD (Maximum support): 32GB
Transmit Distance: >10M
Operating system: Win xp/Win vista/Win7
MP3 S/N RATIO: 60-70dbm
MP3 BITRTE: 32KPB-320KPBS
SNR:≥80dB
