End Stops (2X)
Caps, Large (4X)
Caps, Small (8X)
1
1
Small Cap
Large Cap
FEA-0001 ASSEMBLY INSTRUCTIONS
1—FEA-0001.......................................................... (Qty 1)
Ladder End Stops w/Crossbar Caps
CONTENTS OVERVIEW
One Ladder Stop Kit will be needed for two Crossbar ends.
For a Base/Base (VBB) model, order a quantity of two kits
to place Ladder Stops at both ends of two Crossbars.
For a three Crossbar Base/Base (VBB3) model, order three
kits to place Ladder Stops at both ends of three Crossbars,
or two kits to place them on one side of three Crossbars.
CROSSBAR CAPSLADDER STOPS
1.1
1.2
2.1
2.2
USAM-FEA0001-US01 Rev-A 0618
Loosen the nut to allow
the End Stop to slide into
the Crossbar groove
Position the Ladder Stop to
the desired location, then
torque the nut to 90 in-lbs.
NOTE: Some Front Crossbars may
have additional drilled holes. Press
Crossbar Caps into Crossbar holes if
present and unused.
