SunStone Power SLPO48-100 User manual

LITHIUM BATTERY PACK
USER MANUAL
MODEL: SLPO48-100
※Please read this manual before using the battery pack
※Please keep this manual properly after reading

Sunstone Power Industrial GmbH PT. Solid Power Energi Indonesia Sunstone Power Industry Co., Ltd.
Nobelring 13, 60598 Frankfurt (M) Germany
Komplek Duta Indah Iconic, Blok. C No. 2 Jl. 1803A, Tiley Central Plaza. Shenzhen, China
www.sunstonepower.de MH Thamrin KM.2 Kebon Nanas, Tangerang 15143 Indonesia www.sunstonepower.com
[e-mail] [e-mail] [e-mail]
1. Product key parameters
NO. Specification
Item
56.8V±0.2V
51.2V
40V
100Ah (After standard charging, discharging at 50AH.)
100Ah (After standard charging, discharging at 50AH.)
Step 1: 50A constant current charge to 56.8V;
Step 2: 56.8V constant voltage charge until the charging current reaches
5A.
Temp.：0~45°C
2.5 hours (for reference)
50A
50A
Charging: 0~45°C; Discharging: -20~55°C
1month: -20~45°C
3 months: -10~45°C
6 months: 0~25°C
humidity: 45~90% RH
The battery should be cycled every three months.
After 6000 cycles, at 25°C, 50A charge and discharge 80% DOD,
recoverable capacity ≥ 80%
≤ 100mΩ(50% capacity，AC impedance1kHz measuring)
About 44kg
52~53.5V
483(L)*460(W)*132(H)
Supports parallel connection of multiple battery pack (24units)
Communication (CAN, RS485, RS232), LCD, dry contacts
Black
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
1.10
1.11
1.12
1.13
1.15
1.16
1.17
1.18
1.19
1.20
Charging voltage
Nominal voltage
Cut-off voltage
Nominal capacity
Min. capacity
Standard charging
current and voltage
Charging time
Rated charging current
Rated discharge current
Working temp.
Storage temp. and
humidity range
Cycle life
Battery weight
Ex-work voltage
Dimension
Function
Communication
Color
Initial battery
internal resistance
1.1
1.14
Appearance The battery pack surface is clean, free from scratches and mechanical
damage.

Sunstone Power Industrial GmbH PT. Solid Power Energi Indonesia Sunstone Power Industry Co., Ltd.
Nobelring 13, 60598 Frankfurt (M) Germany
Komplek Duta Indah Iconic, Blok. C No. 2 Jl. 1803A, Tiley Central Plaza. Shenzhen, China
www.sunstonepower.de MH Thamrin KM.2 Kebon Nanas, Tangerang 15143 Indonesia www.sunstonepower.com
[e-mail] [e-mail] [e-mail]
2. Structural characteristics and interface definition
A. Basic structure: 2mm sheet metal box structure and rack.
B. Installation method: screw lock.
C. Surface coating: add spray paint.
2.1 Overall structure
The battery assembly is mainly composed of the following parts: a 3U metal outer box, which con-
tains a 16S module, and accessories include BMS, patch cords, and external terminals. The overall
structure is simple, detachable, easy to maintain and protect, high reliability, light weight, and high
energy density.
2.2 External interface function and introduction
③
②
①
⑤
⑥
④

Sunstone Power Industrial GmbH PT. Solid Power Energi Indonesia Sunstone Power Industry Co., Ltd.
Nobelring 13, 60598 Frankfurt (M) Germany
Komplek Duta Indah Iconic, Blok. C No. 2 Jl. 1803A, Tiley Central Plaza. Shenzhen, China
www.sunstonepower.de MH Thamrin KM.2 Kebon Nanas, Tangerang 15143 Indonesia www.sunstonepower.com
[e-mail] [e-mail] [e-mail]
2.2.2 Battery pack interface functions
2.2.2.1 The positive and negative terminal blocks
The red terminal block is the positive pole of the battery, and the black terminal block is the negative
pole of the battery. It is locked with M6 screws. When installing, the SC25-6 copper nose can be used
for parallel connection of battery packs or external equipment for energy supply or charging.
2.2.2.2 LCD display and control
LCD display and control are divided into display part and control part.
(1) The control part is button control, as shown in the figure below, from top to bottom are POWER,
UP, DOWN.
Power on:
①Long press the POWER switch until the red light turns on (first the
green light turns on, but the switch shouldn’t be released).
②The system self-checks when the red light is flashing (about 10S). After
that, the battery will enter the power-on state.
Power off:
①Long press the switch (about 6S).
②The green light goes out briefly and then flashes to enter the self-test
(about 10S). After that, the battery will be completely power-off.
2.2.1 Battery pack interface definitions
Function
Charge and discharge positive terminal
Charge and discharge negative terminal
Battery pack information and status display
Interface
Positive electrode
Negative electrode
LCD display and control
Dry contact and indicator light
RS485/CAN/RS232
communication interface
Address dial switch
4
6
Remark
-
-
Support continuous 100A
single pin overcharge
Support continuous 100A
single pin overcharge
The external communication of the battery pack
is connected in parallel and connected to the
communication interface of the upper computer
Battery pack status indication, abnormal alarm
Address setting when battery packs are
connected in parallel
Invalid when all six bits are set
to OFF
RS485/CAN is RJ45 interface
RS232 is RJ11 interface
NO.
1
2
3
5

Sunstone Power Industrial GmbH PT. Solid Power Energi Indonesia Sunstone Power Industry Co., Ltd.
Nobelring 13, 60598 Frankfurt (M) Germany
Komplek Duta Indah Iconic, Blok. C No. 2 Jl. 1803A, Tiley Central Plaza. Shenzhen, China
www.sunstonepower.de MH Thamrin KM.2 Kebon Nanas, Tangerang 15143 Indonesia www.sunstonepower.com
[e-mail] [e-mail] [e-mail]
2.2.2.3 RS485/CAN/RS232 communication interface
The communication interface is divided into 2 RS485/CAN and 1 RS232 communication interface.
(2) LCD display: When the wake-up mode is activated, the user can view various status information
of the battery through the LCD. This battery pack LCD display is divided into 6 pages.
On the home page, you can view the battery voltage, current, capacity percentage, and battery pack
status (OK or abnormal code).
On the next page, you can view the maximum and minimum voltage, maximum and minimum tem-
perature of the battery.
User can view the voltage of each cell on pages 3~6.
First Page Second page
Remark
1. In wake/sleep mode, you need to stop press-
ing immediately after long pressing for 3~6 sec,
otherwise the startup will fail.
2. Wake up again in 10S after wake up failure.
3. After under-voltage dormancy, only charging
wakeup is supported.
-
-
Item
POWER
UP
DOWN
Function
Battery pack operation power control
1. Power on
2. Power off
3. Wake up mode
4. Sleep mode
LCD display content page up
LCD display content page down
Remark
1. The dual interface does not divide the A/B
interface and can be connected as required.
2. RJ45 interface.
RJ11 interface.
Item
RS485/CAN
RS232
Function
1. External communication, connect to the
upper computer equipment.
2. The battery packs are connected in parallel.
External communication, connect to the upper
computer equipment.

Sunstone Power Industrial GmbH PT. Solid Power Energi Indonesia Sunstone Power Industry Co., Ltd.
Nobelring 13, 60598 Frankfurt (M) Germany
Komplek Duta Indah Iconic, Blok. C No. 2 Jl. 1803A, Tiley Central Plaza. Shenzhen, China
www.sunstonepower.de MH Thamrin KM.2 Kebon Nanas, Tangerang 15143 Indonesia www.sunstonepower.com
[e-mail] [e-mail] [e-mail]
2.2.2.4 Dry contacts and indicator lights
This product contains 3 dry contacts and 3 groups of 6 LED indicators.
Function
NO.1: voltage protection
NO.2: current protection
NO.3: temperature protection
Normal operation of the battery pack is
turned on, sleep/stop is turned off.
Fault/alarm: red light flashes.
Remark
-
E22: Module communication abnormal level 2 alarm
E51: Module overvoltage level 1 alarm
E52: Module overvoltage level 2 alarm
E61: Module undervoltage level 1 alarm
E62: Module undervoltage level 2 alarm
E71: Module charging overcurrent level 1 alarm
E72: Module charging overcurrent level 2 alarm
E81: Module discharge overcurrent level 1 alarm
E82: Module discharge overcurrent level 2 alarm
E83: Module discharge load short circuit (serious)
E92: Single cell overvoltage level 2 alarm
E101: Single cell undervoltage level 1 alarm
E102: Single cell undervoltage level 2 alarm
E111: Module high temperature level 1 alarm
E112: Module high temperature level 2 alarm
E121: Module low temperature level 1 alarm
E122: Module low temperature level 2 alarm
The dry contact can be normally
open or normally closed.
Item
Dry contact
Operating
indicator
Alarm
indicator
Item
RS485/CAN
RS232
Number
1
2
3
4
5
6
7
8
1
2
3
4
5
6
Signal
CAN-H
CAN-L
-
485-A
485-B
-
GND
GND
232-RXD
232-TXD
GND
GND
-
-
Schematic diagram

Sunstone Power Industrial GmbH PT. Solid Power Energi Indonesia Sunstone Power Industry Co., Ltd.
Nobelring 13, 60598 Frankfurt (M) Germany
Komplek Duta Indah Iconic, Blok. C No. 2 Jl. 1803A, Tiley Central Plaza. Shenzhen, China
www.sunstonepower.de MH Thamrin KM.2 Kebon Nanas, Tangerang 15143 Indonesia www.sunstonepower.com
[e-mail] [e-mail] [e-mail]
3. BMS protection threshold
3.1 Temp. control threshold value
Level
Running normal
Alarm
Protect
Alarm
Protect
Alarm
Protect
Item
Normal operation temp.
Tpmin / Tpmax(°C)
10 < Tpmin < 35
-20 < Tpmin ≤ -15
Tpmin ≤ -20
75 ≤ Tpmax < 85
Tpmax > 85
60 ≤ Tpmax < 65
Tpmax > 65
-
≥ -13
≥ -15
≤ 65
≤ 75
≤ 57
≤ 60
Code
-
E121
E122
E111
E112
E111
E112
Temp. protection recovery
value(°C); delay (5S) Dry contact output
-
-
Dry contact 3 action
-
Dry contact 3 action
-
Dry contact 3 action
Low temp.
threshold value
Radiator high temp.
threshold value
Battery cell high temp.
threshold value
2.2.2.5 Address dial switch
When battery packs are connected in parallel, the battery pack address can be set here, and it is inval-
id when all six bits are set to OFF.
Function
The 4 indicators respectively indicate
100%/75%/50%/25%.
Remark
-
Item
Power
indicator
Remark：
It cannot be charged or discharged when in the Protect state.

Sunstone Power Industrial GmbH PT. Solid Power Energi Indonesia Sunstone Power Industry Co., Ltd.
Nobelring 13, 60598 Frankfurt (M) Germany
Komplek Duta Indah Iconic, Blok. C No. 2 Jl. 1803A, Tiley Central Plaza. Shenzhen, China
www.sunstonepower.de MH Thamrin KM.2 Kebon Nanas, Tangerang 15143 Indonesia www.sunstonepower.com
[e-mail] [e-mail] [e-mail]
4. Daily use and maintenance of battery pack
3.3 Current threshold value
Item
Undervoltage alarm
Normal
Item
Normal
Undervoltage protection
(Cannot discharge)
Full
(Turn off charging)
Overvoltage protection
(Turn off charging)
Charge and discharge
overcurrent alarm
Charge and discharge
overcurrent protection
Short circuit protection
Recovery after 5S
Recovery after 5S
Code
E101
E102
-
-
E92
2.5 < Vmin ≤ 2.9
Vmin ≤ 2.5
2.9 < V < 3.65
3.7 ≤ Vmax < 3.8
Vmax ≥ 3.8
≥ 3.1
≥ 2.8
-
≤ 3.45
≤ 3.5
3.2 Voltage threshold value
Cell voltage range (V);
delay (3S)
Cell voltage recovery
value (V); delay (5S) Dry contact output
-
Dry contact 1 action
-
-
Dry contact 1 action
Remark
-
-
-
No code displayed
-
Code
-
Charge E71 / Discharge E81
Charge E72 / Discharge E82
E83
< 75
75 ≤ Imax ≤ 105
Imax > 105
Imax > 200
(within 1mS)
-
<70A
Current value (A);
delay (3S)
Current recovery value
(A); delay (5S) Dry contact output
-
-
Dry contact 2 action
Dry contact 2 action
Remark：
Charge and discharge overcurrent protection: After charging protection, it cannot be charged but can be
discharged; after discharge protection, it cannot be discharged but can be charged.
Solution
Check whether the communication line is plugged in
tightly, the connection is reliable, and restart after
troubleshooting.
Stop charging and check whether the charging
voltage is too high.
Stop charging immediately and check whether the
charging voltage is too high.
The battery is undervoltage, it is recommended to
charge it as soon as possible.
4.1 Solution to the battery code
Meaning
Module communication abnormal
level 2 alarm
Module overvoltage level 1 alarm
Module overvoltage level 2 alarm
Module undervoltage level 1
alarm
Remark
-
Charging
voltage: 56.8V
Charging
voltage: 56.8V
-
Code
E22
E51
E52
E61

Sunstone Power Industrial GmbH PT. Solid Power Energi Indonesia Sunstone Power Industry Co., Ltd.
Nobelring 13, 60598 Frankfurt (M) Germany
Komplek Duta Indah Iconic, Blok. C No. 2 Jl. 1803A, Tiley Central Plaza. Shenzhen, China
www.sunstonepower.de MH Thamrin KM.2 Kebon Nanas, Tangerang 15143 Indonesia www.sunstonepower.com
[e-mail] [e-mail] [e-mail]
Meaning
Module undervoltage level 2
alarm
Module charging overcurrent
level 1 alarm
Module charging overcurrent
level 2 alarm
Module discharge overcurrent
level 1 alarm
Module discharge overcurrent
level 2 alarm
Module discharge load short
circuit (serious)
Single cell overvoltage level 2
alarm
Single cell undervoltage level 1
alarm
Single cell undervoltage level 2
alarm
Module high temperature level 1
alarm
Module high temperature level 2
alarm
Remark
-
Rated charging
current: 50A
Rated charging
current: 50A
Rated discharge
current: 50A
Rated discharge
current: 50A
-
-
-
-
-
-
Code
E62
E71
E72
E81
E82
E83
E92
E101
E102
E111
E112
Solution
The battery is undervoltage, it is recommended to
charge it as soon as possible.
Check whether the charging current of the charging
device is too large.
1. Check whether the charging current of the
charging device is too large;
2. Use a current clamp to test whether the battery
input current is consistent with the displayed current.
If the difference is large, the BMS current may be
inaccurate and needs to be replaced by a professional
or authorized person.
Check whether the load of the battery is too heavy,
and appropriately reduce the load.
1. Check whether the load of the battery is too
heavy, and appropriately reduce the load;
2. Use a current clamp to test whether the battery
output current is consistent with the displayed
current. If the difference is large, the BMS current
may be inaccurate and needs to be replaced by a
professional or authorized person.
1. Check whether the battery output is short-circuit-
ed;
2. Check whether the battery output load is seriously
overloaded;
3. If E83 is still displayed after eliminating the above
conditions, restart the BMS.
Check whether the voltage of a certain cell exceeds
3.8V on the display screen, but the other voltages are
normal and basically the same. It is possible that the
battery cell is faulty and needs to be repaired.
The battery is undervoltage, it is recommended to
charge it as soon as possible.
The battery is supplied with undervoltage. Charge it
as soon as possible, otherwise the battery may be
damaged.
It is recommended to appropriately reduce the charge
and discharge current.
1. At this time, the BMS has automatically cut off the
charging and discharging current, and automatically
resumes charging and discharging when the
temperature drops, appropriately reducing the
charging and discharging current to avoid over-tem-
perature protection;

Sunstone Power Industrial GmbH PT. Solid Power Energi Indonesia Sunstone Power Industry Co., Ltd.
Nobelring 13, 60598 Frankfurt (M) Germany
Komplek Duta Indah Iconic, Blok. C No. 2 Jl. 1803A, Tiley Central Plaza. Shenzhen, China
www.sunstonepower.de MH Thamrin KM.2 Kebon Nanas, Tangerang 15143 Indonesia www.sunstonepower.com
[e-mail] [e-mail] [e-mail]
4.2 Daily maintenance of battery pack
1. Check the voltage data on the BMS display and the actual battery voltage value to ensure the accu-
racy of the voltage collection of the BMS. If they are inconsistent, proofreading is required. The error
between the collected voltage and the actual battery voltage does not exceed 10mV.
2. Check the temperature collection data and actual temperature value of the BMS, and the data error
between the collected data and the actual temperature value is not allowed to exceed 3°C, to ensure
that the battery will not be charged or discharged when the temperature is too high or too low.
3. Check the BMS current collected data and actual current value, the error is not allowed to exceed
1%, to ensure that the battery will not be charged or discharged by overcurrent.
4. Check the reliability of the charging equipment to ensure that the charging equipment performs
charging according to the voltage and current regulationsent by the BMS, to ensure that the battery
will not be overcharged.
5. Check the connection of the battery pack is good, the contact points are in normal contact, and
there is no accumulation of dust, powder, metal chips.
4.3 Caution
1. Children are not allowed to use the batteries.
2. It is forbidden to disassemble the battery.
3. Keep batteries or battery packs away from dangerous items or materials, such as corrosive chemi-
cals, dangerous machinery and equipment, and high-temperature environments.
Meaning
Module high temperature level 2
alarm
Module low temperature level 1
alarm
Module low temperature level 2
alarm
Remark
-
-
-
Code
E112
E121
E122
Solution
2. If E112 is displayed without charging or discharg-
ing, please restart the BMS once. If the problem
persists, it means that the BMS is damaged and
needs to be replaced by a professional or authorized
person.
It is recommended to charge and discharge in a high
temperature environment.
1. It is recommended to charge and discharge under
a higher temperature environment;
2. If the current ambient temperature is between
-20°C and 55°C but E122 is displayed, please restart
the BMS once. If the problem persists, please check
whether the internal plug is loose;
3. If the internal wiring harness plug is not loose, it
means that the BMS is damaged and needs to be
replaced by a professional or authorized person.

Sunstone Power Industrial GmbH PT. Solid Power Energi Indonesia Sunstone Power Industry Co., Ltd.
Nobelring 13, 60598 Frankfurt (M) Germany
Komplek Duta Indah Iconic, Blok. C No. 2 Jl. 1803A, Tiley Central Plaza. Shenzhen, China
www.sunstonepower.de MH Thamrin KM.2 Kebon Nanas, Tangerang 15143 Indonesia www.sunstonepower.com
[e-mail] [e-mail] [e-mail]
4. Unreasonable use of this of products may cause smoke, such as external short circuit, overcharging,
and high ambient temperature. If smoke occurs, please cut off the power in time, use carbon dioxide
or dry powder fire extinguisher for treatment, and bury it with sand or mud. The crowd must be evac-
uated in time during the entire process.
5. Unreasonable use of this series of products may cause the single battery to swell. In severe cases,
it may cause the casing to rupture or crack. In these conditions, the battery should be stopped imme-
diately. Please contact our technical department or after-sales service department for further solution.
6. It is forbidden to short circuit the positive and negative terminal of the battery directly, and avoid
any metal or other conductive objects contacting the positive and negative terminal of the battery.
This operation may cause personal injury or property damage.
7. It is forbidden to immerse the battery in water or other conductive liquids. This operation may
cause personal injury or property damage.
8. It is forbidden to use this product in series or parallel with other types of batteries. It is also forbid-
den to connect the whole system in series or parallel operation with other batteries. These operations
may cause personal injury or property lose. If necessary, please contact the relevant technical depart-
ment to obtain the correct technical support.
9. It is forbidden to get wet under the environment of more than 95%RH, even immerse in water.
Otherwise, it may cause internal short circuit, loss of function or abnormal chemical reaction, and
cause fire, smoke, explosion and other accidents.
10. It is forbidden to put the battery system into fire or to be exposed to a high temperature environ-
ment exceeding the temperature conditions specified in this specification for a long time. These envi-
ronments above the safe temperature range will cause a significant decrease in the performance and
life of this product, and even cause serious consequences such as combustion and explosion.
11. It is forbidden to store and use in an environment with high static electricity or high electromag-
netic radiation. Otherwise, the electronic devices in this product will be damaged, which may cause
potential safety hazards.
12. Connect the positive and negative terminal of the battery system strictly in accordance with the
instructions, and reverse charging is prohibited.
13. When the electrolyte leaks, avoid contacting the electrolyte with skin and eyes. In case of contact,
wash the area with plenty of water and seek medical assistance. It is forbidden for any person or
animal to swallow any part of the battery system or the substance contained in the battery system.
14. Protect the battery system as much as possible to avoid mechanical vibration, collision and pres-
sure shock, otherwise the battery system may short circuit, resulting in high temperature and fire.
