SunSun CUF Series User manual

Operation Manual
SunSun CUF 3in1 Filter
50945, 50946, 50947
Illustration similar, may vary depending on model
Read and follow the operating instructions and safety information before using for the first time.
Technical changes reserved!
Due to further developments, illustrations, functioning steps and technical data can differ insignificantly.
Updating the documentation
If you have suggestions for improvement or have found any irregularities, please contact us.

© by WilTec Wildanger Technik GmbH Seite 2
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 9
http://www.teichtip.de
The information contained in this document is subject to change without prior notice. No part of this
document can be copied or duplicated in another form without the prior written consent of WilTec Wil-
danger Technik GmbH. The WilTec Wildanger Technik GmbH assumes no liability for any errors in this
user manual or the connection diagram.
Although WilTec Wildanger Technik GmbH has made every effort to make sure that this user manual is
complete, accurate and updated, errors cannot always be avoided. In the event of problems with this
user manual please complete and send this form back to us.
FAX-notification (+++49 2403 55592-15),
from: ________________________________________
Name: ________________
Firm:_____________________
Tel/Fax:__________________
I would like to report the following mistakes:
___________________________________________________________________
Customer Service WilTec Wildanger Technik GmbH
e-mail: [e-mail]
Tel: ++49 2403 55592-0
Introduction
Thank you for purchasing this quality product. To minimize the risk of injury we urge that our clients
take some basic safety precautions when using this device. Please read the operation instruc-
tions carefully and make sure you have understood its content.
Keep these operation instructions safe.

© by WilTec Wildanger Technik GmbH Seite 3
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 9
http://www.teichtip.de
Before the first time use, please read this instruction and acquaint this equipment. In order to use the
equipment safely, the following secure suggestions should be abided.
Caution
CUF is UV clarifier equipment which can be fixed. It contains water pu,p and one piece of UV lamp.
Any damage on the equipment or unmerited operation will bring dangerous radiation to the skin and
eyes. So if there is any damage of the equipment, it cannot be used any more. This equipment is not
intend for use by persons (including children) with reduced physical, sensory of mental capabilities, or
lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the equipment by a person responsible for their safety. The equipment should be placed out of
children reach. For the consideration of security, people younger than 16 years old and those who
cannot identify danger or grasp the instruction cannot use the equipment.
•This equipment should be placed under the water. Be sure the equipment is submerged
completely in the water and the deepness should not bigger than 2m.
•Before the water submerge the equipment, please never plug in to avoid the equipment
working without water which will bring damage to the equipment.
•The equipment is a kind of fixed appliance with rubber feet under it which can help the
eqiupment to fix on the slippy surface (such as glass and so on); Because the UV lamp is
made of quartz glass, please avoid drop of it or wallop on it. The detailed information about
installation, please check the instruction information.
•Before all parts are installed completely, the equipment cannot be plugged in.
•If there is any damage on the power cable, UV lamp or shell, the equipment cannot be used.
And it should be discared as useless.
•When any person in the water, the equipment cannot be used.
•Please make sure that the electrical voltage, frequency used are consistent with the indication
on the label of the equipment.
•When installing the equipment, the installation regulation of domestic should be followed
•The equipment should be earthed, And the professional person should check the condition of
earthed. For the considered of safety, we advise customer to install creepage protector in
order to make sure the electric current will not exceed 30mA.
•Pull in the connecting cable is forbidden. And please keep the connecting cable away from
heat, greasiness or sharpness.
•Make sure the max. pressure of the bod shell endured is less than 0.3 bar.
•When know the frost is coming, please move away UV filter.
•The dirtiness on the quartz tube will influence the effect of the equipment, please clean the
quartz tube in time.
•In order to ensure the effect of the equipment, the UV light tube should be replaced after 8000
hours' usage.
•When the body shell is blocked with the sands and rubbish, it is possible to destroy the quartz
tube. So please add the filter sponge in the inlet of the water. And the sponge should be
cleaned in time (one month one time).
•U'VC is harmful to the eyes and shin. Please do not watch UVC directly or let the shin
approach to the UVC.
•When Install or repair this equipment, the electrical source of the aquarium must be switched
off.
Applicability & Technical Parameter
This series equipment are suitable for aquarium and pond filter the water. They cannot used in the
swimming pool. The major technical parameter is as follows (The Max. water pressure: 2M, Too big
pressure will damage the equipment.)

© by WilTec Wildanger Technik GmbH Seite 4
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 9
http://www.teichtip.de
ITEM
VOLTAGE
POWER
UVC LAMP
H-MAX
Q-MAX
OUTLET
CUF-2500
220-240V/50HZ
28W
9W
1.6M
1000L/H
1/2’’-3/4’’-1’’
CUF-5000
220-240V/50HZ
42W
9W
2.0M
2000L/H
1/2’’-3/4’’-1’’
CUF-6000
220-240V/50HZ
54W
9W
2.5M
2500L/H
1/2’’-3/4’’-1’’

© by WilTec Wildanger Technik GmbH Seite 5
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 9
http://www.teichtip.de
PART LIST
1
Outlet
9
Filter base
17
O-ring
2
Elbow pipe 1
10
adapter
18
Connection pipe 2
3
Filter cover
11
Water pump
19
nut
4
sponge
12
Fountain head(tent type)
20
flange
5
UV-C lamp
13
Fountain head(rain type 1)
21
T-joint
6
Elbow pipe 2
14
Fountain head(rain type 2)
22
screw
7
Filter boxes
15
Fountain sets base
8
Runner plate
16
Connection pipe 2

© by WilTec Wildanger Technik GmbH Seite 6
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 9
http://www.teichtip.de
5-1
UV-C lamp shell body
5-5
45*4 o-ring
5-9
UV-C device head with cable
5-2
Spiral sleeve
5-6
Quartz glass tube sleeve
5-10
Safety clasp
5-3
Quartz glass tube
5-7
60*3.1 o-ring
5-4
Fasten screw
5-8
Uvc bulb
11-1
Impeller cover
11-3
rotor
11-5
shaft
11-2
Rubber bearing
11-4
O-ring
11-6
Shell body

© by WilTec Wildanger Technik GmbH Seite 7
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 9
http://www.teichtip.de
Caution
CUF is UV-C clarify equipment which can be combined. It contains water pump and one piece of UV-C
lamp. Any damage on the equipment or unmerited operation will bring dangerous radiation to the skin
and eyes. So if there is any damage of the equipment, it can not be used any more. This equipment is
not intend for use by person (including children) with reduced physical, sensory of mental capabilities,
or lack of experience and knowledge, unless they have been given supervision or instruction concern-
ing use of the equipment by a person responsible for their safety. The equipment should be placed out
of children reach. For the consideration of security, people under 16 years old and those who can not
identify danger or grasp the instruction can not use the equipment.
1.This equipment should be placed under the water. Be sure the equipment is submerged completely
in the water and the depth should not be greater than 2m.
2.When the water is not enough to submerge the equipment, please never connect power of the
equipment to avoid running without water and cause damage .
3.As the UV-C lamp is made of quartz glass, please avoid drop of it or wallop on it.
4.Before all parts are installed completely, the equipment can not be plugged in.
5.If there is any damage on the power cable, UV-C lamp or shell, the equipment can not be used . And
it should be discarded as useless.
6.Please make sure that the electrical voltage, frequency used are consistent with the indication on the
label of the equipment.
7.When installing the equipment, the installation regulation of pond pumps should be followed.
8.The equipment should be earthed. And the professional person should check the condition of e-
arthed. For the considered of safety, we advise customer to install leakage protector.
9.Pull the connecting cable is forbidden. And please keep the connecting cable away from heat, grea-
siness or sharpness.
10.When the pump have any unusual noise, please unplug to check the reason.
11.When know the frost is coming, please move away UV-C filter to avoid frost crack.
12.The dirtiness on the quartz glass tube will influence the effect of the equipment, please clean the
quartz glass tube in time.
13.When the body shell is blocked with the sands and rubbish, it is possible to destroy the quartz glass
tube and water pump. So please add the filter sponge to the inlet of the water. And the sponge should
be cleaned timely. (once a month).
14.UV-C is harmful to the eyes and skin. Please do not watch UV-C directly or let the skin approach to
the UV-C.
15.When install or repair this equipment, the electrical source of the equipment must be switched off.
Instructions
1.This equipment built-in filter sponge, biochemical basket, UV-C lamp and water pumps. This equip-
ment adopt reasonable water channel, suitable for both indoor, outside pond garden, aquatic breed-
ing, clean water sterilization and water fountains.

© by WilTec Wildanger Technik GmbH Seite 8
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 9
http://www.teichtip.de
2.Through the working of water pump, water flow from the filter cover to filter sponge, and then to the
UV-C lamp. Inside of the UV-C lamp the harmful bacteria and algae will be killed. Then the water flow
to outside finally.
3.The UV-C lamp was designed as a closed device, no UV-C will scattering. And UV-C light 253.7nm
will kill the harmful bacteria and algae to keep a good condition of water.
Installation and Maintenance
Please switched off the electrical power when you clean the inside or change the UV-C lamp. When
clean the inside or change the UV-C lamp, please take below part list as your reference.
Installation
Connect No.15-16-17-20-21 together, choose a suitable fountain head from 12-13-14 and connect to
No. 15. Then connect fountain set to No.10. Adjust the height of the fountain set and submerge the
equipment under water. If only need this equipment to take water, you can only connect No. 1-2, no
need fountain set.
Maintenance
Maintenance for filter sponge and filter material
1. Take of the fountain set, unload the screw No, 22, and open the two clips on the side of the filter
cover, then you can open the filter cover.
2. Take out the filter sponge and filter material boxes, clean or change these. (suggest to clean the fil-
ter sponge every week)
Maintenance of UVC-Lamp
1. Take out the UV-C lamp and open the safety catch, turn the shading cylinder components (NO. 1-2-
3-4-5-6) in anti-clockwise direction till the block position, then pull out the quartz glass tube. Now you
can change your UV-C lamp.
2. If you need to clean the quartz glass tube, please take out the components inside of the shading
cylinder, unload the screw No.4. Then you can take out the quartz glass tube and clean it.
Maintenance of water pump
1. turn impeller cover in anti-clockwise direction till the block position, then you can separate the the
impeller cover and pump body.
2. Take out the impeller, clean it with clean water and suitable brush.
Storage in winter
1. Take out the equipment from water
2. Clean the equipment thoroughly
3. Check the parts and conditions of the equipment
4. Keep this equipment in a area that free from frost. And in a container that with clean water

© by WilTec Wildanger Technik GmbH Seite 9
http://www.WilTec.de
http://www.aoyue.eu März 2020 Version 9
http://www.teichtip.de
Disposal regulations
EU guidelines regarding the disposal of scrap electric appliances (WEEE, 2012/19/EU) were imple-
mented in the law related to electrical and electronic equipment and appliances.
All WilTec electric devices that fall under the WEEE regulations are labelled with the crossed-out
wheeled waste bin logo. This logo indicates that this electric equipment must not be disposed with the
domestic waste.
The company WilTec Technik GmbH has been registrated in the German registry EAR under the WEEE-
registration number DE45283704.
Disposal of used electrical and electronic appliances
(intended for use in the countries of the European Un-
ion and other European countries with a separate col-
lection system for these appliances).
The logo on the article or on its packaging points out
that this article must not be treated as normal house-
hold waste but must be disposed to a recycling collec-
tion point for electronic and electrical waste equipment.
By contributing to the correct disposal of this article you
protect the environment and the health of your fellow
men. Environment and health are threatened by inap-
propriate disposal.
Materials’ recycling helps reduce the consumption of raw materials.
Additional information on recycling this article can be provided by your local community, municipal waste
disposal facilities or the store where you purchased the article.
Address:
WilTec Wildanger Technik GmbH
Königsbenden 12 / 28
D-52249 Eschweiler
Important notice:
The reprint or reproduction, even of excerpts, and any commercial use, even in part of this instructions
manual require the written permission of WilTec Wildanger Technik GmbH.
