Sunx SF4B User manual

SAFETY LIGHT CURTAIN
SF4B
Instruction Manual
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

BEFORE BEGINNING
Liability and Copyright for the Hardware
This manual and everything described in it are copyrighted. You may not copy this manual, in
whole or part, without written consent of Panasonic Electric Works Europe AG (PEWEU).
PEWEU pursues a policy of continuous improvement of the design and performance of its
products. Therefore we reserve the right to change the manual/product without notice. In no
event will PEWEU be liable for direct, special, incidental, or consequential damage resulting
from any defect in the product or its documentation, even if advised of the possibility of such
damages.
We invite your comments on this manual. Please e-mail us at:
[email protected]sonic.com.
Please direct support matters and technical questions to your local Panasonic representative.
LIMITED WARRANTY
If physical defects caused by distribution are found, PEWEU will replace/repair the product
free of charge. Exceptions include:
•When physical defects are due to different usage/treatment of the product other than
described in the manual.
•When physical defects are due to defective equipment other than the distributed
product.
•When physical defects are due to modifications/repairs by someone other than
PEWEU.
•When physical defects are due to natural disasters.
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Important Symbols
One or more of the following symbols may be used in this documentation:
!
DANGER!
The warning triangle indicates especially important safety
instructions. If they are not adhered to, the results could be
fatal or critical injury.
CAUTION
Indicates that you should proceed with caution. Failure to do so may result in
injury or significant damage to instruments or their contents, e.g. data.

NOTE
Contains important additional information.

EXAMPLE
Contains an illustrative example of the previous text section.
1.
2.
3.
Procedure
Indicates that a step-by-step procedure follows.
REFERENCE
Indicates where you can find additional information on the subject at hand.
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

KEY POINTS
Summarizes key points in a concise manner.
SHORTCUTS
Provides helpful keyboard shortcuts.
EXPLANATION
Provides brief explanation of a function, e.g. why or when you should use it.
next page
Indicates that the text will be continued on the next page.
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Safety Light Curtain SF4B
Table of Contents
v
Table of Contents
1. Introduction...........................................................................10
1.1 Target Group............................................................................................11
1.2 Safety Instructions ...................................................................................12
1.3 Applicable Standards/Regulations...........................................................15
2. Before Using the Device ......................................................17
2.1 Features...................................................................................................18
2.2 Part Description .......................................................................................19
2.2.1 How the Display Works ............................................................................20
2.3 Protection Area........................................................................................24
2.3.1 Sensing Area............................................................................................24
2.3.2 Safety Distance ........................................................................................26
2.3.2.1 Calculation Example for Europe......................................................28
2.3.2.2 Calculation Example for the US ......................................................31
2.3.3 Influence of Reflective Surfaces...............................................................33
2.3.4 Placement of Emitter and Receiver..........................................................34
2.4 Mounting..................................................................................................36
2.4.1 Mounting of the Mounting Bracket............................................................36
2.4.1.1 Standard Mounting Bracket MS-SFB-1...........................................36
2.4.1.2 Intermediate Supporting Bracket MS-SFB-2...................................38
2.4.1.3 Dead Zoneless Mounting Bracket MS-SFB-3.................................40
2.4.1.4 Protect-Bar Mounting Bracket MC-SFBH-□....................................41
2.4.2 Mounting of the Bottom Cap Cable..........................................................43
2.4.3 Mounting and Dismantling of a Series Connection..................................44
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Table of Contents
Safety Light Curtain SF4B
vi
2.5 Wiring ...................................................................................................... 47
2.5.1 PNP Output ..............................................................................................48
2.5.2 NPN Output..............................................................................................50
2.5.3 Power Supply Unit....................................................................................51
2.5.4 Output Signal during Self-Diagnosis ........................................................52
2.5.5 Connecting Procedure and Connector Pin Assignment...........................52
2.5.6 Basic Wiring..............................................................................................55
2.5.7 Wiring Examples.......................................................................................57
2.5.7.1 Manual Reset When Interlock is Activated (Control Category 4)....57
2.5.7.2 Series Connection (Control Category 4) .........................................60
2.5.7.3 Parallel Connection (Control Category 4) .......................................63
2.5.7.4 Mixed Connection (Control Category 4)..........................................67
2.5.7.5 Auto-Reset (Control Category 4).....................................................71
2.5.7.6 External Device Monitor Function Deactivated (Control Category 4)
73
2.5.7.7 Muting Function (Control Category 4).............................................75
2.6 Adjustment............................................................................................... 78
2.6.1 Beam-Axis Alignment...............................................................................78
2.6.2 Operation Test..........................................................................................80
3. Functions..............................................................................83
3.1 Self-Diagnosis Function........................................................................... 84
3.2 Interlock Function.................................................................................... 85
3.3 Emission Halt Function............................................................................ 86
3.4 Interference Prevention Function ............................................................ 87
3.5 Auxiliary Output (Non-Safety Output)...................................................... 88
3.6 External Device Monitor Function............................................................ 89
3.7 Muting Function....................................................................................... 91
3.7.1 Specification for the Muting Sensor..........................................................92
3.7.2 Installation of the Muting Sensor..............................................................93
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Safety Light Curtain SF4B
Table of Contents
vii
3.8 Override Function ....................................................................................95
3.9 Functions of the Optional Handy Controller SFB-HC...............................98
4. Operation.............................................................................101
4.1 Normal Operation...................................................................................102
4.2 When Using the Emission Halt Function................................................109
4.3 When an Error Occurs...........................................................................112
5. Maintenance........................................................................115
5.1 Daily Inspection Checklist......................................................................116
5.2 Periodic Inspection Checklist (Every Six Months)..................................118
5.3 Inspection after Maintenance.................................................................119
6. Troubleshooting .................................................................121
6.1 Emitter-Related Problems......................................................................122
6.1.1 All Indicators Are OFF............................................................................122
6.1.2 Fault Indicator (Yellow) Lights up or Blinks............................................122
6.1.3 Digital Error Indicator "C" Lights Up.......................................................123
6.1.4 Emission Halt Indicator (Orange) Lights Up...........................................124
6.1.5 All Beam-axis Adjustment Indicators (Red) Light Up.............................124
6.1.6 Operation Indicator Remains Lit in Red .................................................124
6.2 Receiver-Related Problems...................................................................125
6.2.1 All Indicators Are OFF............................................................................125
6.2.2 Fault Indicator (Yellow) Lights up or Blinks............................................125
6.2.3 Digital Error Indicator "C" Lights Up.......................................................127
6.2.4 All Beam-axis Adjustment Indicators (Red) Light Up.............................127
6.2.5 Operation Indicator Remains Lit in Red .................................................127
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Table of Contents
Safety Light Curtain SF4B
viii
7. Specifications.....................................................................129
7.1 Common Specifications......................................................................... 130
7.2 Specifications by Model Numbers......................................................... 133
7.2.1 Model Numbers SF4B-Fxx with 10mm Beam Pitch...............................134
7.2.2 Model Numbers SF4B-Hxx with 20mm Beam Pitch...............................135
7.2.3 Model Numbers SF4B-Axx with 40mm Beam Pitch...............................136
7.3 Options.................................................................................................. 137
7.3.1 Front Protection Cover ...........................................................................137
7.3.2 Cables.....................................................................................................138
7.3.2.1 Bottom Cap Cables .......................................................................138
7.3.2.2 Extension Cable with Connector on One End...............................139
7.3.2.3 Extension Cable with Connectors on Both Ends...........................139
7.3.2.4 Cable for Series Connection .........................................................139
7.3.2.5 Cables for PNP/NPN Output.........................................................140
7.3.3 Brackets..................................................................................................140
7.3.3.1 Standard Mounting Bracket (M5) ..................................................140
7.3.3.2 M8 Mounting Bracket ....................................................................140
7.3.3.3 M5 Pitch Adapter Bracket..............................................................141
7.3.3.4 M8 Pitch Adapter Bracket..............................................................141
7.3.3.5 Dead Zoneless Mounting Bracket.................................................141
7.3.4 Handy Controller.....................................................................................142
7.3.5 Laser Alignment Tool for Light Curtain...................................................142
7.3.6 Control Units...........................................................................................143
7.3.6.1 Unit with Connectors .....................................................................143
7.3.6.2 Unit for Demanding Industrial Environments.................................143
7.3.6.3 Miniature Unit ................................................................................144
7.3.6.4 Unit with Additional Functions.......................................................144
7.3.7 Protect Bar..............................................................................................145
7.3.8 Test Rod.................................................................................................146
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Safety Light Curtain SF4B
Table of Contents
ix
8. Dimensions .........................................................................147
8.1 Mounting Dimensions ............................................................................148
8.1.1 Rear Mounting with Standard Mounting Bracket (MS-SFB-1) ...............148
8.1.2 Side Mounting with Standard Mounting Bracket (MS-SFB-1)................150
8.1.3 Rear Mounting with Dead Zoneless Mounting Bracket (MS-SFB-3)......152
8.1.4 Side Mounting with Dead Zoneless Mounting Bracket (MS-SFB-3)......154
8.2 Mounting Bracket Dimensions...............................................................156
8.2.1 Standard Mounting Bracket (MS-SFB-1)................................................156
8.2.2 M8 Mounting Bracket (MS-SFB-1-T)......................................................156
8.2.3 Pitch Adapter Bracket (MS-SFB-4) ........................................................157
8.2.4 M8 Pitch Adapter Bracket (MS-SFB-4-T)...............................................157
8.2.5 Intermediate Supporting Bracket (MS-SFB-2) .......................................158
8.2.6 Dead Zoneless Mounting Bracket (MS-SFB-3)......................................158
9. Glossary of Terms..............................................................159
10. Index ....................................................................................163
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Chapter 1 Introduction
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Safety Light Curtain SF4B
1.1 Target Group
11
1.1 Target Group
Thank you for purchasing the Safety Light Curtain from the SF4B series (hereinafter called 'this
device'). Please read this instruction manual carefully and thoroughly for the correct and
optimum use of this product. Kindly keep this manual in a convenient place for quick reference.
This device is a light curtain for protecting a person from dangerous parts of a machine which
can cause injury or accident.
This manual has been written for the following personnel who:
•have undergone suitable training and have knowledge of light curtains as well as safety
systems and standards.
•who are responsible for the introduction of this device
•who design systems using this device
•who install and connect this device
•who manage and operate a plant using this device
Machine designer, installer, employer and operator
The machine designer, installer, employer and operator are solely responsible for ensuring that
all applicable legal requirements relating to the installation and the use in any application are
satisfied and all instructions for installation and maintenance contained in the instruction manual
are followed.
Whether this device functions as intended and systems including this device comply with safety
regulations depend on the appropriateness of the application, installation, maintenance and
operation. The machine designer, installer, employer and operator are solely responsible for
these items.
Engineer
The engineer must be a person who is appropriately trained, has widespread knowledge and
experience, and can solve various problems which may arise in his field of work, e.g. as a
machine designer or a person in charge of installation or operation, etc.
Operator
The operator should read this instruction manual thoroughly, understand its contents, and
perform operations following the procedures described in this manual for the correct operation
of this device.
In case this device does not perform properly, the operator should report this to the person in
charge and stop machine operation immediately. The machine must not be used until correct
performance of this device has been confirmed.
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Introduction
Safety Light Curtain SF4B
12
1.2 Safety Instructions
•Use this device as per its specifications. Do not modify this device since its
functions and capabilities may not be maintained and it may malfunction.
•This device has been developed/produced for industrial use only.
•Do not use this device under conditions or in environments not described in
this manual. Please consult us if there is no other choice but to use this
device in such an environment.
•Do not use this device in fields such as nuclear power control, railroad,
aircraft, automobiles, combustion facilities, medical systems, aerospace
development, etc.
•When this device is to be used for enforcing protection of a person from any
danger occurring around an operating machine, the user must satisfy the
regulations established by national or regional security committees.
•In case of applying this device to particular equipment, follow the safety
regulations in regard to appropriate usage, mounting (installation), operation
and maintenance.
•Use this device by installing suitable protection equipment as a
countermeasure for failure, damage, or malfunction of this device.
•Before using this device, check whether the device performs properly and
has the functions and capabilities as stated in the design specifications.
•Dispose of this device as industrial waste.
Environment
•Do not use a mobile phone or a radio phone near this device.
•If the device is installed in a place where there are reflective surfaces, make
sure to install this device so that reflected light from the reflective surfaces
does not affect the receiver. Alternatively, take countermeasures such as
painting, masking, roughening, or changing the material of the reflective
surfaces, etc. Failure to do so may cause the sensor not to detect properly,
which may result in death or serious injury.
•Do not install this device in the following environments.
- Areas exposed to intense interference light such as direct sunlight
- Areas with high humidity where condensation is likely to occur
- Areas exposed to corrosive or explosive gases
- Areas exposed to vibration or shock at levels higher than those specified
- Areas exposed to contact with water
- Areas exposed to too much steam or dust
- Areas where the beam-receiving part of this device is directly exposed to
light from a high-frequency fluorescent lamp (inverter type) or
rapid-starter fluorescent lamp.
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Safety Light Curtain SF4B
1.2 Safety Instructions
13
Installation
•Always keep the correctly calculated safety distance between this device
and the dangerous parts of the machine.
•Install an extra protection structure around the machine so that the operator
must pass through the sensing area of this device to reach the dangerous
parts of the machine.
•Install this device in a manner that some part of the operator's body always
remains in the sensing area until the operator has finished working with the
dangerous parts of the machine.
•Do not install this device at a location where it can be affected by wall
reflection.
•When installing multiple sets of this device, connect the sets and, if
necessary, install some barriers so that mutual interference does not occur.
•Do not use this device in an environment with reflective light.
•The corresponding emitter and receiver must have the same serial number
and be correctly oriented.
Equipment in which this device is installed
•When this device is used in the PSDI (see page 160) mode, an appropriate
control circuit must be configured between this device and the machinery.
For details, be sure to refer to the standards or regulations applicable in each
region or country.
•In Japan, do not use this device as safety equipment for a press machine or a
shearing machine.
•Do not install this device with a machine whose operation cannot be stopped
immediately in the middle of an operation cycle by an emergency stop.
•This device provides safety 2 seconds after the power has been switched
ON. Make sure that the control system takes the time delay into
consideration.
Wiring
•Switch off the power before wiring the device.
•All electrical wiring should conform to the regional electrical regulations and
laws. The wiring should be done by engineer(s) having the required electrical
knowledge.
•Do not run the sensor cable together with high-voltage lines or power lines
or put them together in the same raceway.
•In case you need to extend the cable of the emitter or the receiver, you can
use the dedicated extension cable. The cable can be extended up to 50m.
However, if the cable is extended in an installation with multiple sensors
connected in series or with the muting lamp (see page 91), the total
extendable length of the cable depends on the number of the sensors
connected in series (see page 52).
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Introduction
Safety Light Curtain SF4B
14
•When this device is used in Korea as a product conforming to the Korean
S-mark, the power line cable connected to this device should be no longer
than 10m.
•Do not control the device at only one control output (OSSD 1, OSSD 2).
•When this device is used in Korea in an installation with multiple sensors
connected in series in conformity with the Korean S-mark, make sure to
ground the device on the 0V side (PNP output).
Maintenance
•When you need to replace parts, always use only genuine replacement parts
from the supplier. If you use substitute parts from another manufacturer, the
sensor may fail to detect properly, which may result in death or serious body
injury.
•The device must be inspected periodically by an engineer with the required
knowledge.
•When you have adjusted or maintained the device, test the device following
the procedure specified in the maintenance (see page 119) chapter before
you switch the system back on.
•Clean this device with a clean cloth. Do not use thinner-based cleaners.
Others
•Never modify this device. When you modify the device, the sensor may fail to
detect properly, which may result in death or serious body injury.
•Do not use this device to detect objects flying over the sensing area.
•Do not use this device to detect transparent objects, translucent objects or
objects smaller than the specified minimum sensing size.
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Safety Light Curtain SF4B
1.3 Applicable Standards/Regulations
15
1.3 Applicable Standards/Regulations
This device complies with the following standards/regulations.
•EU Machinery Directive 98/37/EC, EMC Directive 89/336/EEC
•EN 61496-1 (Type 4), EN 55011, EN 954-1 (Category 4)
•IEC 61496-1/2 (Type 4)
•JIS B 9704-1/2 (Type 4), JIS B 9705-1 (ISO 13849-1) (Category 4)
•UL 61496-1/2 (Type 4), UL 1998, CSA C22.2 No.14, CSA C22.2 No.0.8
•OSHA 1910.212, OSHA 1910.217(C), ANSI B11.1 to B11.19, ANSI/RIA 15.06
•The S-mark certificate has been certified by Korea Occupational Safety & Health
Agency (KOSHA).

NOTE
•The conformity to JIS, OSHA and ANSI for this device has been evaluated by
ourselves.
•: The C-CL US Listing Mark indicates compliance with both
Canadian and U.S. requirements.
•: This device conforms to the EMC directive and the Machinery
directive. The CE-mark on the safety light curtain indicates that this product
conforms to the EMC directive.
•: The S-mark on the safety light curtain indicates that this device has
the S-mark certificate.
•If you want to use this device in a location other than the locations described
above, confirm first that the intended use complies with the standards or
regulations applicable in your region or country.
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Chapter 2 Before Using the Device
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Before Using the Device
Safety Light Curtain SF4B
18
2.1 Features
This device is a light curtain with the following features.
•No special controller is required.
•Control output (OSSD 1, OSSD 2) is available with PNP or NPN output.
•Includes beam-axis alignment indicators which make beam-axis alignment easy.
•Function setting possible with handy controller SFB-HC (optional) (see page 98).
•Many accessories (see page 137).
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG

Safety Light Curtain SF4B
2.2 Part Description
19
2.2 Part Description
Receiver
Emitter
Beam channel
Display section
Bottom cap cable
(Optional)
Standard mounting
bracket (Optional) M8 mounting bracket
(Optional)
M8 pitch adapter bracket
(Optional)
Intermediate supporting bracket
(Accessory)
Dead zoneless mounting bracket
(Optional)
Pitch adapter bracket
(Optional)
Parts of the safety light curtain
Part Description
Emitter Emits light to the receiver facing it. Furthermore, the status of the emitter is indicated on
its display section.
Receiver Receives light from the emitter facing it. Simultaneously the control output (OSSD 1,
OSSD 2) turns ON when the all beam channels receive light from the emitter, and the
control output (OSSD 1, OSSD 2) turns OFF when one or more beam channels are
blocked. The receiver displays its status on the display section.
Beam channel The light-emitting elements of the emitter and the light-receiving elements of the
receiver are placed at the following intervals: 10mm (SF4B-F), 20mm (SF4B-H), and
40mm (SF4B-A).
Standard mounting
bracket (optional) Use this bracket to mount the emitter/receiver. The standard mounting bracket allows
you to adjust the horizontal mounting angle.
M8 mounting bracket
(optional) This allows the light curtain to be mounted at the rear with one M8 hexagon-socket-head
bolt. The horizontal angle can be adjusted.
Pitch adapter bracket
(optional) This bracket is used when you change from a previous light curtain with a sensing
height of 200 to 750mm to this device. The bracket is installed using two M5
hexagon-socket-head bolts. The horizontal angle can be adjusted.
M8 pitch adapter
bracket (optional) This bracket is used when you change from a previous light curtain with a sensing
height of 200 to 750mm to this device. The bracket is installed using two M8
hexagon-socket-head bolts. The horizontal angle can be adjusted.
Rugghölzli 2
CH - 5453 Busslingen Tel.[phone]
Fax [phone] [e-mail]
www.sentronic.com
Produkte, Support und Service
SENTRONICAG
