B013 User Guide
Thanks for purchasing portable digital microscope!
This digital microscope is widely used in many areas, such as:
• Industrial inspection, printed circuit board, precision machinery inspection, CNC
lathe installation monitoring, etc.
• Inspection of cultural relics, gemstones, calligraphy and paintings, security codes.
• Long distance micro focus.
• Product appearance inspection.
It is easy to use. With Supereyes software, you can take photo, record video and measure
freely.
To use the digital microscope smoothly, please read this instruction carefully or learn to
use it by other ways.
Specifications
• Resolution: 12MP (Sensor 13MP）
• Max Resolution: 3840 * 3104
• Lens: interchangeable lens
• Magnification: 1 - 3000X (different
lenses)
• Light source: adjustable &
interchangeable
• Frame rate: max 30FPS
• Interface: type-c
• Working distance:
infinity – 15 mm (lens L750)
infinity – 34 mm (lens L400)
5 – 10 mm（lens L1500）
1.4 - 2.1 mm（lens L3000）
• Measurement：
software measurement
System requirements
• Operating system：
Windows 7/8/10，Mac OS
• USB2.0 port
• More than 600 MB free disk space
Packing list
• Standard package: B013 microscope
body (including lens L750, white light),
Z009 stand, USB cable,
USB stick for software, calibration ruler,
user manual
• Optional items
Lens: L400, L1500, L3000;
Light source: DP13, DR13, DA13, DH13,
DX13, UV13, IR13;
Fixed-focus cap: D750, D400, D1500,
D3000

2 / 5
Structure
How to install lens and light
How to install fixed-focus cap (optional accessories)

3 / 5
Optional accessories

4 / 5
Hardware installation
1. Connect USB cable to Type-C port of the
microscope body, and USB port of computer. Put
microscope into the holder of the stand and
tighten up (keep the focus knob exposed); keep
the lens towards the object as fig 1.
2. Adjust the lift knob to get proper object distance,
rotate the focus ring to make image clear (zoom
in zoom out).
3. Adjust the brightness by the dimming button.
4. Press the photo button to take pictures in hardware (you can also take
pictures in software).
5. When hand-held, the focusing and dimming operations are the same as
above, and it is better to use the corresponding fixed-focus cap.
6. The lifting stand is installed as shown in the figure below:
7. How to use DX13 rotating side mirror (optional accessory):
1) Pull out the moving mirror to move the object to the center of the
screen.
2) Push the moving mirror to the end and lift the microscope so that the
observed part is in the center of the screen. Adjust the focal length to get
clear image.
3) Turn the rotating side mirror and observe in a circle.
Fig 1

5 / 5
Trouble shooting
No.
Troubles
Possible reasons
Solution
1
Black screen
LED off.
Preview is not on.
Choose wrong device.
Connection between PC &
microscope is not good;
Turn on LED and connect lens well.
Click on preview.
Choose right device.
Plug into mother board USB port
2
Vague image,
low frame rate
Wrong focal distance;
connection to PC not well.
High resolution.
Limitation of PC configuration
Adjust focal distance.
Plug to mother board USB port;
Choose lower resolution.
Try another PC
3
Image distortion
Connection to pc not well.
Microscope malfunction
Plug to mother board USB port.
return for repairs
4
Unrecognized
Connection to pc not well.
Microscope malfunction
Plug to mother board USB port.
return for repairs
Notice
1. Please do not touch lens and other optics, otherwise, product
performance may be influenced.
2. Please do not disassemble product to avoid danger and product
damage.
3. Please use and store it under this environment, temperature: 0°C ~ 40°C;
humidity: 45% ~ 85%.
4. In case of dropping tiny object or liquid into microscope, please
disconnect the USB cable immediately and send product to manufacture
for quality inspection and repair.
