SuperLightingLED D4-L User manual

Dimension
Feature
4 Channel Constant Voltage or Constant Current
DMX512 & RDM Decoder
170mm
50mm
23mm
Drives 1-13pcs Hi-power LED per channel x 4CH
Wiring diagram
● 4 channel PWM constant voltage / constant current DMX decoder with digital display.
● DMX decode mode / Stand-alone RGB/RGBW mode / Stand-alone 4 channel dimmer mode.
● DMX address display, set DMX address freely.
● Comply with the latest DMX512, DMX512(1990), DMX512-A, RDM V1.0 (E1.20 - 2006 ESTA Standard)
standard protocols.
● RDM bi-directional communication function, can realize intercommunication between DMX master and
decoder. for example, you can set DMX decoder address by DMX master console.
● Under stand-alone RGB/RGBW controller mode, have 30 mode, include static color, jump, flash, gradual
change style, adjustable speed and brightness.
● Under stand-alone 4 channel dimmer mode, each channel adjust brightness independently, and save up to
8 groups brightness.
● 1/2/4 DMX channel decode optional.
● High or low PWM frequency optional.
● Log or linear dimming curve optional.
● Work with power repeater to expand output unlimitedly.
Power Supply
12-48VDC
Constant Voltage N
AC110-230V
DMX51 2&RDM Deco der
DMX Master
Power Supply
12-24VDC
Constant Voltage N
AC110-230V
+
R
G
B
W
RGBW LED strip
Uin=12-24VDC
Iin=20.5A
Uout=4×(12-24)VDC
Iout=4×5A
Pout=4×(60-120)W
Temp Range:
-30℃~+55℃
D4-LDMX512 & RDM D ecoder
● Short press M key, when display 001~999, enter DMX mode.
● Press ◀ or ▶ key to change DMX decode address(001~999),
long press for fast adjustment.
● If there is a DMX signal input, will enter DMX mode automatically.
● Long press M and ◀ key for 2s, prepare for setup system parameter: decode mode,
output PWM frequence, output brightness curve, automatic blank screen.
short press M key to switch four item.
● Decode mode: short press ◀ or ▶ key to switch one-channel decode("d-1"),
two-channel decode("d-2") or four-channel decode("d-4").
● Output PWM frequence: short press ◀ or ▶ key to switch 500Hz("F-L") or 2KHz("F-H").
● Output brightness curve: short press ◀ or ▶ key to switch linear curve("C-L") or logarithmic
curve("C-E").
● Automatic blank screen: short press ◀ or ▶ key to switch enable ("bon") or disable("boF")
automatic blank screen.
● Long press M key for 2s or timeout 10s, quit system parameter setting.
DMX mode
(001~999)
Operation
DMX mode
System parameter setting
DMX Master
Technical parameter
Model Name Input voltage Output current Output power Output type
D4-L 4CH CV DMX512 decoder Constant voltage
12-24VDC 4CH,5A/CH
D4C-L 4CH CC DMX512 decoder Constant current12-48VDC 4CH,150-1200mA
( )/CHcustomized
4 x (60-120)W
4 x (1.8-57.6)W
User Guide
D4C-L
D4-L
For D4-L, LED power supply voltage and power select :
● 12V lamp, Input 12V power supply, each channel can load 0~60W,
● 24V lamp, Input 24V power supply, each channel can load 0~120W,
The power supply power must larger than load power 20%.
● Input 48V power supply, each channel can series connect 1~13pcs LED,
● Input 36V power supply, each channel can series connect 1~10pcs LED,
● Input 24V power supply, each channel can series connect 1~6pcs LED,
● Input 12V power supply, each channel can series connect 1~3pcs LED.
For D4C-L, LED power supply voltage select:
Power supply select guide
The DMX512 & RDM decoder D4-L / D4C-L which features full support to the latest DMX512 protocols,
is designed with 4 channels output. RDM bi-direction communication function enables the DMX512 master
console to detect and display decoder information and set DMX address. A variety of features can be set via
the numeric digital display and the buttons such as DMX address,DMX decoding mode,PWM output frequency
and dimming curve value.
D+D- D-D+D+D- D-D+

Restore factory default parameter
● Long press ◀ and ▶ key for 2s, restore factory default parameter, display"RES".
● Factory default parameter: DMX decode mode, DMX first address is 1, four channel decode,
high PWM frequence output, logarithmic brightness curve, RGB mode number is 1,
dimmer mode number is 1, disable automatic blank screen.
Stand-alone dimmer mode
● Short press M key, when display L-1~L-8, enter stand-alone dimmer mode.
● Press ◀ or ▶ key to change dimmer mode number(L-1~L-8).
● Each dimmer mode can adjust each channel brightness independently.
Long press M key for 2s, prepare for setup four channel brightness.
Short press M key to switch four channel(100~1FF, 200~2FF, 300~3FF, 400~4FF).
Press ◀ or ▶ key to setup brightness value of each channel.
Long press M key for 2s, or timeout 10s, quit setting.
● Enter stand-alone dimmer mode only when DMX signal
is disconnected or lost.
Stand-alone dimmer mode
(L-1~L-8)
Safety information
1. The product shall be installed and serviced by a qualified person.
2. The product is non-waterproof. Please avoid the sun and rain.
3. Good heat dissipation will prolong the working life of the controller. Please ensure good ventilation.
4. Please check if the output voltage of any power supplies used complywith the working voltage
of the product.
5. Ensure all wire connections and polarities are correct and secure before applying power to avoid
any damages to the LED lights.
6. If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
Malfunctions analysis & troubleshooting
1. Wrong connection of R/G/B/W wires.
2. DMX decode address error.
1. Reconnect R/G/B/W wires.
2. Set corrrect decode address.
Causes Troubleshooting
1. Output cable is too long.
2. Wire diameter is too small.
3. Overload beyond power supply capability.
4. Overload beyond controller capability.
1. Reduce cable or loop supply.
2. Change wider wire.
3. Replace higher power supply.
4. Add power repeater.
1. No power.
2. Wrong connection or insecure.
1. Check the power.
2. Check the connection.
Wrong color
Malfunctions
Uneven intensity
between front and
rear,with voltage drop
No light
RGB change mode list
No. Name
P01
P02
P03
P04
P05
P06
P07
P08
P09
P10
Static red
Static green
Static blue
Static yellow
Static cyan
Static purple
Static white
RGB jump
7 color jump
Red strobe
No. Name No. Name
P11
P12
P13
P14
P15
P16
P17
P18
P19
P20
P21
P22
P23
P24
P25
P26
P27
P28
P29
P30
Green strobe
Blue strobe
White strobe
RGB strobe
7 color strobe
Red fade in and out
Green fade in and out
Blue fade in and out
White fade in and out
RGBW fade in and out
Red yellow smooth
Green cyan smooth
Blue purple smooth
Blue white smooth
RGB+W smooth
RGBW smooth
RGBY smooth
Yellow cyan purple smooth
RGB smooth
6 color smooth
Stand-alone RGB/RGBW mode
Stand-alone RGB/RGBW mode
● Short press M key, when display P01~P30,
enter stand-alone RGB/RGBW mode.
● Press ◀ or ▶ key to change dynamic mode
number(P01~P30).
● Each mode can adjust speed and brightness.
Long press M key for 2s, prepare for setup mode speed,
brightness, W channel brightness.
Short press M key to switch three item.
Press ◀ or ▶ key to setup value of each item.
Mode speed: 1-10 level speed(S-1, S-9, S-F).
Mode brightness: 1-10 level brightness(b-1, b-9, b-F).
W channel brightness: 0-255 level brightness(400-4FF).
Long press M key for 2s, or timeout 10s, quit setting.
● Enter stand-alone RGB/RGBW mode only when DMX signal is disconnected or lost.
Speed
(8 level)
Brightness
(10 level,100％)
(P01~P30)
